IMC F63/503 User manual

IS758 ECN 4744 - March 2020
MOBILE HAND WASH UNIT
INSTALLATION AND USER MANUAL
PLEASE LEAVE WITH OPERATOR
MOBILE HAND WASH UNIT –F63/503
Imperial Machine Company Limited
Unit 1, Abbey Road
Wrexham Industrial Estate
Wrexham LL13 9RF
Tel: [phone]
Fax: [phone]
Spares Fax: [phone]
E-mail: [email protected]
E-mail: [email protected]
Website: www.imco.co.uk

INDEX
INTRODUCTION
1
Guarantee
1
Delivery
1
DIMENTIONS
2
SPECIFICATION
2
PRODUCT FEATURES
3
INSTALLATION
4
Procedure
Location
4
4
Commissioning
5
Emptying / Refilling
6
Cleaning
6
SPARE PARTS
Spare Parts List
Ordering Spear Parts
7
7
7

MOBILE HAND WASH UNIT 1
INTRODUCTION
Congratulations on your purchase of the IMC Mobile Hand Wash Unit.
Thoughtfully designed to allow the users to wash their hands. This manual
outlines the installation, operation procedures relevant to this unit.
Guarantee
The Mobile Hand Wash unit is guaranteed by IMC for 1 years from the date of
purchase from IMC, or from one of its stockists, dealers or distributors. The
guarantee is limited to the replacement of faulty parts or products and excludes
any consequential loss or expense incurred by purchaser. Defects which arise
from faulty installation, inadequate maintenance, incorrect use or fair wear and
tear are not covered by the guarantee.
The guarantee applies in this form to installations within the United Kingdom.
Please observe these instructions carefully.
Delivery
The packaged unit contains:
IMC MOBILE HAND WASH UNIT:
Fully Assembled Hand Wash Unit
Splashback Panel
Paper Tower Dispenser
Soap Dispenser
1
1
1
1
Water container 20L - Natural
2
Instruction Booklet
1
Please notify LINCAT on the day of receipt if anything is missing or damaged.
UK: 01522 875555
Check that the correct machine has been supplied. The data plate is located on
the rear of the unit.

2MOBILE HAND WASH UNIT
520
305
915
514
543
451
1220
DIMENSIONS
SPECIFICATION
Tank Capacity
20 litres
Net Weight
27.4kg

MOBILE HAND WASH UNIT 3
PRODUCT FEATURES
SINK BOWL OVERFLOW
WHEEL
SINK BOWL
WATER SPOUT
TOWELHOLDER SOAP HOLDER
SURROUND
FOOT PUMP
ACCESS KNOB

4MOBILE HAND WASH UNIT
INSTALLATION
These Instructions contain important information designed to help the user obtain
the maximum benefit from their investment in an IMC Mobile Hand Wash Unit.
Please read them carefully before starting work and consult with your
distributor/supplier in the event of any queries.
Be sure to leave this Instruction Manual with the user after installation of the
machine is complete.
Procedure
WARNING
The following table shows the weight and the minimum quantity of
people required to lift each unit:
Net Weight
Quantity of People
IMC Mobile Hand Wash Unit
27.4 kg
2
Before using the hand wash; remove all packaging and ensure that the unit is
checked over for damage, any damage must be reported to the carrier or
distributor/supplier immediately.
Remove any protective plastic coating on the unit.
Do not be alarmed if water is present in the tanks or pipes of the unit, this is
normal and only a mere consequence of the testing procedures.
Location
The Mobile Hand Wash Unit is only suitable for use where there is no risk for the
unit to be adversely affected by its surrounding environment.
The unit must be stationed on a flat surface capable of safely supporting the units
weight when fully laden with water.
The unit it is fitted with a handle on the back to assist when moving.

MOBILE HAND WASH UNIT 5
Commissioning
Remove the front panel by unscrewing the black knob on the front of the unit, tilt
the panel backwards and pull upwards away from the unit at an upward angle.
This will enable the operator to gain access to the clean and waste water
containers inside the unit.
Once the front panel has been removed, lift out the suction hose from the clean
water container and remove the water container. Note the water container can
hold a maximum of 20 litres. Ensure when refitting the water container that the
suction hose has been placed at the bottom container.
We advise that you operate the foot pump and pass water through the unit before
refitting the front panel. To prime the pump ready for operation and pass water
through the unit; place your foot inside the housing above the pump. Depress the
foot pump several times until water is seen coming out of the spout located above
the sink on the unit.
Once all of the above steps have completed and the front panel has been refitted,
your Mobile Hand Wash Unit should now be ready for operation.

6MOBILE HAND WASH UNIT
Emptying / Refilling
Once the unit has completed its total number of operations, the waste water
container will need emptying and the clean water tank refilled.
To empty the waste water container; remove the front panel. The waste-water
pipe can now be removed and the container can be slid out of the unit and
emptied appropriately.
To re-install the waste water container, follow the above steps in reverse.
To refill the clean water container, follow the steps outlined in the commissioning
section.
Cleaning
Clean the externals of the unit as required; using a damp cloth and an appropriate
cleaning product.
DO NOT USE CLEANING MATERIALS CONTAINING ABRASIVES OR
BLEACHES.

MOBILE HAND WASH UNIT 7
SPARE PARTS
Spare Parts List
PART NUMBER
QTY
DESCRIPTION
WC01
1
20 LTR WATER CONTAINER
WP02
1
FOOT PUMP
A19/042
2
MOBILE HANDWASH WHEEL
A21/044
1
KNOB 2160_M M8 x 14 BLACK
Ordering Spare Parts
In the event that spare parts or accessories need to be ordered, please always
quote the SERIES AND SERIAL NUMBER of the machine. This is to be found on
the rating plate located near the supply cable if applicable or at the rear of the
appliance.
For installations outside the UK please contact your supplier.
For information on IMCspares and service support (if applicable), please call IMC
on [phone]. Alternatively, contact us via email:
IMC Service Desk E-mail: [email protected]
IMC Spares Desk E-mail: [email protected]
