Home Comfort EUROTAS V2 User manual

1
MAJ. : 18/11/2014
www.home-confort.net
EN
SURVEILLANCE KIT
IP camera : EUROTAS V2
Distributed by IDK MULTIMEDIA
Reference: CAM-I49MN v2 (black)
Reference: CAM-I49MB v2 (white)
User GUIDE*
Version 1.4
* Please visit our website for the latest version.
Runs exclusively on our Home Confort platform.

2
MAJ. : 18/11/2014
www.home-confort.net
EN
Indoor
MPEG Kits
Motorized
Indoor
MPEG Kits
Outdoor
MPEG Kits
Nessos CAM-E59MB
• CMOS colour sensor: 300,000 pixels
• Frame rate: Up to 30 images per second
• Resolution: 640 x 480 / 320 x 240
• Viewing angle: 60°, x3 Zoom
• Motorized: 355° (horizontal pan) x 90° (vertical
tilt)
• WiFi: 802.11 b/g/n
Eurotas CAM-I49MN (Black) et CAM-I49MB (White)
• CMOS colour sensor: 300,000 pixels
• Frame rate: Up to 30 images per second
• Viewing angle: 60°
• Resolution: 640 x 480 / 320 x 240 / 160 x 120
• Motorized 270° (horizontal pan) x 90° (vertical tilt)
• Night vision: 10 LEDs
• WiFi: 802.11 b/g/n
Elasa CAM-I44FB (White) & CAM-I45FN (Black)
• CMOS colour sensor: 300,000 pixels
• Frame rate: Up to 30 images per second
• Viewing angle: 60°
• Resolution: 640 x 480 / 320 x 240 / 160 x 120
• Night vision: 15 LEDs
• WiFi: 802.11 b/g/n
Nestos CAM-E54FA
• CMOS colour sensor: 300,000 pixels
• Frame rate: Up to 30 images per second
• Night vision: 24 LEDs
• Viewing angle: 60°
• Resolution: 640 x 480 / 320 x 240 / 160 x 120
• I/O: Input/Output contacts
• Protected access to the secure Home Confort platform
• Direct, unlimited access to video surveillance cameras
• Control up to 3 different locations (e.g. primary residence, holiday home, office)
• Option to control all cameras in the location of your choice (up to 6 cameras possible)
• Unlimited email alerts upon detection of intrusion (and transmission of up to 6 photos)
• Instant video recording on the secure platform (6 x 5 free minutes/saved for 15 days)
• Photo capturing and recording on the secure platform (saved for 15 days)
• iPhone, iPad, Android and Smartphone application for alerts and monitoring
• Installation assistance included in the product price
STANDARD SURVEILLANCE PACK: Free services included EN OPTION
- Additional recording time
- Text alerts
Discover a wide range of WiFi indoor, outdoor or motorized
(that run exclusively on our Home Confort platform)
All our products on: www.home-confort.net

3
MAJ. : 18/11/2014
www.home-confort.net
EN
CONTENT OF THE HOME CONFORT SURVEILLANCE PACK
Model EUROTAS Ref: CAM-I49MB(white) / CAM-I49MN (black)
 An IP surveillance camera with WiFi antenna.
 A metallic base and rod with a multi-position ball head that can be attached to a wall or ceiling.
 A wall-mounting kit comprising a set of screws and anchors.
 An RJ45/RJ45 Ethernet cable.
 A mains adapter.
 A User's Guide (in French).
 A link to install the application.
WARNINGS
Computer requirements:
- Minimum hardware requirements:
2.06 GHz processor, 2 GB RAM
10/100 Base-T Ethernet card
VGA card with 64 MB RAM or more
- Operating system: Windows® 2000, XP SP2 , Vista®, Windows® 7 and 8, MAC OS 10.5, Linux
Browser: Internet Explorer® 7 (or later), Mozilla Firefox® 3.5, Safari® 4, Google Chrome®
- Internet access using cable/DSL box or router, or WiFi 802.11b/g/n
Note: You must use a high-speed Internet connection to remotely view the images taken by the IP camera.
Note:
The mains adapter is specific to this camera. Using
another type of power adapter may damage your
camera and void the warranty. You must contact us
if you encounter a failure.

4
MAJ. : 18/11/2014
www.home-confort.net
EN
IMPORTANT
The user of this product bears full responsibility and must ensure that their use of the product is in com-
pliance with French video surveillance laws currently in effect. For more information, contact the Prefecture
of your department, or the French Data Protection Authority (CNIL).
Outside of France, but within Europe: Inquire with the competent authorities in your country as to
the use of video surveillance equipment.
Instructions for use:
Read first:
- Please read the User’s Guide carefully before installing or using this product.
- Check our website regularly for updates to the products and software documentation.
Warning:
- In the event of a breakdown or defect, do not attempt to disassemble or repair the camera yourself; only
individuals or organisations authorised by Home Confort can do this.
- For outdoor use, you are advised to use a waterproof box to protect all of the camera's connections
including the power supply unit.
Avoid areas exposed to strong vibrations.
Do not place any 2.4 GHz mobile phone or other radio source such as Bluetooth devices or microwave
ovens near the camera. This could deteriorate the quality of its WiFi communications. Keep them at least 1
metre away.

5
MAJ. : 18/11/2014
www.home-confort.net
EN
SAFETY INSTRUCTIONS
· Keep out of the reach of children under the age of 36 months.
· This camera can be used outdoors. However, be sure to protect its connections in a waterproof
box (not included), including the power supply unit if is also located outdoors.
· Do not connect the mains adapter when your hands are wet.
· Never submerge this camera in liquid (water, oil, etc.).
· Do not dismount the camera. Only qualified individuals should do this!
· Do not install this device in a confined space. It should remain in a well-ventilated area. Ventilation
should not be blocked by obstacles such as newspapers, a tablecloth or curtains.
· Warning: Read the safety instructions on the electrical plug before installing and using this device.
ATTENTION
ATTENTION : :
Do not dispose of this product with your household trash. Contact your town hall about the specific selective waste
collection system for this type of product.
Electronic and electric products contain substances that are harmful to the environment and/or human health and must
be recycled.This symbol, the crossed-out wheeled trash bin, indicates that the electric and electronic equipment must
be collected separately.
This product must be recycled!

6
MAJ. : 18/11/2014
www.home-confort.net
EN
Camera description*
Infrared LEDs (x15)
For night vision
MICRO
SOCLE
NETWORK LED SIGNAL
PHOTOSENSOR
(Level of day/night light) WIFI ANTENNA
a screw
LENS
Manual adjustment ring Focus
(blurry image)
Facing
* photo no contractual

7
MAJ. : 18/11/2014
www.home-confort.net
EN
Camera description*
Back view
* photo no contractual
RJ 45 ETHERNET
Connection to your network
access
PLUG POWER
Connect the AC adapter plug
Green LED
Indicates the network
presence
Yellow LED
Indicates
communications
AUDIO OUT*
*available according to
version

8
MAJ. : 18/11/2014
www.home-confort.net
EN
Camera description*
If the camera hangs, you can restart it without switching off the power. Hold down the Reset button for
20 seconds, then release. Afterwards, you will need to reinstall your camera in your home-confort personal
space.
Back view (Down)
RESET
(Reset Tools)
MULTI WALL SUPPORT POSITIONS
Screws on the underside of the camera by tightening the knob
* photo no contractual

9
MAJ. : 18/11/2014
www.home-confort.net
EN
To install and register your camera, type in the following address into your Internet browser
http://service.home-confort.net
and follow the instructions to install your kit in just 5 minutes!
Home Confort / Quick installation
You can download the latest version of the installation guide from our website:
www.home-confort.net

10
MAJ. : 18/11/2014
www.home-confort.net
EN
Assistance
Support for the Home Confort software application
and equipment
Should you encounter any problems during the installation or use of the product (software or hardware),
only the HOME CONFORT technical support team is authorized to diagnose the problem.
If you have any questions related to the installation of this product, or if you experience a failure upon
installation (camera not recognised, cannot identify the WiFi network, cannot consult remotely, equipment
failure, missing components, etc.):
> You must contact our Technical Support team using the "Troubleshooting form" available on the
Home Confort website:
http://www.home-confort.net/en/content/troubleshooting-form
You will receive an email with a ticket number, a case number used to reference your
problem throughout the help process.
Customer Service will respond within 24-48 hours,
Monday-Friday: 9:00 a.m. - 12:00 p.m. / 2:00 p.m. - 5:00 p.m.
For more information about accessories and new models,
visit our website at www.home-confort.net.

11
MAJ. : 18/11/2014
www.home-confort.net
EN
INFORMATIONS ET CARACTÉRISTIQUES TECHNIQUES DE LA CAMERA
Home Confort / Kit de surveillance
Fonctions Éléments Description
Image capture
Sensor CMOS 1/4‘’colors
Pixels 300k
Minimum illumination 0. Lux (with active infrared LEDs)
Lens f=3.6mm, F=2.0, (Focus manually adjustable)
60° viewing angle
Video and Audio
Resolution 640 x 480(VGA) / 320 x 240(QVGA) / 160 x 120(QQVGA)
Night vision up to 8 m (10 infrared LEDs)
Compression MJPEG
Refresh rate Up to 30 images per second
Image rotation Yes
Interface
Ethernet 10Base-T/100base-TX
WIFI 802.11b/g/n
Audio In Micro IN
Audio Out 1 x Audio jack « Line-in»
Physical specifications
Motorisation Orientation 270 ° Horizontal / Vertical 90 °
Weight 325g
Dimensions 125 mm (W) x 98 mm (D) x102 mm (H)
Power supply 100-240V~ / DC 5V 2A
Operating temperature
range 0° ~ 55°C (32°F ~ 131°F)
Humidity allowance 20% ~ 85%

12
MAJ. : 18/11/2014
www.home-confort.net
EN
This device functions on transmission frequencies: 2.4 GHz. It complies with European
R&TTE Directive 1999/5/EC. You can download the declaration of conformity from our
website: www.home-confort.net
The product reference is: Réf: CAM-I49MN (Black) ou Réf: CAM-I49MB (White)
