Infinite L-Com SRAQ-G213 User manual

OZONE TRANSMITTER
User Guide for SRAQ-G213
Thank you for choosing L-com product. To ensure safe, accurate performance and product longevity, please take a moment to familiarize yourself
with this manual before powering the device. Please keep it handy for future reference. In case of any questions regarding the installation or use of
product, please call us at 800.341.5266.
Reach out to us at [e-mail] and visit our website at www.l-com.com
M_L-com_SRAQ-G213_11/2022_R1.0
1
Product Description
The SRAQ-G213 gas sensor module detects the presence and concentration of Ozone (O3) gas. Integrated circuitry produces a non-linear voltage
signal corresponding to the gas concentration. The SRAQ-G213 has high sensitivity and selectivity to ozone, and can detect gas concentration in the
range of 10-1000 ppb.
Features
 High sensitivity and good selectivity to O3
 24 VDC power supply
 Fast response
 Analog output
 Wall or DIN rail mountable
Applications
 Food processing and preservation
 Medical hygiene / disinfectant
 Water disinfection
 General environmental air quality monitoring

2
Technical Parameters
Detection Range 10  1000 PPB
Detecting Gas Ozone
Working Voltage 24 VDC ± 0.2 V
Working Current <150 mA
Output Method 0  10 V (Non-linear)
Response Time >3 sec
Recovery Time ≤60 sec
Working Temperature -10~50 °C
Working Humidity <95% RH (Non condensing)
Preheat Time Not less than 2 hours, longer pre-heat time, more stable output
Mounting Diagram
1. Wall mount, hole diameter 4 mm, pitch 36 mm
2. DIN 35 mm rail mount
Notes
1. Confirm the polarity and the voltage of the power supply before powering ON the sensor.
2. The analog output of this module is non-linear. When connect to microcontroller, it should be connected to ADC interface of the microcontroller.
3. The relationship between the resistance ratio and the concentration is a logarithmic relationship.

3
Electrical Diagram
1. 24V and GND are the power interface, D1 is the power indicator.
2. Aout is the analog output interface, VR2 is the signal trimmer potentiometer.
3. VR1 is the magnification (the output of 0-5V and 0-10V can be adjusted freely through this potentiometer).
4. The load resistance of the sensor composed of R7 and RP2 potentiometer is in parallel relationship (can be changed by user).
5. Different sensors use different parameters. The parameters are based on the PCB board.
Typical Sensitivity Curve
The calculation of the resistance ratio according to the output voltage is as follows:
The sensor is energized in relatively clean air for more than half an hour and after measure the output voltage value of Aout.
VCC is the power supply voltage, 5 VDC
RL is the load resistance
VRL = Aout = Vair value
When the sensor detects gas, the RS value can be calculated after measuring the value of Aout.
The VRL value at this time is the Aout value after gas is detected. It is different from the value of the above formula. The VCC value and the RL value
are the same as above.
The R0 and RS values are obtained, and the specific concentration value of the gas is converted by the RS / R0 value of the Sensitivity Characteristic
Curve (To get 0-10V output, through 0-5V, the circuit is enlarged 2 times, so use the calculation method accordingly. VCC is based on 5V as the
benchmark).
The ordinate in the figure is the resistance ratio of the sensor (Rs/R0). The abscissa is the gas concentration. Rs represents the resistance value of the
sensor in different concentrations of gas, and R0 represents the resistance value of the sensor in clean air. All tests in the figures were done under
standard test conditions.
