Hyperkin SUPABOY S User manual

INSTRUCTION MANUAL
To view this manual in French, Spanish,
or Japanese, please go to:
www.hyperkin.com/product-manuals
You can also scan
this QR code to
view the manual:

TABLE OF CONTENTS
Table of Contents ..... 2
Package Contents ..... 5
SupaBoy S Layout ..... 6
Charging the Battery ..... 7
Volume, Headphones, & Brightness ..... 8
Playing Games / Reset a Game ..... 9
Using Controllers ..... 10
Outputting to TV ..... 11
TABLE DES MATIÈRES
Avertissement ..... 2
Contenu de l’emballage ..... 14
Présentation de la console SupaBoy S ..... 15
Recharge de la batterie ..... 16
Volume, Casque et Luminosité ..... 17
Utilisation / Réinitialisation d’un jeu ..... 18
Utilisation de manettes ..... 19
Connexion à un écran de télévision ..... 20
2

TABLA DE CONTENIDO
Tabla de Contenido ..... 2
Contenido del Paquete ..... 22
Sistema SupaBoy S ..... 23
Para cargar la Batería ..... 24
Audifonos, Volumen y Brillo ..... 25
Jugando Juegos / Para restablecer un Juego ..... 26
Usando los Controles ..... 27
Salida a TV ..... 28
3

4
Important Health Warning About Playing Video Games
A very small percentage of people may experience a seizure when exposed to certain visual images,
including ashing lights or patterns that may appear in video games.Even people who have no history
of seizures or epilepsy may have an undiagnosed condition that can cause these “photosensitive
epileptic seizures” while watching video games.
These seizures may have a variety of symptoms, including lightheadedness, altered vision, eye
or face twitching, jerking or shaking of arms or legs, disorientation, confusion, or momentary
loss of awareness. Seizures may also cause loss of consciousness or convulsions that can lead to
injury from falling down or striking nearby objects.
Immediately stop playing and consult a doctor if you experience any of these symptoms. Parents
should watch for or ask their children about the above symptoms – children and teenagers are more
likely than adults to experience these seizures. The risk of photosensitive epileptic seizures may be
reduce by taking the following precautions: sit farther from the screen, use a smaller screen, play
in a well-lit room, and do not play when you are drowsy or fatigued.
If you or any of your relatives have a history of seizures or epilepsy, consult a doctor before playing.

PACKAGE CONTENTS
5
SupaBoy S System
Micro USB Charge Cable
Pocket Pouch
AV Cable
Wrist Strap

SUPABOY S LAYOUT
6
On/Off Switch AV Out
Start ButtonSelect Button
Reset ButtonLED Indicator
Micro USB
Charge Port
Directional Pad Controller Port 1
Headphone Jack
Battery Cover
Volume Control
Brightness Button
Wrist Strap Attachment
NTSC/PAL Switch
Controller Port 2
Left Bumper Button
Right Bumper Button
Cartridge Slot
LCD Screen
Speakers
A, B, X, Y Buttons

CHARGING THE BATTERY
7
PC/MAC USB PORT or
USB AC ADAPTER
Attach the MICRO USB CHARGE CABLE to the SupaBoy S, located on the top of the SupaBoy S
System. Make sure the other end of the cable is connected to a power source (PC/MAC USB port
or USB AC adapter). The LED INDICATOR on the top of the SupaBoy S System will light up RED,
indicating that the SupaBoy S is charging. LED INDICATOR will light up GREEN when the SupaBoy S
is fully charged.
USER SAFETY PRECAUTIONS
• Do not expose SupaBoy S to direct sunlight or extreme temperatures for extended periods of time.
• Please store SupaBoy S at room temperature, which is between 40°F and 80°F.
• When transporting or temporarily storing in a vehicle, temperature should not exceed 150° or
fall below 20°F.
• Storing SupaBoy S at temperatures greater than 170° for extended periods of time may cause
damage to the battery, overheat the device, or cause potential re.
Observe signs of overheating from overcharging. Stop usage or charging if you detect swelling,
smoke, or high temperatures and dispose of the battery pack safely and away from ammable
materials.
MICRO USB CHARGE CABLE

HEADPHONES, VOLUME, & BRIGHTNESS
8
SUPABOY S BOTTOM
To adjust the volume of the SupaBoy S:
1. On the bottom of the SupaBoy S system,
there is a scrolling VOLUME CONTROL dial.
To raise the volume, scroll the VOLUME
CONTROL to the right; to lower the volume,
scroll the VOLUME CONTROL to the left.
To use headphones with the SupaBoy S:
1. Insert headphones into the HEADPHONE JACK
located on the bottom of the SupaBoy S system.
2. Use the VOLUME CONTROL on the bottom of the
SupaBoy S system to adjust volume levels.
To adjust the screen brightness:
Located on the bottom of the SupaBoy S is a BRIGHTNESS
BUTTON. Pushing it allows you to cycle through 5 different
brightness settings, including turning the screen OFF (useful
for conserving battery during AV OUT mode).

PLAYING GAMES
RESET A GAME
9
1. Insert the game cartridge (label side facing towards yourself) into the CARTRIDGE
SLOT, found on the top of the SupaBoy S.
2. Turn the ON/OFF switch to the ON position.
* If the game cartridge is a PAL game, be sure to adjust the NTSC/PAL switch to PAL
before turning the console ON.
The SupaBoy S is able to play NTSC SNES/Super Famicom and PAL SNES Cartridges.
To reset a game, press the RESET button located on the top of the SupaBoy S above the screen.
To adjust the volume of the SupaBoy S:
1. On the bottom of the SupaBoy S system,
there is a scrolling VOLUME CONTROL dial.
To raise the volume, scroll the VOLUME
CONTROL to the right; to lower the volume,
scroll the VOLUME CONTROL to the left.

USING CONTROLLERS
10
To play games using the controller ports of the SupaBoy S:
1. Insert a controller into CONTROLLER PORT 1.
2. To play with two controllers with the SupaBoy S, insert a controller into CONTROLLER PORT 1,
then insert the other controller into CONTROLLER PORT 2.
Note: This can be done while the SupaBoy S is ON or OFF. Also, when the controller is plugged into
Controller 1, the DIRECTIONAL PAD and the face buttons on the SupaBoy S system will be disabled
until the controller is unplugged from CONTROLLER PORT 1.
CONTROLLER 1 CONTROLLER 2
