ISA ZERO TOUCH T5 User manual

EN
USE AND MAINTENANCE MANUAL 428000729137
1
ZERO TOUCH
ISA S.r.l.
Via del Lavoro, 5
06083 Bastia Umbra - Perugia - Italy
Tel. [phone] - Fax [phone]
www.isaitaly.com
T5 T8 T8 OR T12 T16
ZERO TOUCH

2
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
1. NOTES / IMPORTANT NOTES 4
2. MANUFACTURER 10
3. WARRANTY TERMS AND CONDITIONS 10
4. EQUIPMENT IDENTIFICATION 11
5. USE 12
5.1 COMPOSITION 12
5.2 LOAD / UNLOADING OF PRODUCTS 13
5.3 LOAD OF PRODUCTS 13
5.4 USING THE SPIKE TEMPERATURE PROBE 15
5.5 USE OF THE LAMP UV (OPTIONAL) 16
6. SAFETY 17
6.1 SAFETY DEVICES PRESENT 17
6.2 FIXED PROTECTIONS 17
6.3 ISOLATING THE ELECTRIC POWER SUPPLY 17
6.4 RESIDUAL RISKS 17
6.5 RISKS OF CONTACT WITH LIVE PARTS 17
6.6 FIRE 18
6.7 EXPLOSIVE ATMOSPHERE 18
6.8 SLIPPING 18
6.9 TRIPPING 18
6.10 CIRCUIT FAULTS 18
6.11 WARNING SIGNS (IF ANY) 18
6.12 FALLING OBJECTS 18
6.13 COOLING 19
6.14 FOODSTUFFS SAFETY (PACKAGED PRODUCTS) 19
7. DISPOSAL OF WASTE MATERIAL 20
8. INSTALLATION 21
8.1 STORAGE AND UNPACKING 21
8.2 INSTALLATION - POSITIONING - ENVIRONMENTAL CONDITIONS 21
8.3 ELECTRIC CONNECTION 21
9. MAINTENANCE 22
10. FAULTS - TECHNICAL AFTER-SALES ASSISTANCE 23
10.1 ALARMS LIST (WHERE PRESENT) 24
11. TECHNICAL SPECIFICATIONS 25
11.1 CONTAINERS ARRANGEMENT 26
11.2 KIT SUPPORTS ICE CREAM 27
11.3 INSTALLATION 30
11.4 LOAD LIMITS 30
11.5 POSITIONING / LEVELLING 31
12. CONTROL PANEL 32
13. CLEANING 33
14. PROLONGED APPLIANCE SWITCH-OFF 36

EN
USE AND MAINTENANCE MANUAL 428000729137
3
ZERO TOUCH
The manual contains symbols to attract the reader’s attention and highlight particularly
important aspects. The table below illustrates the meaning of the various symbols used.
Read the instructions manual
Danger: Live electrical parts
Use of protective clothing
Requests for maintenance or operations must
be carried out by qualified staff or technical
after-sales centres.
Attention / Danger
Information
Important information
Operations that must be performed by two
persons.
Visual observation
Condensing unit on board
Notes / Important notes
Remote condensing unit
ATTACHMENT
1 WIRING DIAGRAM - 412100768000 37
2 WIRING DIAGRAM - 412100770100 38

4
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
The content of this manual is of technical nature and is owned by
ISA.It is forbidden to reproduce, circulate or modify all or part of
its content without written consent. Any infringement will be legally
pursued.
The manual and the conformity certificate are an integral part of the
equipment and should always accompany the product in the event of a
transfer to a new location or to a new owner. The user is responsible for
the integrity of these documents, for their consultation and during the
whole life cycle of the equipment itself. Keep this manual in a safe place.
It should be available for consultation near the equipment at all times.
If lost or destroyed, you can request a copy of the manual from ISA
by specifying the exact model, serial number and year of manufacture.
The manual reflects the manufacturing technology at the time of supply.
The manufacturer reserves the right to modify its products in any way it
deems necessary, with no obligation to update manuals and machines
relating to previous manufacturing batches.
This equipment is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or by persons
lacking the necessary experience and knowledge, unless they are
supervised by a person responsible for their safety who has instructed
them on how to use the equipment. Children should be supervised to
ensure that they do not play with the equipment. Always refer to this
manual before going ahead with any operation. Before doing any type
of work, disconnect the equipment from the power supply. Any work on
electric and electronic parts or cooling system components should only
be carried out by trained personnel in compliance with current laws.
Always refer to this manual before taking any action. Before attempting
any intervention disconnect the equipment from the power supply. Work
on parts, electronic components or the refrigeration system must be
carried out by qualified personnel, in full compliance with the regulations.
The Manufacturer cannot be held liable for any injury to persons or
animals, or damage to the product itself in the event of:
• Improper use of the equipment or use of the appliance by
unqualified or unauthorised personnel.
• Failure to comply with current legislation.
• Incorrect installation and/or power supply faults.
• Failure to observe the instructions contained in this manual.
• Failure to follow the maintenance programme.
• Unauthorised modifications.
• Installation of non-original spare parts in the equipment.
1. NOTES / IMPORTANT NOTES

EN
USE AND MAINTENANCE MANUAL 428000729137
5
ZERO TOUCH
• Installation and use of the equipment for purposes other than those
for which the appliance was designed and sold.
• Tampering with or damage to the power supply cable.
Liability for applying the safety instructions contained in this manual is
held by the technical personnel responsible for the intended use of the
equipment, who should ensure that authorised personnel:
• Are qualified to carry out the requested activity.
• Are aware of, and carefully comply with, the instructions contained in
this document.
• Are aware of, and apply, the general safety standards applicable to
the equipment.
The buyer is responsible for training personnel using the appliance on
the risks, safety devices and general health and safety rules required
by the laws of the country where the appliance is installed.
Users/operators should be aware of the position of all the controls and
how they work, as well as of the features of the appliance.
They should also read this manual in its entirely.
Maintenance work should be conducted by qualified personnel after the
appliance has been prepared adequately.
Danger
Unauthorised tampering or replacement of one or more parts of the
appliance, use of accessories that modify the use of the same and
use of spare parts different to those recommended, can become the
cause of injury.
Danger
Any work conducted on the on the appliance must involve
disconnection from the power socket and in any case, none of the
protective elements (grid, casing) should be removed by non-
qualified staff. The appliance should not be operated when these
protective elements have been removed.
Note
In order not to compromise functionality and safety of the appliance,
the particularly complex installation and maintenance activities are
not documented in this manual and are performed by specialised ISA
technicians.
1. NOTES / IMPORTANT NOTES

6
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
Never use electric devices inside this appliance. Do not use mechanical or other
means to accelerate the defrosting process, other than recommended by the
manufacturer. Keep the air vents in the casing of the appliance or in the structure
built into the wall free of obstructions. Do not damage the refrigerant circuit.
RISK OF EXPLOSION
Do not store in the equipment products which contain flammable propellants
and explosives.
R744 - REFRIGERANT (WHERE APPLICABLE)
The refrigerant R744 is a gas that is compatible with the
environment. Pay close attention during transport, installation and
that the destruction not to damage the refrigerant pipelines.
IN THE EVENT OF DAMAGE:
Keep away from the flame or ignition sources. Properly ventilate
the premises for a few minutes. Turn the unit off, pull the plug.
Inform customer support service.
WARNING
The refrigerant system is High Pressure.
Do not tamper with the system, but call a specialised and qualified
technician before disassembly.
ATTENTION
Maintenance must be performed exclusively by qualified staff.
1. NOTES / IMPORTANT NOTES

EN
USE AND MAINTENANCE MANUAL 428000729137
7
ZERO TOUCH
R600a - REFRIGERANT (WHERE APPLICABLE)
The refrigerant R600a is a gas that is compatible with the
environment, but highly flammable.
Pay close attention during transport, installation and that the
destruction not to damage the refrigerant pipelines.
IN THE EVENT OF DAMAGE:
Keep flames or sources of ignition away from the appliance.
Properly ventilate the premises for a few minutes. Turn the unit
off, pull the plug. Inform customer support service. The more
refrigerant containing an appliance, the greater must be the
environment in which there is the unit. In areas too small, in the
event of leakage can form a flammable mixture of air and gas. The
volume of the room where the appliance is installed must
be at least 17 m³ for each cooling system present in the
room.
ATTENTION
Maintenance must be performed by qualified personnel that has
been to work with flammable refrigerants.
R290 - REFRIGERANT (WHERE APPLICABLE)
The refrigerant R290 is a gas that is compatible with the
environment, but highly flammable.
Pay close attention during transport, installation and that the
destruction not to damage the refrigerant pipelines.
IN THE EVENT OF DAMAGE:
Keep flames or sources of ignition away from the appliance.
Properly ventilate the premises for a few minutes. Turn the unit
off, pull the plug. Inform customer support service. The more
refrigerant containing an appliance, the greater must be the
environment in which there is the unit. In areas too small, in the
event of leakage can form a flammable mixture of air and gas. The
volume of the room where the appliance is installed must
be at least 19 m³ for each cooling system present in the
room.
ATTENTION
Maintenance must be performed by qualified personnel that has
been to work with flammable refrigerants.
1. NOTES / IMPORTANT NOTES

8
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
STAFF TRAINING
The buyer is responsible for ensuring personnel who will use the
appliance and maintenance technical staff are instructed and trained
adequately. The manufacturer is available for advice, clarifications, etc.
so that the operator and technical staff can use the appliance correctly.
To ensure the operator’s safety, appliance devices should be kept in
constant working order. This manual is intended to illustrate the use
and maintenance of the appliance. The operator has a responsibility and
duty to carefully observe the instructions contained within it.
Failure to comply with safety standards may result in injury to personnel
and damage to the equipment components and control unit. The user
can contact the dealer to request additional information not contained
in this document, or suggest improvements, at any time.
Before the product is delivered to the customer, it is essential that
a trained technical member of staff checks that the appliance is
operating correctly in order to achieve maximum performance.
INTRODUCTION
ISA employs materials of the best quality and as they enter the
company, we constantly monitor their storage and the use as part of the
manufacturing process to prevent damage, deterioration and failure.
All manufacturing elements are designed and manufactured in order
to guarantee reliability and high safety standards. All appliances are
subjected to a strict testing procedure before delivery. However, please
bear in mind that product performance over time depends on correct
use and adequate maintenance. This manual contains the necessary
instructions to maintain the appliance’s initial appearance and functions
over time.
The Use and Maintenance manual contains the necessary information
for understanding how the appliance works and how to use it properly,
namely: the technical description of the various operational units,
equipment and safety systems, operations, how to use the instruments
and the interpretation of any diagnostics reports, main procedures and
information relating to routine maintenance. For correct use of the
appliance, the working environment should comply with current health
and safety standards.
1. NOTES / IMPORTANT NOTES

EN
USE AND MAINTENANCE MANUAL 428000729137
9
ZERO TOUCH
The safety requirements, indications, standards and notes illustrated
in the various chapters of the manual are aimed at establishing a
code of conduct and a series of obligations to be observed when
performing the various activities, in order to create safe conditions
for personnel, the equipment and the surrounding environment. The
safety standards reported in this document are intended for trained,
authorised personnel responsible for:
• Transport
• Installation
• Operation
• Management
• Maintenance
• Cleaning
• Putting out of order
• Disposal
Attention
Reading this manual, albeit in full, is no substitute for adequate
user experience. therefore it should only be considered a useful
reminder of the technical features and the main operations to
perform.
Note
The installers and users must read and understand
the instructions contained herein before any
operation on the appliance.
1. NOTES / IMPORTANT NOTES

10
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
2. MANUFACTURER
ISA S.r.l.
Via del Lavoro, 5
06083 - Bastia Umbra - Perugia - Italy
Tel. [phone]
Fax [phone]
www.isaitaly.com
3. WARRANTY TERMS AND CONDITIONS
The seller's warranty on the equipment is valid for 12 (TWELVE) months from the date of delivery.
The warranty includes repairs or replacements of any faulty parts due to manufacturing processes or
installation after written communication has been received, stating the appliance serial number and date
of installation.
Not included in the warranty:
• all defects caused by incorrect use of the appliance
• all defects caused by incorrect electrical connection
• all defects caused by normal wear (for instance compressor failure and fluorescent lamp malfunctioning
that is not due to manufacturing defects)
• calls for installation, technical instructions, adjustments and cleaning the condenser
If the seller's technical staff detect any tampering, unauthorised repairs or inappropriate use of appliance
the warranty will be invalidated.
Shipment of components covered by the warranty is freight collect only.
Any damage to the appliance detected at the time of delivery due to transport must be reported on the
same shipping note to claim compensation from the carrier.
The seller cannot be held liable in the event of damage to the preserved product due to appliance failure

EN
USE AND MAINTENANCE MANUAL 428000729137
11
ZERO TOUCH
4. EQUIPMENT IDENTIFICATION
• Find the label affixed on the machine to read the technical data.
• Check the machine model and the power supply voltage before you perform any operation.
• If you uncover mismatches, contact the manufacturer or the company that supplied the machine immediately.
1 Manufacturer’s address
2 Symbols of Compliance
3 Type
4 Model Name
5 Article
6 Production Date
7 Production Order
8 Customer Order
9 Product Class
10 Serial Number
11 Property Number
12 Power supply voltage
13 Frequency
14 Fuse value
15 Lamp power
16 Absorption of Heating Elements
17 Rated power
18 Defrosting power
19 Min pressure
20 Max pressure
21 Safety Class
22 Rated current
23 Defrosting current
24 Shelf load
25 Tank load
26 Refrigerant type (compressor)
27 Refrigerant weight
28 Gross Volume
29 Foaming agent
30 RAEE Mark

12
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
5. USE
This appliance is exclusively intended to:
PRODUCT BLAST CHILLING AND FREEZING
The manufacturer is not liable for injury to persons or damage to property or the appliance itself
caused by the displaying of products other than those described above.
THE APPLIANCE IS INTENDED FOR PROFESSIONAL USE.
Uses not allowed
• Food preservation.
• Displaying and/or preserving non-food products (chemicals, pharmaceuticals, etc...).
5.1 COMPOSITION
The appliance is made up from a unique cabinet, onto which all devices necessary to make it a professional
and efficient product for its declared use, are installed.
The appliance is made up from:
• Cooling system at Ventilated Refrigeration (RV)
• Condensing unit on board (UCA)
• Electrical system
• Electronic control board
• Insulated monolithic structure in ecological polyurethane
• Door openable at 180° with automatic closure
• Automatic defrost
• Adjustable telescopic feet
• Heated probe
• Opening door sensor
• Tray collection of condensed water
OPTIONAL
• Swivel drive wheels with locking brake
• Germicidal light
• Pan kit depth 25 mm
• Gastronorm trays
• Kit probe support for liquids

EN
USE AND MAINTENANCE MANUAL 428000729137
13
ZERO TOUCH
5.2 LOAD / UNLOADING OF PRODUCTS
LOAD
It recommends the use of kitchen gloves to avoid burns during contact with hot trays and trolleys.
UNLOADING
We recommend the use of gloves suitable for trays and cold trucks.
5.3 LOAD OF PRODUCTS
• Avoid overlapping of foods.
• Do not cover the containers with insulating films or lids.
NO YES
NO NO
We recommend the use of trays and containers, the less deep as possible but no greater than 6.5 cm; In
addition to better performance it is recommended to load the containers with a maximum 3.5 kg of the
product and with a maximum thickness of 8 cm rapid reduction or 5 cm for rapid freezing.
Note For compact products with a high fat content, or large pieces, to reduce the thickness further.
• Maintain a sufficient gap between the trays to allow proper circulation of air.
YES NO

14
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
• In the event that the machine is not fully loaded, distribute the tins and trays evenly inside the
machine and avoid overcrowding one area.
YES NO
• Position the trays and tins as far inside the refrigerated chamber as possible, making sure they are as
close to the evaporator as possible.
YES NO

EN
USE AND MAINTENANCE MANUAL 428000729137
15
ZERO TOUCH
5.4 USING THE SPIKE TEMPERATURE PROBE
The spike probe should only be used by authorised personnel trained in blast chilling techniques.
Keep out of the reach of children.
The probe should only be used for the purpose for which it was designed;
reading the temperature at the heart of a food product which requires blast chilling or freezing.
Please handle with care as the device has a sharp tip to facilitate its insertion into products
which require blast chilling or freezing.
The spike probe should be positioned accurately in the centre of larger-sized product portions,
ensuring that it does not exit or touch the tray.
To avoid contamination, the probe should be cleaned and sanitized after each work cycle.
CORRECT USE OF SPIKE PROBE HEATING FUNCTION
Attention
This probe heating function should only be used when the probe is inserted in products due to
be frozen.
To avoid the risk of burns, do not touch the probe when the heating function has been activated
or when has been removed from the product.

16
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
5.5 USE OF THE LAMP UV (OPTIONAL)
The UV lamp sterilizing function (optional) must only be used for the purpose for which it was
designed: sterilize internal unit surfaces.
Attention
Avoid exposure and / or observation of UV lamps.
PRE-COOLING
Prior to carrying out either fast blast chilling or freezing operations, it is necessary to pre-cool
the system in order to further reduce operating times.
Therefore, carry out a Soft/Hard unloaded cycle before inserting products for blast chilling.
Warning
To avoid damaging the machine, do not leave hot products inside the chamber for periods of time.
Start the blast chilling or freezing cycle as soon as the product has been introduced into
the machine.
TEMPERATURE
Avoid leaving cooked products due to be blast chilled or frozen for long periods at room
temperatures. The more water content lost, the less succulent the product will be following treatment.
It is recommended to begin the fast blast chilling or freezing cycle as soon as the product preparation
/cooking has ended. The food can be inserted in the blast chilling chamber even at relatively high
temperatures (>100 °C) as long as the unit has been pre-cooled. It should be remembered that blast
chilling cycle times range from +90 °C (from +90 °C to +3 °C for the fast blast chilling cycle: from +90
°C to -18 °C for the fast freezing cycle).
PRESERVATION
Blast chilled or frozen foods should be appropriately covered and protected
(with cling-film, sealed lid or, better still, vacuum sealed). They should be identified by an
adhesive label, detailing in indelible ink contents, preparation date and expiry date.
Blast chilled foods must be kept in a refrigerated environment at a constant temperature
of +2 °C.
Frozen foods must be kept in a refrigerated environment at a constant temperature of -20°C.
Attention
Do not use the blast chiller as a standard refrigerator.

EN
USE AND MAINTENANCE MANUAL 428000729137
17
ZERO TOUCH
6. SAFETY
The equipment is fitted with safety devices. Purchaser must instruct the user to staff about the risks, the
safety devices and the general rules regarding safety provided for by the legislation of the country where the
equipment is installed. Users / operators must be aware of the position and operation of all controls and of
the equipment characteristics; they shall also have fully read this manual.
6.1 SAFETY DEVICES PRESENT
Devices whose operation prevents the occurrence of risk situations in operating conditions (e.g. fuses,
pressure switches, protections, magnet circuit breakers, etc.).
6.2 FIXED PROTECTIONS
Fixed protective devices consist of fixed perimeter shields, which are used to prevent external parts
from entering the equipment.
Danger
It is prohibited to re-start the appliance following maintenance without having correctly restores the
panels.
Visual Check
You should check the integrity of fixed panels and corresponding fixings to the frame, focussing in
particular on the protective panels.
6.3 ISOLATING THE ELECTRIC POWER SUPPLY
Before conducting any maintenance work on the equipment or part of it, it is necessary to section the
power supply that powers it.
Danger
In the event of maintenance operations in which the operator cannot prevent accidental closure of
the circuit by others, to totally disconnect the appliance from the mains electricity.
6.4 RESIDUAL RISKS
During design the manufacturer examined all the areas or parts at risk. Therefore, all necessary
precautions have been taken to prevent risks to persons and damage to the appliance.
Attention
Periodically check that all safety devices are operating correctly.
Do not remove the fixed guards.
Do not introduce objects or tools into the work area.
Although the appliance is fitted with the safety devices prepared, there are still some risks that
cannot be eliminated, but reduced via corrective actions by the final integrator and correct operational
procedures.
Below is a summary of the risks that remain in the equipment in the following stages:
• Normal operation
• Adjusting and set up
• Maintenance
• Cleaning
6.5 RISKS OF CONTACT WITH LIVE PARTS
Risk of breaking or damaging the electrical components of the appliance, with a possible reduction in
safety levels, following a short circuit.
Before connecting the electricity supply, make sure there is no ongoing maintenance work.
Attention
Before making the connection, check that the d.c. current in the installation point does not exceed
that indicated on the protections switches present in the electric control board. If this is not the case,
the user must envision the relevant limiting devices.
It is strictly forbidden to conduct any electrical modification, in order to prevent additional unforeseen
hazards and risks.

18
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
6.6 FIRE
Danger
In the event of a fire, immediately disconnect the master switch from the main power supply line.
6.7 EXPLOSIVE ATMOSPHERE
The equipment must not be located in an area classified as an explosion risk according to 1999/92/EC
such as:
Zone 0
An area in which there is a permanent, long-lasting or frequently explosive atmosphere made up of a
mixture of air and flammable substances in the form of gases, fumes or steam.
Zone 1
An area in which the formation of an explosive atmosphere, made up of a mixture of air and flammable
substances in the form of gases, fumes or steam is occasionally probable during normal activities.
Zone 20
An area in which there is a permanent, long-lasting or frequently explosive atmosphere in the form of
clouds of combustible dust in the air.
Zone 21
An area in which the formation of an explosive atmosphere in the form of clouds of combustible dust is
occasionally probable during normal activities.
6.8 SLIPPING
Any leaks in the areas surrounding the appliance may cause personnel to slip.
Check that there are no leaks and keep these areas clean at all times.
6.9 TRIPPING
Generally untidy deposits of material may constitute a tripping hazard and a total or partial obstruction
of emergency exit routes.
Ensure that operating and transit areas and emergency exit routes are free from obstacles in
compliance with current legislation.
6.10 CIRCUIT FAULTS
Owing to potential faults, safety circuits may become less effective, which results in lower safety levels.
You should check the operational condition of the appliance devices regularly.
6.11 WARNING SIGNS (IF ANY)
The appliance is fitted with warning danger, warning and obligation signs defined in agreement with the
Standard relative to the graphical signs to be used on plants.
The signs are located in clearly visible positions.
Attention
The warning plates present on the appliance must not be removed.
The user is responsible for replacing warning signs that, owing to wear, become unreadable.
6.12 FALLING OBJECTS
Positioning of the cabinet display parts (i.e. counters, rods and hooks), as also product arrangement
inside the cabinet can be the source of potential hazards if not properly performed.
Follow the positioning instructions described in this Manual before you place products inside the
cabinet, check that the counters are properly fastened, as also the hooks, etc. Do not exceed the
maximum load limit. Do not tilt the shelves. Do not place any goods and in general, do not load the
tank sliding element closing devices with any load, while open or closed.
Do not place any goods and in general, do not load the tank sliding element closing devices
with any load, while open or closed.

EN
USE AND MAINTENANCE MANUAL 428000729137
19
ZERO TOUCH
6.13 COOLING
During different operations to perform on the counter, such as cleaning or loading goods, it is necessary to handle
products and/or counter parts at a low temperature with the risk of “cold injury” for the operators and/or accidental
slipping hazard.
Follow the safety regulations in the place where the cabinet is installed; more specifically, be sure to always use the
right PPE (especially gloves).
6.14 FOODSTUFFS SAFETY (PACKAGED PRODUCTS)
The refrigerator cabinet described herein is meant to be used to display packaged products. As such, it is not
designed for direct contact between the foodstuffs and display surfaces. If the foodstuffs do accidentally make
contact with the surfaces and for a rather long time, the product may be contaminated. Follow the guidelines on how
to use the cabinet. If a product package breaks, remove it from the cabinet and clean, if necessary.

20
EN
428000729137 USE AND MAINTENANCE MANUAL
ZERO TOUCH
7. DISPOSAL OF WASTE MATERIAL
During normal operation, the appliance does not generate any environmental contamination. At the
end of its life cycle, or if it is necessary to proceed to permanent decommissioning, we recommend
following the procedures below:
DISPOSAL (USER)
The symbol, applied to either the product or its packaging, indicates that the product should not
be considered as normal domestic waste, but should be taken to a waste collection point for the
recycling of electrical and electronic appliances. The correct disposal of this product helps to prevent
potential negative consequences that might derive from inadequate product disposal. For detailed
information about recycling this product, contact your council, your local waste collection service or
the store where you purchased the product.
PROCEDURE FOR DISPOSAL and RECYCLING AT THE END OF APPLIANCE
LIFE SPAN (AUTHORISED BODIES)
• Switch off the equipment and unplug the power supply cable.
• Remove the lamps (if installed). These should be disposed of separately.
• Remove the power units and the electronic cards. These should be disposed of separately.
• Remove all the independent parts (grids, casings, profiles, etc.) and group them according to
shared features in order to access the heat exchangers, pipes, cables, etc. and be careful not to
damage the cooling circuit.
• Remove all mobile parts (doors, sliding doors, glass parts, etc.) and group the various materials
according to their features.
• Check the type of refrigerant on the plate positioned inside the counter; extract the refrigerant and
dispose of it through authorised services.
• Disconnect the evaporator, the condenser, the compressor, the pipes and fans. These are made of
copper, aluminium, steel and plastic and should therefore disposed of separately.
• On removal of all guards and the various components from the frame, separate the different types
of material making up the appliance (plastic, sheet steel, polyurethane, copper, etc) and collect
them separately.
All recyclable materials and waste should be processed and recycled by professionals, in compliance
with the laws in the country in question.
The company responsible for recycling the materials should be registered and certified as a waste
disposal service in accordance with the country in question.
Attention
Illegal disposal of the product by the owner will result in administrative sanctions as required by cur-
rent laws.
Disposal of the product should comply with current laws on the disposal of coolant liquids
and mineral oils.
Important
If the crossed wheelie bin sign is not present on the appliance, it means that the disposal of the
product is not the manufacturer's responsibility. In this case, the Regulations regarding the disposal
of waste in force are valid.
Additional information
Further information on the disposal of liquid coolant, oils and other substances is available on the
safety data sheet corresponding to the substance itself.
In order to dispose of foamed assemblies, remember that the polyurethane foams used are CFC, HFC
and HCFC free.
