InfRec Thermo Gear G100 User manual

Thermo Gear
G100/G120
Operation Manual
NEC Avio Infrared Technologies CO., Ltd.

Thermo Gear
G100/G120
Operation Manual
Attention
G100/G120 is controlled by the export law. When
y
ou
reexport this product from
y
our countr
y
, the export
license of your country is required.
- Disposing of your used our product -
In the European Union
EU-wide legislation as implemented in each Member State requires
that used electrical and electronic products carrying the
mark(left) must be disposed of separately from normal
household waste. This include electrical accessories, such as
chargers orAC adaptors.
When you dispose of such products, please follow the
agreements made by between you and us.
The mark on the electrical and electronic products only
applies to the current European Union Member States.
Outside the European Union
If you wish to dispose of used electrical and electronic
products outside the Euro
p
ean Union, please contact you
r
local authority and ask for the correct method of disposal.
NEC Avio Infrared Technologies Co., Ltd.

NEC Avio Infrared Technologies Co., Ltd.

Contents
CONTENTS
PREFACE············································································································1
MEASURES FOR SAFETY···············································································3
PRODUCT DETAILS·························································································13
OVERALL CONSTRUCTION··········································································14
ICON DISPLAYS AND NAMES·······································································17
1. PREPARATION
CHARGING BATTERIES··················································································1－1
INSERTING BATTERIES··················································································1－2
INSERTING THE SD CARD ·············································································1－3
SETTING THE CLOCK·····················································································1－4
ATTACHING STANDARD ACCESSORIES···················································1－5
CONFIRMING THE SETTINGS ······································································1－7
2. BASIC
POWER ON/OFF·································································································2－1
THERMAL IMAGE MEASUREMENT···························································2－1
VISIBLE IMAGE DISPLAY··············································································2－3
LASER POINTER ·······························································································2－4
SINGLE IMAGE SAVE······················································································2－5
REPLAY ···············································································································2－7
FILE DELETION ································································································2－8
FORMAT··············································································································2－11
3. SHORTCUT
SHORTCUT FUNCTIONS·················································································3－1
95691-2935-0000

Contents
4.ADVANCED
MENU····················································································································4－1
SAVE MODE – SINGLE IMAGE······································································4－2
SAVE MODE – INTERVAL···············································································4－2
SAVE MODE – MOVING IMAGE····································································4－4
SAVE MODE – PANORAMA ············································································4－6
SCALE – COLOR PALETTE ············································································4－12
SCALE – COL TONE··························································································4－12
SCALE – TMP UNIT···························································································4－13
SCALE – TMP SCALE························································································4－13
SCALE – ZOOM··································································································4－14
SCALE – COMPOSITE ······················································································4－15
MEASURE – TRACE CURSOR ········································································4－21
MEASURE – DELTA TEMP··············································································4－22
MEASURE – RANGE··························································································4－23
MEASURE – WAVE····························································································4－24
MEASURE – TEXT·····························································································4－25
MEASURE – INTVL SAVE················································································4－26
MEASURE – MOVING IMAGE········································································4－28
MEASURE – PANORAMA ················································································4－29
CAL – EMISSIVITY CAL··················································································4－30
CAL – AMBIENT COMPENSATION ······························································4－32
CAL – LENS ASSEMBLY ··················································································4－34
CAL – REF CAL ··································································································4－35
CAL – B.GROUND ······························································································4－36
CAL – CALIBRATION (NUC)···········································································4－37
CAL – FILTER·····································································································4－38
CAL – AVERAGE································································································4－39
CAL – EDGE ENHANCING ··············································································4－40
ALARM – ALARM······························································································4－41
ALARM – COLOR ALARM (Isotherm)···························································4－44
DATA – VIS IMAGE LINK················································································4－46
DATA – VOICE MEMO SAVE··········································································4－47
DATA – VOICE REPLAY ··················································································4－48
DATA – MAKE FOLDER···················································································4－49
DATA – SELECT FOLDER ···············································································4－50
DATA – RENAME FOLDER ·············································································4－51
DATA – DELETE FOLDER···············································································4－52
SET UP··················································································································4－53
95691-2935-0000

Contents
4.ADVANCED
CONNECTING TO PC·······················································································4－54
SEEING IMAGES ON THE MONITOR··························································4－55
ALARM OUTPUT·······························································································4－56
5. MAINTENANCE
INSPECTION / MAINTENANCE·····································································5－1
WHAT IS TO BE DONE·····················································································5－2
6. LIMITED WARRANTY
LIMITED WARRANTY·····················································································6－1
7. SPECIFICATIONS
SPECIFICATIONS······························································································7－1
8. APPENDIX
PRINCIPLE··········································································································8－1
PRACTICAL MEASUREMENT·······································································8－7
MEASURING DISTANCE AND MEASURING FIELD OF VIEW··············8－8
EMISSIVITY OF VARIOUS MATERIALS·····················································8－10
CHECK SHEET FOR SAFETY AND STORAGE
95691-2935-0000

Contents
95691-2935-0000

Preface
◎ PREFACE
▼GREETING
We thank you for your purchase of the Thermo Gear Model G100/G120. Please use
it correctly after reading this manual.
This manual provides information necessary to operate it correctly. Please let us or
our distributor know if there’s anything unclear.
Please check the product condition and verify that no obvious shipping damage has
occurred. Refer to our standard accessories listed on the next page.
You may write the distributor name and address for your possible contact later for
any damage or missing or repair.
Please open the package after it adapts to the room temperature to avoid any cause of
failure due to dewdrop on the surface of the product.
▼FOR SAFE OPERATION
This product is manufactured considering the safety operation. However users’
mishandling or mistake may cause a serious injury or an accident. Please read and
understand the contents of this manual carefully to avoid such risk.
95691-2935-0000
1

Preface
▼CAUTION
 The contents are subject to change without notice.
 This manual is copyrighted with all rights reserved. No part of this manual may
be reproduced, or transcribed without written permission.
 Please let us know any points unclear or missing in this manual.
▼VERIFY THE FOLLOWING IMMEDIATELY WHEN OPENING THE
PACKAGE
 G100/G120 Thermo Gear ····················································· 1
 AC Adapter ·········································································· 1
 Power cable (for AC Adapter) ·············································· 1
 Lens cap (Attached to the unit) ············································ 1
 Battery pack ··········································································· 1
 Battery charger ····································································· 1
 Power cable (for Battery charger) ········································ 1
 SD memory card ···································································· 1
 Wristband··············································································· 1
 USB cable ·············································································· 1
 Carrying case ········································································· 1
 InfRec Analyzer NS9500LT (PC soft were) ·························· 1
 Thermo Gear G100/G120 Operation manual ························· 1
95691-2935-0000
2

Preface
◎ MEASURES FOR SAFETY
We do not assume any responsibility for any damages or accidents caused by abuse,
misuse, or misapplication or modifications without our permission.
WARNING
This may cause customers’ side accidents.
CAUTION
This may cause product side accidents.
Both descriptions relate to the act that this should not be done or is to avoid the
accident in advance.
Also, we recommend to use the safety check sheet or storage check sheet on the last
pages.
<About battery>
The “battery” specified in the “MEASURES FOR SAFTY” section includes battery
pack.
95691-2935-0000
3

Preface
WARNING
 Read this operation manual carefully and take care not to cause any accident.
 Power:
(1) Use the specified AC adapter, and battery to avoid an electric shock or a fire.
(2) Verify the specified power source before the power on.
 Cable, adapter, cord:
(1) Use the AC adapter where is no water around.
(2) Do not use damaged AC adapter or extension cord.
(3) Do not remove the battery or AC adapter from the product while the
power switched to on.
(4) Proceed the correct connection procedure for the product, AC Adapter
and power outlet.
 Gas:
Use and store the product where no poison, flammable materials, explosives,
corrosion or steam exist.
 Stop the operation immediately when abnormality is noticed.
95691-2935-0000
4

Preface
WARNING
 Find the safe place where the product is used for measurement.
 Avoid to carry the camera fixed with tripod or avoid to use the camera with tripod
in the place where is large vibration or shock as it may cause trouble in the
camera.
 Use or storage under water atmosphere:
When the terminal cover are not closed, do not store or use the unit under water
atmosphere especially outside in the rain or snow fall.
 Do not soak the product because of not waterproof although dust and splash-
proof.
 Do not use the product with the conductive gloves or cloths worn.
 Avoid dismantling G100/G120
Dismantling of the G100/G120 is prohibited due to danger.
95691-2935-0000
5

Preface
WARNING
 Handling of Battery Pack. Following should be cared for handling of battery to
keep safety.
(1) Do not disassemble or modify the Battery Pack. To avoid danger, protectors,
such as a protection circuit, are implemented in the Battery Pack. If a protector
is broken by disassembling or modifying, it may cause overheating, explosion,
or fire.
(2) Do not use the Battery Pack near water, for example, in a bathroom.
(3) Do not put the Battery Pack into fire or heat up the Battery Pack. Keep the
Battery Pack away from fire.
(4) Do not allow the battery liquid to get into eyes. It may cause serious personal
injury that can lead to blindness. If the liquid gets into eyes, do not rub; rinse
with clean water immediately and consult a doctor.
(5) Do not allow the liquid leaking out of the Battery Pack to contact your skin.
It may cause personal injury. If the liquid adhered of your skin or clothes,
wash thoroughly the adhered area with clean water immediately.
(6) Do not use a broken or leaking Battery Pack. Using a broken Battery Pack
may cause overheating, explosion, or fire.
(7) If there is a leak or strange smell, remove the Battery Pack immediately from
the product or the Battery Charger. Continuing to use under these conditions
may cause overheating, explosion, or fire.
(8) Do not connect the positive terminal and the negative terminal of the Battery
Pack (metallic part) to each other with any metal objects, such as wire. Do
not carry the Battery Pack together with other metal objects. Metal objects in
contact with the terminals may cause a short circuit.
(9) Do not trample or hammer the Battery Pack. Do not drive a nail into the
Battery Pack.
(10)Do not continue to charge the Battery Pack if it does not become charged
within the specified charging time.
(11)Do not use the Battery Pack if something is wrong with it. If there is a leak or
strange smell, remove the Battery Pack immediately from the product or the
Battery Charger. Continuing to use under these conditions may cause
overheating, breakage, or fire.
(12)Do not use the Battery Pack if foreign objects have entered. Do not insert or
drop metal or other foreign objects into the Battery Pack through the opening.
It may cause overheating, explosion, or fire.
95691-2935-0000
6

Preface
WARNING
(13)Do not use a broken or leaking Battery Pack. Using a broken Battery Pack
may cause overheating, explosion, or fire. Do not allow the liquid leaking out
of the Battery Pack to contact your skin. It may cause personal injury.
Should the Battery Pack liquid contact your skin, immediately rinse it off with
clean water and seek medical attention.
(14)Do not put the Battery Pack into fire Do not put the Battery Pack into fire, and
keep it away from fire. Do not heat up the Battery Pack. It may cause
overheating, explosion, or fire.
(15)Do not give an impact to the Battery Pack. Do not trample or hammer the
Battery Pack. Do not drive a nail into the Battery Pack. It may cause
overheating, explosion, or fire.
(16)Do not disassemble or modify the Battery Pack. To avoid danger, a protector
is implemented in the Battery Pack. If the protector is broken by
disassembling or modifying, it may cause overheating, explosion, or fire. Do
not allow the battery liquid to get into eyes. It may cause serious personal
injury that can lead to blindness. If the liquid gets into eyes, do not rub; rinse
with clean water immediately and consult a doctor.
(17)Do not short out the Battery Pack. Do not short out the Battery Pack as it may
cause overheating, explosion, or fire. Exercise care in handling the Battery
Pack in order not to short the battery with conducting material such as keys or
necklaces. The Battery Pack and conductor may overheat and cause
explosion or fire.
(18)Keep away from children. Failure to comply with this warning may be
hazardous and cause personal injury.
(19)Do not leave the Battery Pack in direct sunlight. Do not leave the Battery Pack
in direct sunlight or in sun-heated cars. The internal heat build-up may cause
overheating, explosion, or fire.
95691-2935-0000
7

Preface
95691-2935-0000
WARNING
 The user must observe the following points to use the instrument safely.
Laser light contact with the eyes may cause a drop of vision or visual
impairment.
(1) Never point the light from the laser pointer towards people.
(2) Never look into the laser pointer's light source.
(3) This measuring device is intended for professional use and not suitable for
general use.
 The user must observe the following points to use the instrument safely.
(1) Don’t look into the LED light's light source.
8

Preface
CAUTION
 The product uses a high sensitive infrared detector and following cautions
are requested.
(1) Storage temperature is -40 to 70°C and storage humidity is less than 90% (not
condensed) except battery pack and battery charger. It should not be beyond
the range. Do not store the product under the sunlight or in the place where the
temperature goes up (e.g. in a car, etc.), for a long time specially in the
summer season.
(2) Do not store the product in the place where there is vibration or shock,
anything may drop, unstable and could be broken, or other not suitable for the
storage.
(3) Do not give shock or vibration over specification to the product during the
transportation, moving, installation or measuring.
 When disposing the G100/G120, hand over to industrial waste disposal
professionals. (Do not dispose as a general waste)
 Environment condition for measurement:
(1) Operation temperature -15 to 50°C.
(2) Humidity: 90%Rh or less (not condensed)
(3) Following condition should be avoided:
Place where so many dusts exist over the specifications of IP54.
Direct sunlight where the product becomes high temperature over the
operating temperature.
Other cautions and warnings described in this manual.
 Give careful attention to the voltage fluctuation and do not use the product
when it is expected to go beyond our specified voltage.
 Use noise filter to void errors in where there are noisy power sources or
induction of high voltage sources affected.
 Do not use or store the product under a strong electro-magnetic field.
 Store the product in a place where there is no danger of dropping.
 DO NOT REMOVE battery or AC adapter before the power is turned off and
pilot lamp goes off entirely.
95691-2935-0000
9

Preface
CAUTION
 Do not apply excessive stress to LCD DISPLAY to avoid damages.
 Battery Handling
(1) A battery is consumables. Replace with a new battery when operating time of
the instrument becomes shorter.
(2) Disposal of the battery must be done according to the waste-disposal law of
the country or region where the battery is disposed of.
 Operating and storing temperatures for batteries:
Operating temperature (charging) : 0 to 40°C (45-85% RH, non-condensing)
(discharging) : -20 to 60°C (45-85% RH, non-condensing)
Storing temperature (within a month) : -20 to 50°C (45-85% RH, non-condensing)
(within three months) : -20 to 40°C (45-85% RH, non-condensing)
(within a year) : -20 to 20°C (45-85% RH, non-condensing)
* As for the operating temperature for charging, the amount of charge at a low temperature
near 0°C is smaller than that at 20°C.
* Time of discharge becomes shorter as temperature decreases.
* The range of storing temperature is specified with 80% recovery rate.
* Recovery rate: Indicates the percentage of an after-storage discharge time against the
discharge time before charge.
 Transportation regulations for lithium-ion batteries:
This product uses lithium-ion batteries which are subject to transportation
regulations. Applied regulations depend on the packing condition or number of
batteries, therefore when you plan to transport this product, please check with a
carrier for appropriate formalities.
95691-2935-0000
10

Preface
CAUTION
 Visual camera handing:
(1) Please use it within an operating temperature condition.
(2) Do not put direct rays into the Visual camera window of main instrument.
(3)Do not give a direct shock to the Visual camera window of main instrument.
* Visual camera window : Please refer to P.14.
 Cautions about visual image acquisition:
The following phenomena may be observed when the G100/G120 acquires
or saves a visual image. These phenomena are not failures.
(1) The color of the visual image periodically changes.
(2) The color of the visual image may be different from the real target object
when the image is replayed in FREEZE.
To avoid such phenomena, perform image acquisitions by changing the
RUN/FREEZE timing or camera angle. In this case, it is recommended
to acquire visual images with observing the image on the screen.
The following phenomena may be observed in the outdoor data acquisition.
Such phenomena are not caused by camera failures.
(3) If the contrast is great (e.g. because of backlight), the object may appear
darker on the camera display compared to the brightness of the background.
To avoid these phenomena, control the frame so that it covers only
target object.
(4) If the bright sunlight enters the visual camera, entire picture may become
reddish.
To avoid these phenomena, shield the camera from bright sunlight.
95691-2935-0000
11

Preface
 Holding the product:
(1) Give much consideration not to drop the product.
(2) When placing the product, do not give strong shock to the product.
(3) To hold LCD Display or Lens Cap might cause failure.
 Don't input laser ray (CO2 laser or etc):
Infrared detector might be damaged as disable to recover by inputting the
laser ray.
 Periodical temperature calibration:
Perform once a year to keep the measurement accuracy.
 To keep your camera qualified for IP54 (dust & splash proofs):
To keep your camera qualified for IP54, we recommend
periodic inspection/change of gasket.
Gasket should be changed approximately once in two years.
Please ask us at periodic inspection or calibration services.
CAUTION
Comments
 Brightness stripe or minute spots that have no influence for measuring may
appear on the LCD Display and Viewfinder, which is not malfunction.
95691-2935-0000
12

Preface
◎ PRODUCT DETAILS
<Items included>
Please make sure all below items are enclosed before you use.
G100/G120
Thermo Gear AC adapter
Power cable
(AC adapter)
Lens Cap
InfRec Analyzer
NEC Avio Infrared Technologies Co., Ltd.
Warranty
Thermo Gear
G100/G120
Operation manual
NEC Avio Infrared Technologies Co., Ltd.
http://www.nec-avio.co.jp
Battery pack Power cable
(Battery charger)
Battery charger
SD memory card
Wristband USB cable
PC Software
InfRec Analyzer
NS9500LT
Carrying case
Warrant
y
Instructional manual
95691-2935-0000
13
