Humminbird ChartSelect User manual

532362-5_A
Introduction ......................................................... 4
Preparation.......................................................... 5
Register Your Humminbird Products .............................. 5
Set Up a Humminbird ChartSelect Account....................... 5
Update Your Fish Finder Software to Display
Purchased Charts................................................... 5
Using ChartSelect................................................... 7
Supplies ............................................................. 7
Purchase Humminbird LakeMaster Legacy Regional Charts ...... 7
Purchase AutoChart Zero Line Region Maps
and AutoChart PC Software .......................................10
Complete Your Chart Purchase ...................................11
Download the Computer Applications ............................12
Save Purchased Charts to the SD or MicroSD Card .............14
View Purchased Charts on Your Fish Finder .....................17
Contact Humminbird ..............................................19
T  C
User Manual
CS

2
T Y
Thank you for choosing Humminbird®, the #1 name in marine electronics. Humminbird has built its reputation by designing and
manufacturing top quality, thoroughly reliable marine equipment. We encourage you to read this operations manual carefully in
order to get the full benefit from all the features and applications of your Humminbird product.
Contact Humminbird Technical Support through our Help Center at https://humminbird-help.johnsonoutdoors.com/hc/en-us.
WARNING! This device should not be used as a navigational aid to
prevent collision, grounding, boat damage, or personal injury.
When the boat is moving, water depth may change too quickly to
allow time for you to react. Always operate the boat at very slow
speeds if you suspect shallow water or submerged objects.
WARNING! The electronic chart is an aid to navigation designed to
facilitate the use of authorized government charts, not to replace
them. Only official government charts and notices to mariners
contain all of the current information needed for the safety of
navigation, and the captain is responsible for their prudent use.
WARNING! Humminbird is not responsible for the loss of data files
(waypoints, routes, tracks, groups, recordings, etc.) that may occur
due to direct or indirect damage to the unit’s hardware or software.
It is important to back up your fish finder’s data files periodically.
Data files should also be saved to your computer before restoring
the fish finder defaults or updating the software. Visit our Web site
at humminbird.com and download your fish finder operations
manual for details.
WARNING! Do NOT delete or change the AC folder, LkMaster folder,
or SI folder when saving an AutoChart Zero Line region map to an
SD or microSD card.
NOTE: Some features discussed in this manual require a separate
purchase. Every effort has been made to clearly identify those
features.
NOTE: The illustrations in this manual may not look the same as
your product, but your product will function in a similar way.
NOTE: To purchase accessories for your fish finder, visit our
Web site at humminbird.com or Contact Humminbird Technical
Support through our Help Center at https://humminbird-help.
johnsonoutdoors.com/hc/en-us.
NOTE: The procedures and features described in this manual are
subject to change without notice. This manual was written in
English and may have been translated to another language.
Humminbird is not responsible for incorrect translations or
discrepancies between documents.
NOTE: Product specifications and features are subject to change
without notice.

3
ENVIRONMENTAL COMPLIANCE STATEMENT: It is the intention of Johnson Outdoors Marine Electronics, Inc. to be a responsible corporate citizen,
operating in compliance with known and applicable environmental regulations, and a good neighbor in the communities where we make or sell our
products.
WEEE DIRECTIVE: EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers, and
manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer electronics to take responsibility
for the management of waste from their products to achieve environmentally responsible disposal during the product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may it be required for EEE designed and intended as
fixed or temporary installation in transportation vehicles such as automobiles, aircraft, and boats. In some European Union member states, these vehicles
are considered outside of the scope of the Directive, and EEE for those applications can be considered excluded from the WEEE Directive requirement.
This symbol (WEEE wheelie bin) on product indicates the product must not be disposed of with other household refuse. It must be disposed of and
collected for recycling and recovery of waste EEE. Johnson Outdoors Marine Electronics, Inc. will mark all EEE products in accordance with the
WEEE Directive. It is our goal to comply in the collection, treatment, recovery, and environmentally sound disposal of those products; however,
these requirements do vary within European Union member states. For more information about where you should dispose of your waste equipment
for recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from which your product
was purchased.
ROHS STATEMENT: Product designed and intended as a fixed installation or part of a system in a vessel may be considered beyond the scope of
Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003 on the restriction of the use of certain hazardous substances
in electrical and electronic equipment.
APEX™, AutoChart®, AutoChart PRO®, AutoChart Zero Line Map Card™, ChartSelect®, FishSmart™, HELIX®, Humminbird®, HumminbirdPC™, LakeMaster®, and SOLIX® are
trademarked by or registered trademarks of Johnson Outdoors Marine Electronics, Inc.
Adobe, Acrobat, Adobe PDF, and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
microSD and SD are trademarks or registered trademarks of SD-3C, LLC in the United States, other countries or both.
Navionics® is a registered trademark of Navionics S.p.A.
© 2022 Johnson Outdoors Marine Electronics, Inc. All rights reserved.

4Introduction
I
ChartSelect allows you to purchase and download LakeMaster Legacy Regional Charts or AutoChart Zero Line Map Card Regions for
use in your supported Humminbird fish finder as well as AutoChart software for your PC. The instructions in this manual describe
how to purchase and download LakeMaster Legacy Regional Charts using the ChartSelect Web site and then save them to encrypted
SD or microSD cards for use in your fish finder. Visit our Web site at chartselect.humminbird.com for the latest list of compatible
models. Click Support > ChartSelect > Supported Plotters.
LakeMaster Legacy Regional Charts are for Humminbird fish finders that are not compatible with VX Technology. If you have a HELIX
G3, G3N, or G4N or an APEX or SOLIX model, visit our Web site at humminbird.com to learn more about VX technology maps and
charts.
For information and instructions about using charts on your fish finder, see your fish finder operations manual. Operations manuals
and accessory manuals for LakeMaster Map Cards, AutoChart, AutoChart Zero Line Map Cards, and other Humminbird LakeMaster
products are available for download on our Web site at humminbird.com.

5 Preparation
P
We recommend that you read this guide completely before making any purchases. Also, visit chartselect.humminbird.com to
confirm fish finder and mobile device compatibility. Click Support > ChartSelect > Supported Plotters.
Technical Support: If you have questions, contact Humminbird Technical Support through our Help Center at https://humminbird-
help.johnsonoutdoors.com/hc/en-us.
1|Register Your Humminbird Products
Register your Humminbird equipment so that you will receive the latest Humminbird news, including accessory compatibility and
software update information.
1. Go to our Web site at humminbird.com, and select Support > Register Your Product.
2. Follow the on-screen prompts to register your products.
NOTE: With an AutoChart purchase, register the provided serial number for future updates. Humminbird LakeMaster charts do not
need to be registered.
2|Set Up a Humminbird ChartSelect Account
1. Go to the ChartSelect Web site at chartselect.humminbird.com, and select Register in the top right corner of the page.
2. Enter your information and follow the on-screen prompts to create a new account.
3. Confirm Account: A confirmation e-mail will be sent to the e-mail address saved to your ChartSelect account. Open the
e-mail and follow the instructions provided to confirm your ChartSelect account.
NOTE: If you did not receive an email, check your spam account and add [email protected] to your safe senders list.
3|Update Your Fish Finder Software to Display Purchased Charts
To display LakeMaster and AutoChart charts, you will need the most up-to-date software
on your Humminbird fish finder. See your fish finder operations manual for additional
information about updating software.
Compatibililty: Visit our Web site at humminbird.com for the latest list of compatible
models.
Supplies: In addition to your Humminbird equipment, you will need a computer with Internet
access and a formatted 32GB SD or microSD card (depending on your model).
1. Before the fish finder software is updated or restored to system defaults, export your
navigation data and copy your screen snapshots to an SD or microSD card. See your
fish finder operations manual for more information.
NOTE: Humminbird is not responsible for the loss of data files (waypoints, routes, tracks,
groups, snapshots, recordings, etc.) that may occur due to direct or indirect damage to the
unit’s hardware or software. It is important to back up your computer and fish finder data
files periodically.
2. Install a formatted 32 GB SD or microSD card into the computer card slot.
NOTE: Do not use an SD or microSD card that is either more or less than 32 GB.
3. Go to humminbird.com, and click Support > Software Updates.
4. Click on your fish finder model. The available software updates are listed as downloads
under each product. Confirm the file name is for your fish finder model.
Inserting an SD Card into the Card Slot
Inserting a microSD Card into the Adapter

6Preparation
∆Read the notices and instructions, and select the Download link at the bottom of the screen.
∆Follow the on-screen prompts to save the software file to the SD or microSD card.
5. Repeat step 4 to download the software updates posted to each product.
6. Insert the SD or microSD card (with the software file) into the fish finder card slot.
Inserting a microSD Card into the Card Slot
7. Power on your Humminbird fish finder. Start Normal mode.
NOTE: When you install the SD card with the software file into your fish finder, the fish finder will detect the update and provide an
automatic prompt to install the software. You can follow the prompts or choose to install the software at a later time. See your fish
finder operations manual for more information.
8. Follow the on-screen prompts to update the software.
9. When the software update is complete, remove the SD or microSD card from the fish finder card slot.
10.Restart: If you don’t have any other software updates to install, power off the fish finder, and restart it.

7 Using ChartSelect
U CS
Use the instructions in this section to purchase Humminbird LakeMaster Legacy Regional Charts and/or AutoChart PC software
on the ChartSelect Web site. Before proceeding, visit chartselect.humminbird.com to confirm fish finder compatibility. Click
Support > ChartSelect > Supported Plotters for a list of Humminbird fish finders that are compatible with ChartSelect Legacy
Regional Charts.
Supplies
In addition to your Humminbird fish finder, you will need a computer with high-speed Internet access and a blank 32 GB (gigabyte)
SD or microSD card (depending on your fish finder model) that is formatted to the FAT32 file system.
WARNING! Humminbird LakeMaster Legacy Regional Charts and AutoChart Zero Line region maps cannot be saved to the same SD or
microSD card. A separate 32 GB SD or microSD card is required for each LakeMaster Legacy Regional Chart or AutoChart Zero Line region
map.
Minimum PC Requirements
Your computer should have the following minimum specifications:
∆Microsoft Windows 7, 8, 10, or higher
OR
∆Mac OS X 10.14 or newer
∆1 GHz* Pentium 4 or Athlon CPU (*2 GHz is recommended)
∆512 MB* RAM (*1024 MB RAM is recommended)
∆10 GB free hard drive
∆SD card reader and/or microSD card reader
∆High-speed Internet connection
NOTE: AutoChart PC is only compatible with Microsoft Windows 7, 8, or 10, and not compatible with MacOS.
1|Purchase Humminbird LakeMaster Legacy Regional Charts
Before proceeding, review the following important information:
∆Save LakeMaster Legacy Regional Charts to One SD Card: You can save only one LakeMaster Legacy Regional Chart to an SD
or microSD card.
A downloaded LakeMaster Legacy Regional Chart can only be saved to one SD or microSD card for the life of the product. In
the event you delete, format, or overwrite the SD or microSD card, purchased charts will remain available for re-download (to
the same SD or microSD card) for 1 year from the date of purchase.
∆Do not save LakeMaster Legacy Regional Charts and AutoChart Zero Line Region maps to the same SD or microSD card. A
separate 32 GB SD or microSD card is required for each LakeMaster Legacy Regional Chart and AutoChart Zero Line Region
map.
∆SD Card Format: The SD or microSD card must be formatted to use the FAT32 file system. Confirm your SD or microSD card
is formatted to FAT32 before saving charts to the card.
∆Chart File Sizes: Chart files range in size, and future updates may require additional space on the SD or microSD card. Use a
32 GB SD or microSD card to ensure enough space for additional charts and/or future chart updates.
WARNING! You must use a blank SD or microSD card that is formatted to FAT32. Do NOT use a chart or map card (e.g., LakeMaster,
Navionics).
NOTE: Do not use an SD or microSD card that is either more or less than 32 GB.
NOTE: Formatting an SD or microSD card will remove any existing content from the card.

8Using ChartSelect
1. Select a LakeMaster Legacy Regional Chart
1. Log in to your chartselect.humminbird.com account.
ChartSelect Home Page
map of
available
regions
new account
setup
account login
2. Find a LakeMaster Legacy Regional Chart. Use the on-screen map to look for your region, or scroll down to review all the
available LakeMaster Legacy Regional Charts.
Selecting a LakeMaster Legacy Regional Chart
LakeMaster
Legacy Regional
Chart name
click to review
complete lake list
click to add product
to your cart
click to review
list of compatible
fish finders
click to see more
information about
the chart

9 Using ChartSelect
3. Click Details to view more information about the selected ChartSelect Legacy Regional Chart.
LakeMaster Legacy Regional Chart Details
4. Purchase Chart: To purchase the LakeMaster Legacy Regional Chart, click Add to Cart.
5. Repeat: Repeat steps 2-4 to purchase additional LakeMaster Legacy Regional Charts.
6. To complete your purchase, proceed to section 3, Complete Your Chart Purchase.

10Using ChartSelect
2|Purchase AutoChart Zero Line Region Maps and AutoChart PC Software
You can purchase individual AutoChart Zero Line region maps or you can purchase an AutoChart or AutoChart PRO bundle, which
includes the map for the region you select and the AutoChart software for your computer.
Before proceeding, review the following information:
∆Save One Zero Line Region Map to One SD or microSD Card: You can save one downloaded Zero Line region map to one SD or
microSD card. Do not save multiple maps to the same SD or microSD card.
A downloaded Zero Line map can only be saved to one SD or microSD card for the life of the product. In the event you delete,
format, or overwrite the SD or microSD card, purchased charts will remain available for re-download (to the same SD or
microSD card) for 1 year from the date of purchase.
∆Do not save LakeMaster charts and AutoChart Zero Line region maps to the same SD or microSD card. A separate 32 GB SD
or microSD card is required for each AutoChart Zero Line region map.
∆SD Card Format: The SD or microSD card must be formatted to use the FAT32 file system. Confirm your SD or microSD card
is formatted to FAT32 before saving charts to the card.
∆Chart File Sizes: Chart files range in size, and future updates may require additional space on the SD or microSD card. Use a
32 GB SD or microSD card to ensure enough space for additional charts and/or future chart updates.
WARNING! You must use a blank SD or microSD card that is formatted to FAT32. Do NOT use a chart or map card (e.g., LakeMaster, Navionics).
NOTE: Do not use an SD or microSD card that is either more or less than 32 GB.
1. Purchase an AutoChart or AutoChart PRO Software Bundle
If you already own AutoChart or AutoChart PRO software, skip this section and proceed to Purchase Individual AutoChart Zero Line
Maps.
1. Log in to your chartselect.humminbird.com account.
2. Select Products > AutoChart > AutoChart PC.
3. Select an AutoChart software bundle. Click Add to Cart.
4. Select a Zero Line region from the displayed menu, and click Add to Cart.
5. To complete your purchase, proceed to step 3, Complete your Chart Purchase.
2. Purchase Individual AutoChart Zero Line Maps
Use the following instructions to select individual AutoChart Zero Line maps for specific regions.
1. Log in to your chartselect.humminbird.com account.
2. Select Products > AutoChart > AutoChart Zero Line SD Card.
3. Select a region from the list of Zero Line region maps.
∆To view the coverage of the selected region, click on the map thumbnail.
4. Click Add to Cart.
5. To complete your purchase, proceed to step 3, Complete you Chart Purchase.

11 Using ChartSelect
3|Complete Your Chart Purchase
1. When you are ready to complete your purchase, click on the cart tab.
2. Review the items in your cart.
∆To remove a chart from your cart, select Remove.
∆To remove all charts from your cart, select Empty Cart.
∆To change the quantity of a specific item in your cart, click plus (+) or minus (-) under Quantity.
Completing Your Chart Purchase
cart tab
3. Confirm your contact information and enter your payment information.
4. When you are ready to complete the purchase, click Purchase.
Check your email for your invoice.
NOTE: If the email does not appear in your inbox, check your spam folder.
5. Keep the ChartSelect web page open and proceed to the next section.

12Using ChartSelect
4|Download the Computer Applications
For LakeMaster Legacy Regional Chart and AutoChart Zero Line chart purchases, proceed to Install the ChartSelect Download Tool.
For AutoChart and AutoChart Pro purchases, proceed to Install AutoChart PC.
Install the ChartSelect Download Tool
(with LakeMaster Legacy Regional Chart and AutoChart Zero Line map purchases)
The ChartSelect Download Tool is a computer application that allows you to manage your purchased charts and save them to
encrypted SD or microSD cards.
1. Review the computer requirements in the section Using ChartSelect: Supplies.
2. Locate the link to download the ChartSelect Download Tool.
The link can be found at the bottom of the Thank You For Your Purchase page, the LakeMaster Legacy Details page or the
ChartSelect Instructions page.
3. Click Mac Download or PC Download (depending on your operating system).
4. Once it is downloaded, double-click the file from your Downloads window or from the location on your computer where you
saved the self-extracting setup file. Select Run.
5. Follow the on-screen prompts to complete the software installation.
NOTE: For Windows 7 users, the ‘Everyone’ or ‘Just Me’ options will depend on the user permissions that are assigned to you on that
computer. The installation may require the installer to have Administrator permissions to install the application for ‘Everyone’.
Downloading the ChartSelect Download Tool
Follow the on-screen instructions to complete the software download.

13 Using ChartSelect
Install AutoChart PC (included with AutoChart purchases only)
Use the following instructions to download AutoChart or AutoChart PRO to your PC.
1. Review the computer requirements in the section Using ChartSelect: Supplies.
2. Download the AutoChart software from the link supplied in your emailed invoice.
3. Once the download has completed, double-click on the AutoChartSetup.exe file from your Downloads window or from the
location on your computer where you saved the extracted file.
4. Follow the on-screen prompts to complete the software installation.
5. Enter your AutoChart serial number when prompted.
NOTE: It is important to save your AutoChart serial number. You will need it any time you wish to install the software.

14Using ChartSelect
5|Save Purchased Charts to the SD or MicroSD Card
Use the following instructions to save your purchased charts to an SD or microSD card.
WARNING! You must use a blank SD or microSD card that is formatted to FAT32. Do NOT use a chart or map card (e.g., LakeMaster,
Navionics).
NOTE: In the event you delete, format, or overwrite the SD or microSD card, purchased charts will remain available for re-download (to
the same SD or microSD card) for 1 year from the date of purchase.
Encrypt Your SD or microSD Card
NOTE: When an SD card is correctly encrypted, an ENCRYPT.TXT file will appear in the root folder of the card. If this does not appear, it
means the card was not correctly encrypted. Repeat the encryption steps for your fish finder model.
NOTE: Ensure your Humminbird fish finder has the latest software installed.
APEX, SOLIX and HELIX Series
Insert a blank SD or micro SD card into your powered up fish finder. The card will be automatically encrypted.
800, 900 and 1100 Series
1. Insert a blank SD card into your powered up fish finder.
2. Press the Menu key twice to open the Main Menu.
3. Press the Right Cursor key to select the Setup Menu tab.
4. Press the Down Cursor key to select Encrypt SD Card.
5. Press the Right Cursor key, and follow the on-screen prompts.
ONIX and ION Series
1. Insert a blank SD card into your powered up fish finder.
2. Press the Home key.
3. Select the Files tool.
4. Under Encrypt, select Encrypt SD Card 1 or Encrypt SD Card 2.
5. Tap, or press the Enter key, to select, and follow the on-screen prompts.
Save LakeMaster Legacy Regional Charts or an AutoChart Zero Line Region Map to the SD or microSD Card
1. Insert the unlocked, encrypted SD card or microSD card into the card slot on your computer.
2. Open the ChartSelect Download Tool.
3. Log in to your ChartSelect account.
Log in to your ChartSelect account using your e-mail
address and password.

15 Using ChartSelect
4. Select your SD card location: Once you have logged in to the ChartSelect Download Tool, a dialog box will open directing you
to select your SD card location. Under Computer, select the SD or microSD card (commonly displayed as Removable Disk),
and click Open to select.
Click Select SD Card to change your SD card location.
5. Select LakeMaster Legacy Regional Chart: From the Legacy Charts tab, select the LakeMaster Legacy Regional product you
want to save to the SD or microSD card. Click the radial circle to select.
OR
Select One AutoChart Zero Line Map: From the Zero Line tab, select the AutoChart Zero Line region map you want to save to
the SD or microSD card. Click the radial circle to select.
WARNING! Do not save LakeMaster Legacy Regional Charts and AutoChart Zero Line maps to the same SD or microSD card. A separate
32 GB SD or microSD card is required for each LakeMaster Legacy Regional Chart or AutoChart Zero Line region map.
ChartSelect Download Tool
select the chart
to download
click to start
download
Legacy Charts tab
Zero Line tab
review SD card
capacity and
availability
6. Click Download. A status bar will display to indicate the download progress.
NOTE: Downloading data to a particular encrypted card will lock the data to that card. The data can then no longer be downloaded to
a different card, but it can be updated on the original card.
NOTE: Map files are large. A fast and reliable internet connection is required.
7. A confirmation box will display when the download is complete. Click OK.
You may pause/cancel the download at any time and resume later.

16Using ChartSelect
ChartSelect Download Complete
download
confirmation box
download
status bar updated SD
card capacity
8. Remove the SD or microSD card from your computer card slot.
The SD or microSD card is now ready for operation.

17
6|View Purchased Charts on Your Fish Finder
Use the following instructions to view your saved and purchased charts on your fish finder.
1. Insert the SD or microSD card (with the saved ChartSelect Legacy Regional Charts) into the fish finder card slot.
When you install an SD or microSD card, the map source is changed automatically to match the SD or microSD card map
source. If you install more than one SD or microSD map card, you can choose which chart source you want to use. Depending
on your fish finder model, the map source menu will be under the Chart Menu Tab (HELIX Series) or under Settings > Chart
(APEX and SOLIX Series).
NOTE: Once the SD or microSD card is installed in the fish finder, AutoChart and LakeMaster menu options are automatically added to
the menu system. See your fish finder operations manual for more information.
2. Select Chart View.
The lake map displayed on your fish finder is based on the GPS latitude/longitude position and the SD or microSD card
installed. GPS reception is required for the correct lake to be displayed.
If you do not have GPS reception, or if you want to display a different map, you can search for a lake using Lake List.
Lake List
APEX/SOLIX
1. Tap Chart in the status bar. Select Info.
OR
Press the ENTER key.
2. Select Lake List.
Sort By: Press the EXIT key to select the sort bar. Tap a column name, or move the Joystick and press it on a column name.
You can sort alphabetically, identify the high-definition lakes (Hi-Def) on your card, sort by state, etc.
Scroll: Use the Joystick to scroll through the list. As each lake is highlighted, you can view information about the lake in the
box displayed on the screen. Scroll faster using the Rotary dial.
Cursor To: Tap an item from the displayed list, or scroll to the item and press the ENTER key.
Selecting a Lake to Display
selected lake
Using ChartSelect

18Using ChartSelect
HELIX
1. Main Menu: Press the MENU key twice. Select the HB Chart tab.
2. Select Lake List.
3. Press the RIGHT Cursor key.
Sort By: Select the Sort By field, and press the RIGHT or LEFT Cursor keys to select a sort option for the list. You can sort alpha-
betically, identify the high-definition lakes (Hi-Def) on your card, etc.
Scroll: Press the UP or DOWN Cursor keys to scroll through the list. As each lake is highlighted, you can view information about
the lake in the box displayed on the screen.
Cursor To: Select a lake on the list. Press the RIGHT Cursor key.
Selecting a Lake to Display
selected lake
information about
the selected lake

19 Contact Humminbird
C H
Any questions relating to the product should be directed to our Help Center at
https://humminbird-help.johnsonoutdoors.com/hc/en-us or in writing to the address below:
Humminbird Service Department
678 Humminbird Lane
Eufaula AL 36027 USA
Social Media Resources:
Facebook.com/HumminbirdElectronics
Twitter.com (@humminbirdfish)
Instagram.com/humminbirdfishing
YouTube.com/humminbirdtv
