HOMEDEPOT BD-108L Operating manual

CHEST FREEZER
PRODUCT USE GUIDE
BD-108L

IMPORTANT NOTE
ITECHNICAL PARAMETERS & PACKAGE INCLUDE
SECTION 1
SECTION 2
PAGES 3-4
PAGES 5
PRODUCT INTRODUCTION
PRECAUTIONS BEFORE USE
USE OPERATION
TROUBLESHOOTING GUIDE
NORMAL PHENOMENA
PAGES 6
PAGES 7
PAGES 8
PAGES 9
PAGES 10
MAINTAINENCE GUIDELINES PAGES 10
WRRANTY PAGES 11
SECTION 3
SECTION 4
SECTION 5
SECTION 6
SECTION 7
SECTION 8
TABLE OF CONTENTS

- 3 - - 4 -
IMPORTANT NOTE
(1). A fitting one phase alternating power must be supplied to the unit. If there is a big
fluctuate with the voltage, please be assisted with a power regulator otherwise it would be
affected on the operating even burn out the compressor.
(2). A single-phase socket and suitable fuse are allowed for the unit only. Do not use the
multifunction socket which may cause the fire or electrical shock.
(3). The broken power wire must be changed by the manufacturer’s maintenance
personnel or similar department.
(4). Be sure to ground the unit.
(5). If the unit is unplugged, power lost or turned off, it needs to wait for five minutes
before restarting the unit.
(6). Never install the unit at inflammable and volatility location and never install the unit at
place of acid or corrosive gas which may cause explosion or fire.
(7). Never splash water outside or inside of the unit as this may cause electrical shock or
short circuit.
(8). Never store volatile, flammable or corrosive material in the unit.
(9). Never store medicine or other medical products. Please contact us if storing this kind
of products.
(10). Handling the frozen contents with naked hands may cause frostbite.
(11). Do not damage the power cord to avoid of the electric leakage or fire.
(12). Make sure to keep the key in a safe place where the children cannot reach. Do not
permit children to play around the unit as danger may result.
(13). Do not break the loop of the cooling system.
(14). Do not put any other electrical equipment in the food closet of the freezer.
(15). Do not use mechanical devices or other means to accelerate the defrosting process
other than those recommended by the manufacturer.
(16). The damaged lamp must be replaced with the same model as the original by the
maintenance and warranty department of the producer or by similar professional and
authorized technicians.
(17). This appliance is not intended for use by persons including children with reduced
physical, sensory, mental capabilities or lack of experience and knowledge, unless they
have been given supervision or instruction concerning the use of the appliance by a
person responsible for their safety. The children should be supervised to ensure that they
do not play with the appliance.
(18). Don`t use the electric products in the food storeroom of this product.
(19). This appliance is intended to be used in household and similar applications such as
–staff kitchen areas in shops, offices and other working environments;
–farm houses and clients in hotels, motels and other residential type environments;
–bed and breakfast type environments;
–catering and similar non-retail applications.
(20). Do not store explosive substances such as aerosol cans with a flammable propellant
in this appliance.

PACKAGE INCLUDE
1X Chest Freezer 1X Plastic Basket
Please check whether the accessories in the above picture are complete. If the
freezer is damaged or incomplete during transportation, please contact the seller
immediately.
1X Owner's Manual
TECHNICAL PARAMETERS
- 5 - - 6 -
PRODUCT INTRODUCTION
Tips:
For the stability of the product, the wheels are only on one side.
If you want to move the freezer, please slightly stand the freezer
up and push it.
Door handle
Freezer box
CHEST FREEZER
PRODUCT USE GUIDE
BD-108L
Model No.
Item Name
Rated Voltage
Rated Power
Capacity
Freezing Temperature
BD-108L
Chest Freezer
115V
62W
3.5 cu.ft
-11.4℉ to 10.2℉(-24℃ to -12℃)
Energy Consumption
Package Weight
Package Size
0.5 kwh/24h
48.5 lbs
22.8x22.6x32.3inch
Compressor
Control pane
Directional wheel

USE OPERATION
- 7 - - 8 -
PRECAUTIONS BEFORE USE
Temperature Control and Adjustment
Food Storage and Quick-freezing
Defrost
1. The internal temperature can be adjusted by temperature control. The higher the figure
means the lower the temperature. The normal position is between 3 and 4.
2. The "1" knob refers to the refrigeration point, and the storage temperature in the
cabinet is about 0°C. When you need to freeze food quickly, turn the knob clockwise to
"7". At this time, the compressor will work continuously. After freezing, turn the knob
counter clockwise back to its original position. Do not turn the temperature control knob
clockwise from "7" to "1".
Portage and Placement
1.In order to avoid any trouble from the compressor or the system, the inclination of the
unit can’t be over 45 o during the transportation.
2.Place the appliance away from the direct sunlight and sources of heat from the stove,
heater, radiator etc. The direct sunlight may affect the acrylic coating and the heat sources
will increase the electrical consumption.
3.Remove the exterior and interior packing before using. It is necessary and
recommended to keep at least 100mm of space away from the back and sides of the unit
and it can allow the proper air circulation to cool down the compressor.
1.Do not put large amount of food into the unit at one time.
2.Let the compressor run for 2 to 3 hours for the first operation.
3.Warm food must be cooled down to normal temperature before put into the unit.
4.Make sure that there is enough space around food.
5.Keep the food in same or similar sort area.
6.Do not put glass bottles and cans whose freezing point is higher than the
compartment temperature into the unit since they may be broken by frozen contents and
cause the injury.
1.Do not use the sharp or metal piece to scrape the frost when defrosting. It needs to turn
off the power and open the doors for defrosting naturally.
2.Dry and clean the unit with the soft cloth after defrosting.
Preparation
*After receiving the freezer or moving the freezer for a long distance,
please let the machine stand for 24 hours before turning it on again.
1.Be sure to ground the unit and the grounding can prevent the electrical shock which
would occur when the electrical insulation of the unit becomes insufficient.
2.Connect the unit to the power supply with the rated frequency and rated voltage
indicated on the rating label. Please use the input power regulator upon 5 times
alternating power if the voltage is much more fluctuant than normal.
3.Use the specified power socket and suitable fuse.
4.Hold the power supply plug not the cord when pulling out the power cord from the
socket.
5.Never splash the water on the unit directly. The wet unit may cause the electric shock
or short circuit.
6.Turn on the power five minutes later after the power is off or stops running in order to
protect the system and the compressor.
7.If the power supply cord needs to be extended, the connected cord area should be
more than 0.824mm2 and the cord is composed of one or more wire. Don't be connected
with the multifunctional power supply socket.
8.Turn on the power and switch the temperature control knob to 3～4 position. Check the
indicator light, compressor and ventilating fan after half an hour. The temperature inside
will cool down obviously and it means the unit working normally.

1.If hearing the sound of water flowing in the unit, this is the refrigerant flowing sound
inside the pipe.
2.If there is some dew on the surface of the unit, please wipe with dry cloth.
3.The temperature on the compressor surface can reach about 70℃～90℃during its
working time.
1.Use the neutral detergent to wipe off the dirt on the surface of the unit then dry and
clean the unit with soft cloth.
2.Use the dust collector to wipe off the dirt on the condenser to keep it in a good
condensing condition.
3.Rubbing some talcum powder on the door gasket can prolong its life.
1. This marking shown on the product or its literature indicates that it should not be
disposed with other household wastes at the end of its working life. In order to prevent
any possible harm to the environment or human health from the uncontrolled waste
disposal, please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
2. Household users should contact either the retailer where purchasing this product from
or their local government office for details of where and how they can take this item for
environmentally safe recycling.
3. Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for
disposal.
TROUBLESHOOTING GUIDE NORMAL PHENOMENA
MAINTAINENCE GUIDELINES
- 9 - - 10 -
Correct disposal of this product
The unit is not cold
enough
Compressor turns on
and off frequently
Vibrationsly
The unit seems to
make too much noise
The door will not
close properly
The unit does not
operate
Not plugged in.
The circuit breaker tripped or blown fuse.
The temperature control is set too warm.
Make sure that the temperature control is set to an
appropriate value.
The external environment may need to set a lower value.
The door is often opened.
The door is not completely closed.
The door gasket is not properly sealed.
The machine does not have the correct gap.
The room temperature is higher than normal.
Too much food has been put in the machine.
The door is often opened.
The door is not completely closed.
The temperature control setting is incorrect.
The door gasket is not properly sealed.
The machine does not have the correct gap.ap.
The rattling noises may come from normal refrigerant flow.
At the end of each cycle, you may hear a gurgling noise
due to refrigerant flowing through the equipment.
The contraction of the inner wall may cause crackling and
popping noises.
The freezer is not placed horizontally.
The unit is not level.
The gasket is dirty.
The shelves are out of position.
Check to ensure that the unit is level.
PROBLEM POSSIBLE CAUSE

After-sales Service Letter of Commitment:
All products purchased in our company are guaranteed to keep in good repair for 1 year.
If quality problems happen in guarantee period, our company will maintain for free or
provide replacement. Additionally, our company provides technical support and fittings for
life. After-sales service isn't restricted by time and hear feedback idea of users and deal
with them in time. If you are caught in some problems when using our products, welcome
to contact us at any time.
Installation should be performed only by the dealer or a qualified expert.
Attempting to install the unit yourself could result in water leakage, refrigerant
leakage, electrical shock. or fire.
WARNING: Do not splash water directly onto the cooler and do not wash
with water.
Short- circuit and electrical shock could result.
Text set off by the exclamation mark contains information that should be strictly
adhered to.
After reading the instruction manual, store the easily accessible place where the
user(s) of this product can easily find it.
WARNING lmproper handling of the unit could lead to death or serious injury.
PRECAUTIONS FOR INSTALLATION
WARNNING
WARNNING
CAUTION lmproper handlingof the unit could lead to serious results depending
on the circumstances.
The purpose of the safety precautions in this manual is to ensure safe and correct use
of the unit to minimize risks that could cause serious damage and injury to you or other
persons. The safety precautions are divided into WARNINGS and CAUTIONS. Cases
where improper handling of the unit could lead to death or seriousinjury are listed under
the warning heading, However, the cases adhere strictly to both types of safety
precautions.
To ensure proper use. Please thoroughly study these SAFETY PRECAUTIONS before
operating the Unito
Warning: Risk of fire / flammable materials, taking care to avoid causing a fire by igniting
flammable material.
– WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
– WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
For defrosting chest freezer, don't use hammer, knife
or bolt. If you use it, it give damage to inside evaporator.
And chest freezer cannot cool, and inside goods can thaw.
Please do not destroy the freeze loop.
Please do not storage anything others except the manufacturer
recommendation
When 5mm frost forms in the freezer, please shave it and throw it away.
If you defrost completely, please do it as follow:
Please make inside empty. And disconnect the power cord plug.
When frost start thawing, please shave it and you will be able to defrost in the short time.
After draining, please wipe the inside, and put a rubber cap on the drain bolt and
inside drain.
①②③WARRANTY
DEFROSTING
SAFETY PRECAUTIONS 1
- 11 - - 12 -
