Innon OC-7N1016 User manual

1
【Product Overview】
Brief Introduction of OC industrial fiber switch: support Max. 8
compatible 10/100BaseT X Ethernet ports and 2xfiber ports. PoE
output is optional for this series, which complies with standard
AT(30W) or AF(15,4W), powering PD devices, such as IP camera,
high-performance wireless AP and industrial grade IP phone. This
switch is highly flexible and anti-EMI. The distance between fiber
ports and control center is up to hundreds of kilometers. DIN-Rail
mounting is catered for industrial application needs. -30°～75°C
operating temperature rang and 8KV Ethernet surge protection can
adapt to a harsh outdoor environment and ensure product reliability.
Brief Introduction of GE industrial fiber switch: support Max. 8
compatible 10 / 100/1000BaseT X Ethernet ports and 2x fiber ports.
PoE output is optional for this series, which complies with standard
AT(30W) or AF(15,4W), powering PD devices, such as IP camera,
high-performance wireless AP and industrial grade IP phone. This
switch is highly flexible and anti-EMI. The distance between fiber
ports and control center is up to hundreds of kilometers. DIN-Rail
mounting is catered for industrial application needs. -30°～75°C
operating temperature rang and 8KV Ethernet surge protection can
adapt to a harsh outdoor environment and ensure product reliability.
【Packing List】
Please check the following items in the package before installing the
switch.
➢Industrial switch 1set
➢User manual 1copy
Equipment is with built-in precision components, please avoid
excessive vibration, and take it gently.
If you find that the device is damaged during transport or any parts
missing, please notify the company or the company's offices, dealers,
and we will solve the problem as soon as possible.
【Product Specifications】
Network
Protocols
IEEE 802.3i 10BASET
IEEE 802.3u 100BASETX
IEEE 802.3x Flow Control
IEEE 802.1af DTE Power via MDI
Power Supply
Input voltage: DC 9-56V
No-load power consumption: 5W
Reverse polarity protection: support
Industrial
Standards
EMI：FCC Part 15 Subpart B Class A，EN
55022 Class A
EMS：EN 61000-4-2 (ESD) Level 3，EN
61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT)
Level 3，EN 61000-4-5 (Surge) Level 3, EN
61000-4-6 (CS) Level 3，EN 61000-4-8
Traffic Control：NEMA-TS2
Vibration：IEC 60068-2-6
Freefall：IEC 60068-2-32
Shock：IEC 60068-2-27
Rail Traffic：EN 50121-4
Safety
CE Mark ,commercial
CE/LVD EN60950
Mechanical
information
Dimension：161x 130x 71mm
Mounting method：Din-rail mounting
Warranty
Replacement within 1 year; 3 years repairing
Fast Ethernet Product Features
➢Support power on POE IP cameras through the wireless access
point (AP) of 5 categories of Ethernet cable.
➢16 x 10/100Mbps Auto-sensing RJ45 ports
➢8KV /6KVPOE Ethernet surge protection, adapt to
a harsh outdoor environment
➢Support Auto MDI/MDIX
➢Flow control mode: full duplex with IEEE 802.3x standard, half-
duplex with Back pressure standard
➢IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
➢A store-and-forward switching mechanism
➢Operating environment temperature:-30 ° ~75 ° c
➢9VDC-56VDC wide input voltage power supply
➢meet IP40 protection degree and EMC industrial grade
requirements, DIN rail installation
Gigabit Ethernet Product Features
➢16x 10/100/1000Mbps Auto-sensing RJ45 ports
➢0-2x 1000Mbps SFP fiber ports
➢8KV /6KVPOE Ethernet surge protection, adapt to
a harsh outdoor environment
➢Support Auto MDI/MDIX
➢Flow control mode: full duplex with IEEE 802.3x standard, half-
duplex with Back pressure standard
➢IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
➢A store-and-forward switching mechanism
➢Operating environment temperature:-30 ° ~75 ° c
➢9VDC-56VDC wide input voltage power supply
➢meet IP40 protection degree and EMC industrial grade
requirements, DIN rail installation,

2
【LED indicator】
➢All LED in the front panel of this series monitor the
working status of the device, simplifying trouble-shooting. The
indication of each LED is as below in the table:
System Status LED
LED
Status
Description
P1
P2
Green on
normal
off
Power off
Ethernet
Port
Yello
w
Light
On
Ethernet port is connected
Blink
Data transmission enable
Off
Ethernet port is
disconnected
Green
Light
On
1000M
Off
NO 1000M
Optical Port：
On
Optical port is connected
Blink
Data transmission enable
Off
Optical port is disconnected
【Installation Guide】
Please use the associated devices for installation.
Please install the switch by the following steps:
1. Place the switch on a sufficiently large and stable desktop or on
solid rail.
2. Connect the switch to the power.
3. Connect the network devices with the corresponding port on
the switch via network cable
Attention
1. Do not place heavy objects on the switch and ensure the switch
always in good ventilation environment.
2. Please power off before plug or remove power adapter.
Power On
Power on after connect switch to power. And then the switch will
automatically initialize, the LED indicator will have the
following conditions:
1. After LED on and then off means that the system has reset
successfully.
2. Power LED is on all the time.
Notice
If the initialization does not match instructions above, please check
the power supply.
Industrial Switch
User Manual
(Do not use device until you read this manual carefully)
