Hyundai power products HYEA5200X User manual

EARTH AUGER
HYEA5200X
Instruction Manual

Introduction
Thank You For Purchasing Your HYUNDAI Product
We work very hard to give all of our customers the best possible service. If you have any
problems, before leaving negative feedback, please contact us to give us a chance to resolve
the issue. We would be delighted if you left us positive feedback! Thank you for purchasing this
product.
Important!
This manual has been produced by Hyundai Power Products and should be kept with the
product. Please read and understand these instructions before you use your product. Failure to
do this may result in personal injury or damage to the product.
The safety precautions and warnings are to ensure your safety and protect you from harm or
damage to the product.
The information contained in this manual was accurate at the time of production, however
HYUNDAI Power Products may make modifications to the product without notification.
WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if the machine is
loaned or sold to another user.
!

Contents
Maintenance And Care..........................................25-32
Safety...............................................................25
Maintenance Schedule....................................26
Checking Your Machine..................................27
Repairs.............................................................27
Cleaning...........................................................27
Spark Plug.......................................................28
Cleaning & Replacing Air Filter........................29
Gear Box.........................................................29
Replacing Fuel Filter.......................................30
Storage.......................................................30-31
AfterStorage....................................................31
Transportation And Handling..........................31
Recycling And Disposal...................................32
Environmental Protection................................32
Spare Parts..................................................................33
Our Product Range......................................................34
Useful Information.......................................................35
Our YouTube Channel.....................................35
Warranty..........................................................35
Manual Updates..............................................35
Returning Your Product...................................35
Leaving A Review............................................35
Ordering Spare Parts......................................35
Notes.......................................................................36-37
Contact Us...................................................................38
Declaration Of Conformity...........................................39
Features.........................................................................4
What’s In The Box.........................................................4
Symbols On The Machine.............................................5
General Safety..........................................................6-16
Understand Your Machine.................................6
Personal Safety..............................................6-7
Inspect Your Machine....................................7-8
Engine Safety.....................................................8
Work Area..........................................................9
During Use...................................................9-11
Remaining Risks..............................................11
Avoid Skin And Eye Contact............................11
Carbon Monoxide............................................12
General Fuel Safety....................................12-13
Electrical Safety...............................................14
Batteries...........................................................14
Vibrations....................................................14-15
Noise................................................................15
Intended Use...................................................15
Personal Protective Equipment.......................16
Getting Started.............................................................17
Assembly Safety..............................................17
Unboxing.........................................................17
Assembly......................................................................18
Preparation...................................................................19
Mixing 2-Stroke Oil..........................................19
StartingProcedure..................................................20-21
Stopping Procedure.....................................................22
Troubleshooting...........................................................23
Specifications..............................................................24

Features
• Earth Auger
• 100mm, 150mm, 200mm Drill Attachments
• User manual
• Tools
• Mixing Bottle
What’s In The Box
4
1 - Fuel Tank
2 - Right Handle
3 - Locking Pin
4 - Drill
5 - Starter Cord
6 - 2-Stroke Engine
7 - Left Handle
8 - Handle Bar
9 - Transmission
10 - Mixing Tank
11 - Tools

5
CAUTION!
Handle carefully.
INSTRUCTION MANUAL
Read and understand
operator’s manual before using
the machine. Failure to follow
instructions could result in
death or serious injury.
Symbols On The Machine
CE SYMBOL
This product complies with
the applicable European
directives and an evaluation
method of conformity for
these directives was done.
HAND PROTECTION MUST
BE WORN
Protective gloves are highly
recommended when working.
FOOT PROTECTION MUST
BE WORN
Non-skid heavy duty footwear
is highly recommended when
working.
HEARING PROTECTION
MUST BE WORN
Suitable safety hearing
protection is recommended.
We have provided safety messages in this manual and on the lawnmower. This information
alerts you to potential hazards that could hurt you or others. Please read these messages
carefully. However, we may not have listed all of the possible hazards, you must also use your
own judgment.
DANGER!
Keep feet away from drilling
area.
DANGER!
Do not drill near underground
cables or pipes.
DANGER!
Keep away from fire and do not
smoke near this machine.
DO NOT SMOKE
Do not smoke, stay away from
sparks, open flames, or other
sources of ignition.

General Safety
6
WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if the machine
is loaned or sold to another user.
!
•WARNING! You must read these
instructions carefully before operating the
machine. Make sure that you are familiar with
the controls and properly operate the
machine. You must learn how to stop the
machine quickly. If you do not follow the
warnings and instructions, it may result in fire
and/or serious injury. Make sure to save all
warnings and instructions for future reference.
• Read this manual and labels affixed to the
machine to understand its limitations and
potential hazards.
• Be thoroughly familiar with the controls and
their proper operation. Know how to stop the
machine and disengage the controls quickly.
• If the unit is to be used by someone other
than original purchaser, or is to be loaned,
rented, or sold, always provide this manual
and any needed safety training before
operation. The user can prevent and is
responsible for accidents or injuries that may
occur to themselves, to other people, or to
property.
• Do not force the machine beyond its limits.
Use the correct machine for your application.
• Know how to stop the engine quickly in
case of emergency. Understand the use of all
controls.
• ALL MAINTENANCE other than that listed in
this manual, should be carried out by
professionally trained and certified personnel.
• You must pass on safety notices to anyone
working with the machine. They must read the
manual before starting work. All safety and
hazard notices must be observed.
• WARNING! Never allow children or people
unfamiliar with these instructions to use the
product. Local regulations can restrict the
minimum age of the operator.
• Keep children, pets, and other people not
using the unit at least 23m (75 feet) away from
the work area. Be alert and shut off the unit if
anyone enters work area. Keep children under
the watchful care of a responsible adult. If you
are approached, stop the unit immediately.
• Stay alert, watch what you are doing and
use common sense when operating the
machine. Never operate the machine when
unwell or tired, or if you have taken alcohol,
medicine, drugs or any substances which may
slow your reflexes and compromise
judgement. A moment of inattention while
operating the machine may result in serious
personal injury.
• Appropriate Personal Protective Equipment
(PPE), MUST be worn at all times when
operating or repairing the machine. Always
wear anti-slip and resistant work footwear and
long trousers while using the machine. Do not
use the machine when barefoot, wearing
sandals or similar lightweight footwear. Do not
wear chains, bracelets or clothing that is loose
fitting or hanging ties or cords. Tie long hair
back. Always wear protective earplugs. Loose
clothes, jewellery, or long hair can be caught
in moving parts. Protect eyes, face, and head
from objects that may be thrown from the unit.
Always wear safety goggles or safety glasses
with side shields when operating.
• Always keep hands and feet away from all
moving parts during operation. Moving parts
can cut or crush body parts.
Understand Your Machine
!Personal Safety
!

7
General Safety
• Always keep hands and feet away from all
pinch points.
• Do not touch parts that might be hot
from operation. Allow parts to cool before
attempting to maintain, adjust, or service.
• Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the machine in unexpected
situations. Extending your body too far can
result in a loss of balance and you may fall
which will result in injury.
• Never place any part of your body where it
would be in danger if movement should occur
during assembly, installation, and operation,
maintenance, repairing or moving.
• Start the engine carefully according to
instructions and with feet away from the
moving parts.
• Do not place your hands or feet near or
under rotating parts. Keep away from any
discharge openings.
• Keep in mind that the operator or user is
responsible for accidents, hazards or
unexpected events involving the machine that
occur to other people or their property. It is
the responsibility of the user to assess the
potential risk of the area where work is being
carried out. The operator or user must take
all necessary precautions to ensure their own
safety and that of others, especially on slopes
or rough, slippery and unstable ground.
• The machine may only be used, maintained
or repaired by people who are familiar with it
and its dangers. Unauthorised changes to the
machine negate the manufacturer’s liability for
damages resulting from this.
• The relevant accident prevention stipulations
and other widely recognised safety rules must
be observed.
• Check your machine before starting it. Keep
guards in place and in working order. Make
sure all nuts, bolts, etc., are securely
tightened.
• You must check the general condition of the
machine before use.
• Never operate the machine when it is in
need of repair or is in poor mechanical
condition. Replace damaged, missing, or
failed parts before using it. Check for fuel
leaks. Keep the machine in safe working
condition.
• Do not use the machine if the engine’s
switch does not turn off the engine when
running. Any petrol powered machine that
can’t be controlled with the engine switch is
dangerous and must be replaced.
• Regularly check to see that keys and
adjusting wrenches are removed from the
machine area before starting it. A wrench or
a key that is left attached to a rotating part of
the machine may result in personal injury.
• Avoid accidental starting. Be sure the
engine’s switch is off before transporting the
machine or performing any maintenance or
service on the unit. Transporting or performing
maintenance or service on a machine with its
switch on invites accidents.
• If the machine should start to vibrate
abnormally, stop the engine and check
immediately for the cause. Vibration is
generally a warning sign of trouble.
• Do not tamper with or disable safety
systems.
• The manufacturer’s stipulations concerning
safety, work and maintenance as well as the
measurements specified in Technical Data,
must be complied with.
Inspect Your Machine
!

General Safety
8
• Keep the machine in good operating
condition. Operating a machine in poor or
questionable condition could result in serious
injury.
• Be sure all safety devices are in working
order and warning labels are in place. These
items are installed for your safety.
• All safety and hazard notices must be kept in
completely legible condition.
• Only use manufacturer-recommended
attachments.
• Before using, always visually inspect to see
that the tools are not worn out or damaged.
Replace worn out or damaged elements and
bolts in set to preserve balance.
• Keep all nuts, bolts and screws tight to
ensure the equipment is in safe working
condition.
• The auger must not rotate in idling mode
when the engine is warm.
• This machine is equipped with an internal
combustion engine. Do not use on, or near,
forest-covered or brush-covered land unless
the exhaust system is equipped with a spark
arrester meeting applicable local, state, or
federal laws.
• A spark arrester, if used, must be maintained
in effective working order by the operator.
• Never start or run the engine inside a closed
area. The exhaust fumes are dangerous,
containing carbon monoxide, an odorless and
deadly gas. Operate this unit only in a
well-ventilated outdoor area. (See carbon
monoxide safety).
• Do not tamper with the engine in an effort to
get it to run at higher speeds. The maximum
engine speed is preset by the manufacturer
and is within safety limits.
• Keep a fire extinguisher on hand when
operating this machine in dry areas as a
precautionary measure.
• Never leave the operating position when the
engine is running.
• The engine parts get very hot when
running, do not touch. Danger of burns.
• Follow the instructions to ignite the engine
carefully whilst keeping feet away from
moving parts.
• Never incline the machine during ignition.
Ignite the machine on a flat surface without
obstacles or high grass.
• Do not over-rev the engine or change the
engine settings.
• Never pick up or carry the machine while
the engine is running.
• Stop the engine whenever you leave the
machine, or before refuelling, when cleaning
or while maintaining.
• Reduce the throttle setting during engine
shut down and, if the engine is provided with
a shut-off valve, turn the fuel off at the
conclusion of working.
• Do not run the engine at a high speed when
you are not using it.
• Keep the engine and exhaust free of grass,
leaves, excessive grease or carbon build up
to reduce the chance of a fire hazard.
Engine Safety
!

9
General Safety
•Make sure you thoroughly inspect the entire
work area and remove all objects and anything
that could be thrown by the machine or could
damage the engine or machine (branches,
stones, wire, toys, etc). Attempting to clear the
work area whilst using the machine will reduce
your concentration and creates a trip hazard.
Any liquid spilled on the floor may result in you
slipping.
•You must only work in daylight or with good
artificial light in good visibility conditions. Keep
people, children and animals away from the
working area.
• Never place the machine in a place with
unstable ground which could give way.
• You must pay special attention when
approaching obstacles that could compromise
visibility.
• Check the working environment for foreign
bodies and remove them.
• Do not use where there is a risk of fire or
explosion.
• Find and locate all fixed objects in the
ground, such as sprinkler systems, poles,
water valves, bases for washing lines etc
Make sure that you check for hidden
electrical cables or similar on the surface of
the ground. Make sure that the area to be
drilled is free of all underground obstacles
such as power cables, water and drainage
pipes.
• You must be careful near ravines, ditches or
embankments.
• Exercise extreme caution when operating on
or crossing gravel drives, walks, or roads. Stay
alert for hidden hazards or traffic.
• Do not work in the rain and when there is a
thunderstorm or lightning risk. If there is bad
weather conditions, do not use the machine.
• Avoid working on ground that is stony, hard
or has many roots, strong recoil may occur at
the handles.
• Be careful on unstable ground. Always
ensure a safe standing position.
• During drilling, ejected rocks or pieces of
wood can injure people and animals.
• Do not use the machine in a wet
environment.
• Operate on a flat level ground. Never
operate on slopes.
• Always hold the unit with both hands when
operating. Keep a firm grip on the handlebars.
Be aware that the machine may unexpectedly
bounce upward or jump forward if the
machine should strike buried obstacles such
as large rocks or roots.
• Walk, never run with the machine.
• Use extreme caution when in reverse or
pulling the machine towards you.
• Do not operate the machine in confined
areas where there may be a risk of crushing
the operator between the machine and
another object.
• Be very careful when pulling the
machine toward you. You must look behind
you to make sure there are no obstacles
before and during operations in reverse gear
(if applicable).
• Before leaving the machine to clear
blockages, check, clean, refuel or after
striking foreign object, you must stop the
engine.
Work Area
!
During Use
!

General Safety
10
• Always secure bore holes, otherwise there is
a risk of injury.
• Drill the hole in the ground in several
sections so you can remove the soil in
between.
• The machine may only be used for its
intended purpose. The user alone is
responsible for unintended use of the
machine. The manufacturer is not liable in the
event of unintended use.
• People working with the machine must not
be distracted.
• Only use the machine in a technically
flawless condition, as well as for its intended
purpose, in a safe manner and being aware of
dangers, in compliance with the operating
instructions. Disruptions which can affect
safety in particular must be eliminated straight
away.
• Do not touch rotating or hot parts.
• Do not smoke whilst using the machine.
• WARNING - The earth auger can catch
clothes, string or wire and draw them in.
• Switch off the machine when not in use.
• Do not overload the appliance.
• Do not touch the exhaust when the engine
is running (risk of burns).
• The auger drill bit is capable of causing
serious injury so AT ALL times you MUST
keep hands and feet clear of all moving parts.
Failure to observe these safety instructions
could result in serious injury or death.
• NEVER attempt to unclog either the auger
drill bit while the engine is running.
Immediately shut off the engine. Allow the
auger drill bit to come to a complete stop.
• WARNING! If something breaks or an
accident happens whilst working, you must
turn off the engine immediately and move the
machine away to prevent further damage. If an
accident happens with injuries or third
parties are injured, carry out the first aid
measures most suitable for the situation
immediately and contact the medical
authorities for any necessary health care.
Carefully remove any debris that might cause
damage or harm persons or animals should it
not be seen.
• The excessive speed of movement or the
absence of maintenance have a significant
influence on noise emissions and vibrations.
It is necessary to take preventive steps to
eliminate possible damage due to high levels
of noise and stress from vibration. You must
maintain the machine well, wear ear protection
and take breaks from working.
• Keep a firm hold on the handlebars with
both hands when working.
• When leaving the machine, the engine must
be switched off.
•Do not work by yourself, someone has to be
close in case of emergencies.
• Do not lean too far forwards when working.
• Keep the earth auger vertical, do not twist it.
• Do not place the earth auger in dry grass or
on flammable objects (fire risk).
• Immediately turn off the motor when you can
feel changes to the machine’s behaviour.
• Ensure you have a safe position, during the
drilling process as well.
• You must only drill holes in soil.
• When leaving the earth auger, the engine
must always be switched off.

11
General Safety
The machine has been built according to the
latest technology and recognised safety rules.
However, there is still a chance of residual
risks whilst working.
Furthermore, despite all measures taken,
remaining risks can occur that are not
obvious.
Remaining risks can be minimised by
complying with the manual as well as the
operating instructions overall.
Mineral oil products degrease your skin. If
your skin comes in contact with these
substances repeatedly and for an extended
period of time, it will desiccate. Various skin
diseases may result. In addition, allergic
reactions are known to occur.
Eyes can be irritated by contact with oil. If oil
comes into your eyes, immediately wash them
with clear water. If your eyes are still irritated,
see a doctor immediately!
Remove the clogged material. Inspect for
damage and check for any loose parts for
repair or replacement.
• NEVER allow an accumulation of earth or
drilled material to build up on the earth auger
drill bit, this will prevent proper discharge from
the hole and will make the auger heavy to
handle.
• Whenever you leave the operating position
or if you have to remove processed material,
leaves or debris from the machine, You MUST
always shut down the engine, disconnect
spark plug HT lead, keeping them away from
the spark plugs to prevent accidental
starting, and wait for all moving parts to come
to a complete stop.
• You MUST keep all combustible materials
and substances away from the engine when it
is hot.
Remaining Risks
!
Avoid Skin & Eye Contact
!

General Safety
12
Never operate the engine in a confined space
where dangerous carbon monoxide fumes
can develop. All ignition operations have to be
effected in an open or well-ventilated area.
Always remember that exhaust fumes are
toxic.
The symptoms of carbon monoxide poisoning
can include but are not limited to the
following; Headaches, dizziness, nausea,
breathlessness, collapsing or loss of
consciousness.
Carbon monoxide poisoning symptoms are
similar to flu, food poisoning, viral infections
and simply tiredness. It is quite common for
people to mistake this very dangerous
poisoning for something else.
To avoid carbon monoxide poisoning DO NOT
use Petrol/Diesel powered equipment inside
any of the following; Home, garage, tent,
camper van, mobile home, caravan or boat.
DO NOT use in an enclosed area or moving
vehicle. This is not exhaustive and if you are in
any doubt contact your dealer.
If you think you have or someone around you
has been affected by carbon monoxide
poisoning; Get them fresh air immediately,
CARBON MONOXIDE IS A COLOURLESS,
ODOURLESS GAS. INHALING THIS GAS
CAN CAUSE DEATH OR SERIOUS
LONG-TERM HEALTH PROBLEMS SUCH
AS BRAIN DAMAGE.
DANGER!
!
DANGER
by leaving the affected area or by opening
doors and windows. If safe and practical to do
so make sure that the machine is turned off.
DO NOT enter a room you suspect of having
carbon monoxide present – instead call the
emergency services.
Contact a Doctor immediately or go to
Hospital – let them know that you suspect
carbon monoxide poisoning.
ALL FUELS ARE HIGHLY FLAMMABLE AND
PETROL VAPOUR IS EXPLOSIVE. TAKE
EXTREME CARE WHEN HANDING FUEL.
KEEP FUEL OUT OF REACH OF CHILDREN.
CAUTION!
General Safety
• Do not smoke each time fuel is handled.
• ALWAYS avoid inhaling fumes.
• ALWAYS carry fuel in the correct and clearly
marked container.
• ALWAYS wear correct, suitable and fit for
purpose Personal Protective Equipment (PPE),
suggested items are but not limited to safety
gloves, overalls.
• To avoid sparking or arcing, keep grounded
conductive objects – such as tools – away
from exposed, live electrical parts and
connections. These events could ignite fumes
or vapors.
• Do not operate the machine with known
leaks in the fuel system.
• Fire hazard - keep fuel away from all
sources of ignition for example heaters,
lamps, sparks from grinding or welding.
• DO NOT carry out hot work on tanks that
Carbon Monoxide
!
General Fuel Safety
!

General Safety
13
• When refilling or draining the fuel tank, use
an approved fuel storage container while in
a clean, well-ventilated outdoor area. While
adding fuel or operating the unit, do not
smoke, and stay away from sparks, open
flames, or other sources of ignition near the
area of operation.
• Always stop the engine and allow it to cool
before filling the fuel tank. Never remove
the cap of the fuel tank or add fuel while the
engine is running or when the engine is hot.
• Loosen the fuel tank cap slowly to relieve
any pressure in the tank.
• ALWAYS keep the handles dry, clean and
free of oil and fuel.
Storage
• Make sure to store fuel in special containers.
• Store fuel in containers specifically designed
and approved for fuel storage.
• Store fuel in a cool, well-ventilated area,
safely away from sparks, open flames, or
other sources of ignition.
• Never store fuel – or a machine with fuel in
the tank – inside a building where fumes may
reach a spark, open flame, or any other source
of ignition (such as a water heater, furnace, or
clothes dryer). Allow the engine to cool before
storing in any enclosure.
• Replace all fuel tank and container caps
securely and wipe up spilled fuel. Never
operate the unit without the fuel cap securely
in place.
• Fuels have a limited storage life. Aged fuel
can cause starting problems and damage the
engine. Purchase only the amount of fuel that
you need.
have contained fuel.
• ALWAYS keep the work area tidy.
• ALWAYS dispose of waste fuels correctly.
Spilled Fuel
• If you have spilled fuel, make sure you do
not attempt to ignite the engine but move the
machine away from the area of spilled fuel and
avoid creating any source of ignition until the
fuel has evaporated and fuel vapours have
dissipated.
• When fuel is spilled on yourself or your
clothes, wash your skin and change clothes
immediately.
• ALWAYS clean up spills promptly using
absorbent granules and a lidded bin.
Fueling / De-Fuelling
• ALWAYS fuel and de-fuel in a well
ventilated area outside of buildings. Use a
funnel to add fuel, only outdoors. Do not
smoke during this and each time fuel is
handled.
• Add fuel before igniting the engine, never
remove the fuel tank cap or add fuel whilst the
engine is running or when it is hot.
• When de-fueling ALWAYS use a proper fuel
retriever.
• Never overfill the fuel tank. Because engine
heat can cause fuel to expand, never fill the
tank to more than 1/2” below the bottom of
the filler neck. This will provide space for fuel
expansion.

General Safety
14
• Prior to carrying out any maintenance work
you MUST identify electrical isolation methods
and isolate all electrical supplies.
• Prior to use and with all electrical supplies
isolated, you MUST check all electrical cables,
plugs and connectors for the following;
• Are intact and have no signs of damage, to
include but not limited to bare wires, chaffing,
cuts and loose wiring.
• If there are any signs of damage, the
damaged item MUST be taken out of service
until the damage has been repaired by an
electrically competent person.
• All trailing cables should be routed so as not
to cause any kind of trip hazard.
• NEVER work on or near electricity with wet
hands, wet clothing and wet gloves.
ELECTRICITY CAN KILL – NEVER WORK
ON LIVE/ENERGISED EQUIPMENT.
DANGER!
Batteries present a risk if they become
damaged by the possible leaking of
electrolyte. This electrolyte is an acid and can
cause serious burn injuries. Care should be
taken when working on or near them. NOTE
the electrolyte may be in a liquid or gel form.
Should you come in to contact with electrolyte
you should;
• Remove all clothing contaminated with
electrolyte. If you cannot remove then saturate
them in water.
• Get medical assistance as soon as possible.
You must advise the medical staff of the type
of acid.
• Lead/acid battery = dilute sulphuric acid.
• Nickel/cadmium = potassium hydroxide
alkali electrolyte.
• Use fresh running water to wash off excess
electrolyte, continue this until medical assis-
tance arrives. Make sure that you do not was
the electrolyte to another part of your body or
face.
• If electrolyte comes in to contact with Eyes
the electrolyte needs to be immediately
washed away with large amounts of water.
Make sure that you do not wash the electro-
lyte to another part of your face or body.
• Gasses from charging batteries are highly
flammable and great care should be taken to
charge in well ventilated areas.
• There is an explosion risk if the battery
terminals are short circuited, when
connecting/disconnecting ALWAYS exercise
great care so that the terminals or battery
leads are NOT allowed to touch and cause a
spark. ALWAYS use suitable insulated tools.
• Prolonged use of hand held (operated)
machines will cause the user to feel the effects
of/from vibrations. These vibrations can lead
to white finger (Raynaud’s phenomenon) or
carpal tunnel syndrome. This condition
reduces the ability of the hand to feel and
regulate temperature, causing numbness and
heat sensations and may cause never damage
and circulatory tissue death.
• Not all factors that lead to white finger
disease are known, but cold weather, smoking
and other diseases that affect blood vessels
Electrical Safety
!
Batteries
!
Vibrations
!

15
General Safety
and blood circulation as well as large and
long-lasting impact of shocks are considered
factors in the formation of white finger. Note
the following to reduce the risk of white finger
and carpal tunnel syndrome;
• Wear gloves and keep your hands warm.
• Take regular breaks.
• All of the above precautions may help
reduce the risk of white finger disease but not
rule out the carpal tunnel syndrome.
Long-term and regular users are therefore
recommended to observe the condition of
your hands and fingers. Seek medical
attention immediately if any of the above
symptoms should occur.
• The operating noise of the machine can
damage your hearing. Wear hearing protection
such as earplugs or ear defenders to protect
your hearing. Long-term and regular users are
advised to have hearing checked regularly. Be
especially vigilant and cautious when hearing
ear protection because your ability to hear
alarm warnings will be reduced.
• Noise emissions for this equipment is
unavoidable. Carry out noisy work at
approved times and for certain periods.
Limit the working time to a minimum. For your
personal protection and protection of people
working nearby it is also advisable for them to
wear hearing protection.
• See Certificate of Conformity section
for Outdoor Noise declaration of conformity.
The HYEA5200X is a petrol earth auger from
Hyundai. The HYEA5200X is powered by a
52cc 2-stroke petrol engine.
This machine is a garden tool and precisely a
pedestrian controlled earth auger. The
operator is able to operate the machine and
use the main controls, always staying behind
the handle.
The machine is manufactured according to the
latest safety requirements. Every precaution is
only effective when it is followed exactly.
Intended Use
The basic version of the equipment is an
earth auger intended for private use, i.e. for
use in home and gardening environments. It
is designed for excavating planting holes, for
perfolas and dences in light soil. It has only
limited use on ground that is hard and stony
and has many roots. The earth auger has been
designed to be operated by one person.
User Types
This machine is intended for use by
consumers, i.e. non professional operators.
The machine is intended for “DIY” and
domestic use only.
Improper Use
Any other usage not in keeping with the above
mentioned ones may be hazardous and harm
persons and/or damage things.
The equipment is allowed to be only used
for its prescribed purpose. Any other use is
deemed to be a case of misuse. The user/
operator and not the manufacturer will be
liable for any damage or injuries of any kind
resulting from such misuse.
Noise
!
Intended Use

General Safety
16
HAND PROTECTION MUST BE WORN
Protective electrically non-conductive gloves are highly recommended when working.
HEARING PROTECTION MUST BE WORN
Suitable safety hearing protection is recommended.
EYE PROTECTION MUST BE WORN
Always wear safety glasses/goggles and/or face shields. Everyday eyeglasses have
only impact resistant lenses; they are not safety glasses/goggles.
FOOT PROTECTION MUST BE WORN
Non-skid heavy duty footwear are highly recommended when working.
PROTECTIVE CLOTHING MUST BE WORN
Do not wear loose clothing, gloves, scarfs, neckties or jewellery
(rings, wrist watches), which can be caught in moving parts.
HEAD PROTECTION MUST BE WORN
Wear a safety helmet with a safety visor.
FACE SHIELD MUST BE WORN
Wear a face shield to protect your face.
RESPIRATOR MUST BE WORN
Wear a respirator.
Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when
operating or repairing the machine. No protective equipment can ensure 100%
protection.
When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit etc. If
more than one item of PPE is worn at the same time, make sure they can be used together, e.g
wearing safety glasses may disturb the seal of a respirator, causing air leaks.
Personal Protective Equipment
!

Getting Started
17
CAUTION - This guide is meant to serve
as a quick reference for operating your
HYUNDAI machine. We always advise reading
the manual in full before operation.
CAUTION - For OUTDOOR use ONLY.
Petrol machines produce carbon monoxide
– a poisonous, colourless and odourless gas
that can cause serious injury or death. Petrol
is highly flammable, always handle with
extreme care and in a well ventilated area.
NOTE - Images may vary depending on
model.
NOTE - The machine can be supplied with
some parts already assembled. Prior to
assembly, check all items have been received.
NOTE - This machine is shipped without
fuel and oil and MUST be filled before use.
Failure to do so may cause damage to the
engine that will not be covered by warranty.
!
!
!
!
!
As soon as you have purchased your
machine, we recommend that you fill out
the information on page 38. If you need to
contact an authorised dealer or customer
service for information on servicing, you
may need to provide this information.
!
WARNING! Unboxing and assembling
the machine should be done on a flat, stable
surface with enough room. Disposal of the
packaging should be done in accordance with
the local regulations in force.
Carefully remove the product from the
packaging and examine it for any sign of
damage caused during shipping. Lay the
contents out and check them. If any part is
damaged or missing, you must not use the
machine. Contact HYUNDAI Power Products
immediately. You must keep the packaging
material in case the machine needs to be
returned or repaired.
WARNING! Some of the packaging
material may be harmful to children. Keep out
of reach of children.
!
IMPORTANT - For all work on the earth
auger, you must turn off the engine,
disconnect the spark plug connector and wear
safety gloves. Start the auger only after
complete assembly and checking it.
!
Assembly Safety
!Unboxing Safety
!

18
Assembly
STEP 1
Place the motor casing on a work bench.
Place the earth auger on the drive shaft,
ensuring that both holes are aligned.
STEP 2
Insert the drive pin. Secure with R-pin.
Inserting The Earth Auger
Unboxing & Assembly Video:
YOU MUST read and understand the instruction manual first.
Go to youtube.com and type in Hyundai HYEA5200X assembly.

19
Preparation
STEP 4
Fuel Type : Use fresh unleaded petrol
mixed 40:1 with semi-synthetic 2-stroke
oil or aspen2 pre-mixed fuel.
Fuel Capacity : 1000ml
STEP 1
Fill the mixing bottle with the correct amount
of fresh unleaded petrol. DO NOT mix the fuel
mixture in the fuel tank. You MUST only use
fresh unleaded petrol and 2 stroke engine oil
mixture.
For the first time ONLY a mixing ratio of 25:1
should be used to lubricate all engine parts to
an optimum level. After this, the mix is 40:1.
STEP 3
Unscrew the fuel tank cap and carefully add
the fuel / 2-stroke oil mixture as in the step
above. Only pour the fuel mixture into the fuel
tank after you have mixed and stirred it.
DO NOT overfill and allow a 25mm gap at the
top of the tank. DO NOT use straight unleaded
petrol. Clean up any spills immediately. Clean
the area around the cap, to prevent dirt from
getting into the fuel or oil tank.
STEP 2
Mix the fuel/oil mixture.
Once full replace and correctly tighten the fuel
cap. Clean up any fuel spilt before starting the
engine.
CAUTION - ALL FUELS ARE FLAMMABLE
• ALWAYS fuel and defuel in a well
ventilated area outside of buildings with the
engine switched off. Allow the engine to cool
down before refueling.
• ALWAYS wear correct, suitable and fit for
purpose Personal Protective Equipment (PPE),
suggested items are but not limited to safety
gloves, overalls.
• NEVER refuel the machine in a building where
the petrol fumes can reach flames or sparks.
• Petrol is highly flammable and explosive.
• Never refuel when the engine is still hot or
running.
Petrol Semi-Synthetic
2-Stroke Oil
2L 50ml
3L 75ml
4L 100ml
Method of mixing 40 parts petrol + 1 part
2-stroke oil
NOTE
• Do not add more 2-stroke oil than specified
to ensure safe operation. This will only result
in a higher production of combustion residues
which will pollute the environment and clog the
exhaust channel in the cylinder as well as the
muffler. In addition, fuel consumption will rise
and performance will decrease.
!
Mixing 2-Stroke Oil

A
20
Starting Procedure
STEP 1
If the engine is cold, move the choke lever
(A) to the START position. The choke lever
opens and closes the choke in the
carburettor.
If the engine is warm, leave the choke lever to
the RUN position.
CAUTION - For OUTDOOR use ONLY.
Petrol machines produce carbon monoxide –
a poisonous, colourless and odourless gas that
can cause serious injury or death. Petrol is
highly flammable, always handle with extreme
care and in a well ventilated area.
NOTE - This machine is shipped without
fuel and oil mixture and MUST be filled before
use. Failure to do so may cause damage to the
engine that will not be covered by warranty.
CAUTION! ALL FUELS ARE FLAMMABLE
Always fuel and de-fuel in a well ventilated area
away from sources of ignition. Move the ma-
chine at least 3m away from the refuelling point
before starting.
!
!
• Always ensure that the machine is in a safe
working condition. Inspect the machine, check
safety devices, the condition of the fuel lines
and check all nuts, bolts and screws are
secure. Make sure that the earth auger can
move freely.
• Check the fuel / 2-stroke oil mixture. Go to
page 19 for more information.
• Before starting, make sure the machine is
clear of all materials and non-essential people.
• Make sure you know how to stop the engine
before starting.
WARNING - If you are not familiar with
this type of machine, you should seek advice
and guidance from your dealer.
!
CAUTION
!
• Always start slowly with half throttle and
keep a firm grip on both handles of the auger
at all times. Keep a wide stance.
• After engine warms up, accelerate the
engine. To accelerate the engine to working
speed, squeeze the throttle lever toward the
main handle.
• Do not force the auger drill bit into the
ground - instead allow the machine to do the
work. If the machine jams you MUST release
the throttle and move the auger drill bit before
re-commencing work.
• To remove blockages DO NOT under any
circumstance use your hands. STOP and
disable the machine and clear the auger drill
bit of materials which have become stuck to
the auger bit.
WARNING - You MUST STOP using the
machine if any of the following occur:
• The engine speed changes with no control
• In case of misfire
• In case of high vibration
• When flames or smoke appear
• In rain or stormy weather
!
Before Each Use
Starting Procedure
