HOTO QWLYD001 User manual

Manual of HOTO Camplight 10
Scan the WeChat code and pay 1
cent to extend the product warranty.

10
01 Product Overview
Battery indicator light
Mode adjusting head
Flashlight
Camp light
Ambient light
Switch button
Foldable lampshade
Outer casing
Charging port
Hook
Read this manual carefully before use, and retain it for future reference.
Thanks for using HOTO Camplight.
1
2
5
7
8
9
10
3
6
4

Press the switch button to turn on the Flashlight gradually；
Press it again to turn off the Flashlight gradually.
The flashlight powers on in the brightest mode by default. Press and hold
the switch button for stepless dimming, adjusting from the highest to the
lowest brightness. Corresponding mode indicators will progressively light
up. Press and hold again to switch from the lowest brightness to the
highest. Corresponding mode indicators will progressively light up.
11
02 How to Use
Mode Adjusting Head
When powered "ON", modes can be freely adjusted by rotating the mode
adjusting head. The selected mode will turn on in the highest light intensity.
ON/OFF
Under the Flashlight Mode:
Flashlight mode: This mode is generally used when travelling and for
long-distance illumination.
Camp Light mode: This mode is generally used for illuminating the
surroundings.
Ambient Light mode: This mode is generally used for creating
atmosphere.
1.
2.
3.
This product has three modes. To select a desired mode, please rotate the
mode adjusting head, and align the markings on the lampshade with those
on the cylinder tool body.

12
Under the Camp Light Mode:
Press the switch button to turn on the Camp Light gradually;
Press it again to turn off the Camp Light gradually.
The camp light powers on in the brightest mode by default. Press and hold
the switch button for stepless dimming, adjusting from the highest to the
lowest brightness. Corresponding mode indicators will progressively light
up. Press and hold again to switch from the lowest brightness to the
highest. Corresponding mode indicators will progressively light up.
brightness to the highest. Corresponding mode indicators will
progressively light up.
Under the Ambient Light Mode:
When the product is being charged: All functions can be used normally.
Press the switch button to turn on the Ambient Light gradually;
Press it again to turn on the Candlelight mode.
Press it again to turn off the Ambient Light gradually.
The ambient light powers on in the brightest mode by default.
Press and hold the switch button for stepless dimming, adjusting from
the highest to the lowest brightness. Corresponding mode indicators will
progressively light up. Press and hold again to switch from the lowest
brightness to the highest. Corresponding mode indicators will
progressively light up. Brightness to the highest. Corresponding mode
indicators will progressively light up.
Brightness can not be changed under Candlelight mode.

13
Charging
Plug the charging cable into the Type-C charging port to charge the product.
Note: This product is equipped with a Type-C charging cable.
Battery indicator light
In the "ON" status:
Flashing red light: 0-10%
Continuous red light: 10%-30% (off after 5 seconds)
Continuous orange light: 30%-60% (off after 5 seconds)
Continuous green light: 60%-100% (off after 5 seconds)
Foldable lampshade
To attach the foldable lampshade, fix
it in the groove between the mode
adjusting head and body's outer
casing where the magnets can be
found.
Charging indicators:
Charging in process: Red breathing light
(breathing rate: every 3 seconds).
Charging completed: Permanent green
light.

03 Warning
14
For proper use Please follow the instructions in this User Guide
to use this product properly.
Repair services Do not disassemble this product. In order to a
void safety accidents, only authorized personnel
are allowed to repair this product.
Charging instructions 1.This product can only be charged with a
charger that meets its charging parameters.
2. If the status indicator light does not work
properly during charging because this product
has not been used for a long period of time,
please charge it for 30 minutes for observation.
Instructions for use 1. This product can emit strong light. Please keep
direct rays of light away from the eyes of people and
animals and the lens of optical equipment.
2. To reduce the risk of injury, children should be
accompanied by their parents when using this
product.
3. To reduce the risk of electric shock, do not
place this product in water or other liquids.
4. Do not place or store this product where it
may fall into the bathtub or sink.
Safety precautions
1. Damages caused by using a charger with unfitting parameters for charging
is not covered by the warranty, and it may lead to other hazards.
2. If battery temperature of this product reaches 45℃, the charging
protection function will be triggered, and the charging will be discontinued.
The recommended ambient temperature for charging is 0-30℃.
Warnings

15
Battery safety warnings
Do not open or shred the battery.
Do not expose the battery to heat sources or flames. Do not store the battery
under direct sunlight.
Do not perform mechanical shocks to the battery.
If the battery accidentally leaks, avoid direct contact of leaking liquid with
skin or eyes. In case of contact, it is recommended to rinse with abundant
water.
Charge the battery before first use.
After long-term storage, the battery needs to be charged and discharged
several times to obtain the best battery performance.
Battery performance is best when used at ordinary temperature (20±5℃),
its performance is the best.
The battery must be removed before this product is disposed of.
Before removing the battery, the power of this product must be cut off.
Please recycle and dispose of the battery in an environmentally correct
manner.
All products bearing this symbol are waste electrical and electronic
equipment (WEEE as in directive 2012/19/EU) which should not be mixed
with unsorted household waste. Instead, you should protect human
health and the environment by handing over your waste equipment to a
designated collection point for the recycling of waste electrical and electronic
equipment, appointed by the government or local authorities. Correct
disposal and recycling will help prevent potential negative consequences to
the environment and human health. Please contact the installer or local
authorities for more information about the location as well as terms and
conditions of such collection points.

16
We Shanghai HOTO Technology Co., Ltd., hereby, declares that this
equipment is in compliance with the applicable Directives and
European Norms, and amendments.
This supplier’s declaration of conformity is hereby for
We declare that the above mentioned device has been tested
and found in compliance with CFR 47 Part 15 Regulation.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Product: HOTO Camplight
Model Number(s): QWLYD001
Brand/Trade: HOTO
Federal Communications Commission Supplier’s
Declaration of Conformity
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:

17
Pressing the main
power button doesn't
light up any light, and
battery indicator shows
a flashing red light.
Issues
The lithium battery
runs low
Charging
Possible Causes Solutions
Troubleshooting
1. The charging cable
is not plugged in
properly, or the
charging cable is not
the designated one;
2. The ambient
temperature for
charging is below 0℃
or above 45℃
1.Please use the
designated charging cable
and the 5V power adapter;
2.Charge this product in
adequate environmental
temperatures 0-45℃
The battery indicator
light is not on during
charging
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Representative of Responsible Party for SDoC
Company: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Putuo District, Shanghai, China
Country: China
Telephone No.: 400-021-8696

Manufacturer:
Address: Building 45, No. 50 Moganshan Rd, Putuo District, Shanghai, PRC,
200060.
Shanghai HOTO Technology Co., Ltd.
04 Specifications
Model: QWLYD001
Net Weight: 135 g
Item Dimensions: φ34×128 mm
Charging Time: Approx. 180 min
Waterproof IP rating: IPX6
Battery Capacity: 3100 mAh
Battery Type: Lithium-ion battery
Rated Voltage: 3.6 V
Input: 5 V 1.5 A
Lighting parameters
180~18lm
(stepless
dimming)
50~5lm
(stepless
dimming)
8h~40h
50~5lm
30h
20h~50h
Ambient light
mode
Camp light
mode
Flashlight
mode
120~12lm
(stepless
dimming)
10h~40h
Brightness
Floodlight Ambient light Candlelight
Flashlight
Functions
Battery
life
4000K
Warm color
light
2700K
Warm color
light
2700K
Warm color
light
5000K
White light
Color
temperature
18

19
DECLARATION OF CONFORMITY
EU Declaration of Conformity
We
Shanghai HOTO Technology Co., Ltd.
Declare that the product:
HOTO Camplight / QWLYD001
Complies with the essential health and safety requirements of the following directives:
2014/35/EU The Low Voltage Directive
References to the following harmonized standard were made:
EN 60598-1:2008
EN 60598-2-4:2018
EN 55015:2019
EN 61547: 2009
EN 62471:2008
2014/30/EU Electromagnetic Compatibility directive References to the following
harmonized standard were made:
2011/65/EU+ (EU) 2015/863 Restrictions of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Authorised signatory and technical file holder:
Shanghai HOTO Technology Co., Ltd.
Building 45, No.50 Moganshan Road, Shanghai, China
