Iecig IVOD User manual

IVOD
User Manual
Shenzhen Iecig technology Co., ltd

Content
1.Preface and Product configuration…1
2.Battery Body Use…………………2-3
3.Atomizer Use………………………4-5
4.Smoking Light Show………………6
5.Charging Process……………………7
6.Precautions and Warranty…………8
7.IVAP Software Use………………9-19

FCC Statment This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, —Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
RF warning statement
The device has been evaluated to meet general RF exposure
requirement.The device can be used in portable exposure condition
without restriction.

The IVOD revolutionarily adopt memorizer system which is able to
record and manage your vapor history.Meanwhile,it can realize
human-machine interaction through connecting with mobile
phone,and show your smoking data clearly.In addtiton,extra larger
Hangge battery give you the perfect vapor all day long.
The IVOD is the first e cigarette used bluetooth technology,realize
remote control by the APP which install in mobile phone through
bluetooth link.
The IVOD is the milestone,the turning point and the new
breakthrough of vapor intelligent e cigarette.
Standard Configuration:
·1 x IVOD Battery Body
·2 x IVOD Atomizer
·1 x USB Charger
·1 x American Standard Adapter
·1 x 10ml Bottle Needle
·1 x IVOD Manual
·1 x Guarantee Card

2
Atomizer
Switch Button
Screw the Atomizer
body in the batte ry
Battery Tube
Compatible with
all 510 type
clearomizers

Shutdown Mod
press on about 10s click the switch
button 5 times
switch the bluetooth on
blue light blink one time
per three seconds
Switch the smoking on
when red light
blink three times
Click the switch button 5 times:
put the smoking on/off
Press on the switch button 10s:
put the bluetooth on/off
Kindly Reminder:
Please put on/off bluetooth function
when the smoking function off.
Introduction of button function:
click the switch button
5 time just only smoking,
but it can memorize your
smoking data,even
through the bluetooth off.

1. Pull out the drip tip from the atomizer.
2.Screw the bottom to the left.
3.Screw the atomizer coil out.
Ensure you can use the IVOD atomizer normally,
(pls refer to the pic):
(1) (2) (3)
4

Make the bottom screw out from the
body,inject the e-liquid in from the
bottom,keep the e-liquid slowly melting
down along the edge of the atomizer .
Kindly Reminder:
1.Don’t make e-liquid full of the
atomizer.
2.Don’t make e-liquid inject in the exit
of the gas at the middle,and it is better
to leave 1-2mm space.

Different battery capacity different color.
Battery Voltage:
Smoking Light Show:
4.2-3.9V Cyan
3.6-3.9V Green
3.2-3.6V Red
Press to smoke
when smoking and
bluetooth working

Charging Process:
To charging IVOD,plug the dedicated cable into
the charging port of the IVOD.
It takes approximately 3 hours to charge via a charger,the charger will not sold tother with
the product,please choose qulified ac/dc charger.
Please allow the battery enough time to be fully charged.
Status indicator lamp
Screw to insert the
battery in the charger

Precautions:
Be sure to read the instructions and precautions before using the product.This will help ensure easier
and safer use.
1.Don't abuse your IVOD even through it's made of metal you can damage it by dropping it.
2.Only have your IVOD repaired by Iecig.Dont attempt to repair the unit yourself as damage of
personal injury can occur.
3.Don't remove the circuit board housing from behind the front cap.Doing so will avoid your warranty.
4.The IVOD operates on a single lithium-ion battery.Never stack two batteries or use batteries that are
not recommended for use in the IVOD.This is very dangerous to use magnets on your batteries.
5.In order to guarantee the normal work of IVOD and the effect of smoking,we suggest that you
should charge in time when the battery power below 10%
6.In order to prolong the validity of IVOD,please dont place it in too hot or too cold environment
7.Please obey local laws or regulations while vaporing with electronic cigarettes.If there are any bans
or potential dangers,please keep the battery locked.
8.IVOD is not waterproof,so please keep it dry.It may cause its componets damaged or electronic
shocks if you touch it with wet hands.
9.Keep your IVOD away from sources of excessive heat.
10.Please use only Iecig's dedicated accessories and batteries,and keep it away from children.
11.Please use only Iecig's dedicated software to modify programs and parameters of IVOD.
12.Don't drop,hit or beat IVOD,or you may cause damage to outer shell or inner components.
Warranty
Please consult with Iecig distributors for their warranty and return policy,we are not responsible for the
defects caused by human error.Iecig's warranty doesn't apply to products purchased through third
party vendors.

IVAP Software Performance
Shenzhen Iecig technology Co., ltd

Seek “IVAP-S”, you could find
the
app run on samsung android 4.2
Seek“IVAP”, you could
find the app run on android 4.3
and higher
to download and install
Seek“IVAP”, you could
find the app run on IOS 6.1
and higher

Step of Run IVAP:
1、Download and Install IVAP
2、Run IVAP
IVAP
Android
IOS
SamaungAndroid 4.2,
Android 4.3 and higher
Iphone 4S and higher
Ipad 3 and higher
Ipad mini and higher
Ipad touch 5 and higer
running on
IOS6.1
and higher
}
Kindly Reminder:
Please keep the bluetooth function of smart phone on all the time.
The smoking and bluetooth function switch on as default
when the atomizer screw in the battery

2.Home The lock will appear when you setted the smoking plan,if the
actual puff exceed the plan puffs,it will be light,you won’t
smoke anymore,but you can click it to un-lock,or it is dark.
Display working figure
(If the atomizer not screw in the battery,
the risistance is 9.9Ω,power is 0W,
but if it is also that when the atomizer on that battery,
the atomizer has broken,in general,this figure will
be changeable with voltage ).
Smoking status displayed in this page.
Light is connected,dark is not.
Click to show puffs statistics(day,week,month,year)
Auto-changeable according to the rest battery capacity.
Slide to adjust out-put voltage as you like.
IVAP Running
1.Login in
click icon"bluetooth"to seach your ecig.
Click icon "go" to log in.
Open the APP IVAP.

For Android
Puffs statistics(day,week,month,year)
Histogram to show day and week statistics
Scattergram to show month and year statistics
Different Part

For IOS
Different Part
Histogram to show day and week statistics
Scattergram to show month and year statistics
To this page,we adopt wattage counter
(In this right of counter,there are two different models
which are used to show puff statistics in Cigarette1.0).

3.Plan Setting
Click to start plan setting in a week,
then the following page will be appeared.
Click again to start the following week plan
after you completed a week plan setting

ForAndroid
Slide to choose the plan you want to try .
Slide to choose the plan you want to try. Different Part
PlanA:
Set the puffs
keep on in a week.
Plan B:
Set the puffs decrease
progressing in a week.
Plan C:
Set the different
puffs in a week.
