HornetTek Travel Lite User manual


TravelLite( 旅)USERMANUAL

2.5”SATAtoUSBEXTERNALENCLOSURE 



Hardware Installation Guide HDD Formatting Guide
Please NOTE: In order to enable HOT-SWAP function, please check to 
make sure the motherboard supports HOT-SWAP function. Otherwise, the 
hot swappable function won't be work as well. 
(Please refer back to motherboard user guide)


☆ Please follow the instructions and make sure your hard drive is successfully installed to
the external enclosure!

STEP1 :
Pull out the USB Cable and open the case.
STEP2 : Place the HDD into the tray. 
Push the HDD to connect the SATA connector. 



Note: Make sure all connectors are connected well.
STEP3:
Screw the case together.
You can start to use this enclosure.
☆ You may format your external HDD through USB connection.
☆ Please make sure your external HDD is turned on and well connected to the PC
before formatting the HDD.
STEP1 :
Right -click “My Computer” icon and select the”Manage” column.

STEP2 :
Select “Disk Management” and you will see your External HDD showed “Unallocated”.
STEP3 :

STEP5: When new partition is completed, the external HDD will be recognized as a
“New Volume”.
STEP6 :
Double-click “My Computer”. You will see the new volume appears on your PC.

Software Installation Guide
1. System requirement
zInte
compatib
zMic ,
Ultimate,
z32M
zIma e
zUSB
controlle
zSup t
l® Pentium® 4, Intel Centrino®, Intel Xeon®, or Intel Core™ Duo (or
le) processor or 100% compatible H/W system.
rosoft® Windows® 2000, XP or Windows Vista™ Home Premium, Business
or Enterprise (compatible with both 32/64-bit editions)
B RAM is recommended
ge r solution 800 x 600 pixel or above
to PATA bridge controller (GL811E, GL811S) and USB to SATA bridge
r (GL830)
por FAT32 & NTFS file system

2.UserGuide
zIntroduction
Backup Manager is a user friendly application for backing up files onto your external USB hard
drives. You may set up the options and press the button on the device to run archives. It will copy
all the selected files from the hard disks on your computer to the external USB disk drive. The
program will keep the records of the backup events. It requires the specific USB hard disk device
to activate some of the functions. For example, you can not select destination path if there is no
proper USB hard disk.
zSteps of Installation
(1) Connect
Connect your external hard drive to USB port
(2) Run Setup
Input CD to start auto run. If the auto run does not initiate, simply double click Setup.exe to
start install shield

(3) Initiate Wizard
Installation shield start running the setup wizard Click “Next” to continue
(4) Prepare for Installation
Verify system requirement and get ready for installation. Click “Install” to continue

(5) Start installation
This step may take a few seconds. Press “Cancel” to exit.
(6) Complete
Installation completed. Press “Finish” to exit
