International comfort products FSA2X Installation instructions

664 04 5001 00 Dec 2007
TECHNICAL SUPPORT MANUAL
Fan Coils
FSA2X & FSA4X
DANGER, WARNING, CAUTION, and
NOTE
The signal words DANGER, WARNING, CAU-
TION, and NOTE are used to identify levels of haz-
ard seriousness. The signal word DANGER is only
used on product labels to signify an immediate haz-
ard. The signal words WARNING, CAUTION, and
NOTE will be used on product labels and through-
out this manual and other manuals that may apply
to the product.
DANGER -- Immediate hazards which will result in
severe personal injury or death.
WARNING -- Hazards or unsafe practices which
could result in severe personal injury or death.
CAUTION -- Hazards or unsafe practices which
may result in minor personal injury or product or
property damage.
NOTE -- Used to highlight suggestions which will
result in enhanced installation, reliability, or opera-
tion.
Signal Words in Manuals
The signal word WARNING is used throughout this
manual in the following manner:
The signal word CAUTION is used throughout this
manual in the following manner:
Signal Words on Product Labeling
Signal words are used in combination with colors
and/or pictures on product labels.
WARNING
Safety Labeling and Signal Words
!
!CAUTION
WARNING
TABLE OF CONTENTS
Wiring Diagram 2................................
Exploded Drawing 3..............................
Parts List 4 -- 7...................................
Airflow Charts 8..................................
Model Number Identification 8.....................
!WARNING
ELECTRICAL SHOCK HAZARD
Failure to turn off electric power could result in
personal injury or death.
Before installing or servicing system, turn off
main power to the system. There may be more than
one disconnect switch, including accessory heat-
er(s).

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X
2664 04 5001 00

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X & FSA4X
664 04 5001 00 3

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X & FSA4X
4664 04 5001 00
FSA2X PARTS LIST
KEY
NO. DESCRIPTION PART NO.
FSA2X1800A1 FSA2X1805A1 FSA2X1807A1
FSA2X1811A1
FSA2X2400A1 FSA2X2405A1 FSA2X2407A1
FSA2X2411A1
FSA2X3000A1 FSA2X3005A1 FSA2X3007A1
FSA2X3011A1
FSA2X3600A1 FSA2X3605A1 FSA2X3607A1
FSA2X3611A1
1Blower Assembly DD10--6 1170634 11111111-- -- -- -- -- -- -- --
1DD10--7 1173881 -- -- -- -- -- -- -- -- 1111-- -- -- --
11173895 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
2Motor, Blower 1/5 HP 1170645 11111111-- -- -- -- -- -- -- --
21/3 HP 1173839 -- -- -- -- -- -- -- -- 1111-- -- -- --
21173840 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
3Capacitor 5 mfd 370 Volts 1171727 11111111-- -- -- -- -- -- -- --
310 mfd 370 Volts 1171729 -- -- -- -- -- -- -- -- 1111-- -- -- --
315 mfd 370 Volts 1171730 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
4Wheel, Blower DD10--6 1170652 111111111111-- -- -- --
4DD10--7 1173847 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
5Coil & Header Assembly 1173887 1111-- -- -- -- -- -- -- -- -- -- -- --
51173888 -- -- -- -- 11111111-- -- -- --
51173899 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
6Distributor Assembly 1172624 1111-- -- -- -- -- -- -- -- -- -- -- --
61171603 -- -- -- -- 11111111-- -- -- --
61171604 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
7Valve, Expansion 1173846 1111111111111111
9Pan, Condensate Assy 1170656 1111111111111111
10 Pan, Condensate 1170657 1111111111111111
11 Element 3.75 KW 1173901 -- -- 2-- -- -- 2-- -- -- 2-- -- -- 2--
11 5.0 KW 1173900 -- 1-- -- -- 1-- -- -- 1-- -- -- 1-- --
11 5.5 KW 1173902 -- -- -- 2-- -- -- 2-- -- -- 2-- -- -- 2
12 Board, Circuit w/ TDR 1171000 -- 111-- 111-- 111-- 1 1 1
13 Board, Rectifier 1171780 -- 111-- 111-- 111-- 1 1 1
14 Switch, Limit 1170673 -- 111-- 111-- 111-- 1 1 1
15 Relay 1170674 -- 111-- 111-- 111-- 1 1 1
16 Disconnect 1173837 -- 111-- 111-- 111-- 1 1 1
17 Transformer 1173844 -- 111-- 111-- 111-- 1 1 1
18 Lug, Ground 1170677 -- 111-- 111-- 111-- 1 1 1
APanel, Top 1173889 111111111111-- -- -- --
A1173892 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
B Bracket, Filter 1170628 111111111111-- -- -- --
B1173894 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
CSupport, Coil 1170629 222222222222-- -- -- --
C1173893 -- -- -- -- -- -- -- -- -- -- -- -- 2 2 2 2
DBase, Fan Coil 1170630 111111111111-- -- -- --
D1173882 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
-- continued on next page --

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X & FSA4X
664 04 5001 00 5
FSA2X PARTS LIST (continued)
KEY
NO.
FSA2X3611A1
FSA2X3607A1 FSA2X3605A1 FSA2X3600A1
FSA2X3011A1
FSA2X3007A1 FSA2X3005A1 FSA2X3000A1
FSA2X2411A1
FSA2X2407A1 FSA2X2405A1 FSA2X2400A1
FSA2X1811A1
FSA2X1807A1 FSA2X1805A1 FSA2X1800A1
PART NO.DESCRIPTION
EPlate, Patch 1173883 1111111111111111
FPanel, Blower Door 1173890 111111111111-- -- -- --
F1173891 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
GFilter 16.5” X 19.625” 1173885 111111111111-- -- -- --
G19.625” X 19.625” 1173886 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
HScrew, Motor Mount 1170636 3333333333333333
JPanel, Blower Cutoff 1170637 111111111111-- -- -- --
J1173897 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
KHousing Assy, Blower 1170638 111111111111-- -- -- --
K1173896 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
LWrapper, Blower 1170639 111111111111-- -- -- --
L1173898 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
MPlate, Blower Side 1170640 1111111111111111
NPlate, Blower Side Motor Side 1170641 1111111111111111
PRing, Inlet 1170642 1111111111111111
QStrap, Capacitor 1170643 1111111111111111
RArm & Grommet Assy 1173747 3333333333333333
SBand, Motor Mount 1171733 1111111111111111
TGrommet, Motor Mount 1171738 3333333333333333
UShield, Condensate Pan 1170658 1111111111111111
VPanel, Control 1170679 -- 111-- 111-- 1 1 1 -- 1 1 1
WBracket Disconnect Mtg 1170661 -- 111-- 111-- 1 1 1 -- 1 1 1
XPanel Protective 1170662 -- 111-- 111-- 1 1 1 -- 1 1 1
YBarrier 1170663 -- 111-- 111-- 1 1 1 -- 1 1 1
PARTS NOT SHOWN
)( Strainer 1171740 1111111111111111
)( Harness Assy, Cooling Control 1171698 1111111111111111
)( Manual, Installation 66401500100 1111111111111111
)( Warranty 40106403001 1111111111111111

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X & FSA4X
6664 04 5001 00
FSA4X PARTS LIST
KEY
NO. DESCRIPTION PART NO.
FSA4X1800A1
FSA4X1805A1
FSA4X1807A1 FSA4X1811A1 FSA4X2400A1 FSA4X2405A1 FSA4X2407A1 FSA4X2411A1 FSA4X3000A1 FSA4X3005A1 FSA4X3007A1 FSA4X3011A1 FSA4X3600A1 FSA4X3605A1 FSA4X3607A1 FSA4X3611A1
01 Blower Assembly DD10--6 1170634 11111111-- -- -- -- -- -- -- --
01 DD10--7 1173881 -- -- -- -- -- -- -- -- 1111-- -- -- --
01 1173895 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
02 Motor, Blower 1/5 HP 1170645 11111111-- -- -- -- -- -- -- --
02 1/3 HP 1173839 -- -- -- -- -- -- -- -- 1111-- -- -- --
02 1173840 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
03 Capacitor 5 mfd 370 Volts 1171727 11111111-- -- -- -- -- -- -- --
03 10 mfd 370 Volts 1171729 -- -- -- -- -- -- -- -- 1111-- -- -- --
03 15 mfd 370 Volts 1171730 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
04 Wheel, Blower DD10--6 1170652 -- -- -- -- 11111111-- -- -- --
04 DD10--7 1173847 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
05 Coil & Header Assembly 1173851 1111-- -- -- -- -- -- -- -- -- -- -- --
05 1173850 -- -- -- -- 11111111-- -- -- --
05 1173852 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
06 Distributor Assembly 1172624 1111-- -- -- -- -- -- -- -- -- -- -- --
06 1171603 -- -- -- -- 11111111-- -- -- --
06 1171604 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
07 Valve, Expansion 1176347 111111111111-- -- -- --
07 1176348 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
09 Pan, Condensate Assy 1170656 1111111111111111
10 Pan, Condensate 1170657 1111111111111111
11 Element 3.75 KW 1173901 -- -- 2-- -- -- 2-- -- -- 2-- -- -- 2--
11 5.0 KW 1173900 -- 1-- -- -- 1-- -- -- 1-- -- -- 1-- --
11 5.5 KW 1173902 -- -- -- 2-- -- -- 2-- -- -- 2-- -- -- 2
12 Board, Circuit w/ TDR 1171000 -- 111-- 111-- 111-- 1 1 1
13 Board, Rectifier 1171780 -- 111-- 111-- 111-- 1 1 1
14 Switch, Limit 1170673 -- 111-- 111-- 111-- 1 1 1
15 Relay 1170674 -- 111-- 111-- 111-- 1 1 1
16 Disconnect 1173837 -- 111-- 111-- 111-- 1 1 1
17 Transformer 1173844 -- 111-- 111-- 111-- 1 1 1
18 Lug, Ground 1170677 -- 111-- 111-- 111-- 1 1 1
APanel, Top 1173889 111111111111-- -- -- --
A1173892 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
B Bracket, Filter 1170628 111111111111-- -- -- --
B1173894 -- -- -- -- -- -- -- -- -- -- -- -- 1 1 1 1
CSupport, Coil 1170629 222222222222-- -- -- --
C1173893 -- -- -- -- -- -- -- -- -- -- -- -- 2 2 2 2
-- continued on next page --

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X & FSA4X
664 04 5001 00 7
FSA4X PARTS LIST
KEY
NO.
FSA4X3611A1 FSA4X3607A1 FSA4X3605A1 FSA4X3600A1 FSA4X3011A1 FSA4X3007A1 FSA4X3005A1 FSA4X3000A1 FSA4X2411A1 FSA4X2407A1 FSA4X2405A1 FSA4X2400A1 FSA4X1811A1 FSA4X1807A1
FSA4X1805A1
FSA4X1800A1
PART NO.DESCRIPTION
DBase, Fan Coil 1170630 111111111111-- -- -- --
D1173882 -- -- -- -- -- -- -- -- -- -- -- -- 1111
EPlate, Patch 1173883 1111111111111111
FPanel, Blower Door 1173890 111111111111-- -- -- --
F1173891 -- -- -- -- -- -- -- -- -- -- -- -- 1111
GFilter 16.5” X 19.625” 1173885 111111111111-- -- -- --
G19.625” X 19.625” 1173886 -- -- -- -- -- -- -- -- -- -- -- -- 1111
HScrew, Motor Mount 1170636 3333333333333333
JPanel, Blower Cutoff 1170637 111111111111-- -- -- --
J1173897 -- -- -- -- -- -- -- -- -- -- -- -- 1111
KHousing Assy, Blower 1170638 111111111111-- -- -- --
K1173896 -- -- -- -- -- -- -- -- -- -- -- -- 1111
LWrapper, Blower 1170639 111111111111-- -- -- --
L1173898 -- -- -- -- -- -- -- -- -- -- -- -- 1111
MPlate, Blower Side 1170640 1111111111111111
NPlate, Blower Side Motor Side 1170641 1111111111111111
PRing, Inlet 1170642 1111111111111111
QStrap, Capacitor 1170643 1111111111111111
RArm & Grommet Assy 1173747 3333333333333333
SBand, Motor Mount 1171733 1111111111111111
TGrommet, Motor Mount 1171738 3333333333333333
UShield, Condensate Pan 1170658 1111111111111111
VPanel, Control 1170679 -- 111-- 111-- 1 1 1 -- 111
WBracket Disconnect Mtg 1170661 -- 111-- 111-- 1 1 1 -- 111
XPanel Protective 1170662 -- 111-- 111-- 1 1 1 -- 111
YBarrier 1170663 -- 111-- 111-- 1 1 1 -- 111
PARTS NOT SHOWN
)( Extension coil asy 1175061 1111-- -- -- -- -- -- -- -- -- -- -- --
)( 1175062 -- -- -- -- 111111111111
)( Extension Support 1175064 1111-- -- -- -- -- -- -- -- -- -- -- --
)( 1175063 -- -- -- -- 11111111-- -- -- --
)( 1175065 -- -- -- -- -- -- -- -- -- -- -- -- 1111
)( Paint 1171357 1111111111111111
)( Strainer 1171740 1111111111111111
)( Harness Assy, Cooling Control 1171698 1111111111111111

TECHNICAL SUPPORT MANUAL Fan Coils: FSA2X & FSA4X
8664 04 5001 00
AIRFLOW PERFORMANCE -- CFM at a given Speed and Static reading
Model Size Blower
Speed
Measured Static Pressure, inlet to outlet (inches water column)
0.10 0.20 0.30 0.40 0.50 0.60
FSA*X18 High 995 955 910 862 811 --
Low 738 711 678 641 600 --
FSA*X24 High 950 908 861 810 754 693
Low 732 699 662 621 576 527
FSA*X30 High 1128 1082 1030 973 911 845
Low 1053 1011 964 911 854 791
FSA*X36 High 1408 1355 1295 1227 1152 1068
Low 1191 1157 1113 1061 1000 931
* Denotes 2 (R--22), 4 (R--410A)
NOTES:
1. Airflow based on dry coil at 230V with factory approved filter and 2 element electric heater.
2. Not recommended for use above 0.60 inches water column external static pressure.
3. Shaded cells indicate airflow is greater than 450 CFM per ton.
STATIC PRESSURE CORRECTION FROM DRY TO WET COIL (inches of water column)
AIRFLOW PERFORMANCE chart was developed using fan coils with DRY coils.
When taking a static reading across a WET coil, adjust the static pressure numbers in the AIRFLOW
PERFORMANCE chart by adding the values in this table.
Model Size CFM
500 600 700 800 900 1000 1100 1200 1300
FSA*X18 .034 .049 .063 -- -- -- -- -- --
FSA*X24 .021 .033 .045 .056 .068 -- -- -- --
FSA*X30 -- -- -- .056 .068 .079 .090 -- --
FSA*X36 -- -- -- -- -- .055 .064 .073 .081
* Denotes 2 (R--22), 4 (R--410A)
STATIC PRESSURE CORRECTION FOR ELECTRIC HEATERS (inches of water column)
AIRFLOW PERFORMANCE chart was developed using fan coils with 2--element electric heaters (7.5 kW or 11 kW).
When using a 1--element electric heater (5 kW), or no electric heater, adjust the static pressure numbers in the
AIRFLOW PERFORMANCE chart by subtracting the values in this table.
Electric
Heater
CFM
500 600 700 800 900 1000 1100 1200 1300
none .012 .018 .028 .050 .075 .100 .130 -- --
5kW .002 .003 .003 .015 .020 .030 .050 -- --
FAN COIL MODEL NUMBER IDENTIFICATION GUIDE
F S A 2 X 18** A 1
F=FanCoil
S = Standard PSC MOTOR TYPE
A = Apartment INSTALLATION TYPE
2=R--22
4 = R--410 REFRIGERANT
X=TXV METERING DEVICE
18** = 18,000 BTUH = 1½tons ** = 00 = no electric heat
24** = 24,000 BTUH = 2 tons ** = 05, 07, or 11 kW electric heat (factory installed)
30** = 30,000 BTUH = 2½tons
36** = 36,000 BTUH = 3 tons NOMINAL CAPACITY
Sales Code
Engineering Revision
International Comfort Products, LLC
Lewisburg, Tennessee 37091
