Wize WR-15GT User manual

WR-15GT
Motorized
retractable monitor
User manual
Signal input : HDMI, VGA
Screen size: 15.6''
Tilt angle : 0-30 degrees, adjustable
Touch function : optional

1. Listing.Shape and Panel Key Description
1.1 Packing list
No. Name QTY
1 LCD MOTORIZED LIFT 1PCS
2 POWER CABLE 1PCS
3 VGA CABLE 1PCS
4 USER MANUAL 1PCS
1.2 Panel key Functions
No. English Button show
1 STOP
2 UP
3 DOWN
4 FORCF(adjust angle)
5 BACK(adjust angle)

FIG1 surface
1.3.1 HDMI Video signal input.
1.3.2 DVI Video signal input.
1.3.3 VGA Video signal input.
1.3.4 Audio signal input(3.5mm stereo)
1.3.5 Audio signal output(3.5mm stereo)
1.3.6 USB input,up for USB put, down for the touch screen control card
interface
1.3.7 RS485 control input(1,2,5)
1.3.8 RS485 control input(When cluster control)
1.3.9 ANT, Remote control receiver antenna（315MHz）。
1.3.10 Standby button interface: PC SW computer start button. SA SW signal
switching key.
1.3.11 AC220V Power input socket
1.4 Control Introduction：
1.4.1 RS485 Software Control:9 holes interface with the computer serial port.
232/485 intermediate bridge converter.
FIG 2 connector(female）
1.4.2 Remote control：（Will be give with goods when customer requested)
FIG 3 Remote control
1.4.3 Control Button：（ Please see Panel Key function, Red/Green means light
power indicator)
1.3 Interface board features(from left to right)

FIG 4 Panel control button
1.4.4 Screen button function：（Pls see the 7 point, screen menu to adjust the
guide）
Auto ▲
▲
Menu Led
FIG 5 Screen Button
“Menu” menu button，“Auto”Automatic adjustment key，“
▲
”Variable increment
key，“
▲
”Variable reduced key，“”Screen Power Switch button。“LED”Power
indicator（Red means no have signal,Green means have signal)
1.4.5 Sub Button function:
FIG6 Sub button and USB
PC SW，SA SW Spare custom button for customer, and spare USB
port for customer to use, it match as the connector board USB.
2. Features and Major Technical Indicator
2.1 Structure Features
The part of screen Lift is adopt bilateral synchronous belt wheel with linear
optical axis transmission and low noise and stable structure. Screen frame is
adopt pure aluminum with tempered glass front and rear,high-end atmosphere.
2.2 ：Major Technical Indicator

No. Name Date
1 Working Voltage AC 220V 50Hz
2 Consumed power ＜60W
3 single-working time 18S
4 Elevation angle ≤30
5 Product weight 22Kg
3. Structural dimensions and installation instructions：
3.1 Size of structure figure.

FIG 6 Size of structure figure.
3.2 Package size:
FIG 8 Package size
3.3 User installed out-cut size figure.
FIG8 OUT-CUT SIZE
3.4 Installation Notes：
3.4.1 Before operation,please remove two "transport fixing screws" on the
cover and clean the inside of the clamshell door foam filler.
3.4.2 The lifter embedded inside the opening, panel flush with the desktop.
3.4.3 Video Signal connector Cable（VGA or HDMI or DVI）

3.4.4 Connect the touch USB Cable(not need to connect the touch USB cable
if without touch function)
3.4.5 If need Central-controlled system,please connect the control line
RS485.
3.4.6 Connected the antenna with antenna base together
3.4.7 Turn on AC220V power supply, panel indicator is light, press UP key to
complete the automatic elevation, the screen lights up, the red indicator
is no signal, the green indicator is signaled.
4. Technical date:
4.1 HEX system controlling code or Central control code（Sheet 4）
All up FF AC E1 FF 00 00 DD 01 DC
All stop FF AC E1 FF 00 00 CD 01 CC
All down FF AC E1 FF 00 00 ED 01 EC
4.2 Computer software control
4.2.1 Download "Multifunctional lifting equipment Control Center" control
software from the company's official website.
4.2.2 Prepare a RS232-485 or USB-RS485 protocol converter.
4.2.3 Uses Windows XP systems to install the software.
4.2.4 Connect the LIFT equipment.
4.2.5 According to the software that comes with help files, you can use to
operate.
5. Solutions of monitor common problems：
Common failure analysis（Sheet 5）
No. Fault phenomenon Analysis reason

5.1 Display is blank ·Power switch is turned off?
·Signal source is interrupted?
5.2 Blurred characters · Is match with the resolution of the
computer?
Contrast and brightness adjustments
are correct？
5.3 Black Screen
·No signal may be turned off
automatically Brightness？
Brightness adjustment if adjust to the
minimum？
·Long press "Auto" key may cause
shutdown, the LED turns red.
6. Solutions of Lifter common problems：
6.1 All machine no power,light does not shine:
Pry the Insurance cover of power to check the fuse if damage? If so,
please change specifications 3.15A fuse.
FIG 9 Location of fuse socket GB
6.2 The control circuit board Common trouble diagnosis method：
6.2.1 Pls check the power supply socket "L" and "N" (between the circuit
board of the LT3 terminal) resistance is about 1.1K or so, which is
normal, if deviate from this range ,it has the problem.
6.2.2 Indicator light does not shine, the key is invalid, but computer control
normal: may be key board cable transport from strong vibration caused

by poor contact.
6.2.3 Circuit boards 12V abnormal, check L7812 if it's damage.
6.2.4 Circuit boards 5V abnormal, check L7805 if it's damage.
6.2.5 Up limit switch belong pulse level control, after the pulse remains
stopped. But the display power required to maintain the state of shading
for photoelectric control.
6.2.6 Down limit switch belong to low pause control, continued to decline at a
high level. Therefore, photoelectric control gobo stop during descent
should remain light shielding state.
7. 17E Screen menu the guide of adjustment
7.1 Color adjust：
FIG 10 color adjustment display
Press “Menu” Button, and Press “Menu” button, the cursor move to the
brightness. Press“
▲
”button, the cursor move to the contrast. If need to return
back, please press ”Auto” button. Press ”Menu” button, display the brightness
value: 50%,press button“▲” or “
▲
” to change the the size of
brightness value.
7.2 Image adjust:

FIG11 Image adjustment display
First press “Menu” button, and then press“▲” button to display the
image adjust, and press “Menu” again, the cursor can move to the
automatic adjustment.If need return back, please press”Auto”button.
7.3 Menu adjust:
FIG12 Menu adjust display.
Press “Menu” button, and press three times “▲” button to display
OSD.Press “Menu”Button,move the cursor to the Language,can
change the language.Press“
▲
” button, the cursor move to the H
Position.If need return back, please press “Auto”Button. Press“
▲
” or
“ ▲” button, can change the number of H Position and V Position.
7.4 Function adjustment
Press “Menu” button, and press four times“▲” button, can display the
“Function” menu.

FIG 13 Function adjust display
Remark:“Auto” button is signal source selection button when
using it independently, and the order of selection is "VGA", "DVI",
"HDMI". When using the auxiliary, it's return back button.
