IronX DXG-5G9V HD User manual

DXG-5G9V HD
User’s Manual
IronX HD Camcorder

i
Table of Contents
About this manual........................................................ iv
Copyright ..................................................................... iv
Precautions ................................................................... v
Operating conditions.............................................vi
Notes on Waterproof Case............................................ vii
Before You Start............................................................. x
1 Introducing the Camcorder ......................1
1.1 System Requirements........................................... 1
1.2 Features .............................................................. 1
1.3 Unpacking the Camcorder................................... 2
1.4 About the Camcorder........................................... 6
1.4.1 Camcorder Views.................................... 6
1.4.2 Button Functions ..................................... 7
1.4.3 LED Indicators......................................... 8
2 Getting Started ..........................................9
2.1 Installing the Micro SD Card............................... 9
2.1.1 Removing the Micro SD card................ 10
2.2 Installing the Battery......................................... 10
2.2.1 Removing the battery............................ 11
2.3 Charging the Battery ......................................... 12
2.4 Turning ON/ OFF the Camcorder ..................... 13
2.5 OLED Screen.................................................... 14
2.6 Changing Modes ............................................... 17
2.7 Connecting to TV (HDMI Cable)....................... 18

ii
2.8 Connecting to PC (Micro USB Cable) ............... 18
3 Capturing Videos and Photos..................19
3.1 Recording Videos............................................... 19
3.2 Taking Photos.................................................... 19
3.2.1 WiFi........................................................ 20
3.2.2 Burst Shooting....................................... 20
3.2.3 Time Lapse Shooting............................. 21
3.2.4 Self-Timer............................................... 21
4 Adjusting the Settings .............................22
4.1 Video Resolution ............................................... 24
4.2 Field of View (FOV) .......................................... 25
4.3 Shooting Interval............................................... 26
4.4 Up/Down........................................................... 27
4.5 Delete................................................................ 28
4.6 OSD Up/Down................................................... 31
4.7 LED .................................................................. 32
4.8 Brightness ......................................................... 33
4.9 Beep .................................................................. 34
4.10 Auto-Off............................................................ 35
4.11 Date and Time ................................................... 36
4.12 RF..................................................................... 38
4.13 Factory Default ................................................. 39
5 Using the Accessories...............................41
5.1 Waterproof Case................................................ 41

iii
5.1.1 Using the Waterproof Case................... 41
5.1.2 Changing the T Tip Adapter................. 42
5.1.3 Changing the Housing Back Door........ 43
5.2 Velcro Strap....................................................... 43
5.3 Assembling the Camcorder Accessories ............. 44
5.4 RF Wrist Strap Remote Control.......................... 45
Appendix..........................................................47
Specifications .............................................................. 47
Troubleshooting .......................................................... 49
FCC Statement ............................................................ 50

iv
Preface
Congratulations on your purchase of this advanced camcorder.
Ensure that you read this manual carefully and keep it in a safe
place for future reference.
About this manual
Every effort has been made to ensure that the contents of this
manual are correct and up to date. However, no guarantee is made
regarding the accuracy of the contents. The manufacturer reserves
the right to change the contents, technology, and specifications
without notice.
Copyright
© Copyright 2013.
All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system or translated
into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, manual or
otherwise, without the prior written permission of the
manufacturer.
