Innotech IB-655 User manual
Please read this instructions carefully before
using this scale.
Product Specifications
•
Model: Innotech IB-655 Bluetooth Smart
Scale
•
Dimensions: 320 x 320 x 25mm
•
Net weight: 4.4lb (2kg)
•
Power: DC 6V
•
Storage temperature: -13—158°F / 25—70
℃
•
Working current:
≦
60mA
•
Batteries: AAA battery X 3
•
Automatic shut-off: 30+/-3 seconds
•
Bluetooth: BLE 4.0
PRODUCT INTRODUCTION
LED Screen Display
1. Scan QR Code, or Download the “Innotech
Scale” application from Play Store (Android) or
App Store (IOS).
OPERATING INSTRUCTIONS
2. Register through the Innotech app following
application prompts to completion.
3. Install the batteries and place the scale on a
hard flat surface.
Insert three new AAA batteries, making sure the
plus and minus(+/-) poles are aligned properly
according to the diagram inside the compartment.
Place the scale on a hard flat surface (not carpet) to
ensure the greatest accuracy and reliability.
CHANGE MEASUREMENT
UNITS
4. Follow the instructions in the app to pair the
scale with your phone.
5. After paring, step on the scale barefoot, and
start weighing.
6. Step onto the measurement platform.
Step on and off the scale to activate it. Stand with
your weight evenly distributed on the measurement
platform and remain still until the measurement is
complete.
When the screen illuminates, open the battery
compartment located on the back of the scale,
press the button inside to switch unit between
pounds and kilograms.
TROUBLESHOOTING
Solution for unsuccessful activation or
connection
•
Do not pair the scale from your Smartphone’s
Bluetooth menu. Use the Innotech application
to pair the scale with your Smartphone.
•
Make sure the batteries are correctly installed.
Replace the batteries if necessary.
•
Fully exit your mobile application and reopen
it.
•
Disconnect Bluetooth and reconnect again.
•
Age: 18—80 years old (*Only weight will be
measured for users under age of 18)
•
Family member capacity: 10
•
Weight: 5.5—397 LBS / 2.5—180 KG
•
Weight increment: 0.2 LBS / 0.1 KG
•
Height: 3 ft 2 in—7 ft 2 in / 100—220 cm
•
Body fat: 5.0%—45.0%
•
Body fat increment: 0.1%
•
Water: 35.0%—75.0%
•
Water increment: 0.1%
•
Muscle: 46—298 LBS / 21.0—135.0 KG
•
Muscle measurement increment: 0.2 LBS /
0.1 KG
•
BMR: 700—3000 KCAL
•
Visceral Fat: 1—59
•
Bone mass: 2.2—8.8 LBS / 1—4 KG
•
Bone increment: 0.2 LBS / 0.1 KG
•
Protein: 5.0%—29.0%
•
BMI: 5—90.0
MEASUREMENT RANGE
•
Donotsteponthescalewhenthesurface or
yourfeet
are wet to avoidslipping.
•
Protect thescalefrom hardknocks,
moisture,dust,
chemicals, drastic changes in
temperature, electromagnet
fieldsandsources
ofheatthataretooclose.
•
Neverstepontheedgeofthescale,itcould
causethe
scale totip.
•
Removethebatteriesif thescaleisnotbeing
usedfora
long time.
•
Do notjump on the scale.
GENERAL ADVICE
Innotech uses Bioelectric Impedance Analysis to
measure body fat, which sends an extremely low
electrical current through the body when taking a
measurement. This low electrical current is
unnoticeable and is safe for individuals.
•
We do not recommend that anyone with a
pacemaker, electrocardiographs and/or
other medical devices implanted in the body
or used for life support use the Innotech
because of this electrical current.
•
We advise any pregnant women to consult
their physician before using the Innotech -
not because any harm is likely to occur, but
simply because each person’s body is
unique, and it is worth asking a doctor about
your specific situation before making such
decisions.
•
Athletes and fitness enthusiasts: Athletes
have different body types. Scales using only
foot electrodes sensors are known to
overestimate it in leaner people.
•
Under 18 years old: Only weight is available
for young people under 18, because they are
growing too fast and their body data is
changing too frequently.
SAFETY PRECAUTION
Cleaning
You can clean your scale using a lint-free
cloth
dampenedwithwater. Ifwateris not
enough toclean
it,youcanalsouseamild
dishwashingsoap.
Changing the batteries
Openthebatterycover,removetheold
batteriesand
replace it withnew batteries.
Disposal
Dispose of this device in accordance with your
local
regulations. Batteries should be disposed of
separately from
household waste.
CLEANING,MAINTENANCE,AND DISPOSAL
1. My phone will not connect to the scale.
What’s wrong?
Please do NOT pair the scale from your
Smartphone’s Bluetooth menu. Install and
open the Innotech app and then follow the
on-screen instructions to pair the scale with
your smartphone.
Click the "Pair Device" button on the top right
of the app if you have another scale to pair.
The "Pair Device" button only pop up if the
app detects another Innotech Bluetooth
Smart Scale.
2. Why doesn’t the scale connect to my
phone? It worked before.
Please try to unpair and pair the scale again.
3. The scale will not turn on, and the LCD
display does not show anything. What
should I do?
Please check if the batteries are installed
correctly or change new batteries.
FAQs
4. Why does my scale show incorrect
weight? My scale is showing a difference
between 4-5 pounds from my
recent/current weight.
Please stand still. The scale might need to
be re-calibrated to show accurate readings.
To do this, please put the scale on a hard,
flat surface like tiles. Step on and off the
scale quickly, the scale will show 0.0 lbs.
This indicates calibration is complete.
5. Why am I receiving variant
measurements?
Please wipe your feet with a damp cloth,
keeping them slightly wet and try it again.
6. Why does the Innotech app/scale
display my body weight only but not the
other body metrics?
Bluetooth connection is necessary to capture
and record all data. Please install the
Innotech App and log in, open the app, pair
the scale, and step on the scale with bare
feet. The app should show all the data.
This could be happening for other reasons.
Please try below troubleshooting solutions
too:
a. Clean the scale surface and feet. The
scale surface is not clean or the user’s
feet are too dry to be measured.
Please clean the scale surface or wet
your feet with a damp towel and try
again.
b. Check the age settings. The app will
only measure and track users age 18
and above. Teenagers under 18 are
growing fast ,and their body data is
frequently changing, only weight can
be measured and tracked.
c. Make sure there is direct contact
between the scale surface and the
user’s feet. Please do not wear socks
or shoes, and remember to remove
the plastic film from the scale surface.
d. Don’t step off too soon. The weighing
process is not finished until the
progress bar on the display screen
completes from left to right.
7. Why is my body composition data
different from the ones I see at the gym,
doctor, etc.?
You may go to “Me” - “Edit” and check if your
personal information set up in the app is
correct. i.e., Gender and Body Type (Normal/
Athlete).
Also, the numbers you see on your scale
may vary from those you see using other
measurement methods and professional
medical instruments. This is normal.
Innotech is a home use scale for reference.
Innotech scale uses BIA (bioelectric
impedance analysis), which is a commonly
used method for estimating body
composition, and in particular body fat. The
bioelectrical impedance analysis (BIA)
method is a lower-cost (from less than one to
several hundred US dollars) but less
accurate way to estimate body fat
percentage.
8. Why do the %fat, %muscle, and %water
comprise 122% of my total body weight?
It is normal for the three index to add up to
more than 100% since water is contained in
the fat and muscle.
9. Does the app sync with Apple Health,
Fitbit and Google Fit?
Yes, Innotech app syncs with Apple Health,
Fitbit and Google Fit. Please turn on
Connect to apple health/Google fit/ Fitbit
from Me—User settings. For iPhone, Fitbit
will sync latest data only if you fully exit Fitbit
(double click home button and swipe with a
finger up) then reopen Fitbit.
10. How many users can share this scale?
How does it register the weight of
different family members? Will other
family members be able to see how much I
weigh?
The scale supports up to 10 user profiles.
Each user can use their own smart-phone or
share one app and create profiles in Family
Management. If they only have their
individual profile in the app, the scale will
only sync their data to their individual device.
Other member users will not have access to
your data unless you permit them to add
your profile to their app. Users can use their
personal smart-phone and app/account to
maintain privacy.
11. Are the batteries rechargeable? What
size are they? How long do the batteries
last?
The scale includes Three AAA batteries that
are not rechargeable and usually last three
to six months. However, rechargeable
batteries also work for Innotech scales.
12. Is this scale waterproof?
The waterproof level is IPX-3, which is
protected against water spraying up to 60
degrees from vertical at 10 liters/min at a
pressure of 80-100kN/m2 for five minutes.
