Quik Bridge International Loop Receiver
Installation Sheet
Introduction
The Quik Bridge International Loop Receiver (see Figure 1)
allows you to use up to 16 learn mode wireless sensors (two
per zone) with any standard hardwire control panel. In
addition, you can use up to 45 keychain touchpads and panic
button transmitters, for a total of 61 wireless transmitters.
Figure 1: Quik Bridge International Loop Receiver
The receiver monitors the alarm, battery, tamper, and
supervisory status of transmitters learned into the receiver’s
eight zones.
The receiver features the following:
•Spatial-diversity receiver enhances reception.
•Eight programmable zone outputs (N/C or N/O).
•Selectable zone supervision (programmable).
•RF (radio signal) jam detection on zone 7 (optional).
•Sensor tamper output summary and receiver
cover/antenna tamper on zone 8 (optional).
•Two yellow trouble LEDs indicate sensor low battery and
supervisory conditions.
•Support for a piezo (used for RF testing only) that
sounds the number of transmissions received from
learned transmitters.
•On-board EPROM stores sensor IDs and programming
information in nonvolatile memory, if power is removed.
•Selectable 1- or 4-hour RF supervisory.
Transmitter compatibility
The receiver is compatible with all current Learn Mode
sensors (433.92 MHz), panic button transmitters, two- and
four-button keychain touchpads, with the exception of smoke
detectors.
Control panel compatibility
The receiver is compatible with control panels designed with
hardwire loops where the loop negative is ground (common-
loop ground).
The receiver is not directly compatible with powered loops
(two-wire smoke detector loops and glassbreak detector
loops). If the loop on the control panel can power a device, it
must not be connected directly to the loop receiver. Instead,
a relay is required when connecting to powered loops.
Compatibility testing
Typically, hardwire loops have the negative (-) side of the
loop common with ground. If this is true, and the loop is
nonpowered, the loop should be compatible with the
receiver.
Although most control panels are compatible with the
receiver open collector outputs, each loop should be tested
for compatibility before connecting receiver outputs to the
control panel loop outputs. If the receiver is not directly
compatible with a control panel loop, you can use a relay to
establish compatibility.
To check if the negative side of the loop is common to control
panel ground, do the following:
1. Turn off or remove control panel power and disconnect
the back-up battery.
2. Use an ohmmeter and measure the resistance between
the negative side of the loop and panel ground. If the
resistance is zero or close to zero, this loop should be
compatible with the loop receiver. If the resistance is not
zero, a relay is required for this loop.
Test the compatibility for all loops that you are going to
connect to the receiver.

2 / 10 P/N 466-1452 • REV E • ISS 16OCT18
Receiver operation
This section covers receiver operation functions including the
DIP switch, tamper switch, advance (ADV) and select (SEL)
switches, outputs, and LEDs.
Figure 2: Receiver components
Program Mode Dip Switch
Program mode dip switch on the receiver board (Figure 2:
Receiver components) controls the mode of operation. When
the DIP switch is up, the receiver is in program mode. When
the DIP switch is down, the receiver is in run mode.
Supervisory Dip Switch
Supervisory dip switch (see Figure 2) controls if the RF
supervisory is 1 or 4 hours. On 1 hour, Off 4 hours
Tamper switch
The tamper switch functions in two ways, depending on
which setting the DIP switch is on (program mode or run
mode).
In program mode
When the receiver is in program mode, if you press the
tamper switch you will cycle through the three programming
areas:
•Learn/delete transmitters.
•Configure zone/trouble outputs N/O or N/C.
•Enable/disable zone supervision, or keychain
momentary or maintained output.
In run mode
If no transmitters are learned into zone 8, the receiver tamper
switch is active. If you trip the tamper switch (by removing
the cover) or remove the antenna you will cause a tamper
alarm on zone 8.
If one or more transmitters are learned into zone 8, the
tamper feature is inactive and does not cause an alarm.
ADV and SEL switches
You can only use these switches when you are in program
mode. The ADV (advance) switch lets you cycle to the zone
you want to program. The SEL (select) switch lets you select
the zone or trouble output for programming.
Outputs
The receiver uses open-collector transistors for the zone and
trouble outputs (see Figure 2). The outputs can be open
(high impedance) or closed (shorted to ground), which can
be configured to be normally closed (N/C) or normally open
(N/O). Each output can be wired to the control panel.
Zone outputs
There are eight zone outputs labeled 1 through 8. When a
learned transmitter is activated, the corresponding zone
output switches to the alarm state and remains in alarm for at
least three seconds, until the transmitter is restored to its
non-alarm state. If the control panel connected to the
receiver is armed, the panel activates an alarm in response
to the zone output transition.
Zone 7 - Receiver jam detect
If no transmitters are learned into zone 7, this output trips
whenever the receiver detects a jam condition. Receiver
jamming occurs when the receiver detects a constant signal
for 30 seconds. The receiver jam detect feature is disabled
automatically if transmitters are learned into zone 7.
Zone 8 - Receiver cover/antenna tamper and sensor
tamper summary
If no transmitters are learned into zone 8, this output trips
whenever the receiver cover or the antenna is removed, or
when the tamper switch of any learned transmitter in any
zone is tripped. When transmitters are learned into zone 8,
the receiver cover/antenna tamper and sensor tamper
summary features are disabled.
Trouble outputs
There are two trouble outputs labeled B (low battery
summary) and S (supervisory failure summary).
B - Low battery
When a learned transmitter sends a low battery signal, this
output switches to, and remain in the alarm state until the
receiver receives a signal from the same transmitter with a
good battery.
Antenna
terminal
block
Antenna
terminal
block
Antenna terminal
block
Select switch
Advance switch
Tamper switch
Program Dip switch
Supervisory Dip
switch
LEDs
Receiver terminal
strip

P/N 466-1452 • REV E • ISS 16OCT18 3 / 10
S - Supervisory
If a learned supervised transmitter fails to report for one or
four hours, this output switches to the alarm state until the
failed or unreporting transmitters have reported to the
receiver.
Test output
There is one test output.
T - Test/piezo
This output momentarily supplies 5 VDC each time a
transmitter sends an alarm signal to the receiver. Connect a
piezo (optional) to this output only when testing RF
transmitter response.
LED indicators
The receiver has the following 11 LEDs (Figure 3: Receiver
LEDs):
•Eight red zone LEDs
•One green power LED
•One yellow low battery LED
•One yellow supervisory LED
Figure 3: Receiver LEDs
In run mode, the LEDs indicate alarm and trouble conditions.
In program mode, the LEDs indicate programming
conditions.
Power LED/self tests
Table 1 below describes the power LED states. The power
LED turns on after power is applied to the receiver and the
self-tests are passed. The LED blinks once each time a
signal is received from a transmitter.
If the receiver fails the self-test, the power LED does not turn
on. Instead, the trouble LEDs flash alternately for a failed
self-test.
Table 1: Power LED states
Power LED
Indication
On steady
Receiver has power and is functioning
normally.
Power LED
Indication
Off (and all other LEDs
off)
Receiver is not properly wired or has a
power failure.
Off (and yellow LEDs
blinking)
Receiver failed power-up test.
Blinks off momentarily
Receiver received an RF signal, whether
learned or not.
Run mode LED indications
In run mode, the LEDs indicate three conditions: alarm, low
battery, and supervisory failure.
Alarm status conditions
When the trouble LEDs are both off, the zone LEDs indicate
alarm information. The zone LEDs turn on for zones that are
open (in alarm). Zone LEDs remain off for zones that are
closed or not used.
Transmitter low battery conditions
The yellow low battery LED indicates when one or more
transmitters have reported a low battery condition. After a
low battery report, the low battery LED will flash or blink once
every three seconds, in sync with at least one zone LED.
Check the corresponding zone transmitters for low battery
conditions.
Transmitter supervisory conditions
The yellow supervisory LED indicates when one or more
transmitters have failed to report to the receiver for one or
four hours. When a supervisory condition exists, the
supervisory LED will flash or blink once every three seconds,
in sync with at least one zone LED. Check the corresponding
zone transmitters for supervisory conditions.
Figure 4: Run mode LED indications shows the alarm, low
battery, and supervisory run mode LED indications.
Figure 4: Run mode LED indications
Supervisory LED
Power LED
Low battery LED
Zone LEDs
Supervisory LED
Power LED
Low battery LED
Zone LEDs
Display if there is an
alarm on a zone 2
transmitter.
Display if there is an
low battery on a zone 5
transmitter.
Display if there is an
supervisory on a zone
7 transmitter.
Alarm
Low battery
Supervisory

4 / 10 P/N 466-1452 • REV E • ISS 16OCT18
Tools and accessories needed
The following tools and accessories are included with the
receiver:
•Mounting screws and anchors
•Spring for tamper switch
•Antenna
The following tools and accessories are needed to install the
receiver, but are not included with the receiver:
•Phillips screwdriver
•Small standard screwdriver
•12 to 22 gauge stranded wire
•Optional piezo for sensor testing
•12 VDC power supply (typically supplied by panel)
•EOL resistors (typically supplied with panel)
Installation
Observe the following guidelines when installing the receiver:
•Leave 10 in. (25 cm) above the receiver for the antenna.
•Avoid areas that may expose the receiver to moisture.
•Avoid areas with excessive metal or electrical wiring,
including furnace and utility rooms. Or, if unavoidable,
mount on metal with the antenna extending above the
metallic surface (see Figure 5).
•Do not install within 3 meters of another receiver.
Caution: Do not install wireless sensors within 31 cm of the
Quik Bridge receiver.
Figure 5: Mounting on metal
To mount the receiver, do the following:
1. To remove the receiver cover, press down on the top
center of the cover (see Figure 6) and pull the cover
away from the base.
Figure 6: Remove the cover
Caution: You must be free of static electricity before
handling circuit boards. Touch a bare metal surface or wear
a grounding strap before handling circuit boards.
2. Press the lower right corner of the base until the lower
right latch releases the circuit board (see Figure 7).
Figure 7: Latches and mounting holes
3. To remove the circuit board, pull it away from the two top
latches and set it aside.
4. Hold the base against the mounting surface and mark
the three mounting holes (Figure 7: Latches and
mounting holes). Leave at least 10 in. (25 cm) above the
base for the antenna.
5. Remove the base and install the anchors provided, if
studs are not present.
6. Mount the base on the wall with the screws provided.
7. To replace the circuit board on the base, slide the top of
the circuit board under the top two latches, then press
the bottom of the circuit board until it snaps under the
lower right latch.
Connecting the antenna to the receiver
To connect the antenna to the receiver, do the following:
Metal
Metal
Top latch
Mounting hole
Mounting hole
Mounting
hole
Top latch
Lower right latch

P/N 466-1452 • REV E • ISS 16OCT18 5 / 10
1. Loosen the inside terminals of the left and right antenna
terminal blocks.
2. Insert an antenna end into each inside terminal.
3. Tighten the terminal screws.
Connecting power to the receiver
To connect power to the receiver, do the following:
1. Turn off or remove power from the panel and disconnect
the battery.
2. Wire receiver terminals (GND) and (+12V) to a non-
switched 12 V supply output on the control panel. Make
sure you observe the correct polarity (see Figure 8).
Figure 8: Connect power to the receiver
3. Turn on or apply power to the panel.
Zone planning
Before programming, write down how you plan to use the
transmitters with each zone.
The following guidelines describe the receiver zone
capabilities. Use these guidelines to complete Table 2 and
record the wireless devices used for each zone.
Keychain touchpads
The receiver can learn up to 45 keychain touchpads. The
following describes the keychain touchpad button functions.
Suggested applications include panic button, momentary or
maintained (toggle on/off) control panel activation for
arming/disarming, or momentary activation for a garage door
opener.
Note: All keychain touchpads learned into the receiver
control the same zone outputs. For example, if keychain
touchpad #1 is learned into zone 1 and keychain touchpad
#2 is learned into zone 2, both keychain touchpads control
both zones.
Zone 1. Lock + unlock
This simultaneous keypress can be learned only into zone 1
and still allows you to learn two additional sensors into zone
1. When learned, this keypress causes a momentary alarm
on zone 1.
Note: Both panic button transmitters and this keypress can
be learned into zone 1 together; however, the total number of
panic buttons and keychain touchpads learned into zone 1
cannot exceed 45. For zones 2 through 6, keychain
touchpads and other sensors cannot be learned into the
same zone.
Zone 2 (lock or unlock)
When learned into zone 2, both of these key presses work
together to provide a maintained (toggle) output response
(only one of these buttons needs to be learned for both to
work).
Typically, this output would be used for a maintained
keyswitch on the control panel for arming/disarming (refer to
your control panel documentation for this application).
Zone 3 (lights)
You can only learn this keypress into zone 3. When learned,
pressing this button switches the zone 3 output. The output
can be configured to switch momentarily (default) or
maintained (toggle on/off for each press). See “Keychain
touchpad zone output responses” en page 7.
Zone 4 (star)
You can only learn this keypress into zone 4. When learned,
pressing this button switches the zone 4 output. The output
can be configured to switch momentarily (default) or
maintained (toggle). See “Keychain touchpad zone output
responses” en page 7.
Zone 5 (lock)
You can only learn this keypress into zone 2 (as detailed
above) or zone 5. When learned into zone 5, pressing this
button switches the zone 5 output. The output can be
configured to switch momentarily (default) or maintained
(toggle). See “Keychain touchpad zone output responses” on
page 7.
Zone 6 (unlock)
You can learn this keypress into zone 2 (as detailed above)
or zone 6. When learned into zone 6, pressing this button
switches the zone 6 output. The output can be configured to
switch momentarily (default) or maintained (toggle). See
“Keychain touchpad zone output responses” on page 7.
Tamper and trouble conditions
Zone 7
Jam detection is set to automatically monitor for radio signals
that can jam the receiver. However, once a transmitter is
learned into zone 7, the RF jam detection is disabled.
Zone 8
Cover/antenna tamper is set to automatically monitor cover
and antenna removal. However, once a transmitter is learned
into zone 8, the cover/antenna tamper is disabled.
Low battery
Receiver terminal B activates whenever the receiver gets a
signal from a transmitter with a low battery. To monitor for
low transmitter battery conditions, connect the receiver B
output to a control panel zone input.
To panel’s 12V supply

6 / 10 P/N 466-1452 • REV E • ISS 16OCT18
RF supervision
Receiver terminal S activates whenever the receiver goes
one or four hours without receiving a signal from a
supervised transmitter. To monitor for RF supervision,
connect the receiver S output to a control panel zone input.
Panic buttons and wireless sensor
Panic buttons
Use zone 1 for up to 45 unsupervised panic button
transmitters. Use zones 2 to 8 for supervised panic button
transmitters (2 per zone).
Wireless sensors
Learn wireless sensors into remaining unused zones (2 per
zone). Make sure that both sensors learned into the same
zone have the same expected response type at the control
panel (delay, instant, interior, 24-hour).
Use Table 2 to record the wireless devices used for each
zone.
Table 2: Transmitter zone assignments
Receiver zone
Panel zone
Transmitter
Function
1
2
3
4
5
6
7 (RF jam detect)
8 (Tamper detect)
B
S
Receiver programming
This section describes the following programming
procedures:
•Learning wireless transmitters
•Deleting wireless transmitters
•Configuring zone/trouble outputs N/O or N/C
•Configuring RF supervision
•Configuring keychain touchpad zone output
Learning wireless transmitters
To learn a transmitter into a zone, do the following:
1. To enter program mode, slide the DIP switch up. The
low battery and supervisory LEDs blink back and forth.
2. Press and release the ADV switch until the desired zone
LED turn on. (If you press and hold the ADV switch, you
will advance to the next zone and cause the zone LED
to flicker.)
3. Press and release the SEL switch once to select this
zone for learning transmitters. The zone LED remains on
and the low battery and supervisory LEDs stop flashing.
4. Trip the transmitters:
•For sensors with tamper switches, remove the
cover.
•For sensors without tamper switches, put the sensor
in alarm. Each time the receiver learns a sensor, the
selected zone LED blinks once.
•For keychain touchpads:
•Zone 1, press the lock and unlock buttons
together.
•Zone 2, press the lock or unlock button.
•Zone 3, press the lights button.
•Zone 4, press the star button.
•Zone 5, press the lock button.
•Zone 6, press the unlock button.
Each time the receiver learns a keychain touchpad
button, all zone LEDs with learned keychain touchpads
blink once.
5. To stop learning transmitters in the selected zone, slide
the DIP switch down.
Repeat the procedure to learn transmitters into another zone.
Deleting wireless transmitters
To delete all transmitters from a zone, do the following:
1. To enter program mode, slide the DIP switch up.
2. Press and release the ADV switch until the desired zone
LED turns on.
3. Press and hold the SEL switch for five seconds to delete
all transmitters from this zone. The zone LED should
turn off.

P/N 466-1452 • REV E • ISS 16OCT18 7 / 10
4. Slide the DIP switch down to put the receiver in run
mode.
To delete a keychain touchpad from the receiver, repeat the
procedure for each button on a keychain touchpad button
that is learned into a zone. A keychain touchpad is deleted
only when all learned buttons are deleted from their
respective zones.
Zone/trouble outputs N/O or N/C
All eight zones and both trouble outputs default to N/C, and
can be changed to N/O.
To program a zone output N/O or N/C, do the following:
1. To enter program mode, slide the DIP switch up.
2. Press the tamper switch once to gain access to
configuring zone outputs. The low battery LED should
turn on or flash.
3. Press and release the ADV switch until the desired zone
LED turns on.
4. Press and release the SEL switch to change the output
configuration to the desired setting. (zone LED on = N/C,
zone LED off = N/O).
5. Repeat the procedure for each zone configuration
change.
6. Slide the DIP switch down to return to run mode.
To program both trouble outputs N/O or N/C, do the
following:
1. To enter program mode, slide the DIP switch up.
2. Press the tamper switch once to gain access to
configuring zone outputs.
3. Press and release the ADV switch until all zone LEDs
are off (nine presses) to select the trouble outputs.
4. Press and release the SEL switch to change the trouble
outputs configuration to the desired setting (low battery
LED on = N/C, low battery LED flashing = N/O).
5. Slide the DIP switch down to return to run mode.
RF supervision
All eight zones default to RF supervised, and can be
changed to be unsupervised.
To enable or disable RF supervision on a zone, do the
following:
1. To enter program mode, slide the DIP switch up.
2. Press the tamper switch twice to gain access to
configuring zone supervision.
3. Press and release the ADV switch until the desired zone
LED turns on.
4. Press and release the SEL switch to change the RF
supervision configuration to the desired setting.
5. Repeat the procedure for each zone configuration
change.
6. Slide the DIP switch down to return to run mode.
Note: Keychain touchpads are not supervised. Panic button
transmitters learned into zone 1 are not supervised.
Keychain touchpad zone output
responses
Zone outputs 3 through 6 can be set up to respond by
switching momentarily or to maintain (toggle on/off for each
activation).
To change the zone output response to momentarily or
maintain, do the following:
1. To enter program mode, slide the DIP switch up.
2. Press the tamper switch twice to gain access to
configuring zone outputs.
3. Press and release the ADV switch until the desired zone
LED (3 to 6) turns on.
4. Press and release the SEL switch to change the zone
output response to the desired setting. The LED for the
selected zone should turn off (maintained) or on
(momentarily), indicating the current configuration.
5. Advance to another programmable option or slide the
DIP switch down to return to run mode.
Connecting the receiver to a
control panel
There are four ways to wire the loop receiver to the control
panel.
Figure 9: Supervised N/O loop wiring diagram shows a
wiring diagram for a supervised N/O loop.
Figure 9: Supervised N/O loop wiring diagram
Note: You can connect multiple normally open (N/O) loop
receiver zone outputs in parallel to panel zone inputs.
Figure 10: N/C loop wiring diagram shows a wiring diagram
for an N/C loop.
Panel terminals
Zone 1
Return
Panel GND
Panel +12V
EOL resistor
Receiver terminals
Panel terminals

8 / 10 P/N 466-1452 • REV E • ISS 16OCT18
Figure 10: N/C loop wiring diagram
Figure 11: Nonsupervised loop wiring diagram shows a
wiring diagram for a nonsupervised loop.
Figure 11: Nonsupervised loop wiring diagram
Figure 12: Relay wiring diagram shows a wiring diagram
when using a relay.
Note: The 12 VDC relay coil resistance must be at least
300 ohms.
Figure 12: Relay wiring diagram
RF reception test
You can test the receiver by either counting the LED flashes
when transmitters are tripped, or by counting the beeps
emitted by an attached piezo beeper (optional).
To test the system using the receiver LED, do the following:
1. Make sure the DIP switch is down (normal operation/run
mode).
2. Trip all sensors in the system. After each trip, watch for
the correct number of LED flashes as indicated in
Table 3.
Table 3: LED/piezo test responses
Transmitter
Should cause
Sensors
7 to 8 beeps and LED flashes
Keypad
touchpads
1-button press
2 beeps and LED flashes
2-button press
8 beeps and LED flashes
To test the system using a piezo beeper, do the following:
1. Connect a piezo beeper between the test output (T) and
ground (GND) as shown in Figure 13: Piezo status
beeper connections.
Figure 13: Piezo status beeper connections
2. Make sure the DIP switch is down (normal operation/run
mode).
3. Trip all sensors in the system. After each trip, listen for
the correct number of beeps from the piezo beeper as
indicated in Table 3.
Securing the cover
To help prevent accidental tamper alarms caused by cover
removal, install the two self-tapping screws (included) on top
of the cover (Figure 14: Cover screws).
Receiver terminals
Zone 1
Return
Panel GND
Panel +12V
Receiver terminals
Panel terminals
Zone 1
Return
Panel GND
Panel +12V
EOL resistor
Receiver terminals
Panel terminals
Zone 1
Return
Panel GND
Panel +12V
N/OCOM N/C
Coil
Coil
Receiver terminals
Panel terminals

P/N 466-1452 • REV E • ISS 16OCT18 9 / 10
Figure 14: Cover screws
Specifications
Compatibility
Control panels with hardware
loops
Power requirements
10 to 14 VDC
Current draw
65 mA maximum
Frequency band
433.050 MHz - 434.790 MHz
Open collector outputs (1-8, B, S)
Maximum applied voltage
16 VDC
Maximum sink current
50 mA (typical) 15 mA
(minimum)
Temperature range
14 to 104°F (−10 to +40°C)
Dimensions (L x W x H)
4.125 x 5.25 x 1.0 in. (103 x
131 x 25 mm) excluding
antenna
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092,
USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product
identification:
Product: 433 MHz Quick Bridge Receiver
Model number: 60-660-43, 60-660-43-EUR,
RXI4N8
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR
SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED
DEALER” OR “AUTHORIZED RESELLER”, IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers
and product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
Certification
TUV 0123
Test report reference: CEQP-60-660-43
Applied standards: EN50130-4(1995)
+A2(2003)
Safety:
Test report reference: CEQP-60-660-43
Applied standards: EN 60950-1:2001
Radio:
TUV 0123
Test report reference: CEQP 60-660-43
Applied standards: EN300220-3 v1.1.1 (09-
2000)
Equipment class
identifier:
None (class 1 product)
European Union
directives
UTC Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of all applicable
rules and regulations, including but not limited
to the Directive 2014/53/EU. For more
information see: www.utcfssecurityproducts.eu
2012/19/EU (WEEE directive): Products
marked with this symbol cannot be disposed of
as unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more
information see:
www.utcfssecurityproducts.eu/recycle/
Contact information
www.utcfireandsecurity.com or www.interlogix.com
Customer support
For customer support in US, see
www.interlogix.com/customer-support.
For customer support in EU, see
www.utcfssecurityproducts.eu
Cover screw hole
Cover screw hole

10 / 10 P/N 466-1452 • REV E • ISS 16OCT18
