HSS Hire 06348 Troubleshooting guide

Air Grinders
Hire Shops
Powerful pneumatic units
100 & 230mm.
Operating & Safety Guide 635
Where appropriate, secure the workpiece in a vice or
with clamps, supporting it on both sides of any cut
line to stop the cut-off wheel becoming trapped.
Next, grip the grinder firmly in both hands and
adopt a comfortable, stable stance that lets you see
what you are doing while keeping the whole of your
body behind the grinder’s wheel.
With the wheel clear of the workpiece, you can
now switch the grinder ON and wait for the wheel to
reach working speed.
To switch the grinder ON, move the safety bar forward
and squeeze in the air control lever, release to switch OFF
If GRINDING…
Work the grinder back and forth across the
surface, holding the wheel at an angle of 10 to 15
degrees – a new wheel may only require a single pass.
If CUTTING…
Move the grinder along the cut in a straight line,
keeping the wheel at a constant angle. Never twist the
grinder or apply sideways pressure – the wheel
could break up and cause damage or serious personal
injury.
WHATEVER you are doing…
On first contact with the surface, the grinder will
try to wander off line. Take great care until you
become familiar with its operations.
Apply just enough pressure to ensure reasonable
progress. Too much pressure will damage the wheel,
the workpiece, and the grinder.
BASIC TECHNIQUES Lift it clear before turning OFF, and wait for moving
parts to stop before putting it aside.
Never push the equipment beyond its design
limits. If it will not do what you want with reasonable
ease, assume you have the wrong grinder for the job.
Ask at your local HSS Hire Shop for advice.
Regularly check the condition of the grinder, if it
show signs of excessive wear contact your local HSS Hire
Shop for a replacement.
Keep the equipment clean. You will find this less of a
chore if you clean up regularly, rather than wait unit the
end of the hire period.
When not in use, store the equipment somewhere
clean, dry and safe from thieves.
Switch OFF the compressor, then open the
grinders air control lever until all the stored air has
been released. Disconnect the air hose and remove
the wheel.
Thoroughly clean the grinder, then neatly coil the
air hose ready for return to your local HSS Hire Shop.
FINISHING OFF
EQUIPMENT CARE
Code 06348 / 06378
©HSS Hire Service Group Plc 1998 No. 635/01
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Web Site: http://www.hss.co.uk
Contact your local
0990 282828
…any comments?
If you have any suggestions to enable us to improve
the information within this guide please fax your
comments or write to the Product Manager at the
address below
Fax: [phone]
Supply
Hose
Air Control
Lever
Safety Bar
2
1

For advice on the safety and suitability of this equipment
contact your local HSS Hire Shop.
There is a serious risk of personal injury if you do
not follow all instructions laid down in this guide.
This equipment has been designed to be used by
an able bodied, competent adult who has read and
understood these instructions. Anyone with either a
temporary or permanent disability, should seek expert
advice before using it.
Keep children, animals and bystanders away from
the work area.
Never use this equipment if you are ill,
feeling tired, or under the influence of
alcohol or drugs.
Safety Goggles MUST be worn by everyone in
the work area.
Some materials being cut or ground by this
process may contain substances which, when
inhaled, can be harmful to health. A suitable mask
must be worn when using this equipment.
This equipment generates potentially harmful
noise levels. To comply with health and safety at
work regulations, ear defenders must be worn by
everyone in the vicinity.
Wear practical, protective clothing and
footwear. Avoid loose garments and
jewellery that could catch in moving parts.
Check the equipment before use. If it shows signs of
damage or excessive wear, return it.
Stop the machine if you experience discomfort or
numbness during use.
Always switch OFF and isolate the grinder from its
air supply before making adjustments to it. Check
that it is switched OFF and that you have removed all
spanners and keys before reconnecting it.
Having switched OFF, always wait for the wheel to
come to rest before putting the grinder down.
Ensure the side handle and guard are correctly
adjusted and secure before starting work.
Ensure the work area is well lit and ventilated, if in
doubt, ask about dust extraction and ventilation
equipment at your local HSS Hire Shop.
Do not work near flammable gases or liquids, petrol
or paint thinner fumes for example. Keep combustible
materials at a safe distance – at least 5m.
Take special care when cutting into anything
containing pipework or electrical cables. If in doubt,
hire a metal detector from your local HSS Hire Shop, to
determine the exact position of such hazards.
GENERAL SAFETY Never allow compressed air to travel down an air
hose which is not connected to the air grinder, this
may cause personal injury.
Most HSS air grinders require a 125 cfm
compressor to run them. The air connections used
are the claw type quick action couplings.
On some models a short air hose adaptor is fitted,
to reduce the operator strain of trying to work with the
heavy conventional hose.
If the grinder fails, or if its hose or coupling gets
damaged, return it. Never try to repair it yourself.
Keep the air hose out of harm’s way, keep it clear of
moving parts. Never run them through water, over sharp
edges or where they could trip someone.
Never carry or pull the equipment by its air hose.
Ensure the air supply is turned OFF before
connecting or disconnecting it from the air hose.
With the compressor warmed up, and the air
supply valve CLOSED, connect the air hose by
pushing it on to the valve and turning clockwise.
Anchor the delivery end of the air hose so that it is
not aimed at any person or property then, taking great
care, slightly open the air supply valve to clear the
hose of any debris. Then fully close the valve
Fit the right wheel for the job. HSS Hire Shops offer
cut-off, grinding and diamond wheels.
Never use a grinding wheel for cut-off work or vice
versa. If in doubt, contact your local HSS Hire Shop.
GETTING STARTED
AIR SAFETY
Regularly check the wheel’s condition and replace
if worn or damaged, using only wheels supplied by
HSS Hire Shops.
Ensure replacement wheels are distortion free and
undamaged and that the paper washers are not
wrinkled or torn. NEVER FIT SUBSTANDARD OR
OLD, USED WHEELS.
To fit a wheel, isolate the grinder from its air supply,
then immobilise the back flange – grip the shaft with
the spanner provided or operate any spindle-lock button.
Remove the front lock flange with the ‘pin’ spanner
and check the condition of both flanges. If either is
damaged, return the grinder to your local HSS Hire Shop.
Now, locate the wheel on the back flange plate,
making sure that both the diameter and the arbor (centre
Hole) are the correct size for the machine.
Finally, secure the wheel in place by screwing on
the front lock flange Either with the boss on the
outside for cutting wheels or the boss on the inside for
grinding wheels.
Take care not to over-tighten then check that the
new wheel rotates freely and does not foul the
guard, before use.
You can now connect the grinder to the air
supply hose, open the air supply valve and start
the compressor.
Side
Handle
Rear
Flange
Wheel
Lock
Flange
Closed
Air Supply
Valve
Air Hose
Open
Air Connection
