Inter-m CDR-01 User manual

Operation Manual
SD Recorder/Multi Source Player
CDR-01

SD RECORDER/MULTI SOURCE PLAYER
W lcom
W lcom
A p rsonal w lcom to you from th manag m nt and mploy s of Int r-M
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value
and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service but if anything is not to your complete
satisfaction we will endeavor to make things right.
Welcome to Inter-M and thank you for becoming part of our worldwide extended family!
ISK OF ELECT IC SHOCK
DO NOT OPEN

CAUTION: TO EDUCE THE ISK OF ELECT IC SHOCK.
DO NOT EMOVE COVE (O BACK).
NO USE -SE VICEABLE PA TS INSIDE.
EFE SE VICING TO QUALIFIED SE VICE PE SONNEL.

To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*WA NING FO YOU P OTECTION PLEASE EAD THE FOLLOWING-WATE AND MOISTU E: Unit should not be used near water(e.g.
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do
not fall and liquids are not spilled into the enclosure through openings.
*Do not install this equipment in a confined space such as a book case or similar unit.
*This apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus.
*This apparatus shall be connected to a mains socket outlet with a protective earthing connection.
*
It has heed to be easy to disconnect the device. To disconnect the device from power, separate AC input cable from inlet or unplug the AC Cord.
* The socket-outlet shall be installed near the equipment and shall be easily accessible.

*These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are qualified to do so.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Caution: To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the blades
can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant
on une autre sortie de courant, sauf si les lames peuvent
étre insérées à fond sans en laisser aucune partie à
découvert.

SD RECORDER/MULTI SOURCE PLAYER
1
CDR-01
Cont nts
Cont nts
Unpacking .......................................................................................................................................2
Installation
Environment....................................................................................................................................2
Important Safety Instructions.............................................................................................................2
F atur s............................................................................................................................................3
Additional D scriptions .................................................................................................................4
M thod to tr at Compact Disc (CD).............................................................................................5
Front Pan l ......................................................................................................................................6
R ar Pan l .......................................................................................................................................9
Op rating M thod .......................................................................................................................10
1. PLAYBACK
1) CD Function ..........................................................................................................................10
2) USB Function.........................................................................................................................11
3) Memory Disc Function............................................................................................................12
2. REPEAT ....................................................................................................................................15
3. INSTANT PLAY .........................................................................................................................15
4. AUTO PLAY..............................................................................................................................16
5. RECORDING ............................................................................................................................17
6. DELETE.....................................................................................................................................18
7. CUE .........................................................................................................................................19
8. PITCH.......................................................................................................................................20
9. EJECT.......................................................................................................................................20
10. DISPLAY MODE ......................................................................................................................20
11. CAUTION...............................................................................................................................21
Block Diagram ..............................................................................................................................22
Sp cifications ................................................................................................................................23
S rvic
Procedures....................................................................................................................................25
Schematic.....................................................................................................................................25
Parts List .......................................................................................................................................25
Variations and Options ...............................................................................................................25
Warranty .......................................................................................................................................25

SD RECORDER/MULTI SOURCE PLAYER
Unpacking
2CDR-01
Unpacking
Please take a few minutes to read this manual to familiarize yourself with important information regarding
installation product features and operation.
As with most electronic devices ORIGINAL PACKAGING (OR EQUAL) IS REQUIRED in the unlikely event that
the product needs to be returned for servicing.
Installation
Installation
Environm nt
Never place this product in an environment which could alter its performance or reduce its service life. Such
environments usually include high levels of heat dust moisture and vibration.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators heat registers stoves or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart stand tripod bracket or table specified by the manufacturer or sold with the apparatus.
When a cart is used use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way such as power-supply cord or plug is
damaged liquid has been spilled or objects have fallen into the apparatus the
apparatus has been exposed to rain or moisture does not operate normally or has
been dropped.
S3125A
S3125A

SD RECORDER/MULTI SOURCE PLAYER
3
CDR-01
F atur s
F atur s
- HIGH PERFORMANCE DAC
One of the best-sounding D/A chip PCM1796 of Burr Brown is used.
- AUX RECORDING FUNCTION
Can record external sound source into the memory disc in MP3 format.
- SD MEMORY DISC FUNCTION
Can save the MP3 WMA or WAV audio files in the SD memory (8GB) using a computer and play the audio
files in the unit. Using SD memory function instead of CD playback can greatly save the lifetime of the CD
mechanism.
- USB
MP3 WMA or WAV audio files in a USB can be played directly.
- INSTANT PLAY FUNCTION
Can be set 10 tracks in 6 memory discs into 10 instant play buttons and it can play the track
directly using 10 instant play buttons.
- MP3/WMA/WAV
Can play CD-DA MP3 WMA and WAV audio formats.
- AUTO PLAY
Automatically play the preset source when the unit is turned on.
- PITCH CONTROL
Controls play speed rapidly or slowly as your preference.
- DIGITAL AUDIO OUTPUTS
Optical and coaxial output provides the S/PDIF digital audio.
- PROFESSIONAL DIGITAL AUDIO OUTPUTS
AES/EBU output provides the professional digital audio output.
- ANTI SHOCK FUNCTION
Strong anti-shock function.
- RS-232C
Can be controlled by a remote controller such as AMX or CRESTRON system.

SD RECORDER/MULTI SOURCE PLAYER
4CDR-01
Additional D scriptions
Additional D scriptions
- MP3 (MPEG AUDIO LAYER-3)
MP3 is a type of MPEG as audio video compression standards.
MP3 is one of music file formats that can contain stereo sound quality as good as audio CD. Compression rate
is 1MB by 1 and about 3~5MB are sufficient if recording a music of 3~5 minutes or so. Different from audio
CD MP3 can contain over 130 tracks for popular songs or folk songs. One MP3 CD can play for about 10
hours. MP3 can compress the music to 1/12 in its size with maintaining the CD sound quality because mp3
removes the frequency range which human being can not discernible. If compress a CD of 50MB to MP3
format then it is about 4~5MB maintaining CD sound quality.
- WMA (WINDOW MEDIA AUDIO)
WMA is a multimedia compression method developed by Microsoft Corporation and is technology compress
only music from ‘Window Media Technologies’. WMA can provide the same sound quality with the MP3 format
with a half file size compared to MP3. WMA file of 64kbps has the same audio sound quality with the MP3 of
128kbps.
- WAV (WAVEFORM AUDIO FORMAT)
WAV or WAVE stands for the waveform audio format. It is the standard format of audio playback in a
computer which is Microsoft or IBM. There are PCM DM DPCM or ADPCM formats. PCM is non-compressed
audio format and is used to rip a CD with the same sound quality with the CD.
- DIGITAL OUTPUT AND STANDARDS
Audio signal is recorded in a CD with a digitalized signal. Usually digital audio signal is converted to analog
signal with a Digital-Analog Converter (DAC) in a player. Optical output delivers the digital audio signal with
optical signal. Coaxial output delivers the digital audio signal with digital data.
The digital interface used in Optical and coaxial output is S/PDIF (Sony/Philips Digital Interface) format which
complies with the standards called as IEC60958.
- RS-232C SERIAL INTERFACE
AMX or CRESTRON remote control system can be used with this RS-232C terminal.
The maximum cable length should be below 15m.
1. RS-232C Terminal
2. Remote control function
Play/Pause Stop Skip down/up Search Down/up etc can be controlled by a remote controller.
3. Downloading of the control protocol
You can download the protocol at the home page (www.inter-m.com)
Pin 123456-9
Purpose X Receive Transmit X Ground X

SD RECORDER/MULTI SOURCE PLAYER
5
CDR-01
M thod to tr at Compact Disc (CD)
M thod to tr at Compact Disc (CD)
The CDR-01 is designed for the playback of CD-DA MP3 WMA or WAV.
Please use a CD with following mark:
- Make the label side upward when inserting a CD in the disc slot.
- Open a CD case with holding the right ending part of a case with the left hand and hold the both sides with the
right hand from below.
- Take off the CD with lightly holding both sides with the right hand while pressing the center of the case with
index finger.
- Lightly wipe out the CD with a soft cloth if fingerprint or dirt is stained on the signal side (opposite the label
side). Wiping out dirt or fingerprint gently with a smooth cloth. Keep disc clean and store it in its case when not
being played.
- Do not use any record spray anti-static solutions benzene and paint thinner or other chemical agents to clean
a CD. The surface of a CD may be damaged by these chemical agents.
- Please keep the disc in its case after use to avoid serious scratches that could cause the laser pickup to skip.
- Keep discs away from direct sunlight and places of high heat and humidity. It may cause deformation.
- Do not paste papers etc to the label side. Do not write on the disc with a ballpoint pen.
- Only use circular compact discs Avoid using non-circular promotional etc. discs.
- The CDR-01 cannot play un-finalized CD-R/RW discs.

SD RECORDER/MULTI SOURCE PLAYER
6CDR-01
Front Pan l
Front Pan l
1. SD MEMORY COVER
It is SD memory cover. Be sure the direction when insert a SD memory into the slot.
※Maximum 32GB SD memory can be used. The built-in SD memory is 8GB.
2. SOURCE SELECT LED
Indicating LED for the selected source.
󱈇CD 󱈇USB 󱈇Memory Disc
3. SOURCE SELECT BUTTON
Push this button to select the source.
󱈇CD 󱈇USB 󱈇Memory Disc
4. MEMORY DISK INSTANT PLAY BUTTON
Use this button to store 10 tracks in 6 memory discs into the INSTANT PLAY Buttons and to play the
preset track directly.
5. DISC SLOT
Insert a CD into the slot label side upwards.
The unit will pull the disc when the CD is partially inserted.
※DO NOT INSERT a 3-inch CD into th slot.
6. EJECT BUTTON
Ejects a disc.
7. SELECT LED
The LEDs indicates the Skip (I◀◀▶▶I) Folder (111) or Search (◀◀▶▶) mode.
5 768 129 10 11 13
1415161819202223242528 27 26 17
21

SD RECORDER/MULTI SOURCE PLAYER
7
CDR-01
8. SELECT BUTTON
Use this button to select the Skip (I◀◀▶▶I) Folder (111) or Search (◀◀▶▶) mode.
After select the mode skip folder or search function can be performed using the ENCODER switch.
- Skip (I◀◀▶▶I) : skips a track or a folder.
- Folder (111) : skips a folder.
- Search (◀◀▶▶) : turning the switch to the clockwise then it searches forward continuously.
turning the switch to the counter clockwise then it searches backward
continuously. Press the button to stop searching and to play the track.
9. ENCODER SWITCH / OK BUTTON
Rotates this switch to perform skip folder change or search function after select the
Skip (I◀◀▶▶I) Folder ( ) or Search (I◀◀▶▶I) mode. In menu mode turning this switch
can change the menu and pushing this button can change the setting.
10. MENU BUTTON
Use this button to select the menu DELETE MDISK AUTO PLAY DELETE INSTANT or PITCH setting.
※MENU button can b us d wh n th unit is in stop mod .
11. ESC BUTTON
Use this button to move back the menu in menu mode.
12. MEMORY DISC SELECT BUTTON
Use this button to select the one of the 6 memory discs.
13. AUTO PLAY SWITCH
Use this switch to set the auto play function.
By setting this switch on the preset source of a CD USB or Memory Disc is automatically played when the
unit is turned on. Playback starts from the first track of the preset source.
14. POWER SWITCH
Use this switch to turn the power on or off.
15. PITCH LED
This LED indicates that the pitch function is on.
※In PITCH mod , th AES/EBU output is off.
16. PITCH CONTROL BUTTON (+/-)
Use this button to control the pitch function.

SD RECORDER/MULTI SOURCE PLAYER
8CDR-01
17. PLAY MODE
Use this button to stop the playback after 1 track is played.
When the PLAY mode button is pressed during the playback playback is stopped after the playback of the
track is end.
18. REPEAT BUTTON
Use this button to select repeat mode REPEAT 1 REPEAT GROUP or REPEAT ALL.
19. INSTANT PROGRAM BUTTON
Use this button to store 10 tracks in 6 memory discs into 10 instant play buttons.
※In CD or USB function, th Instant Program button or th Instant Play function can not b us d.
20. DISPLAY BUTTON
Use this button to select time mode playback time or remaining time.
21. DISPLAY WINDOW
The display shows the current status of the unit or the current menu setting.
22. RECORD BUTTON
Use this button to record the AUX audio into the SD memory.
The built-in SD memory is 8GB. AUX audio is recorded into the memory disk6.
23. PLAY / PAUSE BUTTON
Use this button to play or pause.
24. STOP BUTTON
Use this button to stop playback or recording.
Also this button can exit all the menu mode.
25. CUE BUTTON
If the CUE is on and a track is selected then the track is located to the point
where music begins and the unit is entered into pause mode.
At that time press the play button then playback begins at exactly that point.
26. USB
Use this terminal to mount a USB memory.
MP3 WMA or WAV files in the USB memory can be played .
Maximum 32GB USB memory can be used.
The unit supports USB 1.1.
27. HEADPHONE VOLUME
Adjust the output level of the headphones.
28. HEADPHONE JACK
Use a standard pair of stereo headphones.
※Wh n using h adphon s, b sur not to turn th h adphon volum too high.
List ning at high volum s for xt nd d p riods of tim may r sult in p rman nt h aring damag .

SD RECORDER/MULTI SOURCE PLAYER
9
CDR-01
R ar Pan l
R ar Pan l
1. AC INLET
Connect the power cable supplied with the CDR-01.
2. RS-232C TERMINAL
This terminal allows control by a remote controller such as AMX /CRESTRON etc.
The control protocol can be downloaded from the home page. (www.inter-m.com)
3. COAXIAL OUTPUT
This terminal provides the digital audio signal in S/PDIF format.
4. OPTICAL OUTPUT
This terminal provides the digital audio signal in S/PDIF format.
5. AES/EBU OUTPUT
This terminal provides the professional digital audio signal.
※In PITCH mod , th AES/EBU output is off.
6. ANALOG MONO OUTPUT
MONO output terminal provides the mixed signal of L and R channel outputs.
The maximum output level is +8dBu.
7. ANALOG R CHANNEL OUTPUT (XLR)
This terminal provides R channel signal output. The maximum output level is +8dBu.
8. ANALOG L CHANNEL OUTPUT (XLR)
This terminal provides L channel signal output. The maximum output level is +8dBu.
9. XLR OUTPUT LEVEL SELECT SWITCH
This switch selects the output level maximum +8dBu or +20dBu of the XLR L/R audio output.
10. ANALOG L/R OUTPUT (RCA)
These terminals provide L and R channel signal output. The maximum output level is +8dBu.
12345 9
67 12118 10

SD RECORDER/MULTI SOURCE PLAYER
10 CDR-01
Op rating M thod
11. AUX RECORDING INPUT (RCA)
These terminals are for the aux recording.
The maximum input level is +8dBu.
12. AUX RECORDING INPUT (XLR)
These terminals are for the aux recording.
The maximum input level is +20dBu.
Op rating M thod
1. PLAYBACK
(1) Push the power switch to turn the power on.
The display will indicate NO DISC.
(2) Insert a disc into the slot label side upwards.
Do not forces the disc into the slot The unit will pulls the disc when the CD is partially inserted.
※DO NOT INSERT a 3-inch CD into th slot.
1) CD function
- Playback disc is a ordinary audio CD CD-R or CD-RW disc recorded in CD-DA format and properly
finalized.
(1) Select CD mode by pressing the SOURCE button when the source is not in CD mode
(2) After a disc is inserted the display will indicate the information as below.
- CD-DA : displays total number of tracks and total playback time.
󱈇Track : 27 tracks
Total Playback Time: 1hour 19min. 10sec.
- CD-MP3 : displays total number of folders and total number of files.
󱈇Folder : 64 folders
Track : 257 tracks.
(3) Select a track to play using the SELECT button and the switch.

SD RECORDER/MULTI SOURCE PLAYER
11
CDR-01
- CD-DA : select I◀◀▶▶Iusing the SELECT button and select the track to play by turning the
switch.
- MP3 : • select 111 using the SELECT button and select the folder by turning the switch.
• select I◀◀▶▶Iusing the SELECT button and select the track to play by turning the
switch.
(4) Press the 11111 button to play.
To skip the track during playback select I◀◀▶▶Iusing the SELECT button and select the track
to play by turning the switch.
(5) Press the 111111button again to pause.
Press the 111111button to stop.
※Not :
1. A disc which surfac status is not good or a disc which format is not compatibl
cannot b play d and is stopp d.
2. Wh n a disc format is not compatibl , th window displays ‘READING ERROR’
or ‘NO FILE’.
3. Wh n a disc is ins rt d upsid down, th n th window displays ‘READING ERROR’.
4. DO NOT INSERT a 3-inch CD into th slot.
Ch ck th disc status and format b caus th s ar not failur of this unit.
2) USB function
(1) Insert a USB memory to the USB terminal.
(2) Press the SOURCE select button to select the USB mode.
(3) Total numbers of the folders and total numbers of files to play are displayed.
󱈇Folder : 64 folders
Track : 257 tracks
If no files to play then “NO FILE” is displayed.
If a USB memory is not inserted “NO USB” is displayed.

SD RECORDER/MULTI SOURCE PLAYER
12 CDR-01
(4) Select a track to play using the SELECT button and the switch.
- select 11 using the SELECT button and select a folder by turning the switch.
11 can be selected only when the USB have folders.
- select I◀◀▶▶Iusing the SELECT button and select a track to play by turning the
switch.
(5) Press the 111111 button to play.
To skip the track during playback select I◀◀▶▶Iusing the SELECT button and select
the track to play by turning the switch.
(6) Press the 111111button again to pause.
Press the 111111button to stop.
※Not :
Wh n th track which status is not good or which format is not compatibl , th window
displays “PLAY ERROR”. Th rror track is skipp d and th n xt track is play d.
3) M mory Disc function
The CDR-01 has internal memory of 8GB.
Maximum 32GB SD memory can be used.
Take out the SD memory from the unit and save music files into the disk1 ~ disk5 folders in the SD memory
using a computer. Plug the SD memory into the unit and play the music.
Disk1 ~ disk6 folders are the same with the memory disc 1 ~ disc6 respectively. Aux recording is stored in memory disk6.
※Using m mory function inst ad of CD playback can gr atly sav th lif tim of th CD m chanism.
(1) Take out the SD memory from the unit.
The window displays ‘NO CARD’.
Screw off the cover. Push and release the center of the SD
memory and then take out the SD memory.
(2-1) Storing music files
① SD memory has 6 folders as disk1 disk2 disk3 disk4 disk5 and disk6.
Disk1 disk2 disk3 disk4 disk5 and disk6 are the same with memory disc 1 memory

SD RECORDER/MULTI SOURCE PLAYER
13
CDR-01
disc2 memory disc3 memory disc4 memory disc5 and memory disc6
respectively.
② Save music files into each folders of disk1 ~ disk5.
③ Maximum 499 music files can be saved in disk1 ~ disk5 respectively.
Maximum 100 tracks can be recorded in disk6. Disk6 is for the AUX recording.
Maximum music files in disk1 ~ disk6 are 1800 files.
④ The track number of each memory disc is the order that files are saved to the folder.
If playback sequence is needed then copy music files to the folder in the order of
wanted playback sequence respectively.
⑤ If disk1 ~ disk5 folders uses all the built-in 8GB memory then disk6 can not
be used. The window does not display the number of the memory disk 6.
⑥ Maximum 3GB can be used in memory disc6.
⑦ If disk6 folder have music files which were copied from a computer and record
the AUX music source then the track order of the memory disc6 can be changed.
Use the memory disc6 only for the AUX recording.
(2-2) Making folders in SD memory
① The built-in SD memory has 6 folders. If you use the built-in SD memory as it is then
there is no need to make folders in the SD memory.
② If the folders in the built-in SD memory are deleted or if a new SD memory is needed
then have to make folders in the SD memory as below.
a. Make 6 folders in the SD memory.
b. The order to make folders is the order of the memory disc.
c. Make a folder and name it and then make a folder repeatedly.
d. The folder name of 1 ~ 5 folders can be named as your preference.
e. The folder name of the 6th folder must be disk6.
The folder of disk6 is the same with the memory disc6 and the memory disc6 is
used to record the AUX music source.
※If you do not follow th abov instructions wh n making fold rs in th SD
m mory, th n som m mory disc may not b r cogniz d or th ord r
of th fold rs may not b match d with th ord r of th m mory discs.
③ If you do not want to make folders in a computer but want to make folders in
the unit automatically then follow the instructions below.
a. Plug the SD memory into the slot.
b. Select Memory Disk using the SOURCE select button.
c. Press the button.
d. Press the button when the window displays ‘AUX->REC’.
Recording starts after the window displays ‘INIT’.
e. Press the button after 1 or 2 seconds since recording starts.

SD RECORDER/MULTI SOURCE PLAYER
14 CDR-01
The unit makes 6 folders when records the AUX music source
into the memory disc6.
f. Take out the SD memory and plug it into a computer.
g. Copy music files into the disk1 disk2 disk3 disk4 and disk5 which
are made in the unit.
h. Delete the MP3 file in the disk6 folder.
i. Plug the SD memory into the unit.
It is possible to make folders automatically as above.
(3) Plug the SD memory into the slot
Be sure the direction when insert a SD memory into the slot.
Follow the direction silk under the slot.
Plug the SD memory into the slot until it is locked.
Screw the cover on the slot.
※If SD m mory is mount d during CD or USB playback, playback is stopp d and
th function is chang d to M mory Disc mod .
(4) The window displays the total track of the memory disc1.
(5) Select the memory disc which has music files to play
The window blinks the selected memory disc number.
※Th m mory disc which has no music fil can not b s l ct d. Th window
displays th m mory disc numb r which has music fil s.
(6) Select the track to play using the SELECT button and the switch.
(7) Press the button to play.
To skip the track during playback select I◀◀▶▶Iusing the SELECT button and select the
track to play by turning the switch.
(8) Press the button again to pause.

SD RECORDER/MULTI SOURCE PLAYER
15
CDR-01
Press the button to stop.
2. REPEAT
Press the 111111 button to change the repeat mode.
(1) REPEAT 1: Playback the file selected repeatedly.
(2) REPEAT GROUP: Playback the GROUP selected repeatedly.
(3) REPEAT ALL: Playback the disc USB or a memory disc repeatedly.
(4) OFF mode: Playback the disc without repeats and then stops.
3. INSTANT PLAY
Store the frequently used tracks up to 10 tracks in the memory discs to 10 instant play buttons and
play the preset track directly by pressing the INSTANT PLAY button.
※In CD or USB function, th Instant PLAY function can not b us d.
1) Instant Program
(1) Select the MEMORY DISC function using the SOURCE SELECT button.
(2) Press the 111111 button.
(3) Select the memory disc which has music files to preset.
(4) Select I◀◀▶▶Iusing the SELECT button.
(5) Turning the 111111 switch to select the track to preset.
(6) Press the wanted INSTANT PLAY button for about 2 seconds.
(7) If the track is saved in the selected INSTANT PLAY button then the INSTANT PLAY button is lit.
(8) Press the ESC button to stop the INSTANT program.

SD RECORDER/MULTI SOURCE PLAYER
16 CDR-01
2) Instant Play
Press the INSTANT PLAY button to play.
After playback the track playback stops.
3) D l t INSTANT PLAY s tting
(1) Press the button.
(2) Turning the switch to select ‘DELETE INSTANT’ menu and then press the button.
(3) Turning the switch to select the INSTANT PLAY button to delete and then press the
button.
(4) Press the button when ‘DELETE?’ is displayed on the window.
The LED of the INSANT PLAY button which is selected to delete is off.
(5) To delete all the INSTANT PLAY buttons then select the ‘DEL ALL’ menu using the
switch then press the button.
※Not :
1. If you d l t th track which is m moriz d in a m mory disc, all th tracks pr s t
in th INSTANT PLAY buttons which ar in th sam m mory disc with th d l t d track
ar d l t d.
2. In CD or USB function, th Instant Program button or th Instant Play function can not b us d.
3. If tak out th SD m mory with th pow r on stat , all th pr s t s ttings of th INSTANT
PLAY buttons ar d l t d and all th LEDs of th INSTANT PLAY buttons ar off.
4. If tak out th SD m mory with th pow r off stat and d l t tracks and add tracks in th
SD m mory using a comput r, and plug into th unit. Th tracks which ar pr s t in th
INSTANT PLAY buttons may b chang d to oth r tracks.
B sur to ch ck wh th r all th tracks pr s t in th INSTANT PLAY buttons ar
chang d or not.
4. AUTO PLAY
AUTO Play is the function to preset the source (CD USB or Memory disc) to play and to play the
preset source when the power of the CDR-01 is turned on.
Playback starts from the first track of the selected source.
1) AUTO PLAY s tting
To set the AUTO PLAY function set the AUTO PLAY switch to ON position.

SD RECORDER/MULTI SOURCE PLAYER
17
CDR-01
2) S tting th AUTO PLAY sourc
(1) Press the button.
(2) Turn the switch to select the AUTO PLAY menu
and then press the button.
(3) Select the source (CD USB or DISK 1~DISK 6) to preset and then press the button.
※Not :
Wh n th Auto Play switch is in off position, CD function is th d fault function wh n
th pow r is turn d on. Th window displays th total tracks and th unit is in stop
mod . If no disc, th n th window displays ‘NO DISC’.
5. RECORDING
Aux music source can be recorded in the internal memory disk6.
(1) Connect the AUX music source to the recording input terminals (XLR or RCA inputs).
The maximum input level of RCA input is +8dBu.
The maximum input level of XLR input is +20dBu.
(2) Press the button then the REC button is lit in red. The window displays ‘AUX -> REC’.
※ If do not pr ss th button, th n r cording function will b stopp d aft r 7
s conds sinc th REC button is pr ss d.
(3) Press the button.
The window displays ‘INIT’ and then start recording.
(4) Press the button long to stop recording.
When the button is pressed during recording the recorded music is saved as a track.
(5) Maximum 100 tracks can be recorded in the memory disc6.
(6) If record the AUX music source continuously then a new track is made every 2 hours.
(7) The maximum recording time of the memory disc6 is about 34 hours.
(8) When the recording is end the recorded track is automatically played.
(9) The window displays the recording status as below.
00 : 00 : 01 means the recording time.
REC 100% means the memory remains.
6

SD RECORDER/MULTI SOURCE PLAYER
18 CDR-01
※Not :
1. During r cording, th r ar no analog and digital outputs.
2. CDR-01 can play th MP3, WMA or WAV format as b low.
MP3 : 44.1kHz sampling fr qu ncy, 16bit and 64kbps~320kbps bit rat s.
WMA : 44.1kHz sampling fr qu ncy, 16bit and 64kbps~320kbps bit rat s.
48kHz sampling fr qu ncy, 16bit and 64kbps~192kbps bit rat s.
WAV : 44.1kHz sampling fr qu ncy, 16bit, PCM and st r o format.
3. Th built-in SD m mory is 8GB. Maximum 32GB SD m mory can b us d.
4. It may b a littl diff r nc b tw n th display d m mory siz and th
practical m mory siz .
5. If disk1 ~ disk5 fold rs us s all th built-in 8GB m mory, th n disk6 can not b us d.
Th window do s not display th numb r of th m mory disk 6.
6. Maximum 3GB m mory can b us d in th m mory disc6.
Pl as assign 3GB m mory to th m mory disc6 for th AUX r cording.
If th m mory assign d to th m mory disc6 is not 3GB, th n th display of th
m mory r mains is not match d with th practical m mory r mains b caus th
display of th m mory r mains is r f r to 3GB.
7. If th m mory siz of th m mory disc6 is ov r 3GB or th r is no m mory r mains for
r cording, th n th window displays ‘DISK6 OVERFLOW’ and r cording is stopp d.
8. If copy som music fil s to th disk6 fold r in a comput r and r cord th AUX music sourc ,
th n th track ord r is chang d. Pl as us th disk6 fold r only for th AUX r cording.
9. If 100 tracks ar r cord d in th m mory disc6, th n th window displays
‘REC FULL’ and r cording is stopp d.
6. DELETE
Delete function is used to delete the files in the memory discs.
1) Delete all the memory discs.
(1) Press the button.
(2) Press the button to select the DELETE MDISK menu.
(3) Turn the switch to select DISK FORMAT menu and press the button.
(4) Press button again when ‘OK?’ is displayed on the window.
All the folders are deleted. 6 folders have to be made to use the SD memory. ( see page 12)
※DO NOT TURN OFF THE POWER during formatting th m mory disc, it caus s th
m mory disc fault.
