Indesit WISL 62 User manual

1
GB
English,1
Contents
Installation, 2-3
Unpacking and levelling, 2
Electric and water connections, 2-3
The first wash cycle, 3
Technical details, 3
Washing machine description, 4-5
Control panel, 4
Leds, 5
Starting and Programmes, 6
riefly: how to start a programme, 6
Programme table, 6
Personalisations,
Setting the temperature, 7
Functions, 7
Detergents and laundry, 8
Detergent dispenser, 8
leach cycle, 8
Preparing your laundry, 8
Special items, 8
Precautions and advice, 9
General safety, 9
Disposal, 9
Saving energy and respecting the environment, 9
Care and maintenance, 10
Cutting off the water or electricity supply, 10
Cleaning your appliance, 10
Cleaning the detergent dispenser, 10
Caring for your appliance door and drum, 10
Cleaning the pump, 10
Checking the water inlet hose, 10
Troubleshooting, 11
Service, 12
efore calling for Assistance, 12
WASHING MACHINE
WISL 62
Instructions for use
GB
ÁÚËÃÀÐÑÊÈ,13
BG
ÑÐÏÑÊÈ,25
SB
ÅËËÇÍÉÊÁ,37
GR
Italiano,49
I

2
GB
Installation
Keep this instruction manual in a safe place for
future reference. Should the appliance be sold,
transferred or moved, make sure the instruction
manual accompanies the washing machine to inform
the new owner as to its operation and features.
Read these instructions carefully: they contain vital
information on installation, use and safety.
Unpacking and levelling
Unpacking
1. Unpack the washing machine.
2. Check whether the washing machine has been
damaged during transport. If this is the case, do not
install it and contact your retailer.
3. Remove the 4
protective screws and
the rubber washer with
the respective spacer,
situated on the rear of
the appliance (see
figure).
4. Seal the gaps using the plastic plugs provided.
5. Keep all the parts: you will need them again if the
washing machine needs to be moved to another
location.
Packaging materials are not children's toys.
Levelling
1. Install the washing machine on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or other.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or
loosening the adjustable
front feet (see figure);
the angle of inclination,
measured according to
the worktop, must not
exceed 2°.
Levelling your appliance correctly will provide it with
stability and avoid any vibrations, noise and shifting
during operation. If it is placed on a fitted or loose
carpet, adjust the feet in such a way as to allow
enough room for ventilation beneath the washing
machine.
Electric and water connections
Connecting the water inlet hose
1. Insert seal A into the
end of the inlet hose
and screw the latter
onto a cold water tap
with a 3/4 gas threaded
mouth (see figure).
efore making the
connection, allow the
water to run freely until
it is perfectly clear.
2. Connect the other end
of the water inlet hose to
the washing machine,
screwing it onto the
appliance's cold water
inlet, situated on the top
right-hand side on the
rear of the appliance
(see figure).
3. Make sure there are no kinks or bends in the hose.
The water pressure at the tap must be within the
values indicated in the Technical details table
(on the next page).
If the water inlet hose is not long enough, contact
a specialist store or an authorised serviceman.
 Never use hoses that have already been used.
A

3
GB
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Connecting the drain hose
Connect the drain hose,
without bending it, to a
draining duct or a wall
drain situated between
65 and 100 cm from
the floor;
alternatively, place it
over the edge of a
basin, sink or tub,
fastening the duct
supplied to the tap (see
figure). The free end of
the hose should not be
underwater.
 We advise against the use of hose extensions; in
case of absolute need, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electric connection
efore plugging the appliance into the mains
socket, make sure that:
 the socket is earthed and in compliance with the
applicable law;
 the socket is able to sustain the appliance's
maximum power load indicated in the Technical
details table (on the right);
 the supply voltage is included within the values i
ndicated on the Technical details table
(on the right);
 the socket is compatible with the washing
machine's plug. If this is not the case, replace
the socket or the plug.
 The washing machine should not be installed in an
outdoor environment, not even when the area is
sheltered, because it may be very dangerous to
leave it exposed to rain and thunderstorms.
 When the washing machine is installed, the mains
socket must be within easy reach.
 Do not use extensions or multiple sockets.
 The power supply cable must never be bent or
dangerously compressed.
 The power supply cable must only be replaced by
an authorised serviceman.
Warning! The company denies all liability if and when
these norms are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, setting the 90°C
programme without a pre-wash cycle.
65 - 100 cm
Technical details
Model WISL 62
Dimensions
59.5 cm wide
85 cm high
40 cm deep
Capacity from 1 to 4,5 kg
Electric
connections
please refer to the technical data plate
fixed to the machine
Water
connections
maximum pressure 1 MPa (10 bar)
minimum pressure 0.05 MPa (0.5 bar)
drum capacity 40 litres
Spin speed up to 600 rpm
Control
programmes
according to
EN 60456
directive
programme 2; temperature 60°C;
run with a load of 4,5 kg.
This appliance is compliant with the
following European Community
Directives:
- 89/336/CEE of 03/05/89
(Electromagnetic Compatibility) and
subsequent amendments
- 2006/95/CE (Low Voltage)
- 2002/96/CE

4
GB
Washing machine description
Control panel
Detergent dispenser
ON-OFF
utton
START/RESET
utton
TEMPERATURE
Knob
PROGRAMME
Knob
Leds
FUNCTION
uttons
ON-OFF/
DOOR
LOCK
Led
Detergent dispenser: to add detergent and fabric
softener (see page 8).
LEDS: to find out which wash cycle phase is under
way.
If the Delay Timer function has been set, the time
left until the programme starts will be indicated (see
page 5).
FUNCTION buttons: to select the functions
available. The button corresponding to the function
selected will remain on.
TEMPERATURE knob: to set the temperature or
the cold wash cycle (see page 7).
START/RESET button: to start the programmes or
cancel any incorrect settings.
ON-OFF/DOOR LOCK Led: to find out whether the
washing machine is on and if the appliance door can
be opened (see page 5).
ON/OFF button: to turn the washing machine on
and off.
PROGRAMME knob: to select the wash
programmes. The knob stays still during the cycle.

5
GB
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
ON-OFF/DOOR LOCK led:
If this LED is on, the appliance door is locked to prevent it from being opened accidentally; to avoid any
damages, wait for the LED to flash before you open the appliance door.
 The rapid flashing of the ON-OFF/DOOR LOCK Led together with the flashing of at least one other LED
indicates there is an abnormality (see page 11).
Cycle phase under way:
During the wash cycle, the LEDs gradually illuminate
on to indicate the cycle phase under way:
Prewash
Wash
Rinse
Spin cycle
Note: during draining, the LED corresponding to
the Spin cycle phase will be turned on.
Function buttons
The FUNCTION UTTONS also act like LEDS.
When a function is selected, the corresponding
button is illuminated.
If the function selected is incompatible with the
programme set, the button will flash and the
function will not be enabled.
If you set a function that is incompatible with
another function you selected previously, only the
last one selected will be enabled.
Leds
The LEDS provide important information.
This is what they can tell you:
Delay set:
If the Delay Timer function has been enabled (see
page. 7), once you have started the programme,
the LED corresponding to the delay set will begin to
flash:
As time passes, the remaining delay will be
displayed, and the corresponding LED will flash:
Once the set delay is complete, the flashing LED will
turn off and the programme set will start.

6
GB
Type of fabric and
degree of soil Programmes Te m p e -
rature
Detergent Fabric
softener
Stain removal
option/bleach
Cycle
length
(m inu te s)
Description of ash cycle
pre-
wash wash
Standard
C otton: Extremely soiled whites
(sheets, tablecloths, etc.) 190°C    167 Pre-wash, wash cycle, rinse cycles,
intermediate and final spin cycles
C otton: Extremely soiled whites
(sheets, tablecloths, etc.) 290°C   Delicate/
Traditional 152 Wash cycle, rinse cycles,
intermediate and final spin cycles
C otton: Heavily soiled whites
and fast colours 260°C   Delicate/
Traditional 150 Wash cycle, rinse cycles,
intermediate and final spin cycles
C otton: Heavily soiled whites
and delicate colours 240°C   Delicate/
Traditional 142 Wash cycle, rinse cycles,
intermediate and final spin cycles
C otton: Slightly soiled whites
and delicate colours (shirts,
jumpers, etc.) 340°C   Delicate/
Traditional 99 Wash cycle, rinse cycles,
intermediate and final spin cycles
Synthetics: Heavily soiled fast
colours (baby linen, etc.) 460°C   Delicate 80 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Synthetics: Heavily soiled fast
colours (baby linen, etc.) 440°C   Delicate 71 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Synthetics: Delicate colours (all
types of slightly soiled garments) 540°C   Delicate 71 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Wool 640°C   50 Wash cycle, rinse cycles,
delicate spin cycle
Very delicate fabrics
(curtains, silk, viscose, etc.) 730°C   52 Wash cycle, rinse cycles, anti-
crease or draining cycle
Tim e 4 you
C otton: Heavily soiled whites
and fast colours 860°C   60 Wash cycle, rinse cycles,
intermediate and final spin cycles
C otton: Slightly soiled whites
and delicate colours (shirts,
jumpers, etc.) 940°C   50 Wash cycle, rinse cycles,
intermediate and final spin cycles
Synthetics: Delicate colours (all
types of slightly soiled garments) 10 40°C  40 Wash cycle, rinse cycles,
delicate spin cycle
Synthetics: Delicate colours (all
types of slightly soiled garments) 11 30°C   30 Wash cycle, rinse cycles and
delicate spin cycle
Sport
Sports shoes (MAX. 2 pairs) 12 30°C  50
Cold wash (without detergents),
wash cycle, rinse cycles, and
delicate spin cycle
Fabrics for sportswear
(Tracksuits, shorts, etc.) 13 30°C   63 Wash cycle, rinse cycles, intermediate and final spin cycles
PARTIAL PROGRAMMES
Rinse Delicate/
Traditional Rinse cycles and spin cycle
Spin cycle Draining and spin cycle
Drain Draining
Starting and Programmes
Programme table
Briefly: starting a programme
1. Switch the washing machine on by pressing button .
All the LEDS will light up for a few seconds and
the ON-OFF/DOOR LOCK Led will begin to flash.
2. Load your laundry into the washing machine and
shut the appliance door.
3. Set the PROGRAMME knob to the programme
required.
4. Set the wash temperature (see page 7).
5. Add the detergent and any fabric softener
(see page 8).
6. Start he programme by pressing the START/RESET
button.
To cancel it, keep the START/RESET button pressed
for at least 2 seconds.
7. When the programme is finished, the ON-OFF/
DOOR LOCK Led will flash to indicate that the
appliance door can be opened. Take out your
laundry and leave the appliance door ajar to allow
the drum to dry thoroughly. Turn the washing
machine off by pressing button .
Notes
-For programmes 8 and 9, we advise against exceeding a wash load of 3.5 kg.
-For programme 13 we advise against exceeding a wash load of 2 kg.
-For the anti-crease function: see Easy iron, opposite page. The information contained in the table is purely indicative.
Special programme
Daily (programme 11 for Synthetics) is designed to wash lightly soiled garments in a short amount of time: it only lasts
30 minutes and allows you to save on both time and energy. y setting this programme (11 at 30°C), you can wash
different fabrics together (except for woollen and silk items), with a maximum load of 3 kg.
We recommend the use of liquid detergent.

GB
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Personalisations
Setting the temperature
Turn the TEMPERATURE knob to set the wash temperature (see Programme ta le on page 6).
The temperature can be lowered, or even set to a cold wash ( ).
Functions
To enable a function:
1. press the button corresponding to the desired function, according to the table below;
2. the function is enabled when the corresponding button is illuminated.
Note: The rapid flashing of the button indicates that the corresponding function cannot be selected for the
programme set.
Note: to avoid excessive vi rations, efore every spin cycle the machine distri utes the load in a uniform manner y
continuously rotating the drum at a speed which is slightly faster than the normal washing speed.
When, despite repeated attempts, the load is still not evenly distri uted, the machine spins at a lower speed than
the set frequency.
If the load is excessively un alanced, the machine attempts to distri ute it instead of spinning.
The alancing attempts may extend the total duration of the cycle, up to a maximum of 10 minutes.
Function Effect Comments Enabled ith
programmes:
Delay Timer
Delays the start
of the wash by
up to 9 hours.
Press the button repeatedly until the LED corresponding to the
desired delay is turned on.
The fifth time the button is pressed, the function will be disabled.
N. .: Once you have pressed the Start/Reset button, the delay
can only be decreased if you wish to modify it.
All
Stain
removal
leaching cycle
designed to
remove the
toughest stains.
Please remember to pour the bleach into extra compartment 4
(see page 8).
This function is incompatible with the EASY IRON function.
2, 3, 4, 5,
Rinse cycle.
Easy iron
This option
reduces the
amount of
creasing on
fabrics, making
them easier to
iron.
When this function is set, programmes 4, 5, 7 will end with the
laundry left to soak (Anti-crease) and the Rinse cycle phase
LED will flash.
- to conclude the cycle, press the START/RESET button;
- to run the draining cycle alone, set the knob to the relative
symbol and press the START/RESET button.
This function is incompatible with the STAIN REMOVAL function.
3, 4, 5, 7, 8,
9, 10, Rinse
cycle.
Spin
exclusion
The washing
machine will not
carry out a spin
cycle, but rather
a drum spin at
medium speed to
assist water
draining.
We recommend that you use it when washing garments which are
difficult to iron.
All
programmes
except for 7
and draining.

8
GB
Detergent dispenser
Good washing results also depend on the correct
dose of detergent: adding too much detergent won't
necessarily make for a more efficient wash, and may
in fact cause build up on the interior of your
appliance and even pollute the environment.
Open up the detergent
dispenser and pour in
the detergent and fabric
softener, as follows.
compartment 1: Detergent for pre-wash
(powder)
efore pouring in the detergent, make sure that
extra compartment 4 has been removed.
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in
immediately prior to the wash cycle start.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow from the grid.
extra compartment 4: Bleach
 Do not use hand wash detergent because it may
form too much foam.
Bleach cycle
 Traditional bleach should be used on sturdy
white fabrics, and delicate bleach for coloured
fabrics, synthetics and for wool.
Place extra
compartment 4,
provided, into
compartment 1.
When pouring in the
bleach, be careful not to
exceed the "max" level
indicated on the central
pivot (see figure).
To run the bleach cycle alone, pour the bleach into
extra compartment 4, set the Rinse programme
and enable the Stain removal option (see page 7). To
bleach during a wash cycle, pour in the detergent
and fabric softener, set the desired programme and
enable the Stain removal option (see page 7).
The use of extra compartment 4 excludes the
possibility of using the pre-wash cycle.
Preparing your laundry
 Divide your laundry according to:
- the type of fabric/the symbol on the label.
- the colours: separate coloured garments from
whites.
 Empty all pockets and check for loose buttons.
 Do not exceed the weight limits stated below,
which refer to the weight when dry:
Sturdy fabrics: max 4,5 kg
Synthetic fabrics: max 2.5 kg
Delicate fabrics: max 2 kg
Wool: max 1 kg
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1,200 g
1 towel 150-250 g
Special items
Curtains: fold curtains and place them in a pillow
case or mesh bag. Wash them separately without
exceeding half the appliance load. Use programme 7
which excludes the spin cycle automatically.
Quilted coats and windbreakers: if they are
padded with goose or duck down, they can be
machine-washed. Turn the garments inside out and
load a maximum of 2-3 kg, repeating the rinse cycle
once or twice and using the delicate spin cycle.
Wool: for best results, use a specific detergent,
taking care not to exceed a load of 1 kg.
Detergents and laundry
123
4

9
GB
Precautions and advice
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
 The washing machine was designed and built in
compliance with the applicable international safety
regulations. The following information is provided for
your safety and should consequently be read carefully.
General safety
 This appliance has been designed for non-
professional, household use and its functions must
not be changed.
 This washing machine should only be used by
adults and in accordance with the instructions
provided in this manual.
 Never touch the washing machine when barefoot
or with wet or damp hands or feet.
 Do not pull on the power supply cable to unplug
the appliance from the electricity socket. Pull the
plug out yourself.
 Do not open the detergent dispenser while the
appliance is in operation.
 Do not touch the drain water as it could reach
very high temperatures.
 Never force the washing machine door: this could
damage the safety lock mechanism designed to
prevent any accidental openings.
 In the event of a malfunction, do not under any
circumstances touch internal parts in order to
attempt repairs.
 Always keep children well away from the
appliance while in operation.
 The appliance door tends to get quite hot during
the wash cycle.
 Should it have to be moved, proceed with the
help of two or three people and handle it with the
utmost care. Never try to do this alone, because
the appliance is very heavy.
 efore loading your laundry into the washing
machine, make sure the drum is empty.
Disposal
 Disposing of the packaging material:
observe local regulations, so the packaging can
be re-used.
 The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment, requires that
old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected
separately in order to optimise the recovery and
recycling of the materials they contain and reduce
the impact on human health and the environment.
The crossed out "wheeled bin" symbol on the
product reminds you of your obligation, that when
you dispose of the appliance it must be separately
collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.
Saving energy and respecting the
environment
Environmentally-friendly technology
If you only see a little water through your appliance
door, this is because thanks to the latest Indesit
technology, your washing machine only needs less
than half the amount of water to get the best results:
an objective reached to respect the environment.
Saving on detergent, water, energy and time
 To avoid wasting resources, the washing machine
should be used with a full load. A full load instead of
two half loads allows you to save up to 50% on energy.
 The pre-wash cycle is only necessary on
extremely soiled garments. Avoiding it will save on
detergent, time, water and between 5 and 15%
energy.
 Treating stains with a stain remover or leaving them
to soak before washing will cut down the need to
wash them at high temperatures. A programme at
60°C instead of 90°C or one at 40°C instead of
60°C will save up to 50% on energy.
 Use the correct quantity of detergent depending
on the water hardness, how soiled the garments
are and the amount of laundry you have, to avoid
wastage and to protect the environment: despite
being biodegradable, detergents do contain
ingredients that alter the natural balance of the
environment. In addition, avoid using fabric
softener as much as possible.
 If you use your washing machine from late in the
afternoon until the early hours of the morning, you
will help reduce the electricity board's peak load.
The Delay Timer option (see page 7) helps to
organise your wash cycles accordingly.
 If your laundry has to be dried in a tumble dryer,
select a high spin speed. Having the least water
possible in your laundry will save you time and
energy in the drying process.

10
GB
Care and maintenance
Cutting off the water or electricity
supply
 Turn off the water tap after every wash. This will
limit the wear of your appliance's water system
and also prevent leaks.
 Unplug your appliance when cleaning it and
during all maintenance operations.
Cleaning your appliance
The exterior and rubber parts of your appliance can
be cleaned with a soft cloth soaked in lukewarm
soapy water. Do not use solvents or abrasives.
Cleaning the detergent dispenser
Remove the dispenser
by pulling it out (see
figure).
Wash it under running
water; this operation
should be repeated
frequently.
Caring for your appliance door and
drum
 Always leave the appliance door ajar to prevent
unpleasant odours from forming.
Cleaning the pump
The washing machine is fitted with a self-cleaning
pump that does not require any maintenance.
Sometimes, small items (such as coins or buttons)
may fall into the pre-chamber that protects the
pump, situated in the lower part of the same.
 Make sure the wash cycle has ended and unplug
the appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel
on the lower front of the
washing machine (see
figure);
2. unscrew the lid
rotating it anti-
clockwise (see figure): a
little water may trickle
out. This is perfectly
normal;
3. clean the interior thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
Checking the water inlet hose
Check the water inlet hose at least once a year. If
you see any cracks, replace it immediately: during
the wash cycles, water pressure is very strong and
a cracked hose could easily split open.
 Never use hoses that have already been used.

11
GB
Troubleshooting
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Your washing machine could fail to work. efore calling for Assistance (see page 12), make sure the problem
can't easily be solved by consulting the following list.
Problem
The washing machine won't
start.
The wash cycle won't start.
The washing machine fails to
load water.
The washing machine
continuously loads and unloads
water.
The washing machine does not
drain or spin.
The washing machine vibrates
too much during the spin cycle.
The washing machine leaks.
The ON-OFF/DOOR LOCK Led
flashes rapidly at the same
time as at least one other LED.
There is too much foam.
Possible causes/Solution:
 The appliance is not plugged into the socket, or not enough to
make contact.
 There has been a power failure.
 The appliance door is not shut properly.
 The button has not been pressed.
 The START/RESET button has not been pressed.
 The water tap is not turned on.
 A delayed start has been set (using the Delay Timer, see page 7).
 The water inlet hose is not connected to the tap.
 The hose is bent.
 The water tap is not turned on.
 There is a water shortage.
 The water pressure is insufficient.
 The START/RESET button has not been pressed.
 The drain hose is not fitted between 65 and 100 cm from the floor
(see page 3).
 The free end of the hose is underwater (see page 3).
 The wall drainage system doesn't have a breather pipe.
If the problem persists even after these checks, turn off the water tap,
switch the appliance off and call for Assistance. If the dwelling is on one of
the upper floors of a building, there may be drain trap problems causing the
washing machine to load and unload water continuously. In order to avoid
such an inconvenience, special anti-drain trap valves are available in shops.
 The programme does not foresee the draining: some programmes
require enabling the draining manually (see page 6).
 The Easy iron option is enabled: to complete the programme, press
the START/RESET button (see page 7).
 The drain hose is bent (see page 3).
 The drain duct is clogged.
 The drum was not unblocked correctly during installation (see page 2).
 The washing machine is not level (see page 2).
 The washing machine is closed in between furniture cabinets and
the wall (see page 2).
 The water inlet hose is not screwed on correctly (see page 2).
 The detergent dispenser is obstructed (to clean it, see page 10).
 The drain hose is not secured properly (see page 3).
 Switch off the machine and unplug the appliance; wait for
approximately 1 minute then switch it on again.
If the problem persists, contact Assistance.
 The detergent is not suitable for machine washing (it should bear
the definition "for washing machines" or "hand and machine wash",
or the like).
 You used too much detergent.

12
GB
Before calling for Assistance:
Check whether you can solve the problem on your own (see page 11);
Restart the programme to check whether the problem has been solved;
If this is not the case, contact an authorised Technical Service Centre on the telephone number
provided on the guarantee certificate.
Always request the assistance of authorised servicemen.
Notify the operator of:
 the type of problem;
 the appliance model (Mod.);
 the serial number (S/N).
This information can be found on the data plate situated on the rear of the washing machine.
Service
Service

13
BG
ÁÚËÃÀÐÑÊÈ
Ñúäúðæàíèå
Ìîíòèðàíå, 14-15
Ðàçîïàêîâàíå è íèâåëèðàíå, 14
Õèäðàâëè÷íè è åëåêòðè÷åñêè âðúçêè, 14-15
Ïúðâî ïðàíå, 15
Òåõíè÷åñêè äàííè, 15
Îïè àíèå íà ïåðàëíàòà ìàøèíà, 16-17
Òàáëî çà óïðàâëåíèå, 16
Ñâåòëèííè èíäèêàòîðè, 1
Âêëþ÷âàíå è ïðîãðàìè, 18
Êðàòêî îïèñàíèå: âêëþ÷âàíå íà ïðîãðàìà, 18
Òàáëèöà ñ ïðîãðàìèòå, 18
Ïðîãðàìèðàíå ïîðåä ïîòðåáíî òèòå, 19
Çàäàâàíå íà òåìïåðàòóðàòà, 19
Ôóíêöèè, 19
Ïåðèëíè ïðåïàðàòè è òúêàíè, 20
Êàñåòà çà ïåðèëíèòå ïðåïàðàòè, 20
Öèêúë íà èçáåëâàíå, 20
Ðàçïðåäåëÿíå íà ïðàíåòî, 20
Ñïåöèôè÷íî ïðàíå, 20
Ìåðêè çà áåçîïà íî ò è ïðåïîðúêè, 21
Îáùè ïðåäîõðàíèòåëíè ìåðêè, 21
Ïðåòîïÿâàíå, 21
Ñïåñòÿâàíå è îïàçâàíå íà îêîëíàòà ñðåäà, 21
Ïîääðúæêà è ïî÷è òâàíå, 22
Ñïèðàíå íà âîäàòà è èçêëþ÷âàíå íà
åëåêòðîçàõðàíâàíåòî, 22
Ïî÷èñòâàíå íà ïåðàëíàòà ìàøèíà, 22
Ïî÷èñòâàíå íà êàñåòàòà çà ïåðèëíèòå ïðåïàðàòè, 22
Ïîääðúæêà íà ëþêà è íà êàçàíà, 22
Ïî÷èñòâàíå íà ïîìïàòà, 22
Ïðîâåðêà íà ìàðêó÷à çà ñòóäåíàòà âîäà, 22
Ïðîáëåìè è ìåðêè çà îò òðàíÿâàíåòî
èì, 23
Ñåðâèçíî îá ëóæâàíå, 24
Ïðåäè äà ñå ñâúðæåòå ñ îòîðèçèðàíèÿ ñåðâèç, 24
BG
ÏÅÐÀËÍÀ ÌÀØÈÍÀ
WISL 62
Èí òðóêöèè çà ïîëçâàíå

14
BG
 Âàæíî å äà ñúõðàíÿâàòå èíñòðóêöèèòå, çà äà
ìîæåòå äà ïðàâèòå äîïúëíèòåëíè ñïðàâêè ïî
âñÿêî âðåìå.  ñëó÷àé, ÷å ïåðàëíàòà ìàøèíà ñå
ïðîäàäå, ïðåîòñòúïè èëè ïðåìåñòè òðÿáâà äà ñå
ïîãðèæèòå èíñòðóêöèèòå âèíàãè äà ÿ ïðèäðóæàâàò,
çà äà ñå ïðåäîñòàâè èíôîðìàöèÿ íà íîâèÿ
ñîáñòâåíèê çà ðàáîòàòà è ïðåäóïðåæäåíèÿòà.
 Ïðî÷åòåòå âíèìàòåëíî èíñòðóêöèèòå, çàùîòî
ñúäúðæàò âàæíà èíôîðìàöèÿ çà ìîíòàæà,
èçïîëçâàíåòî è áåçîïàñíîñòòà.
Ðàçîïàêîâàíå è íèâåëèðàíå
Ðàçîïàêîâàíå
1. Ðàçîïàêîâàéòå ïåðàëíàòà ìàøèíà.
2. Ïðîâåðåòå äàëè ïåðàëíàòà ìàøèíà íå å
ïîâðåäåíà ïðè òðàíñïîðòèðàíåòî. Àêî å
ïîâðåäåíà, íå ÿ ñâúðçâàéòå, à ñå îáúðíåòå êúì
ïðîäàâà÷à.
3. Îòñòðàíåòå 4-òå
âèíòà çà ïðåäïàçâàíå
ïðè ïðåâîçà è ãóìåíàòà
ãàðíèòóðà ñúñ
ñúîòâåòíàòà âòóëêà çà
ðàçäàëå÷àâàíå,
ïîñòàâåíè â çàäíàòà
÷àñò (âèæ ôèãóðàòà).
4. Çàòâîðåòå îòâîðèòå ñ ïðåäîñòàâåíèòå
ïëàñòìàñîâè êàïà÷êè.
5. Ñúõðàíåòå âñè÷êè ÷àñòè, çà äà ñå ìîíòèðàò
îòíîâî ïðè íåîáõîäèìîñò ïåðàëíàòà ìàøèíà äà
áúäå òðàíñïîðòèðàíà.
 Îïàêîâú÷íèÿò ìàòåðèàë íå å äåòñêà èãðà÷êà
Íèâåëèðàíå
1. Ìîíòèðàéòå ïåðàëíàòà ìàøèíà íà ðàâåí è
òâúðä ïîä áåç äà ÿ îïèðàòå â ñòåíè, ìåáåëè è äð.
2. Àêî ïîäúò íå å
èäåàëíî õîðèçîíòàëåí,
êîìïåíñèðàéòå
íåðàâíîñòèòå êàòî
îòâèåòå èëè çàâèåòå
ïðåäíèòå êðà÷åòà (âèæ
ôèãóðàòà). Íàêëîíúò,
èçìåðåí âúðõó ãîðíàòà
ïîâúðõíîñò, íå òðÿáâà
äà íàäâèøàâà 2°.
Ñ òî÷íîòî íèâåëèðàíå ìàøèíàòà å ñòàáèëíà è ñå
èçáÿãâàò âèáðàöèèòå, øóìîâåòå è ïðåìåñòâàíåòî
é ïî âðåìå íà ðàáîòà. Êîãàòî íàñòèëêàòà å ìîêåò
èëè êèëèì, ðåãóëèðàéòå òàêà êðà÷åòàòà, ÷å ïîä
ïåðàëíàòà ìàøèíà äà îñòàíå äîñòàòú÷íî ìÿñòî
çà âåíòèëàöèÿ.
Õèäðàâëè÷íè è åëåêòðè÷å êè âðúçêè
Ñâúðçâàíå íà ìàðêó÷à êúì âîäîïðîâîäíàòà ìðåæà
1. Ïîñòàâåòå
óïëúòíåíèåòî À â
êðàÿ íà ìàðêó÷à çà
ñòóäåíàòà âîäà è ãî
çàâèéòå êúì êðàíà çà
ñòóäåíàòà âîäà íà 3/4
(âèæ ôèãóðàòà).
Ïðåäè äà ãî ñâúðæåòå
èçòî÷åòå âîäàòà,
äîêàòî ñå èçáèñòðè.
2. Ñâúðæåòå ìàðêó÷à
çà ñòóäåíàòà âîäà êúì
ïåðàëíàòà ìàøèíà,
êàòî ãî çàâèåòå êúì
ùóöåðà, ðàçïîëîæåí
íà ãúðáà, ãîðå âäÿñíî
(âèæ ôèãóðàòà).
3. Âíèìàâàéòå ìàðêó÷à äà íå ñå ïðåãúâà è
ïðå÷óïâà.
 Íàëÿãàíåòî ïî âîäîïðîâîäíàòà ìðåæà òðÿáâà
äà áúäå â ãðàíèöèòå, óêàçàíè â òàáëèöàòà ñ
òåõíè÷åñêèòå äàííè (âèæ ñëåäâàùàòà
ñòðàíèöà).
 Àêî äúëæèíàòà íà çàõðàíâàùèÿ ìàðêó÷ íå å
äîñòàòú÷íà, ñå îáúðíåòå êúì ñïåöèàëèçèðàí
ìàãàçèí èëè êúì îòîðèçèðàí òåõíèê.
 Íèêîãà íå èçïîëçâàéòå âå÷å èçïîëçâàí ìàðêó÷.
Ìîíòèðàíå
A

15
BG
Ñâúðçâàíå íà ìàðêó÷à çà ìðú íàòà âîäà
Ñâúðæåòå ìàðêó÷à çà
ìðúñíàòà âîäà, áåç äà
ãî ïðåãúâàòå, êúì
êàíàëèçàöèîííàòà
òðúáà èëè êúì òðúáàòà
çà îòâåæäàíå â
ñòåíàòà, ðàçïîëîæåíè
îò ïîäà íà âèñî÷èíà
ìåæäó 65 è 100 ñì;
èëè ãî ïîäïðåòå â êðàÿ
íà ìèâêàòà èëè âàíàòà,
êàòî âúðæåòå âîäà÷à çà
êðàíà (âèæ ôèãóðàòà).
Ñâîáîäíèÿò êðàé íà
ìàðêó÷à çà ìðúñíàòà
âîäà íå òðÿáâà äà áúäå
ïîòîïåí âúâ âîäàòà.
 Íå ñå ïðåïîðú÷âà èçïîëçâàíåòî íà óäúëæèòåëíè
ìàðêó÷è. Àêî å íåîáõîäèìî, óäúëæèòåëÿò òðÿáâà
äà èìà ñúùèÿ äèàìåòúð êàòî îðèãèíàëíèÿ è äà íå
íàäâèøàâà 150 ñì.
Ñâúðçâàíå êúì åëåêòðè÷å êàòà ìðåæà
Ïðåäè äà ñâúðæåòå ùåïñåëà â êîíòàêòà, ïðîâåðåòå
äàëè:
 êîíòàêòúò å çàçåìåí ñúãëàñíî äåéñòâàùàòà
íîðìà;
 êîíòàêòúò ìîæå äà ïîåìå ìàêñèìàëíàòà
ìîùíîñò íà íàòîâàðâàíå íà ìàøèíàòà, óêàçàíà
â òàáëèöàòà ñ òåõíè÷åñêèòå äàííè (âèæ
ñëåäâàùàòà ñòðàíèöà);
 çàõðàíâàùîòî íàïðåæåíèå å â ãðàíèöèòå íà
óêàçàíîòî â òàáëèöàòà ñ òåõíè÷åñêèòå äàííè
(âèæ ñëåäâàùàòà ñòðàíèöà);
 êîíòàêòúò îòãîâàðÿ íà ùåïñåëà íà ïåðàëíàòà
ìàøèíà.  ïðîòèâåí ñëó÷àé çàìåíåòå ùåïñåëà
èëè êîíòàêòà.
 Ïåðàëíàòà ìàøèíà íå ñå ìîíòèðà íà îòêðèòî,
äîðè ïîä íàâåñ, çàùîòî å ìíîãî îïàñíî äà ñå
îñòàâè íà âëèÿíèåòî íà àòìîñôåðíèòå óñëîâèÿ.
 Çà ìîíòèðàíàòà ïåðàëíà ìàøèíà åëåêòðè÷åñêèÿò
êîíòàêò òðÿáâà äà áúäå ëåñíî äîñòúïåí.
 Íå èçïîëçâàéòå óäúëæèòåëè èëè ðàçêëîíèòåëè.
 Êàáåëúò íå òðÿáâà äà áúäå îãúíàò èëè
ñïëåñêàí.
 Çàõðàíâàùèÿò êàáåë òðÿáâà äà ñå çàìåíÿ ñàìî
îò îòîðèçèðàíè òåõíèöè.
Âíèìàíèå! Ôèðìàòà îòõâúðëÿ âñÿêàêâà îòãîâîðíîñò
â ñëó÷àèòå, â êîèòî òåçè íîðìè íå ñå ñïàçâàò.
Ïúðâî ïðàíå
Ñëåä ìîíòèðàíåòî, ïðåäè óïîòðåáà, íàïðàâåòå
åäèí öèêúë íà ïðàíå ñ ïåðèëåí ïðåïàðàò, íî áåç
äðåõè, êàòî çàäàäåòå ïðîãðàìàòà íà 90°Ñ áåç
ïðåäïðàíå.
Ñåðâèçíî
îá ëóæâàíå
Ïðîáëåìè
Ïðåäïàçíè
ìåðêè ÏîääðúæêàÏðîãðàìè Ïåðèëíè
ïðåïàðàòè
Ìîíòèðàíå Îïè àíèå
65 - 100 cm
Òåõíè÷åñêè äàííè
Ìîäåë WISL 62
Ðàçìåðè
øèðè í à 5 9 , 5 ñ ì
âèñî÷èíà 85 ñì
äúëáî÷èíà 40 ñì
Âìåñòèìîñò îò 1 äî 4,5 êã
Åëåêòðè÷åñêî
çàõð àí â àí å
Âèæ òàáåëêàòà ñ õàðàêòåðèñòèêèòå,
ïîñòàâåíà íà ìàøèíàòà
Çàõðàíâàíå ñ
âîäà
ìàêñèìàëíî íàëÿãàíå 1 ÌÐà (10 bar)
ìèíèìàëíî íàëÿãàíå 0,05 ÌÐà (0,5 bar)
îáåì íà êàçàíà 40 ëèòðà
Ñêîðîñò íà
öåíòðîôóãàòà äî 600 îáîðîòà/ìèíóòà
Ïðîãðàìè çà
ïðîâåðêà
ñúãëàñíî íîðìà
N 60456
ïðîãðàìà 2 ; òåìïåðàòóðà 60°;
èçâúðøåíà ñ 4,5 êã ïðàíå
Ïåðàëíàòà ìàøèíà ñúîòâåòñòâà íà
ñëåäíèòå Åâðîïåéñêè äèðåêòèâè:
- 89/336/ÑÅÅ îò 03/05/89 (çà
åëåêòðîìàãíèòíà ñúâìåñòèìîñò)
è ïîñëåäâàùèòå èçìåíåíèÿ
- 2 006/95/ÑÅ (çà íèñêî íàïðåæåíèå)
- 2 002 /96/CE

16
BG
Òàáëî çà óïðàâëåíèå
Îïè àíèå íà ïåðàëíàòà ìàøèíà
Êàñåòà çà ïåðèëíèòå
ïðåïàðàòè
Áóòîí ÂÊËÞ×ÂÀÍÅ/
ÈÇÊËÞ×ÂÀÍÅ
Áóòîí
ÑÒÀÐÒ/ÀÍÓËÈÐÀÍÅ
Êàñåòàòà çà ïåðèëíèòå ïðåïàðàòè: ñëóæè
çà çàðåæäàíå ñ ïåðèëíè ïðåïàðàòè, îìåêîòèòåëè
è äð. (âèæ ñòð. 20).
Ñâåòëèííè èíäèêàòîðè: çà ïðîñëåäÿâàíå
èçïúëíåíèåòî íà ïðîãðàìàòà çà ïðàíå.
Àêî å èçáðàíà ôóíêöèÿòà Delay Timer (òàéìåð çà
çàäàâàíå ÷àñà íà âêëþ÷âàíå íà ïðîãðàìàòà) ùå
ñå ïîêàæå âðåìåòî, êîåòî îñòàâà äî âêëþ÷âàíåòî
íà ïðîãðàìàòà (âèæ ñòð. 17).
Áóòîíè çà óïðàâëåíèå: çà èçáîð íà ôóíêöèèòå.
Çà èçáðàíàòà ôóíêöèÿ ùå ñâåòíå áóòîíúò.
ÒÅÐÌÎÐÅÃÓËÀÒÎÐ: çà çàäàâàíå íà òåìïåðàòóðàòà
èëè çà ñòóäåíî ïðàíå (âèæ ñòð. 19).
Áóòîí ÑÒÀÐÒ/ÀÍÓËÈÐÀÍÅ: çà ñòàðòèðàíå íà
ïðîãðàìèòå èëè çà àíóëèðàíå íà ïîãðåøíî
çàäàäåíîòî.
Èíäèêàòîð ÂÊËÞ×ÂÀÍÅ/ËÞÊ ÁËÎÊÈÐÀÍ: çà
èíôîðìàöèÿ äàëè ïåðàëíàòà ìàøèíà å âêëþ÷åíà
è äàëè ëþêúò ìîæå äà ñå îòâîðè (âèæ ñòð. 17).
Áóòîí ÂÊËÞ×ÂÀÍÅ/ÈÇÊËÞ×ÂÀÍÅ: çà
âêëþ÷âàíå è èçêëþ÷âàíå íà ïåðàëíàòà ìàøèíà.
ÏÐÎÃÐÀÌÀÒÎÐ: çà èçáîð íà ïðîãðàìèòå.
Ïî âðåìå íà èçïúëíåíèå íà ïðîãðàìàòà, êëþ÷úò
îñòàâà íåïîäâèæåí.
ÒÅÐÌÎÐÅÃÓËÀÒÎÐ
 ÏÐÎÃÐÀÌÀÒÎÐ
Ñâåòëèííè
èíäèêàòîðè
Áóòîíè çà
óïðàâëåíèå Èíäèêàòîð ÂÊËÞ×ÂÀÍÅ/
ËÞÊ ÁËÎÊÈÐÀÍ

17
BG
Ñåðâèçíî
îá ëóæâàíå
Ïðîáëåìè
Ïðåäïàçíè
ìåðêè ÏîääðúæêàÏðîãðàìè Ïåðèëíè
ïðåïàðàòè
Ìîíòèðàíå Îïè àíèå
Èíäèêàòîð ÂÊËÞ×ÂÀÍÅ/ËÞÊ ÁËÎÊÈÐÀÍ:
Ñâåòåùèÿò èíäèêàòîð ïîêàçâà, ÷å ëþêúò å áëîêèðàí çà èçáÿãâàíå íà ñëó÷àéíîòî ìó îòâàðÿíå.
Çà èçáÿãâàíå íà ùåòè å íåîáõîäèìî äà ñå èç÷àêà èíäèêàòîðúò äà ïðèìèãíå ïðåäè äà ñå îòâîðè ëþêúò.
 Áúðçîòî ïðèìèãâàíå íà èíäèêàòîðà çà ÂÊËÞ×ÂÀÍÅ/ÁËÎÊÈÐÀÍÅ ÍÀ ËÞÊÀ çàåäíî ñ òîâà íà ïîíå
îùå åäèí èíäèêàòîð ñèãíàëèçèðà çà ïîâðåäà (âèæ ñòð. 23).
Òåêóùè ôàçè:
Ïî âðåìå íà öèêúëà íà ðàáîòà èíäèêàòîðèòå ùå
ñâåòâàò ïîñëåäîâàòåëíî, çà äà ïîêàçâàò åòàïèòå
îò èçïúëíåíèåòî íà ïðîãðàìàòà:
Ïðåäïðàíå
Ïðàíå
Èçïëàêâàíå
Öåíòðîôóãà
Çàáåëåæêà: ïî âðåìå íà ôàçàòà íà îòòè÷àíå íà
âîäàòà ùå ñâåòíå èíäèêàòîðúò çà ôàçàòà íà
öåíòðîôóãàòà.
Áóòîíè çà óïðàâëåíèå
ÁÓÒÎÍÈÒÅ ÇÀ ÓÏÐÀÂËÅÍÈÅ èçïúëíÿâàò ðîëÿòà
íà èíäèêàòîðè.
Ñ èçáèðàíåòî íà åäíà ôóíêöèÿ ñâåòâà ñúîòâåòíèÿò
áóòîí.
Àêî èçáðàíàòà ôóíêöèÿ å íåñúâìåñòèìà ñúñ
çàäàäåíàòà ïðîãðàìà áóòîíúò ùå ïðèìèãâà è
ôóíêöèÿòà íÿìà äà ñå âêëþ÷è.
 ñëó÷àé, ÷å ñå çàäàäå ôóíêöèÿ, êîÿòî å
íåñúâìåñòèìà ñ äðóãà, ïðåäâàðèòåëíî èçáðàíà,
ùå îñòàíå àêòèâíà ñàìî ïîñëåäíàòà èçáðàíà.
Ñâåòëèííè èíäèêàòîðè
Èíäèêàòîðèòå íîñÿò âàæíà èíôîðìàöèÿ.
Åòî êàêâî ñúîáùàâàò:
×à úò çà âêëþ÷âàíå íà ïðîãðàìàòà:
Ïðè èçáèðàíå íà ôóíêöèÿòà Delay Timer (÷àñ çà
âêëþ÷âàíå íà ïðîãðàìàòà) (âèæ ñòð. 19) ñ
âêëþ÷âàíåòî íà ìàøèíàòà ùå çàïî÷íå äà
ïðèìèãâà èíäèêàòîðúò çà èçáðàíîòî çàáàâÿíå:
Ñ òå÷åíèå íà âðåìåòî îñòàòúêúò äî íà÷àëîòî íà
ïðîãðàìàòà ùå ñå èçîáðàçÿâà ñ ïðèìèãâàíå íà
ñúîòâåòíèÿ èíäèêàòîð:
Ñëåä êàòî èçòå÷å âðåìåòî çà îòëàãàíå íà
èçïúëíåíèåòî, ïðèìèãâàùèÿò ñâåòëèíåí
èíäèêàòîð ùå óãàñíå è èçáðàíàòà ïðîãðàìà ùå
ñå ñòàðòèðà.

18
BG
Âèä òúêàíè è
çàìúðñÿâàíå Ïðîãð. Òåìïå- ðàòóðà
Ïåðèëåí
ïðåïàðàò Îìåêîòèòåë
Îïöèÿ
Ïðåïàðàò
ïðîòèâ
ïåòíà /
Èçáåëâàù
ïðåïàðàò
Ïðîäúë è-
òåëíîñò íà
öèêúëà
(ìèíóòè)
Îïèñàíèå íà öèêúëà íà
ïðàíå
ï
ð
åä-
ï
ð
àíå
ï
ð
à-
íå
Ñòàíäà
ð
òíè
Ïàìó÷íè:
Áåëè
èçêëþ÷èòåëíî çàìú
ð
ñåíè
(ֈ
ð
øà
ô
è, ïîê
ð
èâêè è ä
ð
.)
190°C 167
Ï
ð
åäï
ð
àíå, ï
ð
àíå, èçïëàêâàíå,
öåíò
ð
î
ô
óãè
ð
àíå ïî â
ð
åìå è â ê
ð
àÿ íà
öèêúëà
Ïàìó÷íè:
Áåëè
èçêëþ÷èòåëíî çàìú
ð
ñåíè
(ֈ
ð
øà
ô
è, ïîê
ð
èâêè è ä
ð
.)
290°C
Äåëèêàòåí /
Îáèêíîâåí 152 Ï
ð
àíå, èçïëàêâàíå, öåíò
ð
î
ô
óãè
ð
àíå
ïî â
ð
åìå è â ê
ð
àÿ íà öèêúëà
Ïàìó÷íè:
Áåëè è öâåòíè,
óñòîé÷èâè, ñèëíî çàìú
ð
ñåíè 260°C
Äåëèêàòåí /
Îáèêíîâåí 150 Ï
ð
àíå, èçïëàêâàíå, öåíò
ð
î
ô
óãè
ð
àíå
ïî â
ð
åìå è â ê
ð
àÿ íà öèêúëà
Ïàìó÷íè:
Áåëè è öâåòíè,
äåëèêàòíè, ñèëíî çàìú
ð
ñåíè 240°C
Äåëèêàòåí /
Îáèêíîâåí 142 Ï
ð
àíå, èçïëàêâàíå, öåíò
ð
î
ô
óãè
ð
àíå
ïî â
ð
åìå è â ê
ð
àÿ íà öèêúëà
Ïàìó÷íè:
Áåëè, ìàëêî
çàìú
ð
ñåíè, è öâåòíè,
äåëèêàòíè(
ð
èçè,
ô
ëàíåëè è ò.í.)
340°C
Äåëèêàòåí /
Îáèêíîâåí 99 Ï
ð
àíå, èçïëàêâàíå, öåíò
ð
î
ô
óãè
ð
àíå
ïî â
ð
åìå è â ê
ð
àÿ íà öèêúëà
Ñèíòåòè÷íè:
Öâåòíè,
óñòîé÷èâè, ñèëíî çàìú
ð
ñåíè
(áåáåøêî áåëüî è ò.í.)
460°C Äåëèêàòåí 80 Ï
ð
àíå, èçïëàêâàíå,
ô
óíêöèÿ Ï
ð
îòèâ
ñìà÷êâàíå èëè äåëèêàòíà öåíò
ð
î
ô
óãà
Ñèíòåòè÷íè:
Öâåòíè, óñòîé÷èâè,
ñèëíî çàìú
ð
ñåíè (áåáåøêî áåëüî è ò.í.) 440°C
Äåëèêàòåí 71 Ï
ð
àíå, èçïëàêâàíå,
ô
óíêöèÿ Ï
ð
îòèâ
ñìà÷êâàíå èëè äåëèêàòíà öåíò
ð
î
ô
óãà
Ñèíòåòè÷íè:
Öâåòíè, äåëèêàòíè
(âñÿêàêâî ñëàáî çàìú
ð
ñåíî ï
ð
àíå) 540°C
Äåëèêàòåí 71 Ï
ð
àíå, èçïëàêâàíå,
ô
óíêöèÿ Ï
ð
îòèâ
ñìà÷êâàíå èëè äåëèêàòíà öåíò
ð
î
ô
óãà
Âúëíåíè 640°C 50 Ï
ð
àíå, èçïëàêâàíå, äåëèêàòíà
öåíò
ð
î
ô
óãà
Ì íîãî äåëèêàòíè òúêàíè
(ïå
ð
äåòà, êîï
ð
èíà, âèñêîçà è ò.í.) 730°C 52 Ï
ð
àíå, èçïëàêâàíå,
ô
óíêöèÿ Ï
ð
îòèâ
ñìà÷êâàíå èëè èçòî÷âàíå íà âîäàòà
Çà ñâîáîäíîòî â
ð
åìå
Ïàìó÷íè:
Áåëè è öâåòíè,
óñòîé÷èâè, ñèëíî çàìú
ð
ñåíè 860°C 60 Ï
ð
àíå, èçïëàêâàíå, öåíò
ð
î
ô
óãè
ð
àíå
ïî â
ð
åìå è â ê
ð
àÿ íà öèêúëà
Ïàìó÷íè:
Áåëè, ìàëêî
çàìú
ð
ñåíè, è öâåòíè äåëèêàòíè
(
ð
èçè,
ô
ëàíåëè è ò.í.)
940°C 50 Ï
ð
àíå, èçïëàêâàíå, öåíò
ð
î
ô
óãè
ð
àíå
ïî â
ð
åìå è â ê
ð
àÿ íà öèêúëà
Ñèíòåòè÷íè:
Öâåòíè, äåëèêàòíè
(âñÿêàêâî ñëàáî çàìú
ð
ñåíî ï
ð
àíå) 10 40°C 40 Ï
ð
àíå, èçïëàêâàíå è äåëèêàòíà
öåíò
ð
î
ô
óãà
Ñèíòåòè÷íè:
Öâåòíè, äåëèêàòíè
(âñÿêàêâî ñëàáî çàìú
ð
ñåíî ï
ð
àíå) 11 30°C 30 Ï
ð
àíå, èçïëàêâàíå è äåëèêàòíà
öåíò
ð
î
ô
óãà
Ñïî
ð
ò
Ñïî
ð
òíè îáóâêè
(Ì À Ñ . 2 ÷ è
ô
òà.) 12 30°C 50
Ï
ð
àíå ñúñ ñòóäåíà âîäà (áåç ïå
ð
èëåí
ï
ð
åïà
ð
àò), ï
ð
àíå, èçïëàêâàíå è
äåëèêàòíà öåíò
ð
î
ô
óãà
Ñïî
ð
òíî îáëåêëî
(àíöóçè, êúñè ïàíòàëîíêè è ò.í.) 13 30°C 63
Ï
ð
àíå, èçïëàêâàíå,
öåíò
ð
î
ô
óãè
ð
àíå ïî â
ð
åìå è â ê
ð
àÿ
íà öèêúëà
×ÀÑÒÈ×ÍÈ ÏÐÎÃÐÀÌÈ
Èçïëàêâàíå Äåëèêàòåí /
Îáèêíîâåí È çïëàêâàíå è öåíò
ð
î
ô
óãà
Öåíò
ð
î
ô
óãà Èçòî÷âàíå íà âîäàòà è öåíò
ð
î
ô
óãà
Èçòî÷âàíå íà âîäàòà Èçòî÷âàíå íà âîäàòà
Âêëþ÷âàíå è ïðîãðàìè
Òàáëèöà ïðîãðàìèòå
Áåëåæêà
-Çà ïðîãðàìè 8 - 9 å ïðåïîðú÷èòåëíî äà íå çàðåæäàòå ïåðàëíÿòà ñ ïîâå÷å îò 3,5 êã. ïðàíå.
-Çà ïðîãðàìà 13 å ïðåïîðú÷èòåëíî äà çàðåæäàòå ïåðàëíÿòà ñ íå ïîâå÷å îò 2 êã. ïðàíå.
Çà îïèñàíèåòî íà ôóíêöèÿòà áåç íàìà÷êâàíå âèæ ëåñíî ãëàäåíå íà ñëåäâàùàòà ñòðàíèöà. Äàííèòå
ïðèâåäåíè â òàáëèöàòà ñà óêàçàòåëíè.
Ñïåöèàëíà ïðîãðàìà
Äíåâíà 30 (ïðîãðàìà 11 çà ñèíòåòè÷íè òúêàíè), êîÿòî å ðàçðàáîòåíà çà ïðàíå íà ëåêî çàìúðñåíè äðåõè:
òðàå ñàìî 30 ìèíóòè è ïî òîçè íà÷èí ïåñòè âðåìå è ñðåäñòâà. Ñ èçáèðàíåòî íà ïðîãðàìàòà (11 íà 30°C)
ìîæå äà ïåðåòå åäíîâðåìåííî òúêàíè îò ðàçëè÷åí âèä (ñ èçêëþ÷åíèå íà âúëíà è êîïðèíà) ñ ìàêñèìàëíî
òåãëî äî 3 êã. Ïðåïîðú÷âà ñå èçïîëçâàíåòî íà òå÷åí ïåðèëåí ïðåïàðàò.
Êðàòêî îïè àíèå: âêëþ÷âàíå íà ïðîãðàìà
1. Äà ñå âêëþ÷è ïåðàëíàòà ìàøèíà ñ íàòèñêàíå íà
áóòîíà . Âñè÷êè èíäèêàòîðè ùå ñâåòíàò çà
íÿêîëêî ñåêóíäè, ñëåä òîâà ùå óãàñíàò è
èíäèêàòîðúò ÂÊËÞ×ÂÀÍÅ/ËÞÊ ÁËÎÊÈÐÀÍ ùå
çàïî÷íå äà ïðèìèãâà.
2. Çàðåäåòå äðåõèòå çà ïðàíå è çàòâîðåòå ëþêà.
3. Ñ ÏÐÎÃÐÀÌÀÒÎÐÀ ñå çàäàâà æåëàíàòà ïðîãðàìà.
4. Çàäàâà ñå òåìïåðàòóðàòà çà ïðàíå (âèæ ñòð. 19).
5. Èçñèïåòå ïðàõà è äîïúëíèòåëíèòå ïðåïàðàòè (âèæ
ñòð. 20).
6. Ñòàðòèðàéòå ïðîãðàìàòà, êàòî íàòèñíåòå áóòîíà
ÑÒÀÐÒ/ÀÍÓËÈÐÀÍÅ. Çà àíóëèðàíå íàòèñíåòå
áóòîíà ÑÒÀÐÒ/ÀÍÓËÈÐÀÍÅ ïîíå çà 2 ñåêóíäè.
.  êðàÿ íà ïðîãðàìàòà èíäèêàòîðúò ÂÊËÞ×ÂÀÍÅ/
ËÞÊ ÁËÎÊÈÐÀÍ ïðèñâåòâà, ïîêàçâàéêè, ÷å
ëþêúò ìîæå äà ñå îòâîðè. Èçâàæäà ñå ïðàíåòî è
ëþêúò ñå îñòàâÿ ëåêî îòâîðåí, çà äà èçñúõíå
êàçàíà. Ïåðàëíàòà ìàøèíà ñå ÈÇÊËÞ×ÂÀ ñ
íàòèñêàíå íà áóòîíà .

19
BG
Ïðîãðàìèðàíå ïîðåä
ïîòðåáíî òèòå
Ñåðâèçíî
îá ëóæâàíå
Ïðîáëåìè
Ïðåäïàçíè
ìåðêè ÏîääðúæêàÏðîãðàìè Ïåðèëíè
ïðåïàðàòè
Ìîíòèðàíå Îïè àíèå
C
Çàäàâàíå íà òåìïåðàòóðàòà
Òåìïåðàòóðàòà çà ïðàíå ñå çàäàâà ñúñ çàâúðòàíå íà ÒÅÐÌÎÐÅÃÓËÀÒÎÐÀ (âèæ Òàáëèöàòà ñ ïðîãðàìèòå íà ñòð. 18).
Òåìïåðàòóðàòà ìîæå äà ñå íàìàëè äî ñòóäåíî ïðàíå ( ).
Ôóíêöèè
Ðàçëè÷íèòå ôóíêöèè çà ïðàíå, ïðåäâèäåíè â ïåðàëíàòà ìàøèíà, äàâàò âúçìîæíîñò çà ïîñòèãàíå íà
æåëàíîòî áÿëî è ÷èñòî ïðàíå. Çà âêëþ÷âàíå íà ôóíêöèèòå:
1. íàòèñêà ñå áóòîíúò íà æåëàíàòà ôóíêöèÿ ñúãëàñíî òàáåëàòà ïî-äîëó;
2. ñâåòâàíåòî íà èíäèêàòîðà ñèãíàëèçèðà, ÷å ôóíêöèÿòà å âêëþ÷åíà.
Çàáåëåæêà: Áúðçîòî ïðèìèãâàíå íà áóòîíà ïîêàçâà, ÷å ôóíêöèÿòà íå ìîæå äà áúäå èçáðàíà çà çàäàäåíàòà
ïðîãðàìà.
Ôóíêöèè Äåéñòâèå àê äà ñå èçïîëçâà Ðàáîòè ñ
ïðîãðàìè:
Çàäàâàíå ñëåä
êîëêî ÷àñà äà
ñå ñòàðòèðà
ïðîãðàìàòà
Èçïúëíåíèåòî
íà ïðîãðàìàòà
ìîæå äà áúäå
îòëîæåíî â
ðàìêèòå íà 9
÷àñà
Äà ñå íàòèñíå íÿêîëêî ïúòè áóòîíúò, äîêàòî èíäèêàòîðúò ñâåòíå
íà æåëàíèÿ ÷àñ çà âêëþ÷âàíå íà ïðîãðàìàòà
Ïðè ïåòîòî íàòèñêàíå íà áóòîíà ôóíêöèÿòà ùå ñå èçêëþ÷è
Çàáåëåæêà: Ïðè íàòèñíàò áóòîí Start/Reset ÷àñúò íà âêëþ÷âàíå
ìîæå äà ñå ïðîìåíè ñàìî êàòî ñå íàìàëÿâà
Âñè÷êè
Èçáåëâàíå
Öèêúë íà
èçáåëâàíå,
ïîäõîäÿù çà
îòñòðàíÿâàíå
íà óïîðèòè
ïåòíà
Íàïîìíÿìå âè äà èçñèïåòå áåëèíàòà â äîïúëíèòåëíîòî
îòäåëåíèå 4 (âèæ ñòð. 20)
Íå ñå äîïóñêà ôóíêöèÿòà ëåñíî ãëàäåíå.
2, 3, 4, 5,
èçïëàêâàíèÿ.
Ëåñíî ãëàäåíå
Íàìàë ÿ âà
íàìà÷êâàíåòî
íà òúêàíèòå è
óëåñíÿâà
ãëàäåíåòî
Ñúñ çàäàâàíåòî íà òàçè ôóíêöèÿ ïðîãðàìèòå 4, 5, 7 è Äåëèêàòíî
ïðàíå ñïèðàò áåç äà èçñòèñêâàò ïðàíåòî (áåç íàìà÷êâ àíå) è
èíäèêàòîðúò íà ôàçàòà çà èçïëàêâàíå ùå ïðèìèãâà:
- çà äà çàâúðøè öèêúëúò, íàòèñíåòå áóòîíúò ÑÒÀÐÒ/ÀÍÓËÈÐÀÍÅ;
- çà äà íàïðàâèòå ñàìî èçòî÷âàíå, ïîñòàâåòå êëþ÷à çà
ïðîãðàìèòå íà è íàòèñíåòå áóòîíà ÑÒÀÐÒ/ÀÍÓËÈÐÀÍÅ
Íå ñå äîïóñêà ôóíêöèÿòà èçáåëâàíå.
3, 4, 5, 7, 8,
9, 10,
èçïëàêâàíèÿ.
Áóòîí çà
Èçêëþ÷âàíå íà
öåíòðîôóãàòà
Òîçè áóòîí
ñëóæè çà
èçêëþ÷âàíå íà
öåíòîôóãàòà
Ïðå ïîðú÷â àìå
Âè äà ãî
ïîëçâàòå,
êîãàòî ïåðåòå
äðåõè êîèòî
ñà òðóäíè çà
ãëàäåíå
Ïðåïîðú÷âà ñå ïðè ïðàíå, êîåòî òðóäíî ñå ãëàäè
Âñè÷êè
îñâåí 7 è
îòòè÷àíåòî.
Áåëåæêà: Çà äà ñå èç åãíàò ïðåêàëåíè âè ðàöèè, ïðåäè âñÿêà öåíòðîôóãà, ìàøèíàòà ðàçïðåäåëÿ
òîâàðà ðàâíîìåðíî, òîâà ñòàâà êàòî ñå èçâúðøâàò íåïðåêúñíàòè ðîòàöèè íà àðà àíà ïðè ñêîðîñò
ìàëêî ïî-âèñîêà îò òàçè ïðè ïðàíå. Êîãàòî, âúïðåêè ïîñëåäîâàòåëíè îïèòè, òîâàðúò íå úäå
ïåðôåêòíî ðàçïðåäåëåí, ìàøèíàòà èçâúðøâà öåíòðîôóãàòà ïðè ñêîðîñò, ïî-íèñêà îò
ïðåäâèäåíàòà. Ïðè íàëè÷èå íà ïðåêàëåíî äå àëàíñèðàíå ïåðàëíÿòà èçâúðøâà ðàçïðåäåëåíèåòî
âìåñòî öåíòðîôóãàòà.
Åâåíòóàëíèòå îïèòè çà àëàíñèðàíå ìîãàò äà óäúëæàò î ùàòà ïðîäúëæèòåëíîñò íà öèêúëà äî
ìàêñèìóì 10 ìèíóòè.

20
BG
Êà åòà çà ïåðèëíèòå ïðåïàðàòè
Äîáðèÿò ðåçóëòàò îò ïðàíåòî çàâèñè è îò ïðàâèëíîòî
äîçèðàíå íà ïåðèëíèòå ïðåïàðàòè. Ñ ïðåäîçèðàíå
íå ñå ïåðå åôåêòèâíî è ñå ñïîìàãà çà îòëàãàíåòî íà
íàëåïè ïî âúòðåøíàòà ñòðàíà íà ïåðàëíàòà ìàøèíà
è äî çàìúðñÿâàíå íà îêîëíàòà ñðåäà.
Èçòåãëåòå êàñåòàòà çà
ïåðèëíèòå ïðåïàðàòè è
èçñèïåòå ïðàõà çà
ïðàíå è äîïúëíèòå
ïðåïàðàòè ïî ñëåäíèÿ
íà÷èí.
îòäåëåíèå 1: Ïðåïàðàò çà ïðåäïðàíå (íà ïðàõ)
Ïðåäè äà èçñèïåòå ïðåïàðàòà, ïðîâåðåòå äàëè
íå å ïîñòàâåíî äîïúëíèòåëíîòî îòäåëåíèå 4.
îòäåëåíèå 2: Ïðåïàðàò çà ïðàíå
(íà ïðàõ èëè òå÷åí)
Òå÷íèÿò ïðåïàðàò ñå èçñèïâà ïðåäè âêëþ÷âàíåòî
íà ìàøèíàòà.
îòäåëåíèå 3: Äîïúëíèòåëíè ïðåïàðàòè
(îìåêîòèòåë è äð.)
Îìåêîòèòåëÿò íå òðÿáâà äà èçëèçà èçâúí ðåøåòêàòà.
äîïúëíèòåëíî îòäåëåíèå 4: Áåëèíà
 Íå èçïîëçâàéòå ïðåïàðàòè çà ðú÷íî ïðàíå,
çàùîòî îáðàçóâàò ìíîãî ïÿíà.
Öèêúë íà èçáåëâàíå
 Îáèêíîâåíàòà áåëèíà ñå èçïîëçâà çà óñòîé÷èâè
áåëè òúêàíè, à äåëèêàòíàòà áåëèíà çà öâåòíè,
ñèíòåòè÷íè è âúëíåíè òúêàíè.
Ïîñòàâåòå ïðèëîæåíîòî
äîïúëíèòåëíî îòäåëåíèå
4 â îòäåëåíèå 1.
Ïðè äîçèðàíåòî íà
áåëèíàòà íå
íàäâèøàâàéòå
ìàêñèìàëíîòî íèâî,
ïîêàçàíî íà öåíòðàëíèÿ
ùèôò (âèæ ôèãóðàòà).
Ñàìî çà èçáåëâàíå èçñèïåòå áåëèíàòà â
äîïúëíèòåëíîòî îòäåëåíèå 4, èçáåðåòå ïðîãðàìà
èçïëàêâàíå è âêëþ÷åòå äîïúëíèòåëíàòà
ôóíêöèÿ çà èçáåëâàíå (âèæ ñòð. 19).
Çà èçáåëâàíå ïî âðåìå íà ïðàíå èçñèïåòå ïåðèëíèÿ
ïðåïàðàò è äîïúëíèòåëíèòå ïðåïàðàòè, èçáåðåòå
æåëàíàòà ïðîãðàìà è âêëþ÷åòå äîïúëíèòåëíàòà
ôóíêöèÿ çà èçáåëâàíå (âèæ ñòð. 19).
Èçïîëçâàíåòî íà äîïúëíèòåëíîòî îòäåëåíèå 4
èçêëþ÷âà ïðåäïðàíåòî.
Ðàçïðåäåëÿíå íà ïðàíåòî
 Ðàçïðåäåëåòå ïðàíåòî ñúîáðàçíî:
- òèïà íà òúêàíèòå / çíàêúò âúðõó åòèêåòà.
- öâåòîâåòå: îòäåëåòå öâåòíèòå îò áåëèòå äðåõè.
 Èçïðàçíåòå äæîáîâåòå è ïðîâåðåòå êîï÷åòàòà.
 Íå íàäâèøàâàéòå óêàçàíèòå ñòîéíîñòè çà
òåãëîòî íà ñóõîòî ïðàíå:
Óñòîé÷èâè òúêàíè: ìàêñèìàëíî 4,5 êã
Ñèíòåòè÷íè òúêàíè: ìàêñèìàëíî 2,5 êã
Ôèíè òúêàíè: ìàêñèìàëíî 2 êã
Âúëíåíè òúêàíè: ìàêñèìàëíî 1 êã
Êîëêî òåæè ïðàíåòî?
1 ÷àðøàô 400-500 ã
1 êàëúôêà 150-200 ã
1 ïîêðèâêà 400-500 ã
1 õàâëèÿ 900-1200 ã
1 êúðïà 150-250 ã
Ñïåöèôè÷íî ïðàíå
Ïåðäåòà: ñãúíåòå ãè è ãè ïîñòàâåòå â êàëúôêà
èëè ìðåæåñòà òîðáà. Ïåðåòå ñàìî òÿõ áåç äà
íàäâèøàâàòå ïîëîâèíàòà îò òîâàðà. Èçïîëçâàéòå
ïðîãðàìà , êîÿòî àâòîìàòè÷íî èçêëþ÷âà
öåíòðîôóãàòà.
ßêåòà ïóõåíà ïîäïëàòà è àíóðàöè: àêî
ïóõåíàòà ïîäïëàòà å îò ãúñêà èëè ïàòèöà ìîãàò
äà ñå ïåðàò â ïåðàëíàòà ìàøèíà. Îáúðíåòå
ÿêåòàòà è çàðåäåòå ìàøèíàòà äî 2-3 êã, êàòî
ïîâòîðèòå èçïëàêâàíåòî äâà èëè òðè ïúòè è
èçïîëçâàòå ëåêà öåíòðîôóãà.
Âúëíåíè òúêàíè: çà äà ïîñòèãíåòå íàé-äîáðè
ðåçóëòàòè, èçïîëçâàéòå ñïåöèôè÷íè ïåðèëíè
ïðåïàðàòè è íå çàðåæäàéòå ñ ïîâå÷å îò 1 êã.
Ïåðèëíè ïðåïàðàòè è òúêàíè
123
4
