1-1
Hardware Installation
Module Overview
1
Hardware Installation
Module Overview
The Services Module, an HP ProCurve zl module, is an x86 platform designed
to integrate network applications within the HP ProCurve switch architecture.
By integrating with HP ProCurve's Services library, these applications can
offer more value than stand-alone appliances. The module provides services
to download, install, and license customers’ own applications through the
network.
The module is managed through an easy to use Command Line Interface (CLI).
The module can be installed in any HP ProCurve zl switch (either the switch
series 5400zl or 8212zl). A maximum of four Services Modules can be installed
in the same chassis. See “Environmental Specifications” on page 1-5.
The Services Module requires switch software version K.13.51 or later to be
installed in the switch.
The following figure shows the front panel of the Services Module.
Figure 1-1. Front panel of the Services Module
Module
Shutdown button Module
Locator LED
HDD and CF
Status LEDs HDDandNetwork
activity LEDs
USB port
Module
Status LED
zlSM .book Page 1 T hursday ,January 29,2009 11:53 AM

1-2
Hardware Installation
Installing the Module
For a description of the front panel buttons and LEDs, see Table C-1 on page
C-1 in the Web version of this document at www. procurve.com/manuals.
Note The printed version of this document contains the basic information needed
to get you started using the Services Module. It also contains EMC Regulatory
Statements (Appendix A) and Waste Electrical and Electronic Equipment
(WEEE) Statements (Appendix B). Appendices C and D are only in the Web
version of this document at www. procurve.com/manuals. Appendix C gives
more detailed hardware information, and Appendix D gives more detailed
software information.
Installing the Module
To install the module into a switch, the switch can be powered on or off. The
following procedure assumes the switch is powered on.
Installation Precautions
■Static electricity can severely damage the electronic components on the
module. When handling and installing the module, follow these proce-
dures to avoid damage from static electricity:
• Handle the module by its bulkhead or edges and avoid touching the
components and the circuitry on the board.
• When installing the module, equalize any static charge difference
between your body and the switch by wearing a grounding wrist
strap and attaching it to the switch’s metal body, or by frequently
touching the switch’s metal body.
■The module has “low-force”, high-performance connectors. High inser-
tion forces are not necessary to install the module, and should not be
used.
■Ensure the module is fully inserted. Press the module into the slot
until the bulkhead on the module contacts or is very close to contacting
the front face of the switch chassis.
■Once the module is fully inserted, screw in the two retaining screws to
secure the module in place.
■For safe operation, proper switch cooling, and reduction of electromag-
netic emissions, ensure that a slot cover is installed on any unused
module slot. For safety, no more than one slot should be uncovered at a
time when the switch is powered on.
■Check the temperature specifications for the module; different modules
have different temperature requirements.
zlSM .book Page 2 T hursday ,January 29,2009 11:53 AM

1-3
Hardware Installation
Installing the Module
Installation Procedure
Note Before installing the Services Module, confirm that the switch has the most
current version of module-compatible software installed. Otherwise the
switch will not recognize the Services Module. For directions on how to check
the switch software version, see “Initial Configuration” on page 2-3.
1. Use a Torx T-10 or flat-bladed screwdriver to unscrew the screws in the
cover plate over the slot where the module is to be installed. Remove the
cover, and store the cover plate for possible future use.
2. Hold the module by its bulkhead, taking care not to touch the metal
connectors or components on the board.
3. Open the extractor handles.
4. Insert the module aligning with the guides in the slot, and slide it into the
slot until it is fully inserted.
5. Once the module is fully inserted, use the extractor handles to seat it
completely.
6. Tighten the screws.
Figure 1-2. Module being installed
Insert module into the guides
and slide in until fully
inserted.
Open extractor handles
zlSM .book Page 3 T hursday ,January 29,2009 11:53 AM

1-4
Hardware Installation
Installing the Module
The procedure to replace or remove a Services Module is described on page
C-5 in the Web version of this document at www. procurve.com/manuals.
Appendix C also describes the procedure to replace the module’s Hard Disk
Drive (HDD) and the Compact Flash (CF) card.
Verifying that the Module is Installed Correctly
When the module is installed, it undergoes a self test that takes a few seconds.
This happens both when the switch is powered on after installing the module,
and when the module is installed while the switch already has power. The
LEDs help determine if the module has passed the self test, as described in
the table below.
LED Behavior
Error Conditions
Error conditions indicated by the module LEDs are described in Table C-1 on
page C-1 in the Web version of this document at www. procurve.com/manuals.
LED Location
of LED Display for a Properly Installed Module
Test Switch ON briefly while the module is undergoing self test, then OFF.
Note: If the module was installed with the switch powered off,
and then the switch was powered on, the Test LED will stay ON
for the duration of the switch self test.
Figure C-3 and Figure C-4 show the locationof the Test, Fault,and
Module Status LEDs on a 5400zl or 8212zl series switch,
respectively.
Fault Switch OFF
Module
Status Switch The LED goes ON as soon as the module is installed and the switch is powered on, and stays ON steadily.
Module
Status Services Module The LED flashes green while the OS is initializing and goes solid when the Service OS or product is ready.
Figure 1-1 shows the location of all module LEDs.
HDD and CF
Status Services Module The LED goes ON when HDD/CF initialization was successful. It is OFF by default.
zlSM .book Page 4 T hursday ,January 29,2009 11:53 AM

1-5
Hardware Installation
Environmental Specifications
Environmental Specifications
Temperature Operating
0°C to 40°C (32°F to 104°F)a
a. A maximum of four Service Modules are supported in either a
5400z1 or a 8212zl chassis. For the 5400zl chassis, the maximum
supported temperature is 50°C when there are no Service Modules
in the right side of the chassis, and 40°C if there are Service
Modules in the right hand side of the chassis. The 8212zl chassis
is always limited to 40°C.
Note that the 5406zl chassis only has three left hand slots. This
allows the chassis to be operated at up to 50°C with up to three
Service Modules installed. Installing a fourth Service Module
requires that one of the modules be installed in the right side of
the chassis thereby de-rating the chassis to 40°C.
Non-Operating
-10°C to 65°C (-10°F to 149°F)
Relative humidity
(non-condensing) 15% to 90% at 40°C (104°F) 15% to 90% at 65°C (149°F)
Maximum altitude 3.0 km (10,000 ft) 4.6 km (15,000 ft)
zlSM .book Page 5 T hursday ,January 29,2009 11:53 AM
