InFocus HDTV Remote Hexcodes Including Discrete Hexcodes
Label/Function Hexcode Comments*
1 ON-OFF 0D5 Power Toggle for last-used
mode of remote
2 TV 0C5 Discrete TV Power On
3 DVD (RCA default of 3000);
AUX/AUX-HD programmed
to 3000; AUX/AUX-HD
programmed to universal
DVD
AC5 Discrete RCA DVD Power
On; Works with AutoTuning
Feature
4 VCR (RCA default of 2000);
AUX/AUX-HD programmed
to 2000
1C5 Discrete RCA DVD Power
On; Works with AutoTuning
Feature
5 SAT/CABLE (RCA default
of 5000 SAT1); AUX/AUX-
HD programmed to 5000
SAT1 or AUX programmed
to universal SAT or CABLE)
8C5 Discrete RCA SAT/Cable
Power On; Works with
AutoTuning Feature
5 SAT/Cable (programmed to
5001 SAT2 or AUX/AUX-
HD programmed to 5001
SAT1
BC5 Discrete RCA SAT/Cable
Power On; Works with
AutoTuning Feature
6 AUX (default 2001 VCR2;
any VCR programmed to
AUX or AUX-HD)
2C5 Discrete RCA VCR2 Power
On; Works with AutoTuning
Feature
7 AUDIO default 4003;
AUDIO or AUX
programmed to 4003;
AUDIO or AUX
programmed to universal
amp or AV receiver
3C5 Discrete RCA AUDIO
Receiver Power On; Works
with AutoTuning Feature
7 AUDIO or AUX
programmed to 4004 4C5
7 AUDIO or AUX
programmed to RCA
PHONO 4005 or universal
PHONO
5C5
7 AUDIO or AUX
programmed to RCA TAPE
4006 or universal TAPE
6C5
7 AUDIO or AUX
programmed to RCA CD
4007 or universal CD player
7C5
8 GO BACK 0D8 Last channel; go back to
previous menu or exit main
menu
9 CH+ 0D2 Channel Up; Page+ in Guide
10 CH - 0D3 Channel Down; Page- in
Guide
11 MUTE 0C0
12 VOL+ 0D0
13 VOL- 0D1
Note: In remote, Volume
Punchthrough to Audio Amp
can be assigned.
14 GUIDE 0E5 Brings up program guide.
15 CLEAR 0F9 Clears out of on-screen
displays (exit)
16 INFO 0C3 Shows full channel banner.
17 MENU 0F7 Brings up main menu.
18 (UP) 0A6
19 (DOWN) 0A7
20 (LEFT) 0A9
21 (RIGHT) 0A8
Navigation
22 OK 00B
23 DIGIT 1 0CE
24 DIGIT 2 0CD
25 DIGIT 3 0CC
26 DIGIT 4 0CB
27 DIGIT 5 0CA
28 DIGIT 6 0C9
29 DIGIT 7 0C8
30 DIGIT 8 0C7
31 DIGIT 9 0C6
32 DIGIT 0 0CF
* For a complete description of remote functions (excluding discretes), see User's Manual.
Note 1: By default, the TV responds to the 0 ("TV1") preamble. However, this can be
changed in the Connections > Special Features > Remote Setup menu so that the TV
responds to either the 5 ("TV2") or E ("TV3") remote preambles. (This might be done to
avoid command conflicts if there are 2 or 3 TVs within IR range of each other and you want
to control each TV independently). If that change is made in the menu, then the TV
responds to the hexcodes listed here, but with the assigned preamble (e.g., OK is now 50B
or E0B instead of the default 00B). When making this change, the remote must also be
programmed; see the User's Manual for instructions.
Note 2: Whereas the TV and remote will be able to be switched to support TV2 and TV3
preamble, the KBR755TA1 keyboard cannot. Therefore, if a user has three co-located
RCA/InFocus HDTV's, the keyboard will operate only with the TV which responds to the
"TV1" (0) preamble (i.e., the default preamble).
Label/Function Hexcode Comments*
33 INPUT 05C Toggle to next input (video
source)
INPUT+0 = 054 Discrete Front Input (video
source) (N/A to Slim DLP)
INPUT+1 = 055 Discrete Input 1
(composite/S-video source)
INPUT+2 = 056 Discrete Input 2
(composite/component video
source)
INPUT+3 = 057 Discrete Input 3
(composite/S-video source)
INPUT+4 = 058 Discrete Input 4
(composite/component video
source)
INPUT+5 = 075 Discrete HDMI/DVI Input
(video source)
INPUT+6 = 076 Discrete DTVLink Input
(video source) then toggle
INPUT+7 = 077 UNDEFINED Discrete Input
(video source)
INPUT+8 = (8 code) -
INPUT+9 = (9 code) -
INPUT+ON-OFF =
Discrete Off
0C4 Discrete TV Power Off
34 REVERSE 0E2
35 PLAY 0EA
36 FORWARD 0E3
37 RECORD 0E8
38 STOP 0E0
39 PAUSE 0E6
40 SKIP 0AC Skip Timer
LOW VOLTAGE (LVD) 00F When remote batteries get
low, a code is sent and the
TV notifies the user.
41 SOUND 0A5 Audio Mode / SAP Toggle
42 BACKLIGHT 0E1 For factory use
43 ANT-CAB 0FA Toggle between Antenna
Input and Cable Input
Discrete Cable Input 033
Discrete Antenna Input 034
44 PIP 0E4 Pip on/off toggle
45 SWAP 03C PIP swap main/PIP windows
47 CH CTRL 01A Toggle channel focus on
main or PIP
46 FORMAT 06F Toggle Screen Format
(Aspect ratio)
Discrete "Normal" Screen
Format
035
Discrete “Stretch” Screen
Format
036
Discrete “Zoom” Screen
Format
037
Discrete “Cinerama”
Screen Format
067
48 FREEZE 0F3 Freeze picture
49 PRESETS 0ED Toggle Picture Presets
Discrete Vibrant (Day)
Picture Preset
021
Discrete Natural Picture
Preset
022
Discrete Cinematic
(Night) Picture Preset
023
Discrete Videogame
Picture Preset
024
Discrete Professional
Picture Preset
025
Discrete Personal Picture
Preset
026
50 CC 07F Toggle closed captioning
51 FAV - (Need to press a number
after FAV to launch a web
browser favorite website)
FAV+0 = “FAV HOME” 0x20 (PPM5)
FAV+1 = “FAV 1” 0x80 (PPM5)
FAV+2 = “FAV 2” 0x81 (PPM5)
FAV+3 = “FAV 3” 0x82 (PPM5)
FAV+4 = “FAV 4” 0x83 (PPM5)
FAV+5 = “FAV 5” 0x84 (PPM5)
FAV+6 = “FAV 6” 0x85 (PPM5)
FAV+7 = “FAV SEARCH” 0xD7 (PPM5)
Launches favorite web
browser websites that have
been stored.
FAV+8 = 8 (8 code) -
FAV+9 = 9 (9 code) -
* For a complete description of remote functions (excluding discretes), see User's Manual.
