Intellihot i200X Quick start guide

PARAMETERS MODEL
i200X/i201X* i250X/i251X*
Type Indoor,Wall-Hung, Fully Condensing, Direct Ignition
Fuel Preset for NG / LP Convertible
Minimum / Maximum Input (Btu/h) 30,000 / 199,950 30,000 / 250,000
Thermal Efciency 94% 92%
Energy Factor 0.93 N/A
Appliance Annual Fuel Utilization Efciency (AFUE) 91.19% N/A
Combined Appliance Annual Fuel Utilization Efciency
(CAFUE)
91.4% N/A
Dimensions H X W X D (inches) 26 X 17.4 X 14.9 (3.9 cu. ft)
Weight 98 lbs
Water and Gas Connections 3/4” NPT
Space Heating Connections 1” NPT
Minimum Flow Rate No minimum ow rate in learned or programed modes
Venting Materials Sch. 40 PVC, Sch. 40 CPVC, Polypropylene, Stainless Steel
Max 3” Vent Length - Single Pipe / Power Vent 200 ft, deduct 5 ft per 90° elbow 130 ft, deduct 5 ft per 90° elbow
Max 3” Vent Length - Two Pipe / Direct Vent 100 ft, deduct 5 ft per 90° elbow 65 ft, deduct 5 ft per 90° elbow
Max 2” Vent Length - Single Pipe / Power Vent
(2” not allowed at elevations above 4,000 ft)
26 ft, deduct 5 ft per 90° elbow N/A
Max 2” Vent Length - Two Pipe / Direct Vent
(2” not allowed at elevations above 4,000 ft)
21 ft, deduct 5 ft per 90° elbow N/A
Safety Flame Rod, Thermal Fuse, Overheat Prevention Device, Fan Speed Monitor, Flue Temperature
Monitor, Blocked Vent Detector, Water Shut-Off Valve, 2X10A Fuse, Dual Flame Sensing
Water Pressure Min / Max (PSI) 30 / 150
NG/LP - Minimum Static Gas Pressure 1/2” Black Iron
(non-corrugated)
5” 6”
NG/LP - Minimum Static Gas Pressure 3/4” Black Iron
(non-corrugated)
2.5”
NG/LP - Maximum Static Gas Pressure 14”
Gas Pressure for Adjustments 8” for NG, 11” for LP
Electrical 120V AC, 60 Hz
Power Consumption 500W (Max 4.2 Amps), 8W (Standby)
FEATURES & PERFORMANCE i200X/i201X* i250X/i251X*
Space Heating Heat Exchanger Stainless Brazed Plate, Maximum Flow 15 GPM
Domestic Water Heat Exchanger Stainless 316L
Hot Water Capacity (35F Rise) 10.8 13.2
Hot Water Capacity (45F Rise) 8.4 10.3
Hot Water Capacity (77F Rise) 5.0 6.0
Domestic Hot Water Temperature Settings 100 – 140°F
Space Heating Temperature Settings 100 – 180°F
WARRANTY (with recirculation) Residential: Heat Exchanger Coil – 12 years, Parts – 3 years, Labor – 1 year
Commercial: Heat Exchanger Coil – 6 years, Parts – 1 year, Labor – 1 year
The rst gas-red tankless water heaters
designed and built in the USA.
BUILT IN THE USA
The rst gas-red tankless
water heaters designed
and built in the USA.
Designed and
built in the USA
intelligent hot water.
TECHNICAL GUIDE
COMBI
Hot Water + Space Heating
+

Maximum domestic hot water with
space heating.
Provide endless hot water while maintaining a comfortable space
temperature. In most combi boilers, hot water heating is an after-
thought. Intellihot’s combi models deliver a large quanitity of hot
water while simultaneously keeping your house comfortable. They
elegantly combine domestic hot water and space heating with one
unit, one gas line and one vent.
Intellihot’s combi models deliver a full quantity (200MBH or
250MBH) of domestic hot water when needed and easily modulate
down to efciently deliver up to 130 MBH of space heating.
How does it work?
Turn on a faucet and Intellihot will begin to deliver hot water. If
space heating is called for, the on-board circulator begins to
deliver up to 135,000 btu/h to the internal plate-type heat
exchanger (PTHE) simultaneously. With no diverting valve to adjust,
fail or malfunction, the Intellihot combi is extremely robust.The
PTHE separates the domestic hot water from the space heating
water to maintain safety and quality.
Designed and built in the USA.
Founded in 2005, after a traditional water heater broke down
and ooded our founder’s basement, Intellihot today designs,
manufactures and builds tankless water heaters for commercial,
industrial and residential applications—the rst to do so entirely
in the United States.
PLATE-TYPE HEAT
EXCHANGER (PTHE)
PERFORMANCE
• Dedicated ASME-rated, stainless brazed plate
heat exchanger for space heating capable of
up to 135,000 btu/h
• Separates domestic hot water from the space
heating side to maintain safety and integrity of
the domestic side
• Units allow for maximum domestic hot water
supply while SIMULTANEOUSLY delivering up to
130,000 btu/h of space heating with no three-way
valve to fail
• Combines the commercially proven 316L ex heat
exchanger and integral pump with a plate-type heat
exchanger for seamless space heating
• Plastic vent temperature overshoot control
maintains safe stack temperature below the
vent’s maximum temperature rating
• Simple install with self-learning and outdoor auto-
reset for the most comfort and maximum savings
• Eliminates need for a primary/secondary loop
setup and large space requirements of a boiler/
storage tank installation
• No low loss header system needed
HEATED
BUFFER TANK
• Integrated half-gallon buffer tank
eliminates temperature spikes and
cold-water sandwiches
• +/-2°F temperature stability
BURNER SYSTEM
• Features a radially red, downward-blowing,
premixed burner with a negative pressure gas
valve and plenum design
• Delivers a more stable ame under a wide
range of operating conditions, including low
gas pressure, wind and non-equal pressure
zone terminations
• Easily converts from natural gas to LP with the
turn of a screw—no additional parts required
and one SKU for easier inventory management
SELF-LEARNING
RECIRCULATION
Use Intellihot under-sink valve
(part # IGT-SPR-0061)
• Get instant hot water (eliminates
water waste) for any application
• Zero ow-rate activation
INTELLIHOT COMBI | 01 WHAT’S INSIDE
316L FLEX HEAT
EXCHANGER
• Floats freely and acts like a spring to
accommodate all thermal shocks and stresses
• Made of 316L stainless steel for superior
corrosion and erosion resistance
• Self-descaling heat exchanger design prevents
scale buildup
• No welds on the water side ensure robustness
to chlorides
• Low pressure drop compared to other tankless
designs
• Energy reduction up to 40%+ compared to
tank-type water heaters and 15%+ over non-
condensing water heaters
WHAT’S INSIDE?
Contact Information
Intellihot Green Technologies Inc.
2900 W. Main Street, Galesburg, IL 61401
phone: [phone]
email: [email protected]
web: www.intellihot.com
SIMULTANEOUS HOME
HEATING AND HOT WATER
PRODUCTION.
UP TO 4 SHOWERS NONSTOP UP TO 135,000 BTU/HR
+
INTELLIGENT CONTROLS
• Units can be set to control temperature or
allow maximum ow delivery—ideal for short
duration demand spikes or large commercial
dump loads tied with storage tanks
• After every ring cycle, system circulates
internally to equalize temperature, eliminate
hotspots and prevent scale (pump models only)
WATER INLET STRAINER
• Strainer included and factory installed on
the units to deliver debris-free inlet water to
the system
EASY-ACCESS
CONNECTIONS
• Thermostat/pump/outdoor reset

03 PLATE PERFORMANCE/PRESSURE DROP02 DIMENSIONS
INTELLIHOT COMBI
FRONT VIEW
TOP VIEW
WEIGHT: 98 LBS.
SIDE VIEW
BOTTOM VIEW
COMBI DIMENSIONS SPACE HEATING PERFORMANCE
SPACE HEATING SIDE - PRESSURE DROP
4 GPM
Supply Temp (°F) 120 130 140 150 160 170 180
Return Temp (°F) 90 100 100 110 110 120 120 130 130 140 150 160
Btu/h 58,000 39,000 57,500 38,500 57,000 37,800 57,700 38,200 57,100 38,600 37,700 34,500
6 GPM
Supply Temp (°F) 120 130 140 150 160
Return Temp (°F) 90 100 100 110 110 120 120 130 140
Btu/h 85,200 56,900 85,000 56,400 86,000 57,000 86,000 56,262 56,804
8 GPM
Supply Temp (°F) 120 130 140 150
Return Temp (°F) 90 100 100 110 110 120 130
Btu/h 114,500 77,030 114,500 76,500 102,900 75,900 75,100
10 GPM
Supply Temp (°F) 120
Return Temp (°F) 92
Btu/h 136,500
SPACE HEATING:
SUPPLY - 1” NPT
SPACE HEATING:
RETURN - 1” NPT
SPACE HEATING:
SUPPLY - 1” NPT
SPACE HEATING:
RETURN - 1” NPT
SPACE HEATING:
SUPPLY - 1” NPT
SPACE HEATING:
RETURN - 1” NPT
SPACE HEATING:
SUPPLY - 1” NPT
SPACE HEATING:
RETURN - 1” NPT
0 2 4 6
2.86
00
41.7
62.6
83.5
10 4.3
810 12
FLOW RATE (GPM)
(FT OF HEAD)
(PSI)
PRESSURE DROP

Single Zone, Single or Multiple Loop Baseboard Single Pump, Multiple Zones, Multiple Loop Baseboard, Using Individual Thermostats
Single Pump, Multiple Zones, Multiple Loop Baseboard,
Using External Valve Controller
Multiple Zones with Multiple Heating Systems, Multiple Temperatures,
Using External Zone Pump Controller and Individual Thermostats
05 PIPING CIRCUITS04 PIPING CIRCUITS
INTELLIHOT COMBI
PIPING CIRCUITS
03gnitaeHecapS
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter) Preventer
Union Air
Separator
Expansion
Tank
Thermostat Manifold
Set
PumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Heating
System
Pump
Thermostat Outdoor
Reset
Return
72°
72°
Single Zone, Multiple Loop Radiant
* LWCO
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter) Preventer
Union Air
Separator
Expansion
Tank
Thermostat Zone
Valve
PumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Return
72°
Zone1 Zone2 Zone 3 Zone4 Zone 5 Zone 6
Zone1 Pump Zone 2 Pump Zone3 Pump Zone 4 Pump Zone 5 Pump Zone 6 Pump
BoilerTT
Zone Controller
Heating
System
Pump
Thermostat Outdoor
Reset
72° 72° 72°
Single Pump, Multiple Zones, Multiple Loop Baseboard,
Using External Zone Valve Controller
gnitaeHecapS92
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter) Preventer
Union Air
Separator
Expansion
Tank
ThermostatPumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Heating
System
Pump
Thermostat Outdoor
Reset
Return
72°
72°
Single Zone, Single or Multiple Loop Baseboard
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter) Preventer
Union Air
Separator
Expansion
Tank
Thermostat Fan CoilPumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Heating
System
Pump
Thermostat Outdoor
Reset
Return
72°
72°
Single Zone, Air Handler
gnitaeHecapS13
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter) Preventer
Union Air
Separator
Expansion
Tank
Thermostat Zone
Valve
PumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Return
72°
MotorMotorMotor
Heating System
Pump
Thermostat Outdoor Reset
72° 72° 72°
Single Pump, Multiple Zones, Multiple Loop Baseboard,
Using Individual Thermostats
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter)
Check
Valve Preventer
Union Air
Separator
Expansion
Tank
ThermostatPumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Return
72°
Zone1 Zone 2 Zone 3 Zone 4 Zone 5 Zone 6
Zone1 Pump Zone 2 Pump Zone 3 Pump Zone4 Pump Zone 5 Pump Zone 6 Pump
BoilerTT
Zone Controller
Heating
System
Pump
Thermostat Outdoor
Reset
72° 72° 72°
Multiple Pumps, Multiple Zone Baseboard,
Using External Zone Pump Controller and Individual Thermostats
* LWCO
23gnitaeHecapS
Cold Water
Isolation
Kit
Ball
Valve
Gate
Valve
Strainer
(Filter)
Check
Valve Preventer
Union Air
Separator
Expansion
Tank
ThermostatPumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Return
72°
Zone1 Zone 2 Zone3 Zone 4 Zone 5 Zone 6
Zone1 Pump Zone 2 Pump Zone3 Pump Zone 4 Pump Zone 5 Pump Zone 6 Pump
BoilerTT
Zone Controller
Heating
System
Pump
Thermostat Outdoor
Reset
72° 72° 72°
Primary / Secondary Circuit with Multiple Pumps, Multiple Zone Baseboard,
Using External Zone Pump Controller and Individual Thermostats
* LWCO
Cold Water
Isolation
Kit Ball
Valve
Gate
Valve
Strainer
(Filter)
Check
Valve Preventer
Union Air
Separator
Expansion
Tank
ThermostatPumpPressure
Relief
Valve
Drain
Valve
Pressure
Reducing
Valve
KEY
Supply
Return
72°
Manifold Set
Fan CoilThree
Way Valve
Zone1 Zone 2 Zone 3 Zone4 Zone 5 Zone 6
Zone1 Pump Zone 2 Pump Zone3 Pump Zone 4 Pump Zone5 Pump Zone 6 Pump
BoilerTT
Zone Controller
Heating
System
Pump
Thermostat Outdoor
Reset
72° 72° 72°
Multiple Zones, with Multiple Heating Systems, MultipleTemperatures,
Using External Zone Pump Controller and Individual Thermostat

Combi Specications
PARAMETERS MODEL
i200X/i201X* i250X/i251X*
Type Indoor,Wall-Hung, Fully Condensing, Direct Ignition
Fuel Preset for NG / LP Convertible
Minimum / Maximum Input (Btu/h) 30,000 / 199,950 30,000 / 250,000
Thermal Efciency 94% 92%
Energy Factor 0.93 N/A
Appliance Annual Fuel Utilization Efciency (AFUE) 91.19% N/A
Combined Appliance Annual Fuel Utilization Efciency
(CAFUE)
91.4% N/A
Dimensions H X W X D (inches) 26 X 17.4 X 14.9 (3.9 cu. ft)
Weight 98 lbs
Water and Gas Connections 3/4” NPT
Space Heating Connections 1” NPT
Minimum Flow Rate No minimum ow rate in learned or programed modes
Venting Materials Sch. 40 PVC, Sch. 40 CPVC, Polypropylene, Stainless Steel
Max 3” Vent Length - Single Pipe / Power Vent 200 ft, deduct 5 ft per 90° elbow 130 ft, deduct 5 ft per 90° elbow
Max 3” Vent Length - Two Pipe / Direct Vent 100 ft, deduct 5 ft per 90° elbow 65 ft, deduct 5 ft per 90° elbow
Max 2” Vent Length - Single Pipe / Power Vent
(2” not allowed at elevations above 4,000 ft)
26 ft, deduct 5 ft per 90° elbow N/A
Max 2” Vent Length - Two Pipe / Direct Vent
(2” not allowed at elevations above 4,000 ft)
21 ft, deduct 5 ft per 90° elbow N/A
Safety Flame Rod, Thermal Fuse, Overheat Prevention Device, Fan Speed Monitor, Flue Temperature
Monitor, Blocked Vent Detector, Water Shut-Off Valve, 2X10A Fuse, Dual Flame Sensing
Water Pressure Min / Max (PSI) 30 / 150
NG/LP - Minimum Static Gas Pressure 1/2” Black Iron
(non-corrugated)
5” 6”
NG/LP - Minimum Static Gas Pressure 3/4” Black Iron
(non-corrugated)
2.5”
NG/LP - Maximum Static Gas Pressure 14”
Gas Pressure for Adjustments 8” for NG, 11” for LP
Electrical 120V AC, 60 Hz
Power Consumption 500W (Max 4.2 Amps), 8W (Standby)
FEATURES & PERFORMANCE i200X/i201X* i250X/i251X*
Space Heating Heat Exchanger Stainless Brazed Plate, Maximum Flow 15 GPM
Domestic Water Heat Exchanger Stainless 316L
Hot Water Capacity (35F Rise) 10.8 13.2
Hot Water Capacity (45F Rise) 8.4 10.3
Hot Water Capacity (77F Rise) 5.0 6.0
Domestic Hot Water Temperature Settings 100 – 140°F
Space Heating Temperature Settings 100 – 180°F
WARRANTY (with recirculation) Residential: Heat Exchanger Coil – 12 years, Parts – 3 years, Labor – 1 year
Commercial: Heat Exchanger Coil – 6 years, Parts – 1 year, Labor – 1 year
Intellihot Green Technologies Inc.
2900 W. Main Street, Galesburg, IL 61401
phone: [phone]
email: [email protected] · www.intellihot.com
Note: Due to Intellihot’s policy of continuous product improvements, design and technical specications are subject to change without notice. v 10.29.14
(i200X & i201X)
(i201X & i251X)
*ASME “H” certied
