IT-2200 InterTrack
BELT LUXURYTREADMILL
USER GUIDE

Install the treadmill in a dry location away from water, dampness, and dust
Do not run on the treadmill with bare feet. Wear appropriate exercise clothing
Plug the treadmill into a grounded electrical socket
Do not plug into an extension board
Keep children away from the treadmill.
Before operating, ensure safety clip is attached to you so the emergency stop is activated
at the time of accident
After using silicone oil, keep it away from children’s reach to avoid accidental ingestion
Do not wear clothes that can easily hook onto the treadmill
Keep the power cord away from hot objects and surfaces
Do not use the treadmill in the open air
Do not perform repairs yourself or allow non-authorised persons to disassemble or perform
repairs on the treadmill. If repairs are required, cease use immediately and contact
intertrack.net for assistance
Do not use the treadmill if it is damaged in any way
Do not use when intoxicated
The treadmill can not support more than maximum weight of 220kg
Power off and unplug the treadmill before moving
Clean the treadmill regularly. See the Cleaning & Care section of this user guide
Switch off the treadmill after use
SAFETY & WARNING
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.

Electrical Grounding
•Use this product with appropriate electrical grounding. If there is malfunction, the
grounding system will provide a low resistance pathway to ground to protect against
electric path.
•Install this product using Equipment-Grounding Conductor (EGC) and grounding plug.
The plug must be inserted into the proper plug base that has been correctly installed
and grounded according to the local laws or regulations. 220V
•If the ECG is connected improperly, it may cause the danger of electric shock. If you
doubt whether the grounding of this product is right, authorise professional electrician
to check.
•If the grounding plug attached with this product does not match with the plug base,
authorise professional electrician to install right plug. 220V
•Ensure that the grounding plug of this product is connected to the plug base that has
the same shape. Do not use plug base adapter.

1
Upper Frame
7
Running Deck
2
Control Console
8
Running Belt
3
Input Keys
9
Rear Guard
4
Handles
10
Folding Lock
5
Upright Post
11
Side Cover
6
Calinder
12
Lower Frame
12
9
1
2
3
4
7
8
10
5
11
6
OVERVIEW

Step 1: installation of complete machine
1. Hold the Column and slowly pull to the fixing hole position.
2. Fix Column onto Pedestal with M8*20,M8*55 screw and M8 flat gasket.
3. Fix Display Meter onto the Column with M8*20 screw and M8 flat gasket.
ASSEMBLY

Step 2: Assembly of left and right side covers
1. Remove the package stator that hold the frame and the base,and be careful not to
hurt someone when the frame bounces off.
2. Fix the left and right side covers on both sides of pedestal with M4*15 screw and
lock them.
Finally, please ensure that all screws are tightened after all accessories are assembled.

1. Insert power plug into socket and turn on power switch a (light turns red). You will
hear “beep” and window on instrument panel displays.
2. Place safety lock at yellow position of instrument panel, when the treadmill can be
normally used.
3. Please clamp the safety lock onto your clothes when using the machine to avoid
accidents.
4. You can open the safety lock at any time to immediately stop the motor to avoid
falling over.
5. Please place the safety lock back and start starting program to use the machine
again.
Console Operation
Note: Always use a power outlet that is earthed.
OPERATION

START To start the treadmill.
STOP To stop the treadmill.
PROG
Following modes available:
•Manual Control
•Automatic Program
•Custom Program
•HRC Program
•Body Fat Test
To change functions, do the following:
•When in Manual Control, press the PROG
button to enter the Automatic Program.
•Press PROG again to enter Body Fat Test.
•Press PROG again to return to Manual Control.
MODE To select the Countdown mode.
SPEED To adjust the running speed.
INCLINE
•To adjust the incline speed.
•When the console is in standby state, press the
MODE key to change from speed to incline
adjustment.
VOLUME To adjust the volume of music playback.
LAST/NEXT To cycle between the tracks during music playback.
Speed Adjustment Key
Incline Adjustment Key

Manual Control Mode
•When the treadmill is in standby, press the START key to start the treadmill and
enter manual control mode.
•The initial speed will be 1 kilometer/hour.
•Time, Distance and Calorie counts will start from 0.
•Speed and incline of the treadmill can be adjusted in real-time using the SPEED
and INCLINE keys on the console.
•If exercise time exceeds 99: 59 minutes, the time will reset to 0.
Countdown Mode
The treadmill can be set to stop automatically when you reach the desired goal of either
Time, Distance or Calories.
•To enter the Time Countdown Mode, do the following:
1. In the Manual Control mode, press the Mode key to select the Time Countdown
mode.
2. The time display shows 30:00 minutes. The running time can be set via Speed +/-
key or Incline +/- key.
3. Set time range from 8:00 ~ 99:00 minutes. Press the START key to start the timer
countdown.
•To enter Distance Countdown mode, do the following
1. In the Manual Control mode, press the Mode key to select the Distance Countdown
mode.
2. The distance display shows 1.0 km and the distance goal can be set by pressing the
Speed +/- key or Incline +/- key.
3. Set distance range 1.0 ~ 99.0 km. Press the START key to start the distance
countdown.
•To enter the Calorie Countdown mode, do the following
1. In the Manual Control mode, press the Mode key to select the Calorie mode.
2. The calorie display shows 50 calories and calories can be set by pressing the Speed
+/- key or Incline +/- key.
3. Set calorie range from 20 ~ 990. Press the START key to enter the Calorie mode
operation.
During any countdown mode when START is pressed the initial speed will be 1 km/h.
The countdown mode you have chosen will begin the countdown as the other
parameters increases.
The speed and incline of the treadmill can be adjusted manually in real-time using the
SPEED and INCLINE keys.
As the countdown parameter reaches its goal the treadmill will slow down and enter
standby mode.

Automatic Program Function
1. In the Manual Control mode state or MODE setting state, press the PROG key to enter
the Automatic Program function.
2. The display shows 30:00 minutes and can be adjusted by pressing the SPEED +/-key
or INCLINE +/- key. Set the range to 8:00 ~ 99: 00 minutes.
3. Press the START key to start an automatic program.
4. The automatic program is divided into 20 sections. The Speed and Incline values for
each segment run is determined by the automatic program. The run time for each
segment is 1/20 of the total set time.
5. Distance and Calories displays starts from 0 and increases.
6. Speed and incline can be adjusted during the automatic program by pressing the
SPEED and INCLINE keys.
7. When the automatic program is complete the treadmill will enter the standby mode.
Body Fat Test Function
1. In the Manual Control mode or MODE setting state, press the PROG key to enter the
Body Fat Test function.
2. After entering the body fat test settings status, the SPEED display will show the
parameters name.
3. The TIME display shows a parameter value to be set. Adjust the parameter value by
using SPEED +/- key or INCLINE +/- key.
4. Press the MODE key to select and enter the following parameters:
Parameters
F-1
Gender
F-2
Age
F-3
Height
F-4
Weight
Range
Male: 1 and Female: 2 10 to
99 years
100 to 220 centimeters
20 to 150 kilograms
F-5
Body Fat
Initial Value
1
25 years
170 centimeters
70 kilograms
---
5. After entering the parameters, test your Body Fat percentage.
6. Hold the steel sensor plates on the handlebars for about 5 seconds.
7. The body fat percentage will be calculated based on your input parameters and will
be displayed on the screen.

Heart Rate Function
•Hold the steel sensor plates on the handlebars. Use natural grip on both handles.
•After about 5 seconds, the LED pulse display window will display a heartbeat initial
value. Keep your hands still on the sensors for roughly 30 seconds to get an accurate
heart rate measurement.
•The heart rate data will change in real-time if your hands are placed on the sensors.
Initial Program Initial Value Setting Range Display Range
0:00 30:00 8:00 - 99:00 0:00 ~ 99:59
0.0 1-181 - 18
0.00 1.O - 99.0 0.0 - 99.9
P N/A 40 - 199
0.0 20 - 9900 - 999
Time (Min: Sec)
Speed (Km/h)
Distance (Km)
Pulse (Times/Min)
Calories (Kcal)
Incline (Level) 0
1
1.00
N/A
50.0
0 0 - 15 0 - 15
Note: This heart rate test data is not use for medical purposes and should be
.used for sporting purposes only
Sleep Function
• When the treadmill stops running and there is no operation for more than 10
minutes, the sleep mode will be activated. The display is turned off automatically.
• Press any key to wake it up.
Safety Tether and Safety Lock
• Before operating the treadmill, ensure the safety tether is placed in the specified
location.
• If the safety tether is missing or not correctly connected the control console will
display E07 or "---" with a warning note.
• If the safety tether is removed when operating the treadmill, the system will quickly
shut down and the safety lock is activated. The data in the display will be cleared.
Display Parameters Range

Folding the Treadmill
1. Before moving the treadmill, ensure it is turned off and unplugged from the power
outlet.
2. Release the Folding Lock. Fold the Running Deck towards the Upper Frame by
holding the Rear Guard as shown in the image.
. The Cylinder will lock the Running Deck in the upright position.
Folding Lock
Gas Strut
Cylinder
3

Moving the Treadmill
1. Fold the treadmill as per the instructions under the Folding Treadmill section.
2. Move the treadmill by placing a foot at the base to hold it steady. Pull the treadmill
towards you by the hands.
After moving to a safe place for storing, gently tread the Cylinder as shown in the
image below. The Running Deck will slowly fall to its position.
3.

•The running belt can be adjusted in two variables: the degree of tightness and
central position of the running belt.
•The running belt has been adjusted when leaving the factory, but it will be stretched
after use. Deviation from a central position can cause damage by wearing the trim
strip and rear protecting cover. It is normal for the belt to stretch throughout its use.
Adjust the Running Belt
If the running belt is slipping during use or tends to get caught and not run smoothly, adjust
the tightness of the belt. Follow the below instructions:
1. Insert the regulating screw on the back left of running belt using 5 millimeters
hexagon wrench. Turn the wrench by 1/4 of a circle clockwise to regulate the rear
roller to tighten the running belt.
2. Repeat step 1 to adjust the screw on the right. Ensure that the regulating screw is
turned by the same distance to make the rear roller parallel with the frame.
3. Repeat step 1 and 2 until the running belt is tight.
4. If the running belt is too tight, to reduce the tension of the running belt, turn the
wrench anticlockwise by same distance on both sides.
Appropriate maintenance is required to keep your treadmill in optimal condition. Incorrect
maintenance will damage or shorten the service life of the treadmill.
Regulate the Running Belt
Note: The running belt should not be too tight as it can damage the
running belt, roller bearing and increase the pressure of front/rear roller
causing abnormal sound or other problems.
CLEANING & CARE

Adjust Running Belt Position
When using the treadmill, the force of your feet can cause pressure on running belt and
making it unbalanced, which makes the running belt deviate from the center portion.
Such deviation is normal. It will return to the center position when nobody is running on the
running belt. Adjustment is needed if the belt fails to return to the central position.
Follow the instructions below to adjust the position of the belt:
1. Activate the treadmill without a runner on it and adjust speed to 6 kilometers/hour.
2. Observe the distance of the running belt from left edge strip to right edge strip.
3. Do the following:
•If the running belt tilts towards the left, turn the left screw by 1/4 of a circle
clockwise with a hexagon wrench.
•If the running belt tilts towards the right, turn the right screw by 1/4 of a circle
clockwise with a hexagon wrench.
•If the running belt is still not in the middle, repeat the above steps until it is in the
middle.
•After adjusting the belt, set the speed to 16 kilometers/hour. Observe deviation of
running belt and running smoothness. Repeat the adjustment steps in case of
deviation.
4. Ensure that after the adjustment the running belt is not too tight nor loose.
5. If the running belt is too tight, to reduce the tension of the running belt, turn the
wrench anticlockwise by same distance on both sides as shown in the image.
Note: The running belt should not be too tight as it can damage the
running belt, roller bearing and increase the pressure of front/rear roller
causing abnormal sound or other problems.

Automatic Lubricating Oil
The treadmill is oiled when leaving the factory, lubrication process of the treadmill is
automatically oiled frequently during use upon need. so please stay alert to check the
silicone oil bottle and be sure it is not empty in order to let the treadmill lubricated
successfully upon need.
Cleaning
Frequently clean the treadmill to guarantee its service life.
•Cut off the power when cleaning the treadmill. The power line must be pulled out from
the outlet.
•Clean sweat stains on the instrument and other parts with a clean towel and damp
cloth.
•Do not use corrosive articles and liquid to prevent damage to electronic elements. Do
not expose electronic elements to sunlight.
•Place the treadmill in a clean and dry environment. Ensure that power switch is off and
is not plugged to a power outlet.
Note: Do not operate the treadmill while lubricating. Use only non-
petroleum silicone oil.

Code Description Solution
E01
Poor Communication
between Speed Sensors
and Control Console
Inspect connections between speed sensors and
control console.
E02 Short Circuit
If there is open circuit in the treadmill motor,
cease use immediately
If there is a poor contact with the motor, check the
connection.
E03 Speed Sensor Failure If the speed sensor is not in correct position, adjust
its position.
E04 Overvoltage
Ensure the power supply match the treadmill’s
rated power.
E05 Overcurrent Protection
Ensure the resistance of the running deck is not too
high. If it is, lubricate the treadmill.
See the Cleaning & Care section of this user guide.
E06 Diagnostic Testing Error Check the control console
E07 or ---
Safety Tether is in
Incorrect Position
Ensure to connect the safety tether to the control
console.
Safety Lock System Error
TROUBLESHOOTING
For any of the following descriped problem, please contact intertrack.net

SPECIFICATIONS
Motor AC 5.0HP
Automatic incline: 0 - 18%
Max user weight: 220 kg
Speed: 1 - 20 km/h
Running area: 150x52 cm
N/G Weight: 102/114 kg
LED touch screen ( Heart rate, calories, distance
)
Oil system: Automatic lubrication with oil guide tube
Duration of consistent usage : 5 hour (30 Minutes rest in
between)

Need more information?
We hope that this user guide has given you the
assistance needed for a simple set-up. For the
most up-to-date guide for your product, as well as
any additional assistance you may require, head
online to
[email protected]
[email protected]
intertrack.net
