Interlogix TruVision Wedge User manual

TruVision
Wedge
Dome Back Box an
d
Dual View Mount
Installation Guide
P/N 1073093A-EN • REV A • ISS 30SEP15

Copyright
© 2015 United Technologies Corporation,
Interlogix is part of UTC Building & Industrial Systems, a unit of United
Technologies Corporation. All rights reserved.
Trademarks and patents
Trade names used in this document may be trademarks or registered trademarks
of the manufacturers or vendors of the respective products.
Contact information
For contact information, see www.interlogix.com or
www.utcfssecurityproducts.eu.

Installation Guide 3
Content
Product overview 3
Product and package contents 4
TVW-DVM dual view mount 4
TVW-AWB-1 outdoor angled back box 6
TVW-AWB-2 indoor angled back box 8
TVW-2G-AD adapter plate 9
Installation 12
Specifications 23
TruVision wedge camera bracket and mount 23
Product overview
This is the installation guide for the following TruVision wedge
camera models:
TVW-DVM (dual view mount) (use with TVD-PPB)
TVW-AWB-1 (angled back box for outdoor application)
TVW-AWB-2 (angled back box for indoor application)
TVW-2G-AD (Adapter plate for wedge camera with 2-gang
box)

4 Installation Guide
Product and package contents
Check the package and contents for visible damage. If any
components are damaged or missing, do not attempt to use the
unit; contact the supplier immediately. If the unit is returned, it
must be shipped back in its original packaging.
TVW-DVM dual view mount
The TVW-DVM dual view mount (purchased separately) allows
you to install two panoramic cameras on a single mount. You
then obtain a view of the surrounding area without requiring a
complex integration effort when connecting to your storage
device or video management system (VMS).
Camera mount:
Tube adapter (30 x 12 mm): Conduit cover/plug:

Installation Guide 5
Template A:
Template B:
Screw 3 x 10 m (5 pcs m):
Screw (10 pcs):
Drywall anchor 7.5 x
24.5 mm
M4 screw 4 x 25 mm
Screw 3 x 8 mm (2 pcs): Screw 4 x 10 mm (5 pcs):
Rubber ring:

6 Installation Guide
Figure 1: Cameras attached using the dual view mount
TVW-AWB-1 outdoor angled back box
The TVW-AWB-1 outdoor angled back box (purchased
separately) is weather resistant and includes a G1 threaded
conduit access and plug. It conceals the interconnect cables
and eliminates the blind area below the camera when the
camera is installed on a wall.
Camera back box:

Installation Guide 7
Tube adapter (30 x 12 mm):
Conduit cover/plug:
Template A:
Rubber ring:
Screw (5 pcs):
Drywall anchor 7.5 x 24.5 mm
M4 screw 4 x 25mm
Screw 3 x 10 mm (5 pcs):
Screw 3 x 8 mm (2 pcs): Screw 4 x 10 mm (3 pcs):

8 Installation Guide
Figure 2: Camera mounted on an outdoor back box
TVW-AWB-2 indoor angled back box
The TVW-AWB-2 indoor angled back box (purchased
separately) conceals the interconnected cables and eliminates
the blind area below the camera when the camera is installed
on a wall.
Camera back box:

Installation Guide 9
Template B:
Screw 5 pcs:
Drywall anchor (7.5 x
24.5 mm)
M4 screw (4 x 25 mm)
Screw 3 pcs (4 x 10 mm):
Figure 3: Camera mounted on an indoor back box
TVW-2G-AD adapter plate
The TVW-2G-AD adapter plate (purchased separately) allows
you to attach the panoramic wedge camera to a standard 4-inch
2 gang box.

10 Installation Guide
Camera adapter plate:
Template A:
Rubber ring:

Installation Guide 11
Screw 5 pcs:
Drywall anchor (7.5 x 24.5 mm)
M4 screw (4 x 25 mm)
Screw 3 x 8 mm (2 pcs):
Screw 4 x 10 mm (3 pcs):
Figure 4: Wedge camera attached to a 2 gang box

12 Installation Guide
Installation
To mount two wedge cameras on a dual view mount:
1. Attach the TVW-DVM dual view mount to an installed
pendant mount tube. An adapter is included in the kit that,
if required, can be used to match-up with the threading
(G1 male or G1 female) of the pendant mount tube.
2. Loosen the screws with the tamper-resistant hex wrench
(supplied) to remove the camera cover.

Installation Guide 13
3. Pull the cables through the bracket tube and to both back
boxes, conect the cables to cameras and place the
connecters and cables into the back boxes.
4. Mount the two cameras on both sides of the TVW-DVM
dual view mount.

14 Installation Guide
5. Re-attach the camera covers to the cameras.
To mount the wedge camera on an outdoor angled
back box:
1. Drill the holes for the mounting hardware in the mounting
surface using the supplied drill template.

Installation Guide 15
2. Detach the TVW-2G-AD adaptor plate from the back box.
3. Mount the TVW-2G-AD adaptor plate to the mounting
surface using the supplied hardware.
4. Mount the outdoor angled back box to the TVW-2G-AD
adaptor plate using the supplied hardware.

16 Installation Guide
5. Loosen the screws with the tamper-resistant hex wrench
(supplied) to remove the camera cover.
6. Connect the cables, conceal the cables and connectors
inside the back box and mount the camera base to the
outdoor angled back box.

Installation Guide 17
7. Re-attach the dome cover to the camera.
To mount the wedge camera on an indoor angled back
box:
1. Drill the holes for the mounting hardware in the mounting
surface using the supplied drill template.

18 Installation Guide
2. Mount the indoor back box to the mounting surface by
using the supplied hardware.
3. Loosen the screws with the tamper-resistant hex wrench
(supplied) to remove the camera cover.

Installation Guide 19
4. Connect the cables, conceal the cables and connectors
inside the back box, and mount the camera base to the
indoor angled back box.
5. Re-attach the dome cover to the camera.

20 Installation Guide
To mount the wedge camera on a 2-gang box:
1. Install the 2-gang box (separately purchased) in the wall
according to the local applicable codes and regulations
2. Attach the TVW-2G-AD adapter to a pre-installed 2-gang
box on wall.
