IceManCooler ICE-D50 User manual

Dimension()
148 mm
85 mm
66 mm
33.5 mm
32 mm
Front Right
Back
Top
V=288ml
Volume
Single D5 Reservoirs
 D5
ICE-D50

USER GUIDE
R
IceManCooler
High Performance Liquid Cooling

2017.8 V1.0
www.icemancooler.com
  ，
。
5.25"
：
This reservoir requires two 5.25" drive bay in your computer
chassis,Please make sure you have enough to install.
CAUTION:
。。
。 。
，。。
Icemancooler
This product is intended for experienced users only. Please consult with a qualified
technician prior to installation. Improper installation may cause damage to your
equipment. Icemancooler assumes no liability whatsoever, expressed or implied,
for the use of these products, nor their installation. The following instructions are
subject to change without notice. Please visit our web for up to date information.
！
！
：
Do not use alcohol or alcoholic liquids on this reservoir!
Do not place upside down or sideways!
WARNING:
G1/4 stop plug x4
DUAL slot D5 reservoirs x1
O-ring(61.5x2.65) x2
Pump Holder
Pump screws(M4x10) x4
Reservoirs screws(M3x6) x10
Included:






x1
x4
(61.5x2.65) x2
(M4x10)
G1 4/
x4
(M3x6) x10
:
Pumps &other fittings Not included!
！

()Reservoirs

()Pump
(O-ring)
()Screw M4x8
M4x8
()
Installing The Pump
 。(61.5x2.65)
STEP 1:
(O-ring)

，(M4x10)
STEP 2:
Attach provided o-ring to pump.(61.5x2.65) Insert pump into reservoir, then fasten
screws(M4x10) in cross pattern.
(Ring)
Installing The Reservoirs ()
 ，  。
STEP 2:
()Panel
 
Remove two 5.25” drive bay covers
if applicable.
Slide reservoir horizontally into chassis from front,
Align reservoir front panel flush with chassis panel.
8M3x6
 。
()Screw M3x6
M3x6
， ，。
STEP 4:
()Plug
Fasten reservoir to 5.25” bays with
M3x6 screws provided.
When loop(s) completed, remove stop plug from
front panel and fill loop.
()
Connection Mode
(Default):
():Mode 2
1
()
Loop 2
2
()Loop 1
 (Mode 3):
STEP 3:
STEP 1:
