hygena AE6BSMP User manual

Built-in pyrolytic oven
Operating Instructions -Please keep for future reference
Important - Please read these instructions fully before using
These instructions contain important information which will help you get the best from your
appliance and help to ensure safe and correct installation, use and maintanence.
AE6BSMP
hygena
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 600 4632

Contents
Product code
1
Parts
Safety Information
Installation
Positioning
Cabinet cut-out sizes
Electrical connection
User instructions
Using the oven
Using the timer
Accessories
Cleaning and Maintenance
Cleaning and Maintenance
Transporting the oven
Trouble Shooting
Technical specifications
Guarantee
2
3-4
5-7
5
6
7
8-14
8-11
12-13
14
15
15
15
16
17
18
AE6BSMP
Customer Helpline 0845 600 4632

Parts
2
Please familiarise yourself with the parts and accessories listed below
1
2
3
4
5
6
7
8
1. Control panel
2. Oven door handle
3. Oven door
4. Oven light
5. Oven rack support
6. Fan cover
7. Grill pan and handle set
8. Oven rack
Accessories
Grill pan and handle set
If you have damaged or missing parts, call the Customer Helpline: 0845 600 4632

READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY
BEFORE USING YOUR APPLIANCE, AND KEEP IT IN A
CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY.
THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN
COMMON. YOUR APPLIANCE MAY NOT HAVE SOME OF THE
FEATURES THAT ARE EXPLAINED IN THIS MANUAL. PAY
ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES, WHILE
YOU ARE READING THE OPERATING MANUAL.
General Safety Warnings
-This appliance can be used by
children aged from 8 years and
above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
-WARNING: The appliance and
its accessible parts become hot
during use. Care should be
taken to avoid touching
heating elements. Children less
than 8 years of age shall be
kept away unless continuously
supervised.
-WARNING: Danger of fire: do
not store items on the cooking
surfaces.
-WARNING: If the surface is
cracked, switch off the
appliance to avoid the
possibility of electric shock.
-The appliance is not intended
to be operated by means of an
external timer or separate
remote-control system.
-During use, the appliance
becomes hot. Care should be
taken to avoid touching
heating elements inside the
oven.
-During use, handles held for
short periods in normal use
can get hot.
-Do not use harsh abrasive
cleaners or sharp metal
scrapers to clean the oven
door glass and other surface
since they can scratch the
surface, which may result in
shattering of the glass or
damage to the surface.
-Do not use steam cleaners for
cleaning the appliance.
WARNINGS

-WARNING: Ensure that the
appliance is switched off before
replacing the lamp to avoid the
possibility of electric shock.
-CAUTION: Accessible parts
may be hot when the cooking
or grilling is in use. Young
children should be kept away.
-Your appliance is produced in accordance with all applicable
local and international standards and regulations.
- Manintenance and repair work must be made only by
authorized service technicians. Installation and repair work that
is carried out by unauthorised technicians may endanger you. It
is dangerous to alter or modify the specifications of the
appliance in any way.
-Prior to installation, ensure that the local distribution
conditions (nature of the gas and gas pressure or electricity
voltage and frequency) and the requirements of the appliance
are compatible. The requirements for this appliance
are stated on the label.
-CAUTION: This appliance is designed only for cooking food and
is intended for indoor domestic household use only and should
not be used for any other purpose or in any other application,
such as for non-domestic use or in a commercial environment
or room heating.
-Do not try to lift or move the appliance by pulling the door
handle.
-All possible security measures have been taken to ensure your
safety. Since the glass may break, you should be careful while
cleaning to avoid scratching. Avoid hitting or knocking on the
glass with accessories.
-Ensure that the supply cord is not wedged during the
installation. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons in order to prevent a hazard.
-While the oven door is open, do not let children climb on the
door or sit on it.
Installation Warnings
-Do not operate the appliance before it is fully installed.
-The appliance must be installed by an authorized technician
and put into use. The producer is not responsible for any
damage that might be caused by defective placement and
installation by unauthorized people.
-When you unpack the appliance, make sure that it is not
damaged during transportation. In case of any defect; do not
use the appliance and contact a qualified service agent
immediately. As the materials used for packaging
(nylon, staplers, styrofoam...etc) may cause harmful effects to
children, they should be collected and removed immediately.
-Protect your appliance against atmospheric effects. Do not
expose it to effects such as sun, rain, snow etc.
-The surrounding materials of the appliance (cabinet) must be
able to withstand a temperature of min 100°C.
During usage
-When you first run your oven a certain smell will emanate
from the insulation materials and the heater elements. For this
reason, before using your oven, run it empty at maximum
temperature for 45 minutes. At the same time you need to
properly ventilate the environment in which the product is
installed.
-During usage, the outer and inner surfaces of the oven get hot.
While opening the oven door, step back to avoid the hot steam
coming out of the oven. There may be a risk of burns.
-Do not put flammable or combustible materials, in or near the
appliance when it is operating.
-Always use oven gloves to remove and replace food in the
oven.
-Do not leave the cooker while cooking with solid or liquid oils.
They may catch fire on condition of extreme heating. Never
pour water on to flames that are caused by oil. Cover the
saucepan or frypan with its cover in order to choke the flame
that has occured in this case and turn the cooker off.
-If you will not use the appliance for a long time, plug it off.
Keep the main control switch off. Also when you do not use the
appliance, keep the gas valve off.
-Make sure the appliance control knobs are always in the "0"
(stop) position when it is not used.
-The trays incline when pulled out. Be careful not to let hot
liquid spill over.
-When the door or drawer of the oven is open, do not leave
anything on it. You may unbalance your appliance or break the
cover.
-Do not put heavy things or flammable or ignitable goods
(nylon, plastic bag, paper, cloth...etc) into the drawer. This
includes cookware with plastic accessories (e.g. handles).
-Do not hang towels, dishcloths or clothes from the appliance
or its handles.
During cleaning and maintenance
-Always turn the appliance off before operations such as
cleaning or maintenance. You can do it after plugging the
appliance off or turning the main switches off.
-Do not remove the control knobs to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR
APPLIANCE, WE RECOMMEND YOU ALWAYS USE ORIGINAL
SPARE PARTS AND TO CALL ONLY OUR
AUTHORIZED SERVICE AGENTS IN CASE OF NEED.

5
We hope that this modern, functional oven,
which is made with quality parts and materials
will meet your cooking needs. Make sure you
read the manual to help to ensure successful
results and also to help prevent problems with
the appliance in the future. The information given
below contains important points that are
necessary for correct positioning and service
operations. They should be read without
exception especially by the technician who will
position the appliance.
3 - Furniture
The dimensions and material of
the cabinet in which the oven will be installed
must be appropriate and resistant to
increases in temperature.
5- In a correct installation, contact with
electrical or insulated parts must be
prevented. Insulating parts need to be fitted in
a way to ensure that they cannot be removed
by using any kind of tool.
6 -Installing the appliance in the close to a
refrigerator or a deep-freezer is not
recommended. Otherwise, the performance
of the above-mentioned appliances will be
negatively affected due to emanating heat.
IMPORTANT - Contact an authorised service
agent for installation of your oven.
Choosing a place for the oven
1- There are several points to pay attention to
when choosing a place for your oven. Make
sure to take into account our
recommendations below in order to prevent
any problems and dangerous situations,
which might occur later.
2 - When choosing a place for the oven,
attention should be paid to ensure that there
are no flammable or combustible materials in
close vicinity, such as curtains, oil, cloth etc.
surrounding the oven must be
made of materials resistant to temperatures
above 80 C°.
4 - Required changes to wall cabinets and
exhaust fans above the built-in combined
product as well as minimum heights from the
oven board are shown in Figure 1.
Accordingly, the exhaust fan should be at a
minimum height of 65 cm from the hob board.
If there is no exhaust fan the height should
not be less than 70 cm.
Figure 1
Installation Customer Helpline 0845 600 4632
Positioning

You can use either cabinet 1
or cabinet 2 cut-out sizes
A
B
600mm
Min 25mm
580mm
560mm
600mm
555mm
600mm
560mm
A DETAIL
20mm
Minimum 40mm(The wooden
part can be extended up
to cut-out depth)
Product sizes
B DETAIL
Countertop
Built-in oven
Min.25mm
Control
panel
Distance between
countertop and
control panel
Min. 50mm
Built-in hob
Distance between
countertop snd
top panel of built-in
oven
C DETAIL
Front
frame
Spacer
Mounting
screw
Wooden
part
Insert the oven into cabinet by pushing it forward. Open the oven door and insert 2 screws in the holes
located on the oven frame. While the product frame touches the wooden surface of cabinet, tighten the
screws.
Cabinet cut-out sizes
6
OPTION 1: Regular Installation OPTION 2: Flush Installation
C
555mm
555mm 570mm
570mm
595mm
595mm
Installation Customer Helpline 0845 600 4632

Figure 2
BLUE
BROWN
YELLOW+GREEN
Wiring and safety of the oven
In case of any damage to the
feeder cable, please call the Authorised
Service agent. The cable be replaced by
the Authorised Service agent.
The instructions given below must be followed
without fail during wiring :
IMPORTANT - The earthing cable must be
connected via the screw with the earthing
mark. Supply cable connection must be as
shown in Figure 2. If there is no earthed outlet
conforming to regulations in the installation
environment, call the Authorised Service
immediately.
IMPORTANT - The earthed outlet must be in
close vicinity of the appliance. Never use an
extension cord.
IMPORTANT - The supply cable should not
contact the products hot surface.
IMPORTANT -
must
IMPORTANT - Wiring of the appliance must
be performed by the Authorized Service agent.
H05VV-F type supply cable must be used.
IMPORTANT - Faulty wiring may damage the
appliance. Such damage will not be covered
under the warranty.
IMPORTANT - The appliance is designed to
connect to 220-240V~ electricty supply if your
household supply is different than the value
given above, call the Authorized Service
immediately.
IMPORTANT - The Manufacturer declares that
it bears no responsibility whatsover for any
kind of damage and loss arising from not
complying with these safety instructions.
7
Installation Customer Helpline 0845 600 4632
Electrical connection

User Instructions
Using the oven
8
Customer Helpline 0845 600 4632
1
7
2
8
3
910 11
45
12 13 14
6
1. Thermostat indicator light
2. Manual operation symbol
3. Minute minder symbol
4. Timer Display
5. Auto function symbol
6. Oven function indicator light
7. Thermostat control knob
8. Button 1 - Minute minder
9. Button 2 - Manual operation
10. Button 3 - End cook
11. Button 4 - Duration
12. Button 5 - Minus
13. Button 6 - Plus
14. Oven function control knob

Oven Function Control Knob:
Select the oven functions by turning the
control knob (Figure 3). You need to adjust the
function selection button and the oven
thermostat knob together to a temperature
value you wish to select-Otherwise the
function stage you selected will not operate.
Oven Thermostat Knob:
For you to select the oven function control
knob. When the temperature inside your oven
reaches the value you set, the thermostat will
cut the circuit and the thermostat light will go
off. When the temperature falls below the set
value, the thermostat will again be turned on
and the thermostat light will be on.
Defrost function
The oven lights will be turned on,
the fan starts operating.
To use the defrost function, take your frozen
food and place it in the oven on a shelf placed
in the third slot from the bottom. It is
recommended that you can place an oven
tray under the defrosting food, to catch the
water accumulated due to melting ice. This
function will not cook or bake your food, it will
only help to defrost it.
Turbo function
The oven lights will
be turned on, the ring heating element and
fan will start operating.
The turbo function evenly disperse the heat in
the oven. All foods on all racks will be cooked
evenly. It is recommended to pre-heat the
oven about 10 minutes.
Static cooking function
The oven lights will
be turned on, the lower and upper heating
elements will start operating.
Oven functions
's warning
's thermostat and warning
's thermostat and warning
Figure 3
Figure 4
Figure 5
9
Customer Helpline 0845 600 4632
User Instructions

The static cooking function emits heat,
ensuring even cooking of the lower and upper
food. This is ideal for making pastries, cakes,
baked pasta, lasagne and pizza. Prehating the
oven for 10 minutes is recommended and it is
best to cook on only one shelf at a time in this
function.
Fan function
The oven lights will
be turned on, the upper and lower heating
elements and fan will start operating.
This function is very good for obtaining results
in baking pastry. Cooking is carried out by the
lower and upper heating element within the
oven and by the fan providing air circulation,
which will give a slight grill effect to the food.
It is recommended to pre-heat the oven about
10 minutes.
Grilling function
The oven lights will
be turned on, the grill heating element will
start operating.
The function is used for grilling and toasting
foods, use the upper shelves of oven. Lightly
brush the wire grid with oil to stop foods
sticking and place foods in the center of the
grid. Always place a tray beneath to catch any
drips of oil or fat. It is recommended to pre-
heat the oven about 10 minutes.
WARNING - When grilling, the oven door must
be closed and the oven temperature should
0
be adjusted to 200 C.
Faster grilling function
The oven lights will
be turned on, the grill and upper heating
elements will start operating.
The function is used for faster grilling and for
covering a larger surface area, such as grilling
meats, use the upper shelves of oven. Lightly
brush the wire grid with oil to stop foods
sticking and place foods in the center of the
grid. Always place a tray beneath to catch any
drips of oil or fat. It is recommended to pre-
heat the oven about 10 minutes.
WARNING - When grilling, the oven door must
be closed and the oven temperature should
0
be adjusted to 200 C.
's thermostat and warning
's thermostat and warning
's thermostat and warning
Double grill and Fan function
The oven lights will
be turned on, the grill and upper heating
elements and fan will start operating.
The function is used for faster grilling of
thicker foods and for covering a larger surface
area. Both the upper heating elements and
grill will be energised along with the fan to
ensure even cooking.
Use the upper shelves of oven. Lightly brush
the wire grid with oil to stop foods sticking
and place foods in the center of the grid.
Always place a tray beneath to catch any
drips of oil or fat. It is recommended to pre-
heat the oven about 10 minutes.
WARNING - When grilling, the oven door must
be closed and the oven temperature should
0
be adjusted to 200 C.
Pyrolytic cleaning function
This function allows you to clean throughly the
oven cavity.
WARNING - Before activating pyrolytic
cleaning function, remove any excessive
spillage and make sure that the oven is empty.
Do not leave anything inside the oven cavity
(e.g. wire grids, shallow tray, deep tray etc. )
As this could heavily damage them.
WARNING - Before activating the pyrolytic
cleaning function, remove the wire oven
shelves and shelf supports (if available).
WARNING - Ensure that the oven door closed
before activating the pyrolytic cleaning
function.
WARNING - The oven door will be locked
when the pyrolytic function started.
WARNING - When the pyrolytic cleaning
function is on, it is advisable not to use a hob
if it is fitted above the oven. This could cause
overheating and damage to both appliances.
WARNING - During the pyrolytic cleaning
cycle the oven door becomes hot. Children
should be kept away until it has cooled.
WARNING - At the end of pyrolytic cleaning
process, the display shows the time of day.
's thermostat and warning
10
Customer Helpline 0845 600 4632
User Instructions

Pyrolytic Cleaning
1 - The oven cavity is coated with a special
emanel resistant to high temperatures.
2 - During the pyrolytic cleaning operation,
the temperature inside the oven can reach
0
about 475 C does burning food residuals.
For your security, during the pyrolytic
cleaning operation, the oven door
automaticly locks.
3 - Upon completion of the cleaning
operation the oven door will be locked
until the oven cavity has cooled down.
4 - The cooling fan operates until the oven
has cooled down. After cooking, it is
advisable to remove all the food residues
with a wet sponge.
5 - It is advisable to wipe the oven over with a
sponge soaked in warm water after each
pyrolytic cleaning cycle is carried out.
6 - During the Pyrolytic operation, some smell
and fume will be emanated due to
destruction of the food residual, it is
normal. Oven cleaning fumes could be
fatal to birds and disturb especially
childrens and pets, so all should be
moved into the other room until it was
finished. During the Pyrolytic operation,
the room where the oven installed must
be ventilated sufficiently and the kitchen
door should be closed to avoid passing
smell and fume to other rooms..
11
Customer Helpline 0845 600 4632
User Instructions

Use the thermostat control knob to set the
temperature that you require.The manual
operation symbol will appear on the display.
Use the oven function knob to select the mode
of cooking that you require.
It is then possible to set the duration of the
cooking time that you require.
Press the button 4 and the display will show a
value of 00:00. Set the period of time that you
wish the duration function to countdown for, by
using the button 5 and 6.
Once the display has got to your desired
countdown time, let go of the button 5 and 6.
The countdown will start immediately an the
word A will appear on the time display.
Once a countdown time has been set, it is
possible to shorten or lengthen the time by
using the button 5 or 6.
An alarm will sound when the countdown time
has elapsed and the oven will switch off. The
word A will flash and the heating symbol will
disappear.
To silence the audible signal and return the
oven to manual operation mode. You should
press the button 2, the word A will disappear
from the display and the manual operation
symbol will appear instead.
IMPORTANT - If you do not turn the thermostat
control and oven function knob to 0. Then the
appliance will continue to operate as soon as
you press the button 2.
Setting the end cook function
This function is similar to the duration function,
however instead of selecting a period of time
that you wish the oven to switch off. You select
the time of day that you wish the oven switch
off.
Use the thermostat control knob to set the
temperature that you require.The manual
operation symbol will appear on the display.
Use the oven cooking function knob to select
the mode of cooking that you require.
Press the button 3 and the display will show a
value of 00:00. Set time of day that you wish
the oven to stop cooking by using the button 5
and 6. The timer will calculate how long the
cooking time will be, based on the time of day
After your appliance is connected to your
mains supply for the first time, the numbers on
the timer display will flash. Before you can
select a cooking function or set a temperature,
you must set the appliance into “manual
operation” mode.
To select manual operation mode, press the
button 2 on the control panel.
Setting the time of day
After setting your oven for manual
operation,you should also set the time of day.
Use the button 5 and 6 to adjust the time that
appears in the display.
After setting the display to the correct time,
release the button 5 and 6. After 5 seconds the
time will fix in the display you will be able to
use your oven.
Setting the minute minder function
You are able to set the minute minder at any
time, regardless of whether an oven function
has been selected. You can set a period of
time using the minute minder function and an
alarm will sound when this period of time has
elapsed.
Press the button 1, the display will show a
value of 00:00. Set the period of time that you
wish the minute minder to countdown for, by
using the button 5 and 6.
Once the display has got to your desired
countdown time, let go of the button 5 and 6.
The minute minder symbol will appear on the
time display.
Once a countdown time has been set, it is
possible to shorten or lengthen the time by
using the button 5 and 6.
An alarm will sound when the countdown time
has elapsed. The alarm can be silenced by
pressing the button 1 or 2.
Setting the duration function
This function will allow you to set a countdown
time similar to the minute minder function.
However the oven will no longer continue to
heat,once the countdown period has elapsed.
12
Using the timer
Customer Helpline 0845 600 4632
User Instructions

that you have selected and show it on the
display.
Once the display has got to the time of day that
you want the oven to stop cooking, let go of the
button 5 and 6. The countdown will start
immediately and the word A will appear on the
timer display.
When the time is set,it can be modified by
pressing the button 5 and 6.
When the time of day reaches the end of
cooking time that you set, the oven will switch
off and an alarm will sound. The word A will
flash and the heating symbol will disappear.
To silence the audible signal and return the oven
to manual operation mode, you should press
the button 2, the word A will disappear from the
display and the manual operation symbol will
appear instead.
Setting the start and end time function
This function will allow you to set a time in the
future that the oven switches on and a time that
the oven will switch off.
Use the thermostat control knob to set the
temperature that you require. The manual
operation symbol will appear on the display.
Use the oven function knob to select the mode
of cooking that you require.
Press the button 4 and the display will show a
value of 00:00. Set the period of time that you
wish to cook for, by using the button 5 and 6.
The word A will appear on the timer display.
Immediately press the button 3 and the timer
display will show the value 00:00. Set the time
of day that you want the oven switch off at,
using the button 5 and 6.
The oven will calculate what time it needs to
switch on, so that your food will cook for the
length of time that you selected. It will
automaticly switch itself on, once it reaches the
time of day that it has calculated.
When the time of day reaches the end cooking
time that you set, the oven will switch off and an
alarm will sound. The word A will flash and the
heating symbol will disappear.
To silence the audible signal and return the oven
to manual operation mode, you should press
the button 2, the word A will disappear from the
display and the manual operation symbol will
appear instead.
Adjusting the audible signal
To adjust the level of the audible signal, when it
is sounding, press the button 5 and it will adjust
through the 3 sound levels. Release the button
5 and the sound level of the audible signal will
be set.
13
Customer Helpline 0845 600 4632
User Instructions

You can use other cooking utensils, but they must
be heat and flame resistant. You can also use
glass dishes, cake molds, special oven trays that
are appropriate for use in oven. Pay attention to
the using instructions by the manufacturer of
those accessories.
In case small size dishes are used, place the dish
onto the chrome grid, it will completely be on the
middle part of the grid.
Do not leave an oven tray or dish in a cold
environment right after cooking. Do not put onto
cold and wet surfaces. Place on a dry kitchen
cloth or dish cross, ensure it to cools slowly,
otherwise the glass tray or dish may be broken.
If you will grill in your oven; we recommend you
use the grill that was given in the tray provided (If
your product includes this material). If you use the
big wire grill; put a tray onto one of the lower
shelves for oils to be collected. Also put some
water into it for ease of cleaning.
Using the grill pan and handle set
WARNING - Always use an oven glove to protect
your hand when using the grill as all the metal
parts can become very hot!
The grill pan has a detachable handle. Ensure
when using the grill pan handle that it is
centralized and secure as shown in the figure.
Do not leave the handle in position when grilling.
If the handle is left in position when grilling, it will
get very hot.
14
Customer Helpline 0845 600 4632
User Instructions
Accessories
Figure 6
WARNING- Fit the
grid correctly into
any correspondent
rack in the oven
cavity and push it to
the end.

Cleaning
Before starting to clean your oven, be sure that
all control buttons are off and your appliance
has cooled. Unplug the appliance.
Do not use cleaning materials containing
particles that might scratch the enamelled and
painted parts of your oven. Use cream
cleaners or liquid cleaners, which do not
contain particles. As they might harm the
surfaces, do not use caustic creams, abrasive
cleaning powders, rough wire wool or hard
tools. In the event the excess liquids spilling
over your oven should burn, it may cause a
damage to the enamel. Immediately clean up
the split liquids. Do not use steam cleaners for
cleaning the oven.
Cleaning the interior of the oven
Make sure to unplug the oven before starting
to clean it. You will obtain best results if you
clean the oven interior while the oven is slightly
warm. Wipe your oven with a soft piece of
cloth dampened with soap water after each
use. Then wipe it again, this time with a wetted
cloth, and wipe it dry. A complete clean using
dry and powder type cleaners. For product
with catalytic enamel frames, the rear and side
walls of the inner frame do not require
cleaning. However; depending on usage, it is
recommended that you replace them after a
certain period of time.
The door seal may be cleaned using a sponge
that has been soaked in lukewarm water. Do
not use abrasive cleaners and do not crumble
the seal.
Check the door seals around the oven
periodically. If the seals are damaged, please
contact your nearest Technical Service Center,
to get a replacement seal helpline number
0845 600 4632.
Maintenance
Replacing the Oven Light
It is recommended that you leave this
operation to the Authorized Service agent.
Unplug the oven first and make sure that it is
cold. After removing the lid in front of the light,
take the bulb of its place. Insert the new bulb
resistant to 300ºC, which you will find at
Authorized Services, into the place of the
bulb(230V, 25W, Type E14) you have
removed. Then fit the light protecting glass
back into its place. After that, your oven will
be ready for use.
If you need to transport your oven, keep the
original case of product and carry in its
original case when needed to be carried.
Follow the transport signs on case. Tape the
oven to the cooking panel. Place a paper
between on the oven door, then tape it to the
side surfaces of oven. Tape cardboard or
paper onto the front cover on interior glass of
oven as it will be suitable to the tray. If it does
not have the original case; prepare a carriage
box so that the appliance, especially external
surfaces (glass and painted surfaces) of oven
is protected against external forces.
Transporting the oven
15
Cleaning and Maintenance Customer Helpline 0845 600 4632
Cleaning & Maintenance

Trouble Shooting Customer Helpline 0845 600 4632
Problem Possible cause Solution
- Oven does not turn on. - Power is turned off.
- Timer has not adjusted to the
day of time.
- Make sure tthe electrical
- Adjust the timer.
connections are operational and
switches are set to the open/
on positions.
No heat or oven does not
warm up.
- Oven temperature control is
incorrectly set.
- Oven door has been left open.
- Check the oven temperature control
knob is set correctly.
- Make sure oven door is closed.
Avoid opening frequently during cooking.
Oven light does not operate. - Lamp has failed.
- Electrical supply is
disconnected or switched off.
- Replace lamp according to the
instructions on page 12.
- Make sure the electrical supply is turned
on at wall socket outlet.
Cooking is uneven within
the oven.
- Oven shelves are incorrectly
positioned.
- Position the shelves towards the top or
bottom of the oven following cooking
guidelines. The top of the oven will be
hotter than the bottom.
Important If problems persist call an
authorised installation engineer or the
customer helpline on 0845 600 4632.
Basic troubleshooting before contacting service
16

Technical Specifications
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product. For
more detailed information about recycling of this
product, please contact your local city office,
your household waste disposal service or the
shop where you purchased the product.
The symbol on the product or
on its packaging indicates that
this product may not be treated
as household waste. Instead it
shall be handed over to the
applicable collection point for
the recycling of electrical and
electronic equipment.
Disposal information
We apologise for any inconvenience caused by any minor inconsistencies in these
instructions , which may occur as a result of product improvements and
development.
52098132 01/11 R000
Model/Item
Power supply
Maximum power
Size(H x W x D)
Electric Cooker energy rating
Energy Comsumption according
to the EN50304
Oven Volume
Net weight
Cut-Out Dimensions(H xW x D)
(230)V~/50 Hz
3200 W
595x595x570 mm
600x600x580 mm
56 lt.
37.5 kg.
AE6BSMP
A
0.89 / 0.79
Customer Helpline 0845 600 4632
17

52093022 01/13
