Wico Command Control User manual

INSTALLATION INSTRUCTIONS FOR
COMPUTER COMMAND
ANALOG JOYSTICKS
IBM* COMPUTER
Analog Joystick for IBM® Personal Computer
CONNECTION: To connect the WICO Computer Command IBM® analog
joystick, simply plug the analog joystick cord into the WICO interface
card port (or similar analog controller card) located on rear panel of the
IBM® System Unit. For installation of WICO Interface Card (or similar
analog controller card) see appropriate card installation instructions.
Your joystick is now ready for operation.
APPLE* COMPUTER
Analog Joystick for Apple® II, lie and II Plus Home Computers
CONNECTION: To connect the WICO Computer Command Apple® analog
joystick, first remove the Apple® computer cover. Next, carefully insert
the joystick plug into the 16- pin game I/O port and run the connector
cord through the slot provided on the rear of the Apple® unit, as shown in
diagram. Then replace the computer cover, and your joystick is ready
for operation.
HANDLE
RADIO SHACK* COMPUTER
RIGHT LEFT
TRIM
CONTROL
Analog Joystick for Radio Shack® TRS80® Color Computer
CONNECTION: To connect the WICO Computer Command Radio Shack®
analog joystick, simply plug the computer connection plug directly into
the Color Computer joystick panel input. Your joystick is now ready
for operation.
NOTE: If only one joystick is to be used, connect joystick to the right
joystick input.
All WICO Computer Command analog joysticks are designed with Spring
Return /Free Positioningmodes.The joystick handle can be set to center
automatically (Spring Return) or "float free" (Free Positioning) by using
the mode selection switches on the bottom of the unit (see installation
diagrams). Mode selection must be done onlywhen the joystick is in the
center position -unit damagemayotherwise result.
OPERATION: To assure directional accuracy, always position your
Computer Command analog joystick with the word "TOP" facing away
from you. With the unit properly positioned, 360 degree movement and
variable speed control is provided by moving the joystick handle.
All WICO Computer Command analog joysticks are designed with linear
trim controls for each axis (see X, Yas molded on control base). Linear
'iwr\ controls allow user to adjust cursor position for most efficient use of
ring Return mode. By sliding either or both trim controls, joystick
center position and corresponding screen position can be easily adjusted.
FIRE/FUNCTION BUTTONS: All WICO Computer Command analog
joysticks provide either one or two fire/function buttons (Apple® and
IBM® models feature two independently operating buttons; Radio Shack®
model features one button) located at unit's left-hand side, on top of
base. Fire/function buttons are completely software compatible and
can be used for any application depending on program design.

MEET THE ENTIRE
COMMAND CONTROL LINE
Any one makes aperfect gift.
WICO makes the controls for more than 500 different arcade video game...
Arcade owners demand the most durable, most accurate, fastest controls
money can buy. That's what WICO delivers. And now, WICO brings the same
high quality and high scores to your home video system.
•Superior control.
•Pinpoint firing accuracy.
Incredible durability.
•Full 5-foot cord for ease
of movement.
The COMMAND CONTROL joysticks
•Injection-molded modular construction and 6leaf-type molded switches
-just like WICO's commercial arcade models.
•Two fire button locations, activated by abase-mounted slide switch.
•Work directly with the Atari® 2600™ Sears Arcade Game, Atari* 400™ 600™
800™ and 1200™ Home Computers, and the Commodore 64™ and VIC-20™
Home Computers.
Joystick 15-9714
Extra-long arcade-style bat handle grip that moves smoothly
and easily into all 8standard positions.
Famous Red Ball™ Joystick 15-9730
*Arcade-type red ball handle that moves smoothly and easily
into all 8standard positions.
Power Grip™ Joystick 50-2020
•Ergonomically-engineered grip handle designed to fit bofl-
the hand and mind, and to lessen hand fatigue.
:^f
t-7-"
"<' if?
/'^-lip Three-Way Deluxe Joystick 50-2010
A^*Your choice of three different ergonomic handles to change
^~St as easi,v as vou chan9evideo games.
The COMMAND CONTROL joystick/ keypads
•Arcade-size joystick handle.
•Rubber diaphragm module delivers arcade action and feel.
Keypad is 12-key button cluster with tactile feedback switches.
•Fire buttons on handle and each side of keypad base.
Three different models available:
•ColecoVision™ model -50-0299
•Intellivision™ Imodel -50-0300
•Intellivision™ II model-50-0298
The COMMAND CONTROL Atari® 5200™
analog joystick 50-1043
Designed specifically for the Atari® 5200™
•Dual heavy-duty potentiometers for full 360 degree movement
and speed control of on-screen objects.
•Arcade-size handle features spring return/free position-
ing option.
•Two leaf-switch activated fire buttons.
•Includes Y-cord for use with original Atari® 5200™ controller.
•Externally mounted trim controls.
The COMMAND CONTROL trackballs
**-_ -•Injection-molded modular construction.
c_3 j.phenolic ball provides unique 360 degree movement to an
'\_ --- sinfinite number of positions and varies the speed of on-
screen objects.
•Quick-action fire button (s) next to the ball, for smooth, two-handed control.
•Three different models available:
•Atarif Sears and Commodore model -72-4545
•Texas Instruments model -72-4560
•Odyssey® Video Game model -72-4555
The COMMAND CONTROL adaptors
•Make Command Control and THE BOSS™ switch-type
joysticks (except ColecoVision™/lntellivision™ models) work
with up to 13 different home video games and computers.
•Three different models available:
•Texas Instruments Home Computer-72-4530
•Apple® II, lie, II Plus Home Computers*-72-4525
•Odyssey® Home Video Game
(plug-in controls) -72-4540
The COMMAND CONTROL extension cords
•For use with all Command Control joysticks, adaptors and trackballs (except
the WICO Joystick/Keypad for Intellivision™ I).
•Two lengths available: 6' length-15-1755 •12' length-15-1756

MEET THE ENTIRE
COMPUTER COMMAND™ LINE
Any one makes aperfect gift.
Over 500 different arcade video games use WICO controls. ..trie
most durable, most accurate, fastest controls money can buy. That
kind of quality has never been available for home computers. Now,
WICO Computer Command is the first complete line of controls built
to match wits with today's sophisticated computer software.
•Fast, ultra-smooth movement.
•Instantaneous stopping power.
•Arcade-strong construction.
•Full 5-foot cord for ease
of movement.
The COMPUTER COMMAND analog joysticks
Designed specifically for today's most popular com-
puter software.
•Dual heavy-duty potentiometers for full 360 degree
movement and speed control of on-screen objects.
•Handle can spring back to center or float freely.
•Big, arcade-size grip.
•Trim controls mounted outside for easy adjustment.
•Responsive leaf-switch activated fire button(s) on base.
•Three different models available:
•IBM® Personal Computer model-50-0110
(Requires WICO IBM® Interface Card-
50-2070-or similar analog controller card)
•Apple® II, He, II Plus Home Computer model-
50-1030
•Radio Shack® TRS80® Color Computer model
-
50-1010
The COMPUTER COMMAND trackballs
Designed specifically for this year's most popular
computers.
'Phenolic ball provides 360 degree movement to <»..
infinite number of positions and varies the speed of
on-screen objects.
»Features an optical encoder design.
•Quick-action fire button(s) next to the ball for smooth,
two-handed control.
•Three different models available:
•Apple® II, II Plus Home Computer model-72-4521
(Requires WICO Apple® PCI Controller Card
model-50-2071)
•Radio Shack® TRS80® Color Computer
model-72-4550
•IBM® Personal Computer model -50-2090
(Requires WICO IBM® Interface Card-50-2070)
The COMPUTER COMMAND Mouse
•An optically-encoded mechanical cursor control that
simplifies word processing, spreadsheets, programs,
graphics and games.
•Three function buttons provide awide range of pro-
gram applications and allow more work options to be
exercised without accessing the keyboard.
•Two models available:
•Apple® II and II Plus Home Computer model
-
50-2110 (Requires WICO Apple® PCI
Controller Card)
•IBM® Personal Computer model-50-2111
(Requires WICO IBM® Interface Card-50-2070
to be used with RS-232 Mouse software)
The COMPUTER COMMAND Interface Cards
•IBM® model 50-2070
•Can be used with WICO IBM00 Mouse, trackball
and analog joystick.
•RS-232C compatible serial port.
Apple® PCI model 50-2071
•Can be used with WICO Apple® Mouse and track-
ball and any Command Control or THE BOSS
switch -type joystick. Does not interfere with any
normal use of WICO Computer Command analog
joysticks or similar analog joystick.
•Allows Apple® II and II Plus owners complete
software compatibility for programs such as word
processing, electronic spreadsheets, games or
any other programs.
•Gives trackball control for Apple® programs using
keyboard or controllers for directional information.
•Eliminates complicated keystroke sequences for
cursor control.

THE BOSS™ Joystick model 50-2030
Starting today, you're the boss. You play to win. And you do. The
reason? THE BOSS is precision-engineered to do what no joystick
has ever done. It has amind like acomputer -and the guts to
match. You and THE BOSS can boss any game around.
•Heavy-duty PC. Board and sensitive leaf-switches provide instant
contact for superb accuracy and speed.
•No-slip grip gives hours of comfortable play.
•Thermo-molded base and heavy duty components take your
toughest punishment.
•Split- second reaction time for unmatched accuracy.
•Works directly with the Atari w2600™ Atari® 400™ 600™ 800™
and 1200™ Home Computers, Sears Arcade Game, and the
Commodore 64™ and VIC-20™ Computer Systems.
•With appropriate WICO Command Control adaptors, will work with
Texas Instruments Home Computers, ApplewII, lie, II Plus Home
Computersr and Odyssey® Video Games.
