IFR NAV-402AP-3 User manual


5$037(676(7


1$9$3

MASTER
MOD
~
6 0
MONITOR
0
0
0
1 0
.1 1.5
2 0
24
4 0
86
2 0
8 0
10
30%
100%
DDM
LOC MODE
AVG
-dBm
OUTPUT
DDM
G/S TUNE
VAR FREQ
~
~~
m






2SHUDWLRQ0DQXDO
,VVXH

OPERATION MANUAL
RAMP TEST SET
NAV-402AP-3
PUBLISHED BY
IFR, INC.
COPYRIGHT IFR, Inc. 2001
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical, photocopying,
recording or otherwise without the prior permission of the publisher.
Original Printing Jul 1/00
Issue-2 Oct 1/01
10200 West York / Wichita, Kansas 67215 U.S.A. / [phone] / FAX [phone]

OPERATION MANUAL
NAV-402AP-3
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
Nomenclature Statement:
In this manual the NAV-402AP, NAV-402AP Test Set, Test Set or Unit refers
to the NAV-402AP-3 Marker, G/S, VOR, COMM and Auto Pilot Ramp and
Bench Test Set.
For continued EMC compliance, all external cables must be 3 meters or less
in length.

OPERATION MANUAL
NAV-402AP-3
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
SAFETY FIRST: TO ALL OPERATIONS PERSONNEL
REFER ALL SERVICING OF UNIT TO QUALIFIED TECHNICAL PERSONNEL. THIS UNIT CONTAINS NO
OPERATOR SERVICEABLE PARTS.
WARNING: USING THIS EQUIPMENT IN A MANNER OTHER THAN SPECIFIED BY THE ACCOMPANYING
DOCUMENTATION MAY IMPAIR THE SAFETY PROTECTION PROVIDED BY THE EQUIPMENT.
CASE, COVER OR PANEL REMOVAL
Removing the Chassis Assembly from the Case Assembly exposes the operator to electrical hazards that
can result in electrical shock or equipment damage. Operate Test Set only with the Chassis Assembly
installed in the Case Assembly.
SAFETY IDENTIFICATION IN TECHNICAL MANUAL
This manual uses the following terms to draw attention to possible safety hazards, that may exist when
operating this equipment.
CAUTION: THIS TERM IDENTIFIES CONDITIONS OR ACTIVITIES THAT, IF IGNORED, CAN RESULT IN
EQUIPMENT OR PROPERTY DAMAGE (E.G., FIRE).
WARNING: THIS TERM IDENTIFIES CONDITIONS OR ACTIVITIES THAT, IF IGNORED, CAN RESULT IN
PERSONAL INJURY OR DEATH.
SAFETY SYMBOLS IN MANUALS AND ON UNITS
CAUTION: Refer to accompanying documents. (This symbol refers to specific CAUTIONS represented on
the unit and clarified in the text.)
AC OR DC TERMINAL: Terminal that may supply or be supplied with ac or dc voltage.
DC TERMINAL: Terminal that may supply or be supplied with dc voltage.
AC TERMINAL: Terminal that may supply or be supplied with ac or alternating voltage.
EQUIPMENT GROUNDING PRECAUTION
Improper grounding of equipment can result in electrical shock.
USE OF PROBES
Check the specifications for the maximum voltage, current and power ratings of any connector on the Test
Set before connecting it with a probe from a terminal device. Be sure the terminal device performs within
these specifications before using it for measurement, to prevent electrical shock or damage to the
equipment.
POWER CORDS
Avoid using power cords which are frayed, broken or expose bare wiring when operating this equipment.
USE RECOMMENDED FUSES ONLY
Use only fuses specifically recommended for the equipment at the specified current and voltage ratings.
INTERNAL BATTERY
This unit contains a Nickel Cadmium Battery, serviceable only by a qualified technician.
CAUTION: MODE GENERATORS CAN BE A SOURCE OF ELECTROMAGNETIC INTERFERENCE (EMI) TO
COMMUNICATION RECEIVERS. SOME TRANSMITTED SIGNALS CAN CAUSE DISRUPTION
AND INTERFERENCE TO COMMUNICATION SERVICES OUT TO A DISTANCE OF SEVERAL
MILES. USERS OF THIS EQUIPMENT SHOULD SCRUTINIZE ANY OPERATION THAT RESULTS
IN RADIATION OF A MODE (DIRECTLY OR INDIRECTLY) AND SHOULD TAKE NECESSARY
PRECAUTIONS TO AVOID POTENTIAL COMMUNICATION INTERFERENCE PROBLEMS.

OPERATION MANUAL
NAV-402AP-3
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
LIST OF EFFECTIVE PAGES
Page 1
Oct 1/01
LIST OF EFFECTIVE PAGES
CHAPTER/SECTION/SUBJECT PAGE DATE
Title / Copyright Page Oct 1/01
Statements Oct 1/01
Safety Page Jul 1/00
List of Effective Pages 1 Oct 1/01
List of Effective Pages 2 Jul 1/00
Table of Contents 1 through 2 Jul 1/00
Introduction 1 through 2 Jul 1/00
1-Table of Contents 1 through 2 Jul 1/00
1-List of Illustrations 1 through 2 Jul 1/00
1-List of Tables 1 through 2 Jul 1/00
1-1-1 1 through 2 Jul 1/00
1-2-1 1 through 4 Jul 1/00
1-2-2 1 through 10 Jul 1/00
1-2-3 1 through 12 Jul 1/00
1-3-1 1 through 12 Jul 1/00
1-4-1 1 through 2 Jul 1/00
1-5-1 1 through 2 Jul 1/00
Appendix A 1 through 2 Jul 1/00
Appendix B 1 through 2 Jul 1/00
Appendix C 1 through 2 Jul 1/00
Index 1 through 2 Jul 1/00

OPERATION MANUAL
NAV-402AP-3
LIST OF EFFECTIVE PAGES
Page 2
Jul 1/00
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
TABLE OF CONTENTS
Page 1
Jul 1/00
TABLE OF CONTENTS
Title Chapter/Section
Title Page
Copyright Page
Statements
Safety Page
Record of Revisions
List of Effective Pages
Table of Contents
Introduction
Chapter 1
Section 1 - Description 1-1
Section 2 - Operation 1-2
Section 3 - Specifications 1-3
Section 4 - Shipping 1-4
Section 5 - Storage 1-5
Appendix A - Table of I/O Connectors
Appendix B - Metric/British Imperial Conversion Table with Nautical
Distance Conversions
Appendix C - Abbreviations
Index

OPERATION MANUAL
NAV-402AP-3
TABLE OF CONTENTS
Page 2
Jul 1/00
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
INTRODUCTION
Page 1
Jul 1/00
INTRODUCTION - NAV-402AP TEST SET
This manual contains NAV-402AP operating instructions for Marker, G/S, VOR, LOC, COMM
and Auto Pilot systems. It is strongly recommended that personnel be thoroughly familiar
with the contents of this manual before attempting to operate this equipment.
Refer all servicing of unit to qualified technical personnel.
ORGANIZATION
This manual is divided into the following Chapters and Sections:
CHAPTER 1 - OPERATION
Section 1 - DESCRIPTION (description of the NAV-402AP)
Section 2 - OPERATION (installation; description of controls, connectors and
indicators; and general operating procedures)
Section 3 - SPECIFICATIONS
Section 4 - SHIPPING
Section 5 - STORAGE

OPERATION MANUAL
NAV-402AP-3
INTRODUCTION
Page 2
Jul 1/00
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
1-TABLE OF CONTENTS
Page 1
Jul 1/00
CHAPTER ONE
NAV-402AP TEST SET
OPERATION MANUAL
TABLE OF CONTENTS
Title Chapter/Section/Subject Page
SECTION 1 - DESCRIPTION
1. General Description and Capabilities 1-1-1 1
1.1 Description 1-1-1 1
1.2 Functional Capabilities 1-1-1 1
SECTION 2 - OPERATION
1. Installation 1-2-1 1
1.1 General 1-2-1 1
1.2 Battery Operation 1-2-1 1
1.3 Battery Charging 1-2-1 1
1.4 Safety Precautions 1-2-1 1
1.4.1 Complying with Instructions 1-2-1 1
1.4.2 Grounding Power Cord 1-2-1 1
1.4.3 Operating Safety 1-2-1 1
1.4.4 CAUTION and WARNING Labels 1-2-1 2
1.5 AC Power Requirements 1-2-1 2
1.6 FCC Requirements 1-2-1 2
1.7 Battery Recharging 1-2-1 2
1.8 Bench Operation 1-2-1 3
1.9 External Cleaning 1-2-1 3
2. Controls, Connectors And Indicators 1-2-2 2
2.1 Front Panel 1-2-2 4
2.2 Rear Panel 1-2-2 10
3. General Operating Procedures 1-2-3 1
3.1 General 1-2-3 1
3.2 Signals Simulated 1-2-3 1
3.3 Operation CAUTIONS 1-2-3 1
3.4 Ramp Operation 1-2-3 1
3.5 Bench Operation 1-2-3 2
3.6 Counter Operation 1-2-3 2
3.7 Battery Parameters 1-2-3 2
3.8 Operate LOC and G/S Simultaneously 1-2-3 2
3.9 Marker Operation (Typical Control Settings) 1-2-3 3
3.10 VOR Operation (Typical Control Settings) 1-2-3 4
3.11 Localizer Operation (Typical Control Settings) 1-2-3 5
3.12 Glide Slope Operation (Typical Control Settings) 1-2-3 6
3.13 Communication Operation (Receiver Tests)
(Typical Control Settings) 1-2-3 7
3.14 Communication Operation (Transmitter Tests)
(Typical Control Settings) 1-2-3 8

OPERATION MANUAL
NAV-402AP-3
1-TABLE OF CONTENTS
Page 2
Jul 1/00
Title Chapter/Section/Subject Page
SECTION 3 - SPECIFICATIONS
1. NAV-402AP Specifications 1-3-1 1
1.1 RF Output 1-3-1 1
1.2 Marker Mode 1-3-1 2
1.3 VOR Mode 1-3-1 3
1.4 LOC Mode (Primary or Auxiliary) 1-3-1 4
1.5 G/S Mode 1-3-1 5
1.6 COM Mode 1-3-1 6
1.7 External Frequency Counter 1-3-1 7
1.8 Power Meter 1-3-1 8
1.9 Battery Level Monitor 1-3-1 8
1.10 Bearing Monitor 1-3-1 8
1.11 Battery 1-3-1 8
1.12 AC Power 1-3-1 9
1.13 Environmental 1-3-1 9
SECTION 4 - SHIPPING
1. Shipping Test Sets 1-4-1 1
1.1 Information 1-4-1 1
1.2 Repacking Procedure 1-4-1 1
SECTION 5 - STORAGE
1. Storing Test Sets 1-5-1 1

OPERATION MANUAL
NAV-402AP-3
1-LIST OF ILLUSTRATIONS
Page 1
Jul 1/00
LIST OF ILLUSTRATIONS
Title Chapter/Section/Subject Page
Battery Recharging 1-2-1 3
NAV-402AP Front and Rear Panels 1-2-2 2
Repacking Procedure 1-4-1 2

OPERATION MANUAL
NAV-402AP-3
1-LIST OF ILLUSTRATIONS
Page 2
Jul 1/00
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
NAV-402AP-3
1-LIST OF TABLES
Page 1
Jul 1/00
LIST OF TABLES
Title Chapter/Section/Subject Page
Specified Fuse Ratings 1-2-1 2
Correspondence Chart for Decibels, Volts and Watts 1-2-3 9
Correspondence Chart for 90 Hz and 150 Hz Tones (LOC) 1-2-3 12
Correspondence Chart for 90 Hz and 150 Hz Tones (G/S) 1-2-3 12
VOR Bearing Select Switches 1-3-1 10
90 Hz and 150 Hz Tones Variable Phase Relationships 1-3-1 11

OPERATION MANUAL
NAV-402AP-3
1-LIST OF TABLES
Page 2
Jul 1/00
THIS PAGE INTENTIONALLY LEFT BLANK.

OPERATION MANUAL
IFF-701Ti
1-1-1
Page 1
Jul 1/00
SECTION 1 - DESCRIPTION
1. GENERAL DESCRIPTION AND
CAPABILITIES
1.1 DESCRIPTION
The NAV-402AP is a Bench and Ramp Test
Set designed to meet the electronic
functional test requirements of Category I
and Category II ILS Systems,
Communication (COMM), Navigation (NAV)
and Marker (MKR) Systems.
The NAV-402AP contains features to allow
testing of sophisticated autopilot systems.
These features include: automatic LOC
DDM, automatic sweep, two fixed VOR
frequencies; and two fixed, paired LOC and
G/S frequencies.
1.2 FUNCTIONAL CAPABILITIES
The NAV-402AP has the following features
and capabilities:
● Signal Generator with a variable
attenuator which can be connected to
the equipment under test by a radiated
signal from a self-contained antenna or
by a coaxial cable. The signal
generator can be operated under either
fixed frequency control or in variable
frequency mode in each band.
● The generator can be modulated
internally by a 1020 Hz Ident Tone,
Marker, VHF Omnidirectional Range
(VOR), Localizer (LOC) or Glide Slope
(G/S) Tones.
● A six-digit counter which indicates the
RF of the signal generator on any band,
the frequency of a COM Transmitter
under test, any external signal input
from 1 MHz to at least 300 MHz, or the
VOR Bearing selected by the Bearing
Select Switches.
● A built-in RF power meter measures
COM Transmitter power, from 0-10W or
0-100W, either peak or average power
by selecting a switch position located on
the Front Panel. A COM Transmitter
demodulation output permits viewing or
listening to COM modulation.
● A built-in modulation meter measures
Signal Generator Percent of Modulation
on any frequency band from 0-30% or
0-100%. Front Panel controls permit
quick setting of modulation percentages.
● A 90°bearing check monitor allows
quick verification of basic VOR bearing
from the VOR demod signal.
● A NICAD battery and built-in charging
system permit completely portable
operation for up to 2 hours continuous
duty. Any time the Test Set is plugged
to an ac line, the battery is being
charged. In battery operation, an
automatic timer turns the Test Set off
after 6 to 10 minutes. The Test Set can
be recycled by pressing the PWR/BAT
Switch to the BAT position.
