Intel mobileye 8 Connect User manual

User Manual
Mobileye®
8 ConnectTM

Thank you for
choosing Mobileye®
By choosing the Mobileye® 8 ConnectTM Advanced
Driver AssistanceSystemsSeries("Mobileye 8Connect"
orthe"System"),youjointhemanydriversworldwidewho
useourvariousadvanceddriverassistancetechnologies
tomakeroadssafer fordrivers,passengers, pedestrians,
cyclists and other vulnerable road users.
This user manual describes each of the Mobileye 8
Connect functions.
For additional information, visit our website at
www.mobileye.com
Thank you, and drive safely!
2Mobileye 8 Connect™

3User Manual

Mobileye 8 Connect Overview 6
11
14
General Information
System Components
Safety Information
Installation and Safety Instructions
6
6
7-9
10
Mobileye 8 Connect Capabilities
Data Collection
Cellular
Activating the Mobileye 8 Connect
11
12
13
Mobileye 8 Connect Alerts
Forward Collision Warning – (FCW)
Urban Forward Collision Warning – (UFCW)
Pedestrian & Cyclist Collision Warning - (PCW)
Lane Departure Warning – (LDW)
Headway Monitoring Warning – (HMW)
Trac Sign Recognition & Speed Limit Indication
– (SLI & TSR)
Intelligent High-Beam Control (IHC) (Optional)
Turn Signal Reminder (Optional)
Virtual Bumper (VB)
15-16
16-17
18-19
20-21
22-23
24-25
26-27
28-29
30-31

Eyewatch Control Panel
EyeWatch Advanced Mode
EyeWatch Icons
Brightness Level Control
Volume Control
FCW Sensitivty Menu
HMW Sensitivty Menu
LDW Sensitivty Menu
SLI Sensitivty Menu
IHC Menu
Exit (To the main screen)
System Power
License And Product Warranty
Limited Use License
Limited Product Warranty
Warranty Disclaimer
If Service is Needed
32
37
38
40
32
33
34
34
34
35
35
36
36
40
41
42
42-43

Since the Mobileye 8 Connect supports over-the-air updates, the
system parameters and information included in this user manual
may change from time to time. The information included in this user
manual is correct at the time of publishing. For the most up to date
user manual, check our website: www.mobileye.com.
General information
The Mobileye 8 Connect is comprised of:
• 1 camera module with a connector cable and a built-in SIM card.
•
1 EyeWatch
TM
: a display and control unit for visual and audio alerts
and system conguration ("EyeWatch").
• 1 GPS unit, including a GPS module and GPS antenna.
• Signals and power connector cable.
• CAN-sensor (CAN-Reader) cable.
• 2 external fuse holders with 2A fuses.
• VHB surface cleaner.
• Cellular modem and SIM card (internal component).
System Components
6Mobileye 8 Connect™

Safety information
Before using the Mobileye 8 Connect, please read the instructions
and warning in this user manual carefully.
WARNING! THE MOBILEYE 8 CONNECT IS NOT A SUBSTITUTE FOR
SAFE AND ALERT DRIVING.
DO NOT ATTEMPT TO CHANGE SETTINGS ON THE MOBILEYE 8
CONNECT WHILE DRIVING!
Do not press any Mobileye 8 Connect buttons before understanding
their functions. Subject to all the terms of this user manual, by
installing the Mobileye 8 Connect, you acknowledge and agree to
operate the Mobileye 8 Connect in accordance with the important
Safety Information and the Installation and Safety Instructions set
forth below. If you do not agree to these terms, please return the
Mobileye 8 Connect in its original packaging to the dealer within 30
days of purchase to receive a full refund.
• The Mobileye 8 Connect is an advanced driver assistance system
that alerts drivers to certain potentially dangerous situations. The
Mobileye 8 Connect does not replace any functions that drivers
ordinarily perform in driving a motor vehicle, nor does it decrease
the need for them to stay vigilant and alert in all driving conditions,
to conform to all safe driving standards and practices, and to obey
all trac rules and regulations.
•
While the Mobileye 8 Connect represents state-of-the-art innovation
in computer vision and other technologies, the system is based
on articial intelligence technology trained to detect vehicles,
7User Manual

pedestrians, certain lanes and/or specic trac signs. The system’s
functionality is dependent upon minimum light conditions and does
not guarantee denite detection, nor does it guarantee warning
over all potential driving and/or road related risks.
•
As a general rule, the system’s detection and response capabilities
are inuenced by various factors including, but not limited to, height,
form, shape, movement (including limb movement), contours, angle
of movement, degree of prominence in relation to the environment,
distance from the vehicle, speed, driver behavior, and more. In
addition, road, weather, light (or lack thereof), visibility and other
conditions can adversely aect the Mobileye 8 Connect detection
and response capabilities in regard to any and all of its functions
and alerts as specied above and below. Any conditions that block
the camera’s view, partially or fully, will result in no or reduced
functionality of these functions and alerts. You should always ensure
that the vision sensor has a clear eld of view.
• The Mobileye 8 Connect is not an automated driving system and
does not act as a substitute for any aspect of driver vehicle control
or safe driving practices. Drivers are strongly cautioned not to rely
on the Mobileye 8 Connect as a substitute, to even the slightest
degree, for the exercise of due caution in driving safely and avoiding
accidents.
• The Mobileye 8 Connect does not "see" better than the driver; it is
designed to assist drivers by providing warnings solely in specic
situations. It is the driver’s responsibility to act responsibly and
with caution, to show awareness at all times and rely on their vision
and hearing while driving.
8Mobileye 8 Connect™

• Accordingly, drivers should not rely on the Mobileye 8 Connect to
assure their driving safety, but rather should continue to rely on
safe driving practices.
• The Mobileye 8 Connect detects fully visible rear-ends of vehicles.
Therefore, crossing, oncoming, and passing vehicles cannot be
detected.
• The Mobileye 8 Connect is designed for driving along paved roads
with lanes that are clearly marked.
• Although the Mobileye 8 Connect detects multiple signs in various
territories, it may not detect all existing signs in all territories.
Drivers should exercise caution in using the Mobileye 8 Connect
display unit. Driver attention should always remain focused on the
road, including while looking at the Mobileye 8 Connect display.
•
The device emits minor units of radiation during its use in accordance
with the applicable laws and regulations.
Every eort has been made to ensure the accuracy of all information
in this user manual. However, Mobileye Vision Technologies Limited
("Mobileye") makes no express or implied warranty or representation
based on the enclosed information. Mobileye reserves the right to
alter the equipment specications and descriptions in this publication
without prior notice.
•
Any errors or omissions may be reported to Technical Support,
Mobileye Vision Technologies Limited.
• Global Support Email: [e-mail]
• European Support Email: [e-mail]
9User Manual

• The Mobileye 8 Connect installation must be performed by a
Mobileye authorized installer.
•
The Mobileye 8 Connect should not be transferred between vehicles,
other than by an authorized Mobileye installer.
•
The Mobileye 8 Connect should only be operated with 12VDC-
24VDC power.
•
Do not cover or obstruct the Mobileye 8 Connect vision sensor, the
EyeWatch display, the control unit or the GPS unit.
•
Do not use the Mobileye 8 Connect for any purposes other than
those described in this user manual.
• Features and functions noted as “Optional” may not be available
for all vehicle types. These features and functions may also require
additional equipment and/or involve extra costs. Contact Mobileye
or an authorized dealer for more information.
•
The Mobileye 8 Connect cannot be installed in all vehicles. Contact
Mobileye or an authorized dealer to determine if a system can be
installed in a particular make and model.
Installation and Safety Instructions
10 Mobileye 8 Connect™

• To facilitate the provision of certain advanced features, including the
advanced driver assistance system (ADAS) safety features referred
to in this User Manual (“Safety Alerts”), the Mobileye 8 Connect
collects and transfers to Mobileye road-related data and other
relevant data. This data can include, for example, the location of
trac signs, trac lights, and lane markings; details of safety alerts
it generated; and the data collection time and location information
at which they were collected. Collection of the aforementioned data
occurs in the background with no eect on the proper operation of
the Mobileye 8 Connect safety features. To the contrary, it allows
us to enhance, improve and develop our products’ and services’
performance.
• For more information about the data we collect, how the data are
used and disclosed, and contact details for any further information,
refer to the “Privacy and Your Information“ notice available on our
website, at: https://www.mobileye.com/privacy-policy/. Mobileye
may update this notice from time to time.
•
By installing and/or using this Mobileye 8 Connect, you acknowledge
and agree that Mobileye may collect the aforementioned data
through the Mobileye 8 Connect, and that Mobileye owns and shall
at all times retain all right, title and interest in and to any such
data collected.
Data Collection
11User Manual

• The Mobileye 8 Connect is equipped with a cellular module and
antenna:
•
Do not insert or remove the SIM card when the Mobileye 8 Connect
is powered on.
• Do not cut or modify the SIM card as the Mobileye 8 Connect will
not communicate with the card in this situation.
•
Make sure that the GPS unit is attached to the windshield and
faces outwards.
Over The Air
• The Mobileye 8 Connect may receive and install over-the-Air
software updates that add new features and enhance existing ones.
• The Over-The-Air releases will be pursuant to Mobileye’s discretion
and without further notice.
•
The Over-The Air might include dierent settings, sensitivities,
software modications and/or new features.
•
Some Over-The-Air features may only be available upon subscription
and payment of a fee.
Cellular
12 Mobileye 8 Connect™

Mobileye 8 Connect is automatically activated upon vehicle ignition.
After system activation, when the Mobileye 8 Connect
EyeWatch main screen appears, this indicates that the
system is now fully functional.
Activating the Mobileye 8 Connect
ATTENTION: To prevent possible deterioration of the system's
accuracy, do not remove or tamper with the vision sensor unit
or the windshield mount.
CAUTION: The vision sensor unit can heat up during operation.
Refrain from touching the vision sensor unit during or
immediately after operation.
13User Manual

Alerts
Mobileye®
8 ConnectTM
14 Mobileye 8 Connect™

FCW
Forward Collision Warning
HOW DOES THE FCW WORK?
The FCW provides an alert before a possible collision with the vehicle
in front.
The FCW alert is based on a calculation of the time-to-collision (TTC)
with the vehicle ahead.
The FCW includes 3 sensitivity levels with dierent TTC thresholds:
Low up to 2.4 seconds
Medium up to 2.8 seconds
High up to 3 seconds
For safer driving, we recommend the "high" sensitivity threshold.
The above mentioned TTCs' were examined internally, when vehicle
speed is lower than 120km/h (74mph).
WHEN IS THE FCW OPERATIONAL?
The FCW is operational when the system is active.
The FCW is enabled when the vehicle's speed range is between
30km/h (18.6 MPH) and 200 km/h (124 MPH).
The FCW is congured to provide alerts only up to 80m ahead of the
user's vehicle. Mobileye may modify the congurations at any time
upon its sole discretion.
15User Manual

HOW DOES THE FCW AUDIO ALERT SOUND?
At speeds above 30km/h (19mp/h) the system issues a series of
several high-pitched beeps (denoting urgency)
WHICH ICON REPRESENTS THE FCW VISUAL ALERT?
A red vehicle icon on the EyeWatch display.
ALERT VOLUME LEVEL & SETTINGS
The FCW is a critical alert; therefore, it cannot be disabled or muted.
The FCW volume level can be set from 3-5.
UFCW
Urban Forward Collision Warning
HOW DOES THE UFCW WORK?
The UFCW provides an alert before a possible low-speed collision
with the vehicle in front.
The UFCW alert is based on a calculation of the time-to-collision
(TTC) with the vehicle ahead.
WHEN IS THE UFCW OPERATIONAL?
The UFCW is operational when the system is active.
The UFCW is enabled when the vehicle’s speed is under 30km/h
(19mp/h).
Mobileye may modify the congurations at any time upon its sole
discretion.
16 Mobileye 8 Connect™

HOW DOES THE UFCW AUDIO ALERT SOUND?
At speeds under 30km/h (19mp/h) the system issues two short beeps.
WHICH ICON REPRESENTS THE UFCW VISUAL ALERT?
A red vehicle icon on the EyeWatch display.
ALERT VOLUME LEVEL & SETTINGS
The UFCW is a critical alert; therefore, it cannot be disabled or muted.
The UFCW volume level can be set from 3-5.
17User Manual

PCW
Pedestrian & Cyclist
collision Warning
HOW DOES THE PCW WORK?
When a pedestrian and/or cyclist crosses in front of the vehicle's path,
the PCW collision warning provides an alert before a possible collision.
WHEN IS THE PCW COLLISION WARNING OPERATIONAL?
The PCW collision warning is operational when the vehicle's speed
under 50 km/h (43 mph).
The PCW collision warning is active both during the day and nighttime,
subject to the minimum light required for the system to properly
function.
HOW DOES THE PCW COLLISION WARNING AUDIO ALERT SOUND?
It is a series of loud, high-pitched beeps.
WHICH ICON REPRESENTS THE PCW COLLISION WARNING VISUAL
ALERT?
A red pedestrian icon on the EyeWatch displays.
This PCW Collision Warning is enabled when the vehicle drives between
7km/h (4.3 mph) and 50km/h (31mph).
PCW DETECTION IN THE "DANGER ZONE"
A pedestrian or a cyclist has been detected in an area dened as the
"Danger Zone", but the Time-To-Collision is not critical. Therefore,
a green pedestrian icon is displayed on the EyeWatch, but no audio
alert sounds.
18 Mobileye 8 Connect™

This functionality is enabled when the vehicle drives between 1km/h
(0.62mph mph) and 50km/h (31 mph). The detection is made only
when the subject is within a certain proximity (congured as the PCW
detection range) of the vehicle.
ALERT VOLUME LEVEL & SETTINGS
The PCW collision warning is a critical alert; therefore, it cannot be
disabled or muted.
The PCW collision warning volume level can be between 3 to 5.
Note!
→
PCW activation speed may be changed by Over-The-Air
update at Mobileye's discretion
→PCW detection at night will require a minimum light for the
system's camera lens exposure.
→The Mobileye 8 Connect may also detect other vulnerable
road users (VRUs).
19User Manual

LDW
Lane Departure Warning
HOW DOES THE LDW WORK?
The LDW provides an alert when the vehicle unintentionally departs
from the driving lane. An unintentional departure is dened as
departing from the driving lane without using the turn signals. If a
turn signal is used when changing lanes, an alert is not generated.
WHEN IS THE LDW OPERATIONAL?
The LDW is active for a vehicle driving at speeds greater than 55km/h
(34 mph).
HOW DOES LDW AUDIO ALERT SOUND?
It is a series of short, sharp beeps.
WHICH ICON REPRESENTS THE LDW VISUAL ALERT?
The dashed, white line on the EyeWatch display represents a right
or left lane deviation.
ALERT VOLUME LEVEL & SETTINGS
The LDW includes a separated volume level that can be set using the
EyeWatch advanced menu. The volume level can be set between 0
(mute) to 5.
ALERT Sensitivity
The LDW can be set to 3 sensitivity levels:
0= LDW is disabled
20 Mobileye 8 Connect™
