Ignis AWV 508 User manual

5019 100 01018
Programme Type of fabrics / Degree of soiling / Notes Max.
Load
kg
Detergent and Additives Option Temperature
°C
Maximum
Spin Speed
rpm
Programme
time
approx.
min (1)
Prewash Washing Softener Half Load
Cotton with
Prewash Heavily soiled sheets, tablecloths, underclothes, shirts etc. in hard
wearing and high temperature resistant cotton.
The maximum load for heavily soiled washing is 3.5 kg. 4.5 Yes Yes ❉❉ 90 550 130
Cotton Averagely soiled, hard wearing and temperature stable textiles in
cotton and linen (bed linen, table linen, underwear, shirts, etc.). 4.5 —Yes ❉❉ 90 550 115
Coloured Cotton Moderately soiled sheets, tablecloths, underclothes, towels, etc.
in hard wearing and temperature resistant cotton. 4.5 —Yes ❉❉ 60 550 90
Synthetics Blouses, shirts, cotton blouses, dark coloured terry towelling,
jeans, etc. lightly soiled. 2.0 —Yes ❉❉ 40 550 70
Rinse + Spin This programme allows starch or softener to be added.
It is followed by an intensive spin cycle. 4.5 —— ❉—Cold 550 20
Spin Programme for intensive spin cycle. 4.5 —— — — — 550 15
Delicate Delicate fabrics and curtains (dresses, skirts, shirts, blouses,
etc.). 1.5 —Yes ❉—40 550 55
Wool Machine washable woollens with pure new wool label. 1.0 —Yes ❉—40 550 45
Rinse + Spin This programme allows starch or softener to be added.
It is followed by a gentle spin cycle. 1.5 —— ❉—Cold 550 15
Spin Programme for gentle spin cycle. 1.5 —— ———
550 10
Drain Drain only, without spin cycle. —— — ————
5
(1)Programme duration
figures (guideline) are
valid for maximum
temperature wash with
no special functions.
GB PROGRAMME TABLE
AWV 508
Half Load
Option Spin
Cotton Delicate
Prewash Wool
Coloured
Cotton Drain
Synthetics On/Off
Rinse + Spin
N.B.: The excess of detergent in the dispenser could cause technical problems.

5019 100 01018
Programmes with prewash last about 15 minutes more than programmes without prewash. Water and energy
consumption values were measured in standard conditions in compliance with the Standard IEC 60 456. Individual
consumption may vary in comparison with the values specified in the table, because of differences in supply water
pressure and temperature, the load and the type of wash.
ADDING DETERGENT AND ADDITIVES
Pour the detergent and additives into the respective
compartments as follows:
•Programme with pre and main wash
•Main wash programme without prewash
•Fabric softeners and starch
•Stain removers
•Anti-scale agents (water hardness 4)
Important Note:
•Do not fill beyond the “MAX”level mark.
•For programme with prewash: do not use liquid
detergent.
•For programmes without prewash from cold to 40°C, it is recommended to use a liquid
detergent to avoid whitish residues on the coloured laundry.
CLOSE THE DOOR AND SELECT THE PROGRAMME
•Turn the programme selector knob clockwise to the desired programme.
PRESS ANY DESIRED OPTION BUTTON(S)
“Half Load”button
•Reduces the water consumption in the “Cotton”and “Synthetics”programmes
especially during the rinse.
•Especially suitable for lightly soiled or small loads (reduces the quantity of detergent).
•Not suitable for high temperature programmes.
PROGRAMME START
Open the water inlet tap and press the “On/Off”button. The pilot lamp lights up.
DOOR LOCK
During the running programme, the door cannot be opened.
The door locks automatically in all programmes.
If the programme is stopped or if an electrical power failure occurs, the door unlocks
automatically after about 1 minute.
PROGRAMME END
•The programme selector knob is at “STOP”.
1. Press the “On/Off”button. The pilot light goes out.
2. Cancel the option by pressing the appropriate button.
3. Turn the water supply tap off.
4. Wait for the door to unlock (about 1 minute).
5. Open the door and the drum flaps and unload the machine.
SELECTING A NEW PROGRAMME, SPIN SPEED, OPTIONS AFTER
PROGRAMME START
1. Press the “On/Off”button to switch off the appliance.
The pilot light goes out.
2. Select the new programme and option.
3. Press the “On/Off”button to switch on the appliance.
The pilot light lights.
TO STOP, RESET A PROGRAMME BEFORE THE END
1. Press the “On/Off”button to switch off the appliance.
The pilot light goes out.
2. Set the programme selector on “Drain”.
3. Press the “On/Off”button to start the “Drain”programme.
Only open the door when the programme selector is at “STOP”and
the door is unlocked (after approximately 1 minute).
ENERGY AND WATER CONSUMPTION DATA
Programme Temperature
(°C)
Load
(kg)
Water
(l)
Energy
(kWh)
Programme
time
(min)
Cotton 90 4.5 69 1.75 115
Coloured Cotton 60 4.5 69 0.95 90
Synthetics 40 2.0 66 0.35 70
Delicate 40 1.5 70 0.65 55
Wool 40 1.0 70 0.55 45
GB
