ICELAND 352212 Mounting instructions

ICELAND Fridge Freezer
           
          
       


/ /

1
Points of safety
For proper usage and safety, please read the
Instruction before using it.
Please follow all items of Instruction for safety
while using it.
Cautions
Own socket for its own use
The electric power must
be well connected to the
earth.
Dust and bad connection
might cause electric shock.
Keep the plug and socket clean
Cautions
Attentions
This symbol indicates the possi-
bility of death or serious injury.
This symbol indicates the poss-
ibility of injury or damage to
property.
Short circuit caused by
damaged plug can make
fire.
No extruding the plus strengthly
No damaging the power line
Short circuit caused
by forcible bending,
stretching,twisting
packing,cutting the
wire might make fire.
The meaning of symbols used in this manual is
shown in following table
Never do this
No touching
No removing
Must follow while using it
Pull the plus out during
maintenance
Connected to the earth
Attentions
Customer cannot change the plug and wire without
authorization. If the wire is destroyed. it should be
changed by the service authorized service personnel

5
2
INSTALLATION
1 Placing rightly
Above 5cm
Above 5cm
Above 5cm
Adjustable
feet
Keeping proper space
Too small space around it, putting goods on the
top or side, and pasting our on the side might
prevent heat generation, resulting in unnecessary
wastage of energy.
Contacting between back and wall might cause
vibration and noise.
Heat radiated from the refrigerator might wear
our the wall or other things of space is too small.
Avoiding heat and moisture
Heat, sunlight shining directly would infulence
cooling seriously and waste the electric energy.
Many troubles are caused by moisture.
Locating firmly and horzontally
Rotate the adjustable feet one round (let the from
feet hand in the air) and then firm the refrigerator
horizontally (to avoid vibration and noise).
! Attentions
A piece of wood should be placed first if the re-
frigerator is located on the carpet etc.
Earth line
! Cautions
The earth line should be connected if the refrigerator
is located at the moist place such as toilet,
laundryroom, basement etc.
Earth terminal (triangle plug)
Please connect one side of the earth line to
the earth terminal
2
Clearing with
wet cloth
Tear down the tape
firming case
3
Turn on the power
4
Storing after turning on
power 4~5 hours
The smell of plastic will disappear
automatically a period later.
Donˇt o pen
the door
I n h o t s easo n f reez ing foo d s c ompl ete l y n eeds 24 hou r s.
check the cooling condition in the next day .something such as
ice-cream should be frozen completely.
5Pay more attention while moving.
Screw compressors are adopted inside. Inclination angle is no more than 45 degree.
Changing the light bulb
Temperature adjustment . . . Usually in MID position
If you need to replace the lamp, please according to below instruction,
1.oull out the power plug first,
2.unscrew the old lamp, replace the new lamp,
Note: the lamp power is 10W,
the bulb must be according to IEC 60079-15.
Temperature knob is to be adjusted temperature of box. The number on it can not show temperature
Big number show the temperature of box is low and little number show is high."0"show stop. In winter,
usually place the knob at 4-7,In summer usually place the knob at 4-1.
Caution:
1.Please obey the step of control;
2.Improper adjust may lead to lower temperature, higher temperature or influence energy consumption.

3
6
Cautions
No stretching of the power line directly
Please shut the power
off while handling the
plug, damaged wire
might make fire.
Never use damaged wire, plug, socket
It might cause electric shock,
short circuit, even fire.
Shut off power while maintenance
Unplug the socket
while cleaning.
Accident(short circuit)
may happen if it continues
to run.
Please contact to the
authorized service
personnel without delay.
Pull our plug in emergency
Be sure to connection to earth well
Do not install the unit in moist place
If inflammable gas is leaked, open the
window to have fresh air, do not pull out plug
Do not remove or repair it bu yourself
Make sure the appliance
is properly earthed.
Avoid using the appliance
in a damp moist place.
Spark may happen if
the plug is pulled out
which can result in fire
or explosion.
Please contact with the
authorized service center
without delay.
?
Cautions
Remove the door gasket while discarding it
Remove the door gasket
to avoid children being
trapped inside.
Attentions
Please locate it on even and smooth
place, regulate by screwing the feet
Turning over would
cause accidents.
OK !
Do not stretch hand to the bottom.
Do not store too much foods.
Too much storing drop
the cooling efficiency.
Recycle foam, refrigerant, etc, according
to relevant national regulations.
Forbidden to throw away foam, refrigerant, etc.
To avoid frostbite, do not touch foods and
vessel in freezer with moist hands
Touching foods and
vessel in the freezer
with moist hands would
cause frostbite.
Close the door with the handle
Closing the door with
hands on the upside,
downside or other sides
might hurt the fingers.
Do not put bottle into the freezer case
Glass may explode and
hurt people hand while
storing or extracting
foods.
When place fridges, please remove
the foam tray
Especially when use refrigerant 600a,should
remove the foam tray, or cause to explode.

7
4
Maintenance
Cleaning procedure
Always disconnect
the power plug.
air, then moving it.
Clean the dust at back and ground
Do not stretch hands to the bottom
Cautions
Wipe off any oil on the
surfaces
soak a soft cloth in warm
water or dish abluent.
wiper off all abluent.
Check power line and plug
If the power line and plug damaged.
Dust on the plug.
Unusual heat of plug.
If the socket become flexible.
If the plug inserted incompletely.
If the power line and plug are damaged or
Sticked dust, it would cause electric shock or
fire.
Replugging in the power at least
10 minutes later.
Adjust the regulate feet and let it hang in the Caution
Back of refrigerator
Attention
Inspection after cleaning
10 minutes
Common phenomena trouble shooting
Instruction trouble shooting
the following cases are not malfunction. please check according to below steps
before asking for service
No current; abnormal voltage; fusing; out in the plus uneffectively ,check the plug and fuse.
Not efficient
The temperature adjustment knob is in the 0 position;
space around the refrigerator is not enough;
the door has been opened too frequently and too long;
the refrigerator is exposed to the sunlight directly or place near some heat sources;
there is no space between foods;
there are hot foods inside the case.
Please read the points of attention, keep away from the heat source, do not open the door frequently ,
put the hot foods in the case after it is cooled down. adjust the knob to 5 to 6 position.
Foods frozen in the refrigerator compartment or chilled case.
The temperature knob is in 7 position;
foods containing rich water and freezed easily are near the rear wall.troubles of sensors or controls,
adjust the knob to 3 position
Noises
the refrigerator is not located firmly;
the refrigerator has been struck to other objects;
the copper pipe has been struck each other in the mechanical room;
locate the refrigerator at a firm base and separate the copper pipe from other objects in the
mechanical room
Compressor can not stop working automatically
store too much foods at one setting;
open the door frequently or too long;
the temperature knob is in 7 position;
Foods should be stored in separated batches, do not store too much food at one setting;
Decrease the frequence of opening the door and shorten the time of opening the door;
Compressor cannot start
turning on the power, the refrigerator cannot work exceeding 30seconds.pullthe plug down at once.
Reinsert the plug, if the refrigerator still do not work. Please contact with service department.

8
WAR NING:
WARNING---keep ventilation opening, in the appliance enclosure or in the built-in structure, clear
of obstruction.
WARNING---do not use mechanical devices or other means to accelerate the defrosting process.
WARNING---do not use electrical appliances inside the food storage compartments of the appliance.
WARNING---do not damage the refrigerant loop.
If the supply cord is damaged, it must be replace bu the manufacture or its service agent or
a similarly qualified person in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
WARNING----Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING----Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
Correct Disposal of this product This marking indicates that this product should not
be disposed with other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources.
To return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this product
for environmental safe recycling.
