i-PRO WV-S15700-V2L User manual

Network Camera
For professional use only Outdoor use
Model No. WV-S15700-V2L
WV-S15600-V2L
WV-S15500-V3L
About the user manuals
Product documentation is composed of the following documents.
•Installation Guide (this document): Provides information about “Precautions”,
“Precautions for installation” and the installation method.
•Basic Information (Refer to the link on the following support website):
Provides information about “Precautions for use”, “Parts and functions” and “Detail
specifications”.
•Operating Instructions (Refer to the link on the following support website):
Explains how to perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/training-support/documentation-database-list
“<Control No.: C****>” used in these documents should be used to search for information on our technical
information website (https://i-pro.com/global/en/surveillance/training-support/support/technical-information)
and will guide you to the right information.
• Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
• microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.
• The external appearance and other parts shown in this manual may differ from the actual product within the
scope that will not interfere with normal use due to improvement of the product.
Disposal of Old Equipment and Batteries
Only for European Union and countries with recycling systems
These symbols on the products, packaging, and/or accompanying documents mean that used
electrical and electronic products and batteries must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to
applicable collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any potential
negative effects on human health and the environment.
For more information about collection and recycling, please contact your local authority.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
Note for the battery symbol (bottom symbol)
This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.
NOTE: This equipment has been tested and found
to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at his
own expense.
FCC CAUTION: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
Supplier’s Declaration of conformity
Trade name : i-PRO
Model No. : WV-S15700-V2L /
WV-S15600-V2L / WV-S15500-V3L
Responsible Party :
i-PRO Americas Inc.
8550 Fallbrook Drive, Suite 200 Houston,
Texas 77064
Support Contact: 1-800-513-5417
For U.S.A.
CAN ICES-3(A)/NMB-3(A)
For Canada
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
For U.S.A.
Méthode
d’installation
Vis de fixation
recommandée
La capacité
de traction
minimale
requise
Quand la caméra
vidéo est directement
installée au plafond
ou sur le mur.
M4 × 16 mm
{5/8 pouces}
/ 4 él.*
724 N {163 lbf}
* La longueur de la vis est un exemple lors de
l’installation de la caméra au plafond ou sur un mur
robuste d’une épaisseur de 20 mm {25/32 pouces}
ou plus.
 Do not install or clean the camera, or touch this product, the power cable or the
connected cables during thunder storms.
Failure to observe this may cause electric shock.
 Refer installation work to the dealer.
Installation work requires technique and experience. Failure to observe this may cause fire, electric shock, injury,
or damage to the product. Be sure to consult the dealer.
 Stop the operation immediately when something is wrong with this product.
When smoke goes up from the product, the smell of smoke comes from the product, or the exterior of the
product has deteriorated, continued use will cause a fire or fall of the product resulting in injury, or damage to
the product.
In this case, turn the power off immediately and contact qualified service personnel for service.
 Select an installation area that can support the total weight.
Selecting an inappropriate installation surface may cause this product to fall down or topple over, resulting in
injury or accidents. Installation work shall be started after sufficient reinforcement.
 Periodic inspections shall be conducted.
Rust on the metal parts or screws may cause a fall of the product resulting in injury or accidents.
Consult the dealer for the inspections.
 The exclusively designed mount bracket shall be used.
Failure to observe this may cause a drop resulting in injury or accidents.
Use the exclusively designed mount bracket for installation.
 The screws and bolts must be tightened to the specified torque.
Failure to observe this may cause a drop resulting in injury or accidents.
 Turn the power off when do wiring of this product.
Failure to observe this may cause electric shock. In addition, short circuit or wrong wiring may cause fire.
 Install this product in a location high enough to avoid people and objects from bumping
the product.
Failure to observe this may cause injury.
 Do not install this product in locations subject to vibration.
Loosening of mounting screws or bolts may cause a fall of the product resulting in injury or accidents.
 Correctly perform all wiring.
Short circuits in the wiring or incorrect wiring may cause fire or electrical shock.
 The measures of protection against snowfall shall be taken.
Weight of snow may cause a fall of the product resulting in injury or accidents. Protect the product against
snowfall by installing it under eaves.
 Install the product securely on an installation surface in accordance with the installation
instructions.
Failure to observe this may cause injury or accidents.
 Do not rub the edges of metal parts with your hand.
Failure to observe this may cause injury.
 Turn the power off when cleaning this product.
Failure to observe this may cause injury.
WARNING:
• Operation of this product in a residential environment could cause radio interference.
Caution: Notice:
• The DC power supply connected to the camera
must be in the same building.
• The network camera is only intended for a
connection
to an ethernet or PoE network without
routing to the outside plant.
• This product has no power switch. Be sure to
install disconnect devices such as a circuit breaker
to shut down the main power of power supplying
equipment to this product.
• Only connect 12 V DC Class 2 power supply (UL
1310/CSA 223)
, limited power source (IEC/EN/UL/CSA
60950-1, IEC/EN/UL/CSA 62368-1 Annex Q) or IEC/EN/UL/
CSA 62368-1 PS2.
• Before attempting to connect or operate this
product, please read these instructions carefully.
• This product is not suitable for use in locations
where children are likely to be present.
• Do not install this product in locations where
ordinary persons can easily reach.
• This product is a professional equipment.
• For information about screws and other
parts
required for installation, refer to the
corresponding section of this document.
: Direct current symbol
Precautions
 Do not insert any foreign objects.
Fire or electrical shock may be caused if water or any foreign objects, such as metal objects, enter inside the
unit.
Turn the power off immediately and contact qualified service personnel for service.
 Do not use this product in an inflammable atmosphere.
Failure to observe this may cause an explosion resulting in injury.
 Avoid installing this product in the locations where salt damage occurs(except for
WV-S15700-V2LK, WV-S15500-V3LK) or corrosive gas is produced.
Otherwise, the mounting portions will deteriorate and injury or accidents due to a fall of the product may occur.
 Do not strike or give a strong shock to this product.
Failure to observe this may cause injury or fire.
 Keep microSD memory cards away from infants and children.
Otherwise, they may swallow the cards by mistake.
In this case, consult a doctor immediately.
 Do not hang down from this product or use this product as a pedestal.
Failure to observe this may cause injury or accidents.
 Do not damage the power cable.
Do not damage, fabricate, twist, stretch, bundle, or forcibly bend the power cable. Do
not place heavy objects on it, and keep it away from heat sources.
Use of a damaged power cable may cause electric shock, short circuit, or fire.
Consult the dealer for repair.
 Do not install this product on a place that is greatly influenced by wind.
Installation on a place where the wind speed is 60 m/s {approx. 134 mph} or more may cause a fall of the
product resulting in injury or accidents.
 Do not sprinkle more water, exceeding the performance limit of waterproof with a high
pressure cleaning machine, etc.
Fire or electrical shock may be caused by immersion.
 Do not attempt to disassemble or modify this product.
Failure to observe this may cause fire or electric shock. Consult the dealer for the repair or inspections.
The model number and serial number of this prod-
uct may be found on the surface of the unit.
You should note the model number and serial num-
ber of this unit in the space provided and retain this
book as a permanent record of your purchase to aid
identification in the event of theft.
Model No.
Serial No.
For U.S.A.
Installation Guide
Included Installation Instructions
WV-S15700-V2L
© i-PRO Co., Ltd. 2022
avs0222-1032
Printed in China
i-PRO Co., Ltd.
Fukuoka, Japan
https://www.i-pro.com/
Authorised Representative in EU:
i-PRO EMEA B.V.
Laarderhoogtweg 25, 1101 EB
Amsterdam, Netherlands
i-PRO EMEA B.V. UK Branch
1010 Cambourne Business Park,
Cambridgeshire CB23 6DP

About notations
The following notations are used when describing the functions limited for specified models.
The functions without the notations are supported by all models.
157 V2L The functions with this notation are available when using the model WV-S15700-V2L(4K model) series.
156V2L The functions with this notation are available when using the model WV-S15600-V2L(6M model) series.
155V3L The functions with this notation are available when using the model WV-S15500-V3L(5M model) series.
W
The functions with this notation are available when using the model with the i-PRO white body.
B
The functions with this notation are available when using the model with the black body.
Open Source Software
• This product contains open source software licensed under GPL (GNU General Public License), LGPL (GNU
Lesser General Public License), etc.
• Customers can duplicate, distribute and modify the source code of the software under license of GPL and/or LGPL.
• For details concerning licensing and source code of open source software, click “Click here for OSS
information” on “Support” page of the setup menu of this product and read the displayed content.
• Please note that we shall not respond to any inquiries regarding the contents of the source code.
Copyright
Except for open source software licensed under GPL/LGPL and so on, distributing, copying, disassembling,
reverse compiling and reverse engineering of the software provided with this product are all expressly prohibited.
In addition, exporting any software provided with this product violating export laws is prohibited.
Trademarks and registered trademarks
• Microsoft, Windows, Windows Media, Microsoft Edge, and ActiveX are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
• Intel and Intel Core are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
• Adobe, Acrobat, and Reader are either registered trademarks or trademarks of Adobe in the United States
and/or other countries.
• microSDXC Logo is a trademark of SD-3C, LLC.
• iPad and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
• Android and Google Chrome are trademark of Google LLC.
• Firefox is a trademark of the Mozilla Foundation in the US and other countries.
• The word “QR Code” is a registered trademark of DENSO WAVE INCORPORATED in Japan and other countries.
• All other trademarks identified herein are the property of their respective owners.
Precautions for installation
i-PRO Co., Ltd. assumes no responsibility for injuries or property damage resulting from failures arising
out of improper installation or operation inconsistent with this documentation.
 In order to prevent injury, the product must be securely mounted to an installation
surface according to Installation Guide.
 Installation area for this product
Select an appropriate place for the installation area (such as a strong installation surface) in your particular environment.
• Make sure that the installation area is strong enough to hold this product, such as a concrete ceiling.
• Install the camera in the foundation area of the architecture or where sufficient strength is assured.
• Do not mount the product on a plaster board or a wooden section because they are too weak. If the product
is unavoidably mounted on such a section, the section shall be sufficiently reinforced.
• <WV-S15700-V2LK,WV-S15500-V3LK only> Please pay attention to the installation location such as in places
where seawater does not splash directly. Especially when installing this product in coastal areas and area that
are sprayed with snowmelting agent that are not exposed to rainwater, periodically clean by rinsing to remove
adhered salt. Prepare the foundation of the installation site, installation support, and any other installation
setting with heavy salt damage resistance treatment.
 Do not place this product in the following places
• Locations where a chemical agent is used such as a swimming pool
• Locations subject to moisture or oil smoke such as a kitchen
• Locations that have a specific environment that is subject to an inflammable atmosphere or solvents
• Locations where a radiation, an X-ray, a strong radio wave or a strong magnetic field is generated
• Locations near coasts directly subjected to sea breezes(except for WV-S15700-V2LK,WV-S15500-V3LK), or
locations subject to corrosive gases such as from hot springs, volcanic regions, etc.
• Locations where the temperature is not within the specified range
• Locations subject to vibrations, such as on vehicles, marine vessels, or above product lines (This product is
not designed for on-vehicle use.)
• Locations subject to condensation as the result of severe changes in temperature
• Locations near rubber products (packing, rubber feet, etc.)
 Screw tightening
Do not use an impact driver. Use of an impact driver may damage the screws or cause tightening excessively.
 Installing in low temperature environments
This product is equipped with an internal heater unit for use in cold climates. The heater unit turns on
automatically when the temperature inside the product drops below around –15°C {5 °F}. When this product
is installed and operated in low temperatures below –20 °C {–4 °F}, it may require time to start up since the
camera will wait to be warmed up internally by the internal heater right after the power is turned on. Also, the
camera may not function properly, if it is installed and operated in an environment where the temperature is
below -25 °C {-13 °F}. In such a case, wait approximately 2 hours or more until the camera is warmed up. Then,
turn on the power again. As the camera warms up, snow or frost accumulated on the front panel will melt.
However, it may not be defrosted from the cover depending on the ambient temperature or weather condition.
 About reflection of light from outside or IR light
A ghost may appear on the screen depending on the incident angle of external light.
In the case of using the IR light, installation of a camera near a wall may cause reflection of infrared rays resulting
in a part of the screen or the entire screen turning whitish.
• Refer to our technical information website <Control No.: C0109> for image examples and measures to take.
 Take notice of humidity
Install this product when the humidity is low. If installation is performed when it is raining or in very humid
conditions, the inside may be affected by humidity, causing mist-over inside the front panel.
 Protection from lightning
When cables are used outdoors, there is a chance that they may be affected by lightning. In such a case, install
a lightning arrestor close to the camera, and make the length of the network cable between the camera and
lightning arrestor as short as possible to prevent the camera from being affected by lightning.
 When noise disturbance may happen
Noise may appear in video or audio near a strong electric field from a TV or radio antenna, motors and
transformers, or a strong electric field/magnetic field from a power line (lamp line) of AC100 V or more. Conduct
the power distribution work to keep 1m {3.28feet} away from them or conduct the electric conduit work using
metal pipes. (Be sure to make ground connection of the metal pipes.)
 Make sure to remove this product if it will no longer be used.
 This product has no power switch.
When turning off the power, disconnect the power supply from the 12 V DC power supply or the PoE device.
 About the battery
A battery is installed inside the camera. Do not leave the battery exposed in environments of excessive heat as a
result of sunlight or fire.
 Equipment classification and power source indication label
Remove the front part of the unit and refer to the indication label on the bottom side of this unit for the
equipment classification, power source, and other information.
 About static electricity
Before installing or removing this product, be sure to touch metal objects to discharge static electricity from your body.
Troubleshooting
Before requesting service, refer to “Troubleshooting” of Basic Information and Operating Instructions. Then,
confirm the trouble.
Specifications* *For further information, refer to the Basic Information.
Power source *1: DC 12 V
PoE (IEEE802.3af compliant)
Power consumption *1: DC 12 V: 1.0 A/ Approx. 12.0 W
PoE DC 48 V: 240 mA/ Approx. 11.5 W (Class 0 device)
Operating environment
Ambient operating temperature:
Ambient operating humidity:
–40 °C to +60 °C *2{–40 °F to +140 °F}
(Power On range: –30 °C to +60 °C {–22 °F to +140 °F})
10 % to 100 % (no condensation)
Storage environment
Storage temperature:
Storage humidity:
–30 °C to +60 °C {–22 °F to +140 °F}
10 % to 95 % (no condensation)
Monitor output
(for adjustment):
VBS: 1.0 V [p-p]/75 Ω, composite, Pin jack
An NTSC or PAL signal can be outputted from camera
(either press the INITIAL SET button quickly (within 1 second) or use
software to select NTSC or PAL signal).
EXT I/O terminals: ALARM IN 1
(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)
ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1)
ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)
Audio input: ø3.5 mm stereo mini jack
For microphone input: Recommended applicable microphone: Plug-in power type
(Sensitivity of microphone: –51 dB to –38 dB (0 dB=1 V/Pa, 1 kHz))
Input impedance: Approx. 2 kΩ (unbalanced)
Supply voltage: 2.5 V ±0.5 V
For line input: Input level: Approx. –10 dBV
Audio output *3: ø3.5 mm stereo mini jack (Audio output is monaural.)
Output impedance: Approx. 600 Ω (unbalanced)
Output level: –20 dBV
Waterproof *4: IP66 (IEC 60529), Type 4X (UL50E)
NEMA 4X compliant
Shock resistance: IK10 (IEC 62262)
Wind resistance: Up to 40 m/s {approx. 89 mph}
Dimensions: 133 mm (W) × 133 mm (H) × 383 mm (L)
{5-1/4 inches (W) × 5-1/4 inches (H) × 15-3/32 inches (L)}
Mass: Approx. 2.4 kg{5.3 lbs}
Finish: Main body: Aluminum die cast and resin*5,
W
B
Outer fixing screws: Stainless steel (Corrosion-resistant treatment)
Front panel: PC resin, Clear
• WV-S15700-V2LN, WV-S15700-V2LK, WV-S15600-V2LN,
WV-S15500-V3LN, WV-S15500-V3LN1, WV-S15500-V3LNK
：with ClearSight coating
Others: Heavy salt damage resistance specifications (ISO14993 compliant)
• WV-S15700-V2LK, WV-S15500-V3LK
*1 Refer to our technical information website <Control No.: C0106> for further information about Power source
and Power consumption information.
*2 When using with the IR LED light constantly lit, the upper limit of the operating temperature range is +50 °C {+122 °F}.
*3
157 V2L 156V2L
This camera is not equipped with the function to change the audio output to the monitor output.
155V3L
The audio output can be switched to the monitor output. Refer to the "Operating Instructions" on our support
website for descriptions of how to switch the output.
*4 Only when installation work is properly performed according to the Installation Guide and appropriate
waterproof treatment is performed.
*5 The heavy salt damage resistance coating is only provided for WV-S15700-V2LK / WV-S15500-V3LK.
Optional accessories
<Brackets> <Cables>
Corner mount bracket: WV-QCN500-W RJ45 Ethernet cable: WV-QCA500A
Pole mount bracket: WV-QPL500-W, WV-QPL500-B I/O cable: WV-QCA501A
The latest information → Technical information website “Accessory Selector” <Control No.: C0501>
※ When using the bracket in heavy salt damage region, use the salt damage-resistant bracket listed
on our technical information website <Control No: C0501>.
Standard accessories
Installation Guide (English / Japanese) ..... 1 pc.(each)
Installation procedure leaflet (English / Japanese) ... 1 pc.(each)
IMPORTANT SAFETY INSTRUCTIONS ................ 1 pc.
Code label*1........................................................... 1 pc.
*1 This label may be required for network management. Use caution not to lose this label.
The following parts are used during installation procedures.
Adapter box ........................................................... 1 pc.
Adapter box mounting pin ...................................... 1 pc.
Mounting screw
(M4 × 8 mm {5/16 inches})................................... 2 pcs.
(of them, 1 for spare)
Grommet cover....................................................... 1 pc.
Grommet .............................................................. 2 pcs.
(of them, 1 for spare)
RJ45 cap.............................................................1 pc.
Rain wash coating label (with ClearSight coating
model only)............................................................. 1 pc.
Other items that are needed (not included)
• Fixing screw
Installation method Recommended
screw*1
Minimum pull-out
strength*2
Directly mount :
Directly mount the camera onto the installation surface. M4 × 16 mm
{5/8 inches} × 4 pcs.*3
*4
724 N {163 lbf}
Gangbox/ Junction box :
Mount the camera to a gangbox/ junction box.
Mount the camera using the exclusively designed mount
bracket.
Refer to the operating instructions of each
bracket.
*1 Select screws according to the material of the location that the camera will be mounted to. In this case,
wood screws and nails should not be used.
*2 This value indicates the minimum pull-out strength required value per screw. For information about the
minimum pull-out strength, refer to our technical information website <Control No.: C0120>.
*3 The screw length is an example when installing the camera on a robust installation surface with a
thickness of 20 mm {25/32 inches} or more.
*4 Please consider using anti-corrosive mounting screws or caulking.
• Ethernet cable with RJ45 plug (category 5e or better, straight, all 4 pairs (8 pins))
• As necessary, audio input cable, audio output cable, alarm I/O cable, power supply cable
• 5 mm {3/16 inches} hexagon wrench and other required tools.
Installation
For information about the installation procedure, refer to the provided installation procedure leaflet.
