Iiyama AQ5311D BK User manual

USER MANUAL
DEUTSCH
ENGLISH
NEDERLANDS
FRANCAIS
TABLE OF CONTENTS
Thank you very much for choosing the iiyama LCD monitor.
We recommend that you take a few minutes to read carefully through this brief but
comprehensive manual before installing and switching on the monitor. Please keep this
manual in a safe place for your future reference.
FOR YOUR SAFETY .............................................................................. 1
SAFETY PRECAUTIONS ................................................................. 1
SPECIAL NOTES ON LCD MONITORS ............................................. 3
CUSTOMER SERVICE ...................................................................... 3
CLEANING ....................................................................................... 3
BEFORE YOU OPERATE THE MONITOR ................................................ 4
FEATURES ....................................................................................... 4
CHECKING THE CONTENTS OF THE PACKAGE ............................. 4
CONTROLS AND CONNECTORS .................................................... 5
CONNECTING YOUR MONITOR ...................................................... 6
COMPUTER SETTING ....................................................................... 8
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE ....................
PANEL ROTATION ............................................................................
OPERATING THE MONITOR ................................................................... 10
ADJUSTMENT MENU CONTENTS .................................................... 11
SCREEN ADJUSTMENTS ................................................................. 14
POWER MANAGEMENT FEATURE .................................................. 17
TROUBLE SHOOTING ............................................................................ 18
APPENDIX .............................................................................................. 1
SPECIFICATIONS ............................................................................. 1
COMPLIANT TIMING ......................................................................... 20
CONNECTOR PIN ASSIGNMENT ...................................................... 21
SVENSKA
AQ5311D
AQ5311D BK
ITALIANO
All manuals and user guides at all-guides.com
all-guides.com

ENGLISH
CE MARKING DECLARATION OF CONFORMITY
This LCD monitor complies with the requirements of the EC Directive 89/336/EEC “EMC Directive” nd 73/23/EEC
“Low Volt ge Directive” s mended by Directive 93/68/EEC.
The electro-m gnetic susceptibility h s been chosen t level th t gives correct oper tion in residenti l re s,
business nd light industri l premises nd sm ll-sc le enterprises, inside s well s outside of the buildings. All
pl ces of oper tion re ch r cterised by their connection to the public low volt ge power supply system.
This digit l pp r tus does not exceed the Cl ss B limits for r dio noise emissions from digit l pp r tus s set out
in the r dio interference regul tion of the C n di n dep rtment of communic tions.
CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE
STATEMENT
nWe reserve the right to change specifications without notice.
nAll trademarks used in this user manual are the property of their respective owners.
nThis manual is printed on recycled paper.
FCC DECLARATION OF CONFORMITY
Model Number: AQ5311D / AQ5311D BK
Trade Name: iiy m
Responsible party: IIYAMA North Americ , Inc.
Address: 1560 Brookhollow Drive, Suite 208, S nt An , CA 92705 U.S.A.
Telephone number: 714-437-5111
This device complies with P rt 15 of the FCC Rules. Oper tion is subject to the following two conditions: (1) This
device m y not c use h rmful interference, nd (2) this device must ccept ny interference received, including
interference th t m y c use undesired oper tion.
This device h s been tested nd found to comply with the limits for Cl ss B Person l Computers nd peripher ls,
pursu nt to P rt 15 of the FCC Rules. These limits re designed to provide re son ble protection g inst h rmful
interference when the device is oper ted in residenti l environment. This device gener tes, uses nd c n r di te
r dio frequency energy, nd if not inst lled nd used in ccord nce with the instructions, m y c use h rmful
interference to r dio communic tions. However, there is no gu r ntee th t interference will not occur in p rticul r
inst ll tion. If you determine the device does c use h rmful interference to r dio or television reception (this m y
be determined by monitoring the interference while turning the device off nd on), you re encour ged to try to
correct the interference by one of the following me sures:
nReorient or reloc te the receiving ntenn .
nIncre se the sep r tion between the device nd receiver.
nConnect the device into n outlet on circuit different from th t to which the receiver is
connected.
nConsult the de ler or n experienced r dio or TV technici n for help.
To meet the FCC requirements, you should use sign l c ble with ferrite core t both ends.
CAUTION Ch nges or modific tions not expressly pproved by iiy m could void the users uthority to
oper te the device under FCC compli nce regul tions.
All manuals and user guides at all-guides.com

ENGLISH
FOR YOUR SAFETY
WARNING
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and
contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause
fire or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the monitor. Removing the cabinet may expose you to the danger of fire or
electric shock.
DO NOT PUT ANY OBJECT INTO THE MONITOR
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your
monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object
inside may cause fire, electric shock or damage.
INSTALL THE MONITOR ON A FLAT, STABLE SURFACE
The monitor may cause an injury if it falls or is dropped.
DO NOT USE THE MONITOR NEAR WATER
Do not use where water may be splashed or spilt onto the monitor as it may cause fire or electric shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the monitor only with the specified power supply. Use of an incorrect voltage will
cause malfunction and may cause fire or electric shock.
PROTECT THE CABLES
Do not pull or bend the power cable and signal cable. Do not place the monitor or any other heavy objects
on the cables. If damaged, the cables may cause fire or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the monitor during a heavy thunder storm as the continual breaks in power
may cause malfunction. It is also advised not to touch the plug in these circumstances as it may cause
electric shock.
SAFETY PRECAUTIONS
FOR YOUR SAFETY 1
All manuals and user guides at all-guides.com

ENGLISH
CAUTION
INSTALLATION LOCATION
Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky
areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines
directly on the monitor.
DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION
The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place
any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables
and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the monitor from overheating. Covering the slots may cause fire. To
allow adequate air circulation, place the monitor at least 10 cm (or 4 inches) from any walls.
Do not remove the tilt stand when operating the monitor. Ventilation slots on the back of the cabinet will be
blocked and the monitor may overheat if the stand is removed. This may cause fire or damage. Operating
the monitor on its back, side, upside down or on a carpet or any other soft material may also cause
damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE MONITOR
When you move the monitor, turn off the power switch, unplug the monitor and be sure the signal cable
is disconnected. If you do not disconnect them, it may cause fire or electric shock.
UNPLUG THE MONITOR
If the monitor is not in use for a long period of time it is recommended that it is left unplugged to avoid
accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable itself as
this may cause fire or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE MONITOR ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the monitor, otherwise, you may damage your
computer.
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the monitor against a bright background or in a dark room. For
optimal viewing comfort, the monitor should be just below eye level and 40-60 cm (16-24 inches) away
from your eyes. When using the monitor over a prolonged time, a ten minute break every hour is
recommended as looking at the screen continuously can cause eye strain.
OTHERS
2 FOR YOUR SAFETY
All manuals and user guides at all-guides.com

ENGLISH
The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE When you first turn on the LCD monitor, the picture may not fit in the display area
because of the type of computer that is used. In this case, adjust the picture position to
its correct position.
n
Due to the nature of the LCD screen, an afterimage of the previous screen may remain
after switching the image, when the same image is displayed for hours. In this case, the
screen is recovered slowly by changing the image or turning off the Power Switch for
hours.
n
You may find slightly uneven brightness on the screen depending on the desktop pattern
you use.
n
SPECIAL NOTES ON LCD MONITORS
FOR YOUR SAFETY 3
Contact your dealer or iiyama service center for the backlight replacement when the
screen is dark, flickering or not lighting up. Never attempt to replace it by yourself.
n
Due to the nature of the backlight, the screen may flicker during initial use. Turn off the
Power Switch and then turn it on again to make sure the flicker disappears.
n
NOTE The fluorescent light used in the LCD monitor may have to be periodically replaced. For
the warranty coverage on this component, please check with local iiyama service center.
If you have to return your unit for service and the original packaging has been discarded,
please contact your dealer or iiyama service center for advice or replacement packaging.
n
n
WARNING If you drop any materials or liquids such as water into the monitor when cleaning, unplug
the power cable immediately and contact your dealer or iiyama service center.
n
CAUTION For safety reasons, turn off the power switch and unplug the monitor before you clean it.n
NOTE To protect the LCD panel, do not scratch or rub the screen with a hard object.
n
Never use any of the following strong solvents. These will damage the cabinet and the
LCD screen.
n
Thinner
Benzine
Abrasive cleaner
Spray-type cleaner
Wax
Acid or Alkaline solvent
Touching the cabinet with any product made from rubber or plastic for a long time may
cause degeneration or loss of paint on the cabinet.
n
CABINET Stains can be removed with a cloth lightly moistened with a mild detergent solvent. Then
wipe the cabinet with a soft dry cloth.
LCD
SCREEN
Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.
CUSTOMER SERVICE
CLEANING
All manuals and user guides at all-guides.com

ENGLISH
4 BEFORE YOU OPERATE THE MONITOR
FEATURES
The following accessories are included in your package. Check to see if they are enclosed with the monitor. If
anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office.
nPower Cable*1
nAC Adapter
nD-Sub Signal Cable MB32*2, MB36*3
nDVI-D Signal Cable DV65*2, DV64*3
nCable Cover
nAC Adapter Holder
nBand
nScrew
nUser Manual
CAUTION *1 TO USERS IN 120V AREA
The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using a
power supply higher than this rating, then a power cable with a rating of 10A/250V must
be used.
K52.8cm 20.8") TFT Color LCD Monitor
KSupports Resolutions up to 2048 × 1536 QXGA)
KSuper Wide Viewing Angle and High Resolution
KDigital Character Smoothing
KAutomatic Set-up
KPlug & Play VESA DDC2B Compliant
Windows® 95/98/2000/Me/XP Compliant
KPower Management
KErgonomic Design: MPR3 Approved
KDigital Input DVI-I) for Clear Display
K90° Panel Rotation Design
KVESA Standard 100mm×100mm) Compliant
CHECKING THE CONTENTS OF THE PACKAGE
BEFORE YOU OPERATE THE MONITOR
*2Accessory for AQ5311D
*3Accessory for AQ5311D BK (Cabinet color: Black)
Please remove the sto er in on the back of the stand before you install the monitor.
Careful attention is required as the monitor is s rung loaded and may ex and quickly
when removing it.
Stopper pin
All manuals and user guides at all-guides.com
all-guides.com

ENGLISH
CONTROLS AND CONNECTORS
APower Indicator
Green: Normal operation
Orange: Power Management
The monitor enters into power management mode which reduces the power
consumption to less than 13.5W when receiving no horizontal and/or vertical sync
signal.
BPower Switch
CMenu Button
D / Contrast Button
E / Brightness Button
FExit Button
GKeyhole for Security Lock
You can fasten a security lock and cable to prevent the monitor from being removed without
your permission.
HConnector for AC Adapter (DC-IN)
ID-Sub mini 15pin Connector (ANALOG RGB)
JDVI-I 2 pin Connector (DVI)
< Front > < Back >
NOTE
NOTE
BEFORE YOU OPERATE THE MONITOR 5
All manuals and user guides at all-guides.com

ENGLISH
6 BEFORE YOU OPERATE THE MONITOR
CONNECTING YOUR MONITOR
[Example of Connection]
Power Cable (Accessory)
to D-Sub connector
of computer Computer
to DVI connector
of computer
< Back >
DVI-D Signal Cable
DV64/DV65 (Accessory)
D-Sub Signal Cable
MB32/MB36 (Accessory)
AC Adapter (Accessory)
AEnsure that both the computer and the monitor are switched off.
BConnect the computer to the monitor with the signal cable. (See page 21 for CONNECTOR PIN
ASSIGNMENT.)
CConnect the AC Adapter to the Connector for AC Adapter of the monitor.
DConnect the Power Cable to the AC Adapter first and then to the power supply.
NOTE nThe signal cables used for connecting the computer and monitor vary by the type of computer
used. An incorrect connection may cause serious damage to both the monitor and the computer.
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is
required please contact your local iiyama dealer or regional iiyama office.
nFor connection to Macintosh computers, contact your local iiyama dealer or regional iiyama
office for a suitable adaptor.
nMake sure you tighten the finger screws at each end of the signal cable.
nCables are connected easily by rotating the panel 0 degrees. (See page for PANEL
ROTATION.)
nCables can be bundled together inside the Cable Cover at the back of the stand. See next page
for cable wiring.
nAC Adapter can be fastened on the back of the monitor with the AC Adapter Holder. See next
page for AC Adapter installation.
All manuals and user guides at all-guides.com

ENGLISH
BEFORE YOU OPERATE THE MONITOR 7
[Cable Wiring]
ACollect cables at the back of the stand.
BPlace the Cable Cover by inserting the tabs into
guide holes and then sliding the cover
downward.
[AC Adapter Installation]
AAttach the AC Adapter Holder to the
AC Adapter.
BPlace the AC Adapter Holder by
inserting the tabs into the cavities
on the back of the monitor.
CTighten the Screw to fasten the AC
Adapter Holder.
DBundle up the adapter cable with the
Band.
AC Adapter
(Accessory)
AC Adapter Holder
(Accessory)
Screw (Accessory)
Cavity
Band (Accessory)
Push to loosen
the Band.
All manuals and user guides at all-guides.com

ENGLISH
8 BEFORE YOU OPERATE THE MONITOR
COMPUTER SETTING
nSignal Timing
When you connect the monitor to the computer for the first time, set the signal timing of the computer to
VGA before connection. Change to the desired signal timings listed on page 20 in COMPLIANT TIMING,
after you confirm that the picture appears normally at VGA.
nWindows 5/ 8/2000/Me/XP Plug & Play
The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on
Windows 5/ 8/2000/Me/XP by connecting the monitor to DDC2B compliant computer with the Signal
Cable supplied. Windows 5/ 8/2000/Me/XP Monitor Information File for iiyama monitors may be
necessary for your computer and obtained via the Internet, using the address:
http://www.iiyama.com (U.S.A.)
http://www.iiyama.co.uk (U.K.)
NOTE nFor additional information on how to download the driver for your monitor, please
access one of the internet sites noted above.
nMonitor Drivers are not required in most cases for Macintosh or Unix operating systems.
For further information, please contact your computer dealer first for advice.
All manuals and user guides at all-guides.com

ENGLISH
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE
PANEL ROTATION
AAdjust the monitor’s height to the maximum.
BRotate the panel 0 degrees.
Portrait: Turn clockwise.
Landscape: Turn counter clockwise.
NOTE Attempting to rotate without fully
extending upward may cause damage
to stand.
CAdjust the monitor’s angle to your preference.
nFor optimal viewing it is recommended to look at
the full face of the monitor, then adjust the monitor’s
height and angle to your own preference.
nHold the panel so that the monitor does not topple
when you change the monitor’s height or angle.
nYou are able to adjust the monitor’s height up to
110 mm, angle up to 35 degrees right and left, 35
degrees upward.
NOTE nDo not touch the LCD screen when you
change the height or the angle. It may
cause damage or break the LCD screen.
nCareful attention is required not to catch
your fingers or hands when you change
the height or the angle.
BEFORE YOU OPERATE THE MONITOR 9
90˚
110mm
35˚35˚
35˚
All manuals and user guides at all-guides.com
all-guides.com

ENGLISH
10 OPERATING THE MONITOR
OPERATING THE MONITOR
To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT
TIMING shown on page 20. You are also able to adjust the picture by following the button operation shown
below. For more detailed adjustments, see page 14 for SCREEN ADJUSTMENTS.
(Press the Menu Button to start the On Screen Display feature. Move the cursor
by using the / Buttons.
BSelect the adjustment icon relating to the adjustment you want to make by
using the / Buttons. Press the Menu Button again.
The On Screen Display disappears in optional setting seconds after you stop pressing the buttons
while performing an adjustment. (See pages 12 and 13 for OSD TIME.)
Any changes are automatically saved in the memory when the On Screen Display disappears. Turning
off the power should be avoided while using the Menu.
n
NOTE
CUse the / Buttons to make the appropriate adjustment or setting.
Adjustments for FINE, COARSE and POSITION are saved for each signal timing. Except for these
adjustments, all other adjustments have only one setting which applies to all signal timings.
n
n
DPress the Exit Button to return to the previous display. Any changes are
automatically saved in the memory.
MAIN MENU
MAIN MENU
BRIGHTNESS
Adjustment icon
Adjustment menu item
presently selected
All manuals and user guides at all-guides.com

ENGLISH
ADJUSTMENT MENU CONTENTS
You can skip the Menu display and perform an adjustment immediately by using the following
button operations.
lBrightness: Press the Brightness Button when the Menu is not displayed.
lContrast: Press the Contrast Button when the Menu is not displayed.
lAutomatic set-up: Press the and Buttons at the same time when the Menu is not displayed.
*1Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too bright.
*2See page 14 for SCREEN ADJUSTMENTS.
Direct
Analog / DVI-Analog Input
OPERATING THE MONITOR 11
Adjustment Item Problem / Option Button to Press
BRIGHTNESS *1
Direct
CONTRAST
Direct
Direct
IMAGE SET-UP AUTO *2
MANUAL FINE
COARSE
COLOR PRESET1
PRESET2
PRESET3
USER
MODE
RED
GREEN
BLUE
OSD POSITION H-POS
V-POS
INPUT SELECTION ANALOG
DVI-ANALOG
DVI-DIGITAL
Too dark
Too bright
Too dull
Too intense
Adjust FINE, COARSE, H-POSITION and V-
POSITION automatically.
To correct flickering text or lines
300K
6500K
5500K
Too weak
Too strong
Too far to the left
Too far to the right
Too low
Too high
Select the Analog RGB input.
Select the DVI-Analog input.
Select the DVI-Digital input.
All manuals and user guides at all-guides.com

ENGLISH
12 OPERATING THE MONITOR
The picture is displayed at the optimum resolution.
Stretch the picture to fit the full screen.
Adjustment Item Problem / Option Button to Press
H-POSITION Too far to the left
Too far to the right
V-POSITION Too low
Too high
IMAGE SIZE *3NORMAL
EXPANDED
LANGUAGE ENGLISH
FRANCAIS
DEUTSCH
ITALIANO
ESPANOL
JAPANESE
English
French
German
Italian
Spanish
Japanese
OSD TIME
INFORMATION
You can set the OSD display duration time
between 5 and 60 seconds.
The model name, year of manufacture, the
current horizontal scan frequency and vertical
refresh rate are displayed.
*3Main Menu does not appear on the screen if you press the Menu Button while you select NORMAL at
resolution of less than XGA (1024×768). Select EXPANDED temporarily to display the Main Menu.
All manuals and user guides at all-guides.com

ENGLISH
Direct
Direct
OPERATING THE MONITOR 13
DVI-Digital Input
Adjustment Item Problem / Option Button to Press
BRIGHTNESS *1
CONTRAST
COLOR PRESET1
PRESET2
PRESET3
USER
MODE
RED
GREEN
BLUE
OSD POSITION H-POS
V-POS
INPUT SELECTION ANALOG
DVI-ANALOG
DVI-DIGITAL
Too dark
Too bright
Too dull
Too intense
300K
6500K
5500K
Too weak
Too strong
Too far to the left
Too far to the right
Too low
Too high
Select the Analog RGB input.
Select the DVI-Analog input.
Select the DVI-Digital input.
Stretch the picture to fit the full screen.
IMAGE SIZE *2NORMAL
EXPANDED
LANGUAGE
ENGLISH
FRANCAIS
DEUTSCH
ITALIANO
ESPANOL
JAPANESE
English
French
German
Italian
Spanish
Japanese
The picture is displayed at the optimum resolution.
OSD TIME
INFORMATION
You can set the OSD display duration time
between 5 and 60 seconds.
The model name, year of manufacture, the current
horizontal scan frequency and vertical refresh
rate are displayed.
*1Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too bright.
*2Main Menu does not appear on the screen if you press the Menu Button while you select NORMAL at
resolution of less than XGA (1024×768). Select EXPANDED temporarily to display the Main Menu.
All manuals and user guides at all-guides.com

ENGLISH
14 OPERATING THE MONITOR
SCREEN ADJUSTMENTS
nThe screen adjustments described in this manual are designed to set image position and minimize flicker
or blur for the particular computer in use. They are unlike the adjustments you would make on a CRT
monitor.
nThe monitor is designed to provide the best performance at resolution of 2048 × 1536, but can not provide
the best at resolutions of less than 2048 × 1536 because the picture is automatically stretched to fit the
full screen or displayed at optimum resolution. It is recommended to operate at resolution of 2048 × 1536
in normal use.
nDisplayed text or lines will be blurred or irregular in thickness when the picture is stretched due to the
screen enlargement process.
nIt is preferable to adjust the image position and frequency with the monitor controls, rather than the
computer software or utilities.
nPerform adjustments after a warm-up period of at least thirty minutes.
nAdditional adjustments may be required after the Automatic set-up depending on the resolution or signal
timing.
nThe Automatic set-up may not work correctly when displaying the picture other than the Test.bmp
(screen adjustment pattern). In this case, manual adjustments are required.
Zebr p ttern
This is the im ge
displ yed t 2048 × 1536.
Color b r
Picture fr me
Adjust the image by following the procedure below to get the desired picture when selecting Analog input.
There are two ways to adjust the screen. One way is automatic adjustment for FINE, COARSE and
POSITION. Another way is performing each adjustment manually.
Perform the Automatic set-up first when the monitor is connected to a new computer, or resolution is
changed. If the screen has a flicker or blur, or the picture does not fit in the display area after performing
the Automatic set-up, manual adjustments are required. Both adjustments should be made by using the
screen adjustment pattern (Test.bmp) obtained via the iiyama web site (http://www.iiyama.com or http:/
/www.iiyama.co.uk).
This manual explains adjustment under Windows 5/ 8/2000/Me/XP.
ASet the IMAGE SIZE feature to NORMAL and dis lay the icture at the o timum resolution.
BEnter the Test.bm (screen adjustment attern) to wall a er.
NOTE nConsult the appropriate documentation for doing this.
nTest.bmp is made at resolution of 2048 × 1536. Set the display position to center in the
wallpaper setting dialogue box. If you use Microsoft® PLUS! 5/ 8 cancel the setting of
“Stretch desktop wallpaper to fit the screen”.
[Adjustment pattern]
All manuals and user guides at all-guides.com
all-guides.com

ENGLISH
F1) Adjust the H-POSITION so that the left side of the icture frame will move to the left
edge of the dis lay area.
NOTE nWhen the left side of the picture frame moves apart from the left edge of the display area
during the COARSE adjustment, adjust steps 1) and 2).
nAnother way to make the COARSE adjustment is to correct the vertical wavy lines in the
zebra pattern.
nThe picture may flicker during the COARSE, H-POSITION and V-POSITION adjustment.
nIn case the picture frame is bigger or smaller than the data display area after the COARSE
adjustment, repeat steps from C.
2) Stretch the right side of the icture frame to the right edge of the dis lay area by
adjusting the COARSE in IMAGE SET-UP.
CSelect AUTO in IMAGE SET-UP and erform the Automatic set-u .
Or ress the and Buttons at the same time when the Menu is not dis layed.
(Direct adjustment)
DAdjust the image manually by following rocedure below when the screen has a flicker or
blur, or the icture does not fit in the dis lay area after erforming the Automatic set-u .
EAdjust the V-POSITION so that the to and bottom of the icture frame will fit to the
dis lay area.
OPERATING THE MONITOR 15
All manuals and user guides at all-guides.com

ENGLISH
16 OPERATING THE MONITOR
NOTE nIn case the strong flicker or blurs remain on a part of the screen, repeat steps F and G
because the COARSE may not be adjusted correctly. If the flicker or blurs still remain, set
the refresh rate of computer to low (60Hz) and repeat steps from C again.
nAdjust the H-POSITION after the FINE adjustment if the horizontal position moves during the
adjustment.
HAdjust the BRIGHTNESS and COLOR to get the desired icture after you com lete the FINE
and COARSE adjustments.
Put back your favorite wall a er.
GAdjust the FINE in IMAGE SET-UP to correct horizontal wavy noise, flicker or blur in the
zebra attern.
All manuals and user guides at all-guides.com

ENGLISH
Even when using the power management mode, the monitor consumes electricity. Turn off
the Power Switch whenever the monitor is not in use, during the night and weekends, to
avoid unnecessary power consumption.
NOTE n
It is possible that the video signal from the computer may be on while the H or V sync signal
is missing. In this instance, the POWER MANAGEMENT feature may not work properly.
n
OPERATING THE MONITOR 17
POWER MANAGEMENT FEATURE
Power Management Mode
When the H-sync signal / V-sync signal / H and V sync signals from the computer are off, the monitor
enters into Power Management Mode which reduces the power consumption to less than 13.5W. The
screen becomes dark, and the power indicator turns to orange. From Power Management Mode, the
image reappears in several seconds when either the keyboard or the mouse are touched again.
The power management feature of this product automatically reduces unnecessary power consumption
of the monitor when your computer is not in use.
To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a
power management step the monitor takes as described below. The power management function, including
any timer settings is configured by the operating system. Check your operating system manual for
information on how this can be configured.
n
0 13.5 W 100%
POWER
CONSUMPTION
Green
Orange
Power Indicator
NORMAL MODE
POWER MANAGEMENT MODE
All manuals and user guides at all-guides.com

ENGLISH
TROUBLE SHOOTING
Perform the adjustments described in OPERATING THE MONITOR, depending on the problem you have.
2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE
MONITOR or if the problem persists.
If you are experiencing a problem which is not described below or you cannot correct the problem,
discontinue using the monitor and contact your dealer or iiyama service center for further assistance.
3.
18 TROUBLE SHOOTING
Problem Check
The picture does
not appear.
(Power indicator
does not light up.) The Power Cable is firmly seated in the socket.o
o
oThe AC socket is live. Please check with another piece of equipment.
oIf the blank screen saver is in active mode, touch the keyboard or the mouse.
oIncrease the Contrast and/or Brightness.
The computer is ON.
oThe Signal Cable is properly connected.
o
The Power Switch is turned ON.
A
(Power indicator
is green.)
oThe signal timing of the computer is within the specification of the monitor.
(Power indicator
is orange.) If the input signal selection is different, switch the INPUT SELECTION.
o
oIf the monitor is in power management mode, touch the keyboard or the mouse.
The screen is not
synchronized.
oThe Signal Cable is properly connected.
oThe signal timing of the computer is within the specification of the monitor.
B
oThe signal timing of the computer is within the specification of the monitor.
oThe video output level of the computer is within the specification of the monitor.
The screen
position is not in
the center.
oThe signal timing of the computer is within the specification of the monitor.
The screen is
too bright or too
dark.
The screen is
shaking.
C
D
E
The video output level of the computer is within the specification of the monitor.o
oThe power voltage is within the specification of the monitor.
oThe signal timing of the computer is within the specification of the monitor.
The computer is ON.
The Signal Cable is properly connected.
o
o
1.
If the monitor fails to operate correctly, please follow the steps below for a possible solution.
The AC Adapter cable is firmly connected.o
All manuals and user guides at all-guides.com
