Model 13310-4xx Series
Loudspeakers
Instruction and Service Manual
This manual covers the following loudspeaker models:
 Model 13310-411, 16-ohm, 25 watts,ULClass IIDivision 1
 Model 13310-412, 8-ohm, 25 watts,ULClass IIDivision 1
 Model 13310-413, 70 V line, 25 watts, ULClass IIDivision 1

Pub. 42004-503A
Tel: [phone]
GAI-Tronics 3030 Kutztown Rd. Reading PA 19605 USA
Document No. 42004-503A 9/29/2015 Fax: [phone]
[email protected]
www.gai-tronics.com
Sheet 2 of 5
Warranty
Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics
equipment supplied hereunder shall be free of defects in material and workmanship, shall
comply with the then-current product specifications and product literature, and if applicable, shall be fit
for the purpose specified in the agreed-upon quotation or proposal document. If (a) Seller’s goods prove
to be defective in workmanship and/or material under normal and proper usage, or unfit for the purpose
specified and agreed upon, and (b) Buyer’s claim is made within the warranty period set forth above,
Buyer may return such goods to GAI-Tronics’ nearest depot repair facility, freight prepaid, at which time
they will be repaired or replaced, at Seller’s option, without charge to Buyer. Repair or replacement shall
be Buyer’s sole and exclusive remedy. The warranty period on any repaired or replacement equipment
shall be the greater of the ninety (90) day repair warranty or one (1) year from the date the original
equipment was shipped. In no event shall GAI-Tronics warranty obligations with respect to equipment
exceed 100% of the total cost of the equipment supplied hereunder. Buyer may also be entitled to the
manufacturer’s warranty on any third-party goods supplied by GAI-Tronics hereunder. The applicability
of any such third-party warranty will be determined by GAI-Tronics.
Services. Any services GAI-Tronics provides hereunder, whether directly or through subcontractors,
shall be performed in accordance with the standard of care with which such services are normally
provided in the industry. If the services fail to meet the applicable industry standard, GAI-Tronics will
re-perform such services at no cost to buyer to correct said deficiency to Company's satisfaction provided
any and all issues are identified prior to the demobilization of the Contractor’s personnel from the work
site. Re-performance of services shall be Buyer’s sole and exclusive remedy, and in no event shall GAI-Tronics
warranty obligations
. 
Warranty Periods. Every claim by Buyer alleging a defect in the goods and/or services provided hereunder shall be
deemed waived unless such claim is made in writing within the applicable warranty periods as set forth above.
Provided, however, that if the defect complained of is latent and not discoverable within the above warranty periods,
every claim arising on account of such latent defect shall be deemed waived unless it is made in writing within a
reasonable time after such latent defect is or should have been discovered by Buyer.
Limitations / Exclusions. The warranties herein shall not apply to, and GAI-Tronics shall not be responsible for,
any damage to the goods or failure of the services supplied hereunder, to the extent caused by Buyer’s neglect,
failure to follow operational and maintenance procedures provided with the equipment, or the use of technicians not
specifically authorized by GAI-Tronics to maintain or service the equipment. THE WARRANTIES AND
REMEDIES CONTAINED HEREIN ARE IN LIEU OF AND EXCLUDE ALL OTHER WARRANTIES AND
REMEDIES, WHETHER EXPRESS OR IMPLIED BY OPERATION OF LAW OR OTHERWISE, INCLUDING
ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Return Policy
If the equipment requires service, contact your Regional Service Center for a return authorization number (RA#).
Equipment should be shipped prepaid to GAI-Tronics with a return authorization number and a purchase order
number. If the equipment is under warranty, repairs or a replacement will be made in accordance with the warranty
policy set forth above. Please include a written explanation of all defects to assist our technicians in their
troubleshooting efforts.
Call 800-492-1212 (inside the USA) or 610-777-1374 (outside the USA) for help identifying the Regional Service
Center closest to you.

__________________________________________________________________________________________________________________
Tel: [phone]
GAI-Tronics 3030 Kutztown Rd. Reading PA 19605 USA
Document No. 42004-503A 9/29/2015 [email protected]
www.gai-tronics.com Fax: [phone]
Sheet 3 of 5
INSTRUCTION & SERVICE MANUAL
13310-4XX LOUDSPEAKERS
For Use In Hazardous Locations - Dust
The 13310-4xx series Loudspeakers are certified
by
UL as Audible-signal Appliances for Use in
HazardousLocations
1) Introduction
The 13310-4xx series are UL certified loudspeakers which
produce a loud warning signal in a hazardous area. The
loudspeakers are approved for use in Dust applications in
Class II Division 1 & 2 as well as Class II Division 1 & 2 and
Class III Division 1 & 2 as well as Class II Zone 20, 21 and
22.
2) Warnings
CAUTION
TO REDUCE THE RISK OF IGNITION OF
HAZARDOUS ATMOSPHERES:
DISCONNECT FROM SUPPLY BEFORE OPENING.
KEEP TIGHTLY CLOSED WHEN IN OPERATION.
WARNING
FIT SEALING FITTING IN CONDUIT RUNS WITHIN 18
INCHES FROM ENCLOSURE.
EQUIPMENT MUST NOT BE INSTALLEDWITH THE
HORN FACING UPWARDS OF HORIZONTAL.
ATTENTION
POUR REDUIRE LE RISQUE D’INFLAMMATION
DES ATMOSPHÈRES DANGEREUSES:
COUPER L 'ALIMENTATION AVANT OUVERTURE.
CONSERVER FERMÉ PENDANT LE FONCIONNEMENT.
AVERTISSEMENT
CONDUITS DOIVENT ÊTRE SCELLÉS EN MOINS DE 18
POUCES.
ÉQUIPEMENT NE DOIT PAS ÊTRE INSTALLÉ AVEC LE
KLAXON TOURNÉE VERS LE HAUT DE HORIZONTAL.
3) Ratings and Markings
3.1 Class / Division Ratings for US and Canada
The 13310-4xx Loudspeakers comply with the following
standards for hazardous locations:
UL 1203
CSA C22.2 NO. 30-M1966
The 13310-4xx Loudspeakers also comply with the
following standards for signaling equipment:
UL1480
CSA C22.2 NO. 205-12
3.2 Class / Division Ratings for US & Canada
Class II Div 1 FG T6 Ta −40°C to +70°C
Class III Div1 Ta −40°C to +70°C
Installation must be carried out in compliance with the
National Electric Code / Canadian Electric Code.
3.3 Class / Zone ratings US and Canada
Zone 20 IIC T6 Ta −40°C to +70°C
Installation must be carried out in compliance with the
National Electric Code / Canadian Electric Code.
3.4 Ambient Temperature Range
−40ºC to +70ºC
3.5 Enclosure Ratings
The product is rated for ingress protection as follows:
IP rating per EN60529: IP66
Type rating per UL50E / NEMA250: 4 / 4X / 3R / 13
3.6 Electrical Ratings
Model No. Input Power
(Watts) Max I/P Volts
13310-413 70V Line 25 70
13310-412 8 Ohm 25 14.14
13310-411 16 Ohm 25 20
3.7 Frequency Range
All models: 400 Hz to 8000 Hz
4) Installation
4.1 Safe Installation Requirements
The product must only be installed by suitably qualified
personnel in accordance with the latest issues of the
relevant standards.
The installation of the units must also be in accordance with
the NEC / CEC and any local regulations and should only
be carried out by a competent electrical engineer who has
the necessary training.

Pub. 42004-503A
__________________________________________________________________________________________________________________
Tel: [phone]
GAI-Tronics 3030 Kutztown Rd. Reading PA 19605 USA
Document No. 42004-503A 9/29/2015 [email protected]
www.gai-tronics.com Fax: [phone]
Sheet 4 of 5
The Equipment must not be installed with the horn facing
upwards of horizontal.
To maintain the ingress protection rating and mode of
protection, the cable entries must be fitted with suitably rated
cable entry and/or blanking devices during installation. If
conduit is used for installation, seal conduit within 18 inches
from the enclosure.
If entries are fitted with adaptors they must be suitably rated
for the application. Fitting of blanking elements into adaptors
is not permitted.
If a high IP (Ingress Protection) rating is required then a
suitable sealing washer or O-ring must be fitted under any
cable gland or blanking device with metric threads.
Only the explosionproof cover is to be used for access to the
enclosure for installation, service and maintenance.
Connections are to be made into the terminal blocks using
solid or stranded wire, sizes 0.5–4.0mm2/ AWG 20–12. Wire
insulation needs to be stripped 6–7mm. Wires may be fitted
securely with crimped ferrules. Terminal screws need to be
tightened down with a tightening torque of 0.4 Nm / 3.5 Lb-in.
Earthing connections should be made to the Internal Earth
terminal in the explosionproof chamber or the external earth
stud.
Check that the ‘O’ ring seal is in place before replacing the
explosionproof cover.
4.2 Mounting
Figure1. Fixing locations.
13310-4xx Loudspeakers should only be installed by trained
competent personnel.
The Loudspeakers may be secured to any flat surface using
the three 7mm fixing holes. The enclosure provides IP66
protection and is suitable for indoor and outdoor use
providing it is positioned so that water cannot collect in the
horn, and the cable entry is sealed.
4.3 Installation Procedure
a. Secure the Loudspeaker to a flat surface via the three
7mm fixing holes in the mounting bracket.
b. Remove the explosionproof cover of the loudspeaker by
unscrewing it, taking care not to damage the threads in
the process. (Refer to Section 5.)
c. Fit an M20x1.5 suitably certified cable gland or ½” NPT
conduit into the corresponding entry in the enclosure and
connect the field wiring to the appropriate loudspeaker
terminals as shown in Section 6 / Figure 3 (70V Line In) or
Section 7 / Figure 4 (Low Impedance) of this manual. The
power supply terminals on the low impedance units are
duplicated so that units may be connected in parallel. An
end-of-line monitoring resistor may be fitted to either type
of unit. Additional entries which are not used must always
be fitted with suitably certified blanking elements.
d. Replace the explosionproof cover of the loudspeaker,
taking care not to damage the explosionproof threads and
checking that the O-ring seal is in place. Tighten the cover
fully.
4.4 Hornless Variants
The 13310-4xx Loudspeaker is also available as a variant
with no horn fitted in the factory. The Horn threaded nose
portion has a fitment thread of 1-3/8” – 18 UNF (to BS1580
or ANSI B1.1). The customer is responsible for sourcing
and correctly fitting a suitable horn that meets all of the
relevant safety requirements.
5) Access to the Explosion-proof Enclosure
In order to connect the electrical supply cables to the
loudspeaker, it is necessary to remove the explosion-proof
cover to gain access to the explosion-proof chamber. This
can be achieved by unscrewing the explosion-proof cover,
taking extreme care not to damage the explosion-proof
threads in the process.
Figure2.AccessingtheExplosion‐proofEnclosure
On completion of the cable wiring installation, the explosion-proof
threads should be inspected to ensure that they are clean and
that they have not been damaged during installation. Also check
that the ‘O’ ring seal is in place on the thread diameter in contact
with the flat face of the explosion-proof cover. When replacing
the explosion-proof cover ensure that it is tightened fully.
6) 70V Line In Wiring
Figure3.LineInTerminals
Internal Earth
Terminal
E
D
C
B
A
Blankin
g
elemen
t
External Earth
A
ssembl
y
(Appropriate
cable glands to
be customer
supplied) Flameproof
cover

Pub. 42004-503A
__________________________________________________________________________________________________________________
Tel: [phone]
GAI-Tronics 3030 Kutztown Rd. Reading PA 19605 USA
Document No. 42004-503A 9/29/2015 [email protected]
www.gai-tronics.com Fax: [phone]
Sheet 5 of 5
The cable connections are made into the terminal blocks on
the PCB assembly located in the explosionproof enclosure.
See Section 5 of this manual for access to the explosion-
proof enclosure. The 70V Line loudspeakers are fitted with a
five-way terminal block. Terminal A is common and one of
the other terminals B, C, D or E should be selected
depending on what output level is required. (See table
below).
Terminals Watts
A - B 25W
A - C 12.5W
A - D 6W
A - E 2W
For 8-ohm and 16-ohm models a single conductor with a
cross sectional area of up to 2.5mm² / ~13 AWG can be
connected to each terminal. The 70V transformer model is
supplied with two (2) sets of terminals (in and out), a single
conductor with a cross sectional area of up to 2.5mm² / ~13
AWG can be connected to each terminal. If more than one
wire is fitted into a terminal, a ferrule should be used to
secure the wires. When connecting wires to the terminals
great care should be taken to dress the wire so that when the
cover is inserted into the chamber the wires do not exert
excess pressure on the terminal blocks.
7) Low Impedance Wiring
Figure4.LowImpedanceTerminals
The 8-ohm and 16-ohm lowimpedance models have dual
input terminals on the PCB assembly for input and output
wiring. A cable of up to 2.5mm² can be connected toeach
terminal. If DC line monitoring is used, cut the link on the
board. (See Figure 4.)
8) Earthing
The unit has both a primary internal and secondary external
earth fixing point.
Internal earth connections should be made to the internal
Earth terminal. See Figure 3 and Figure 4. It should be fitted
to the internal earth point using a ring crimp terminal to
secure the earth conductor.
In addition, external earth connections can be made to the
M5 earth stud (see Figure 2), using a ring crimp terminal to
secure the earth conductor to the earth stud. The external
earth crimp ring should be located between the two M5 plain
washers provided and securely locked down with the M5 spring
washer and M5 nut.
The earth conductor should be at least equal in size and rating
to the incoming power conductors but at least a minimum of
0.82mm2/ 18 AWG in size.
9) End-of-Line DC Monitoring
On 13310-4xx Loudspeakers, DC line monitoring can be used
if required. Both the 70V Line units and the Low Impedance
units have blocking capacitors fitted. It should be noted that
each loudspeaker has a 1M ohm bleed resistor connected
across the blocking capacitor and this should be taken into
account when selecting the value of the end-of-line monitoring
resistance.
The end-of-line monitoring resistor can be connected across
the terminals on the end-of-line unit.
On 70V line units, the end-of-line resistor used must have a
minimum resistance value of 4k7 ohms and a minimum
wattage of 2.5 watts.
On low impedance units, the end-of-line resistor used must
have a minimum resistance value of 2k ohms and a minimum
wattage of 0.5 watts or a minimum resistance value of 500
ohms and a minimum wattage of 2 watts. On the low
impedance units, care must be taken with the polarity of the
monitoring voltage. If an end-of-line resistor is fitted to a unit,
the links on the printed circuit boards of all loudspeakers in the
line must be cut for the dc blocking capacitors to be in circuit in
order to dc monitor the line. (See Figure 4.)
10) Maintenance, Repair and Overhaul
Maintenance, repair and overhaul of the equipment should only
be carried out by suitably qualified personnel in accordance
with the current relevant standards and regulations.
Units must not be opened while an explosive atmosphere is
present.
If opening the unit during maintenance operations, a clean
environment must be maintained and any dust layer removed
prior to opening the unit.
The threaded flame path joints are not intended to be repaired.
Internal Earth
Terminal
DC Line
Monitoring Link
- - + +

(Rev. 10/06)
Warranty
Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any
GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall
comply with the then-current product specifications and product literature, and if applicable, shall be fit
for the purpose specified in the agreed-upon quotation or proposal document. If (a) Seller’s goods prove
to be defective in workmanship and/or material under normal and proper usage, or unfit for the purpose
specified and agreed upon, and (b) Buyer’s claim is made within the warranty period set forth above,
Buyer may return such goods to GAI-Tronics’ nearest depot repair facility, freight prepaid, at which time
they will be repaired or replaced, at Seller’s option, without charge to Buyer. Repair or replacement shall
be Buyer’s sole and exclusive remedy. The warranty period on any repaired or replacement equipment
shall be the greater of the ninety (90) day repair warranty or one (1) year from the date the original
equipment was shipped. In no event shall GAI-Tronics warranty obligations with respect to equipment
exceed 100% of the total cost of the equipment supplied hereunder. Buyer may also be entitled to the
manufacturer’s warranty on any third-party goods supplied by GAI-Tronics hereunder. The applicability
of any such third-party warranty will be determined by GAI-Tronics.
Services. Any services GAI-Tronics provides hereunder, whether directly or through subcontractors,
shall be performed in accordance with the standard of care with which such services are normally
provided in the industry. If the services fail to meet the applicable industry standard, GAI-Tronics will
re-perform such services at no cost to buyer to correct said deficiency to Company's satisfaction provided
any and all issues are identified prior to the demobilization of the Contractor’s personnel from the work
site. Re-performance of services shall be Buyer’s sole and exclusive remedy, and in no event shall GAI-
Tronics warranty obligations with respect to services exceed 100% of the total cost of the services
provided hereunder.
Warranty Periods. Every claim by Buyer alleging a defect in the goods and/or services provided
hereunder shall be deemed waived unless such claim is made in writing within the applicable warranty
periods as set forth above. Provided, however, that if the defect complained of is latent and not
discoverable within the above warranty periods, every claim arising on account of such latent defect shall
be deemed waived unless it is made in writing within a reasonable time after such latent defect is or
should have been discovered by Buyer.
Limitations / Exclusions. The warranties herein shall not apply to, and GAI-Tronics shall not be
responsible for, any damage to the goods or failure of the services supplied hereunder, to the extent
caused by Buyer’s neglect, failure to follow operational and maintenance procedures provided with the
equipment, or the use of technicians not specifically authorized by GAI-Tronics to maintain or service the
equipment. THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE IN LIEU OF AND
EXCLUDE ALL OTHER WARRANTIES AND REMEDIES, WHETHER EXPRESS OR IMPLIED BY
OPERATION OF LAW OR OTHERWISE, INCLUDING ANY WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Return Policy
If the equipment requires service, contact your Regional Service Center for a return authorization number
(RA#). Equipment should be shipped prepaid to GAI-Tronics with a return authorization number and a
purchase order number. If the equipment is under warranty, repairs or a replacement will be made in
accordance with the warranty policy set forth above. Please include a written explanation of all defects to
assist our technicians in their troubleshooting efforts.
Call 800-492-1212 (inside the USA) or 610-777-1374 (outside the USA) for help identifying the
Regional Service Center closest to you.
