Infrared Seiko VK64 User manual

TABLE OF CONTENTS
MOVEMENT – SEIKO VK64
PRECAUTIONS AND PREVENTIVE MEASURES
CARING FOR YOUR INFRARED
WATER RESISTANCE
LIMITED WARRANTY
3
7
5
9
11
6

MOVEMENT - SEIKO VK64
MOVEMENT – SEIKO VK64
PRECAUTIONS AND PREVENTIVE MEASURES
CARING FOR YOUR INFRARED
WATER RESISTANCE
LIMITED WARRANTY
1. Normal position
2. Pull the crown out to the position
3. Turn the crown to set the hour and minute hands.
(Check that AM / PM is set correctly)
4. Push the crown back to the position
If the crown is pulled to the second position while the
chronograph has started, the chronograph hands will
continue to move. This is not a malfunction.
1. Normal position
2. Pull the crown out to the position
3. Turn the crown counter-clockwise to set the date
4. Push the crown back to the position
Do not set the date between 9:00PM and 3:00AM, otherwise
the date may not change properly. If it is necessary to set
the date during that period, rst change the time to any time
outside it, set the date, and then reset the correct time.
SETTING THE TIME SETTING THE DATE
A A
CB
A
A
3
INFRARED MANUAL

MOVEMENT - SEIKO VK64
4
INFRARED MANUAL
1. Normal position
2. Pull the crown out to the position
3. Press the pusher for two seconds and then release
4. Push the crown back to the position
It is not necessary to set the chronograph hands after the
battery is exchanged. If the chronograph hand positions
are incorrect, follow above procedure, all the chronograph
hands will be reset to “0” position.
1. Press the pusher to start the chronograph.
The chronograph hands will start moving.
2. Press the pusher again to stop the chronograph.
The chronograph hands will indicate the elapsed time.
3. Press the pusher to reset the chronograph.
All chronograph hands will reset to the “0” position.
The chronograph can measure up to 60 minutes and
chronograph stops after a measurement for 60 minutes.
RESET HOW TO USE THE CHRONOGRAPH
A
C
D
D
E
E
A

PRECAUTIONS AND PREVENTIVE MEASURES
5
INFRARED MANUAL
TEMPERATURE AND SHOCKS
Do not expose your watch to sudden temperature changes (exposure to sunlight followed by immersion in
cold watch) or extreme temperatures - over 60C (140F) or below 0C (32F)
MAGNETIC FIELDS
Do not expose your watch to intense magnetic elds such as loudspeakers, portable telephones,
computers or refrigerators, and other electromagnetic appliances.
SHOCKS
Avoid thermal or other shocks as it may harm your watch. In the event of a violent shock, you can contact
Infrared Customer Service for repairs.
HARMFUL PRODUCTS
Avoid direct contact with solvents, detergents and perfumes, cosmetic products, etc – this may damage
the bracelet, case or lead to discoloration.

CARING FOR YOUR INFRARED
6
INFRARED MANUAL
Infrared watches are built to the toughest manufacturing guidelines ensuring your timepiece is always
reliable and rugged. This is a workwear watch after all. However, here are a few tips to preserve and extend
your watch’s lifetime
• Clean the case and bracelet regularly - this will help prevent possible corrosion by perspiration.
• Avoid running the chronograph constantly as this will lead to shorter battery life.
Your watch is rated at 10 ATM which means you can clean it using a toothbrush and soapy water
occasionally.

WATER RESISTANCE
7
INFRARED MANUAL
Water Resistance of watches is rated based on laboratory pressure tests comparable to a swimmer or
diver sitting still at that pressure level. Unfortunately, many water-based activities involve a lot of movement
and other environmental changes such as temperatures. This means the watch’s water resistance may be
challenged or defeated when pushing to the maximal ATM.
The water resistance of a watch cannot be guaranteed permanently. It may be affected by aging gaskets
or by accidental shocks while being used.
Never pull the crown when the watch is under water as this will ood the watch and will lead to its
destruction. Make sure the crown is properly pushed in before entering the water with it

WATER RESISTANCE
8
INFRARED MANUAL
Key points:
• Water resistance does not include the strap – leather straps are particularly fragile to sea water
• Avoid showering with your Infrared as this may damage the nishing
• Make sure your crown is properly pushed before entering the water
METERS ATM FEET Hand
wash Rain Car wash Swim Diving
30 3 100
50 5 165
100 10 330
200 20 660

LIMITED WARRANTY
9
INFRARED MANUAL
COMPONENTS UNDER WARRANTY
Please note that your warranty covers only the
following parts:
• Movement
• Hands
• Dial
Repairs of the damaged part/s will only begin after a
thorough inspection.
Infrared Watches offers an extended warranty period of two (2) years from the date of purchase. As a
client, you are expected to abide by the following rules set to qualify for the international warranty.
EXCLUSIONS:
The warranty does not cover the following:
• Battery, case, crystal, strap and buckle or
bracelet, stem or crown
• Damage resulting from improper handling, lack
of care, accidents, or normal wear and tear
• Water damage due to negligence unless
marked water-resistant
• Repairs, on a watch not purchased from Infrared
Watches’ ofcial website or authorized resellers

CONTACT US
[email protected]
www.infrared-watches.com
INSTAGRAM: @infraredwatches.ofcial
FACEBOOK: Infrared Watches
