Home UMB-953545 Installation guide

11 ft Round Offset Umbrella
Assembly & Care Instructions
IMPORTANT: RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
Item Number: 4774783
Model: UMB-953545
TOLL FREE: 1-855-880-7205
8am - 5pm, Monday through Friday, Eastern Standard Time
Do Not Return To Store
FOR OUTDOOR USE ONLY
Designed in USA
Made in China
For assistance with assembly, parts, or customer service, please call:

2
Contents
Package Contents
Assembly and Use
Battery Replacement
Replacement Parts
Care and Maintenance
Warning and Cautions
Warranty
2
3 - 7
8
9
9
10
10
Package Contents
Compare carton contents with package contents list. If any part is missing or
damaged, call customer service TOLL FREE at 1-855-880-7205 for replacement parts
or further assistance.
Part Description Quantity
A Outer Base Components 2
B Inner Base Components 2
C Lower Cross Leg 1
D Upper Cross Leg 1
F Holder Pole w/ Control Knobs 1
N Umbrella Frame with Canopy 1
L Pole Support Cup 1
M Base Cap 4
M1 Base Cap Inner Seal (pre-assembled) 4
GG Hex Bolt 4
HH Flat Washer 4
1x
D
1x
C
1x
F
1x
N
4x
GG
1x
L
4x
HH
2x
2x
4x
M
M1
A

3
Assembly and Use
Step 1: Place Upper Cross Leg (D) over Lower Cross Leg (C) to form “X” shape.
Tools Required for Assembly: Open end wrench or adjustable wrench (not
included).
Step 3: Attach Pole Holder (F) to cross legs (C&D) using screws (GG) and washers
(HH) found in blister pack. Hand tighten only. Adjust Pole Holder (F) until positioned
correctly on base. Tighten all bolts being careful not to over-tighten.

4
Assembly and Use (cont’d)
Step 3: Lay base components (A&B) on top of cross legs to form rectangular base.
Step 4: Unscrew caps from each section of umbrella base and fill with sand fully.
A
B
M
H
J
F
Reposition caps and tighten into place.

5
Assembly and Use (cont’d)
Step 5: Pull holder pole ring from top of Holder Pole (F) and unscrew both control
knobs. Slide Pole Support Cup (L) onto Holder Pole (F). Replace control knobs and
holder pole ring.
Step 6: Insert Umbrella Frame (N) into Holder Pole (F) and tighten control knobs to
secure the umbrella in place. Fixed stop pin on frame will rest on holder pole ring.
Unfasten storage staps before use.
WARNING: Fully assemble umbrella base prior to inserting frame to avoid
umbrella tipping. Failure to assemble and install as instructed could result in
the umbrella tipping over, causing personal injury and/or property damage.
Storage Straps
Control Knobs

6
Assembly and Use (cont’d)
Step 7: To open umbrella, press the button in the crank house and slide up
along umbrella pole. Turn Crank Handle to right until Lower Center Hub
reaches end of Support Pole (shown above), and canopy has proper
tension. Press button to lock into the pole hole in place at desired angle.
Step 8: To close umbrella, press the crank button and slide down to lock into the
lowest pole ho le and make sure the canopy is fully closed. Secure with
straps.
Step 9: To rotate canopy 360 degrees, loosen control knobs on Holder Pole and turn
umbrella to desired postion. Re-tighten control knobs to secure.
Control
knob Rotate
Press Button
Crank Handle
Support Pole
Close
Open
Lowe Center
Hub

7
Warning and Cautions
Care and Maintenance
• Use mild soap and warm water to clean canopy. Rinse with clean water and dry
thoroughly. Do not machine wash. Do not iron. Air dry the canopy thoroughly before storing for
extended periods of time. Make sure the canopy is completely open during drying process to
prevent shrinkage.
• If crank becomes too hard to turn, check to see if rope has slipped off pulley. If you continue
to crank, the rope or crank handle may break. If parts have broken, call customer service, toll
free: 1-855-880-7205 8am-5pm, Monday - Friday, Eastern Time.
• Placement of umbrella over or near a swimming pool will cause premature fading not covered
under our warranty.
Warranty
90 DAY WARRANTY
This product is covered under a manufacturer’s 90 day warranty from date of purchase against
defects in materials and workmanship. This warranty does not cover damage due to neglect, abuse,
or weather related damage. For full warranty disclosure, call customer service toll free at 1-855-880-
7205.
NOT COVERED UNDER WARRANTY
This warranty excludes the following: acts of nature (i.e. wind, fire, or freeze); damage caused by
improper assembly, accident, disaster, misuse, abuse, negligence and discoloration or fading of the
finish or wicker as a result of exposure to the elements. Product not intended for commercial use.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
INFORMATION: It is suggested that the consumer use a cover (not included) to
protect umbrella against the elements.

8
Replacement Parts
For replacement parts, call our customer service department at:
1-855-880-7205, 8am - 5pm EST, Monday - Friday.
Part Description Quantity Re-order Number
A 2
2
1
1
1
1
1
4
1
Base (outside) BSE-ABMP-11-BWN-T-M
B Base (inside) BSE-BBMP-11-BWN-T-M
C Lower Cross Leg CSL-C58X-BWN-T
CAN Canopy (Silver Mink) CAN-11O8RBO-T-SM
D Upper Cross Leg CSL-D58X-BWN-T
F Holder Pole HDP-F58X-BWN-T-M
L Pole Support Cup PSC-L58X-BWN-T-M
M Base Cap BSE-CAP-11-BWN-T-M
KIT Hardware Kit HDW-953545-KIT

customer service
TOLL FREE: 1-855-880-7205
8am - 5pm, Monday through Friday, Eastern Standard Time
Enjoy!
