AS25
Thermoelectric cooler
Operating manual . . . . . . . . . . . . . . . . . . . . .5
EN
COOLING BOXES
BORDBAR
AS25-O-16s.book Seite 1 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

BordBar AS25
3
maxoff
eco
A
1
2
3
4
1
2
1
2
3
1
AS25-O-16s.book Seite 3 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

BordBar AS25
4
4
AS25-O-16s.book Seite 4 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
BordBar AS25
5
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
8 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
AS25-O-16s.book Seite 5 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
Explanation of symbols BordBar AS25
6
1 Explanation of symbols
!
!
A
I
2 Safety instructions
2.1 General safety
!WARNING!
•Do not operate the device if it is visibly damaged.
•If this device's power cable is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified person in order
to prevent safety hazards.
•This device may only be repaired by qualified personnel. Improper
repairs can lead to considerable hazards.
•This device can be used by childrenaged 8 years or over, as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Cleaning and user maintenance must not be carried out by children
without supervision.
•Children must not play with the device.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
AS25-O-16s.book Seite 6 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
BordBar AS25 Safety instructions
7
•Children must be supervised to ensure that they do not play with the
device.
•Always keep and use the device out of the reach of children under the
age of 8 years.
•Do not store any explosive substances such as spray cans with a
flammable propellant in the device.
!CAUTION!
•Disconnect the device from the power supply
– before each cleaning and maintenance
– after every use
•Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the device as follows:
– With the DC cable to a DC plug socket in the vehicle (e. g.
cigarette lighter)
– Or with the AC connection cable to the AC mains supply
•Never pull the plug out of the socket by the cable.
•If the cooler is connected to the DC socket: Disconnect the cooler and
other power consuming devices from the battery before connecting
the quick charging device.
•If the cooler is connected to the DC socket: Disconnect the cooler or
switch it off when you turn off the engine. Otherwise you may dis-
charge the battery.
•The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
•The cooling device contains inflammable cyclopentane in the
insulation. The gases in the insulation material require special disposal
procedures. Deliver the device at the end of its life-cycle to an appro-
priate recycling.
AS25-O-16s.book Seite 7 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
Scope of delivery BordBar AS25
8
2.2 Operating the device safely
!CAUTION!
•Before starting the device, ensure that the power supply line and the
plug are dry.
ANOTICE!
•Do not use electrical devices inside the cooler unless they are
recommended by the manufacturer for the purpose.
•Do not place the device near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.).
•Danger of overheating!
Ensure at all times that there is sufficient ventilation so that the heat that
arises during operation does not build up. Make sure that the device
is sufficiently far away from walls and other objects so that the air can
circulate.
•Ensure that the ventilation openings are not covered.
•Do not fill the inner container with ice or fluid.
•Never immerse the device in water.
•Protect the device and the cable against heat and moisture.
3Scopeofdelivery
No. in
fig. 1,
page 3
Quantity Description
A 1 Cooling device BordBar AS25
– 1 Connection cable for 12 Vgconnection
– 1 Connection cable for 230 Vwconnection
AS25-O-16s.book Seite 8 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
BordBar AS25 Intended use
9
4 Intended use
The cooler is suitable for cooling foodstuffs.
The cooling device is intended to be used in household and similar applications such
as
•staff kitchen areas in shops, offices and other working environments
•farm houses
•clients in hotels, motels and other residential type environments
•bed and breakfast type environments
•catering and similar non-retail applications
The device has been designed for use with a 12 Vgon-board power supply socket
of a car (cigarette lighter), boat or caravan as well as a 230 Vwmains supply.
The appliance may also be used for camping use. The appliance shall not to be
exposed to rain. It can be used as a box or cupboard.
I
!
NOTE
The seatbelt can be fed through the lugs on the cooler to fasten it to the
car seat (see fig. 4, page 4).
CAUTION! Health hazard!
Please check if the cooling capacity of the device is suitable for storing
the food or medicine you wish to cool.
AS25-O-16s.book Seite 9 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
Technical description BordBar AS25
10
5 Technical description
The cooler is suitable for mobile use. It can cool goods to max. 18 °C under the
ambient temperature or keep them cool.
Its cooling system is a non-wearing Peltier cooling, the heat is discharged by a fan.
When the cooler is connected to a 230 V AC mains supply, it can be used in two
different operating modes:
•ECO mode: the cooler consumes less energy
•MAX mode: the cooler reaches maximum cooling capacity
The desired cooling capacity is selected with the cooling capacity control:
➤To increase the cooling capacity, turn the cooling capacity control clockwise.
For the maximum cooling capacity turn the cooling capacity control clockwise
all the way to the stop (max position).
➤To decrease the cooling capacity, turn the cooling capacity control
counterclockwise.
To turn off the cooler, turn the cooling capacity control counterclockwise all the
way to the stop (off position).
When the cooler is connected to the DC socket, the cooling capacity cannot be
adjusted. In this case the cooler cools maximal.
Pockets on the outside provide additional storage space. Note that objects stored in
them are not cooled.
5.1 Description of the device
No. in
fig. 1, page 3 Description
1 Shoulder strap
2 ECO cooling capacity control
3 Ventilation slots
4 Handle
AS25-O-16s.book Seite 10 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
BordBar AS25 Operation
11
6Operation
!
A
I
6.1 Energy saving tips
•Choose a well ventilated installation location which is protected against direct
sunlight.
•If you want to set an increased energy efficiency and a limited cooling capacity for
the cooler device, use the device’s ECO mode.
•Allow warm food to cool down first before placing it in the cooling device to
keep cool.
•Do not open the cooling device more often than necessary.
•Do not leave the cooling device open for longer than necessary.
CAUTION!
Food may only be stored in its original packaging or in suitable
containers.
NOTICE!
•Ensure that the objects placed in the cooler are suitable for cooling
to the selected temperature.
•Ensure that food or liquids in glass containers are not excessively
refrigerated. Liquids expand when they freeze and can therefore
destroy glass containers.
•Ensure that your cooler is well ventilated so that any heat created can
dissipate. Otherwise proper functioning cannot be ensured. It is
especially important not to cover the air vents.
•Risk of spillage. Lift the cooler by the handle, not by the shoulder
strap.
NOTE
•Before starting your new cooling device for the first time, you should
clean it inside and outside with a damp cloth for hygienic reasons
(please also refer to the chapter “Cleaning and maintenance” on
page 13).
•If the handle is folded back of if the cooler is being carried, the lid is
locked. You can only open the lid when the handle is folded for-
wards.
AS25-O-16s.book Seite 11 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
Operation BordBar AS25
12
6.2 Using the cooler
➤Place the cooler on a firm base.
➤Connect the 12 V connection cable (fig. 21, page 3) into the cigarette lighter
socket or a 12 V socket in the vehicle
or
➤Plug the 230 V connection cable (fig. 22, page 3) into the AC voltage socket
and connect it to the 230 Vwmains supply.
I
✓The cooler starts cooling the interior.
➤When operating at the AC mains supply: Push the ECO cooling capacity
control (fig. 12, page 3) to the desired position.
➤To switch off the cooler, disconnect the plug.
6.3 Connecting to a cigarette lighter
I
NOTE
Close the box tightly by pushing down the lid.
NOTE
If you connect the device to the cigarette lighter of your vehicle,
remember that the ignition must be turned on to supply the device with
power.
AS25-O-16s.book Seite 12 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
BordBar AS25 Cleaning and maintenance
13
7 Cleaning and maintenance
!
A
➤Occasionally clean the device interior and exterior with a damp cloth.
➤Make sure that the air inlet and outlet vents on the device are free of any dust and
dirt, so that heat can be released and the device is not damaged.
8Guarantee
The statutory warranty period applies. If the product is defective, please contact the
manufacturer's branch in your country (see the back of the instruction manual for the
addresses) or your retailer.
For repair and guarantee processing, please include the following documents when
you send in the device:
•A copy of the receipt with purchasing date
•A reason for the claim or description of the fault
WARNING!
Always disconnect the device from the power supply before you clean
and service it.
NOTICE! Risk of damage
•Never clean the cooler under running water or in dish water.
•Do not use abrasive cleaning agents or hard objects during cleaning
as these can damage the cooler.
AS25-O-16s.book Seite 13 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
Troubleshooting BordBar AS25
14
9 Troubleshooting
10 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
Fault Possible cause Suggested remedy
Your cooler does not
work (plug is inserted).
There is no voltage
flowing from the 12 V
socket (cigarette
lighter) in your vehicle.
The ignition must be switched on in
most vehicles for voltage to flow at the
cigarette lighter.
No voltage present at
the AC voltage socket.
Try using another plug socket.
The cooler does not cool
(plug is inserted).
The inner fan or the
cooling element is
defective.
This can only be repaired by an
authorised customer services unit.
Operation with a 12 V
socket (cigarette lighter):
The ignition is on and the
cooler is not working.
Pull the plug out of the
socket and make the
following checks.
The cigarette lighter
socket is dirty. This
results in a poor elec-
trical contact.
If the plug of your cooler becomes very
warm in the cigarette lighter socket,
either the socket must be cleaned or
the plug has not been assembled
correctly.
The fuse of the 12 V
plug has blown.
Replace the fuse (5 A) in the 12 V plug
(fig. 31, page 3).
The vehicle fuse has
blown.
Replace the vehicle's 12 V socket fuse
(usually 15 A). (Please refer to the
operating manual of your vehicle.)
AS25-O-16s.book Seite 14 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua

EN
BordBar AS25 Technical data
15
11 Technical data
BordBar AS25
Ref. no.: 9600000459
Connection voltage: 12 Vg
220 – 240 Vw, 50 – 60 Hz
Power consumption: 47 W (12 Vg)
max. 55 W (230 Vw)
7.5 W (AC, ECO mode)
Cooling capacity: max. 18 °C below ambient temperature
Category: Pantry
Energy efficiency class: A++
Energy consumption: 66 kWh/annum
Gross capacity: 21 l
Usable capacity: 20 l
Climate class: ST
Ambient temperature: +16 °C – +38 °C
Noise emission: 39 dB
Weight: 4.2 kg
Testing/certification:
4
AS25-O-16s.book Seite 15 Montag, 7. November 2016 11:47 11
Autogoods “130”
130.com.ua
