IFoundry Systems USB Serial-IR Adapter IFSYS-8004 Reference guide

www.ifoundrysys.com
Doc. P/N: MDMA01449 Rev. 1.25
© 2008 iFoundry Systems 10 July 2008
Specifications subject to change
IFSYS-8004 USB Serial-IR Adapter Product Brief
The IFSYS-8004 USB Serial-IR Adapter is intended for applications which
need to transfer raw serial data wirelessly over a serial infrared link. It is
ideal for OEMs, and equipment designers who do not wish to make
significant changes to their legacy serial software, but who now require a
wireless means of transferring data. IFSYS-8004 comes with a USB driver
that appears as a virtual serial port in the host system, allowing existing
legacy serial applications to work with little or no modification. IFSYS-8004
hardware simply encodes the serial data stream into IrDATM physical layer
infrared pulses for transmission and demodulates incoming infrared pulses
into serial UART data. Data between host and adapter is transferred over
the USB link. The IFSYS-8004 USB Serial-IR Adapter allows equipment
designers to work with raw serial data without having to worry about the
intricacies of a higher level protocol.
Key features
Converts “raw” serial data to infrared.
Hardware is IrDATM V1.1 physical layer compliant, with a transmit
range of 1m.
USB low power device. Driver appears as a Microsoft Windows™
virtual COM port.
Ideal for industrial and medical equipment and instrumentation
a
pp
lications.
IFSYS-8004 Block Architecture

www.ifoundrysys.com
Doc. P/N: MDMA01449 Rev. 1.25
© 2008 iFoundry Systems 10 July 2008
Specifications subject to change
IFSYS-8004 USB Serial-IR Adapter Product Brief
SPECIFICATIONS
Features
IrDATM V1.1 compliant physical layer hardware, 1m transmit range
Supports SIR communication speeds:
•9,600 bps
•19,200 bps
•57,600 bps
•115,200 bps
Operating System support
Windows XP, XP Professional
Windows 2000, 2000 Professional
Windows Vista
Interface
USB V1.1, compatible with USB V2.0 ports.
Electrical characteristics
Temperature:
•Operating: 0oC to +40oC
•Storage: -20oC to +70oC
Average current consumption:
•~60mA (max.) (transmitting @ 115,200bps)
•~350uA (max.) (USB suspend mode).
Regulatory qualifications
FCC
CE
Safety (EN60950)
Others [*1]
Dimensions
Casing (excluding cable): 49mm (W) x 63mm (L) x 34mm (H).
Cable length: 1.5m
Weight: ~120g
Ordering Information
Order Number Order Description
IFSYS-8004A:3101 Bulk packed units in box of 120. Without CDs and Warranty
cards.
[*1] iFoundry can provide assistance to equipment designer/manufacturer in certifying to other regulatory
standards.
IrDATM is a trademark of the Infrared Data Association.
iFoundry Systems Singapore
Unit 03-20/22
67 Ayer Rajah Crescent
Singapore 139950
