Isotech ITL-M-17701 Operating instructions

Page 1 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
LOW TEMPERATURE
FURNACE MODEL
ITL-M-17701
User Maintenance Manual/Handbook
Isothermal Technology Limited, Pine Grove, Southport, PR9 9AG, England
Tel: [phone] Fax: [phone] Internet: www.isotech.co.uk E-mail: [email protected]
The company is always willing to give technical advice and assistance where appropriate. Equally, because of the programme of
continual development and improvement we reserve the right to amend or alter characteristics and design without prior notice. This
publication is for information only.

Page 2 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
GUARANTEE
ⓒIsothermal Technology Limited
This instrument has been manufactured to exacting standards and is guaranteed for twelve months against
electrical break-down or mechanical failure caused through defective material or workmanship, provided
the failure is not the result of misuse.
In the event of failure covered by this guarantee, the instrument must be returned, carriage paid, to the
supplier for examination and will be replaced or repaired at our option.
FRAGILE CERAMIC AND/OR GLASS PARTS ARE NOT COVERED BY THIS GUARANTEE.
INTERFERENCE WITH OR FAILURE TO PROPERLY MAINTAIN THIS INSTRUMENT MAY INVALIDATE
THIS GUARANTEE
Recommendation: the life of your ISOTECH Instrument will be prolonged if regular maintenance and
cleaning to remove general dust and debris is carried out.
The company is always willing to give technical advice and assistance where appropriate. Equally,
because of the programme of continual development and improvement we reserve the right to amend or
alter characteristics and design without prior notice. This publication is for information only.
Isothermal Technology Limited
Pine Grove, Southport, PR9 9AG, England
Telephone: [phone]/544611 Fax: [phone]
Email: [e-mail] / Website: www.isotech.co.uk

Page 3 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
CONTENTS
EMC INFORMATION......................................................................................................................................................4
HEALTH AND SAFETY INSTRUCTIONS ......................................................................................................................5
UNPACKING...................................................................................................................................................................6
SECTIONAL VIEW OF TRANSPORT CLAMP...............................................................................................................6
INSTALLATION OF THE THERMOMETER SUPPORT (REMOVED FOR TRANSIT)..............................................7
SAFETY ..........................................................................................................................................................................8
CAUTIONARY NOTE..................................................................................................................................................8
ELECTRICAL INSTALLATION....................................................................................................................................8
THIS EQUIPMENT MUST BE EARTHED...................................................................................................................8
THE LOW-TEMPERATURE FURNACE.........................................................................................................................9
INTRODUCTION.............................................................................................................................................................9
NEW FEATURES........................................................................................................................................................9
GENERAL LAYOUT......................................................................................................................................................10
QUICK START..............................................................................................................................................................12
USING THE OVERTEMPERATURE CONTROLLER ..................................................................................................13
How to log in as the SUPERVISOR:......................................................................................................................15
How to log in as the Engineer:...............................................................................................................................15
USING THE CONTROLLER .....................................................................................................................................16
The Isotech splash screen and controls: ...............................................................................................................16
Changing the Set Point..........................................................................................................................................17
To change the Setpoint of the equipment:.............................................................................................................17
How to globally change from °C to °F or Kelvin:....................................................................................................17
Process to apply a User linearization to the furnace .............................................................................................17
Enabling the AUTOTUNE feature:.........................................................................................................................19
How to change the Date and Time or the Language of the equipment:................................................................19
To change the DATE and TIME or LANGUAGE: ..................................................................................................19
The NETWORK INTERFACE:...............................................................................................................................20
To access the NETWORK INTERFACE:...............................................................................................................20
DATA LOGGING:...................................................................................................................................................20
FTP SERVER ARCHIVING: ..................................................................................................................................21
PROGRAMMER FUNCTION:................................................................................................................................21
To create, install and run a PROGRAM via the controller interface please follow the instructions below: ...........22
PROGRAM DETAILS: ...........................................................................................................................................22
How to create a simple PROGRAM using the controller interface:.......................................................................23
To enable/RUN this PROGRAM:...........................................................................................................................24
To edit an existing PROGRAM:.............................................................................................................................24
Using the HOLDBACK feature:..............................................................................................................................25
To enable this feature: ...........................................................................................................................................25
FIGURE 14: SEALED METAL FREEZING POINT CELL .........................................................................................26
FIGURE 15: SEALED METAL FREEZING-POINT CELL BODY DIMENSIONS......................................................27
FIGURE 16: SINGLE-ZONE/LOW TEMPERATURE/VERTICAL TUBE FURNACE................................................28
REALISING THE FOLLOWING FIXED POINTS: INDIUM, LEAD, ZINC .....................................................................29
FREEZING THE TIN CELL...........................................................................................................................................30
A useful hint ...........................................................................................................................................................30
FIGURE 17: TYPICAL MELT/FREEZE SEQUENCE................................................................................................31
CELL HANDLING..........................................................................................................................................................32
CELL KIT...................................................................................................................................................................32
FIGURE 18: LOW TEMPERATURE FURNACE CELL ASSEMBLY............................................................................34
THERMOMETRIC FIXED POINTS: A TUTORIAL .......................................................................................................35
DEFINING FIXED POINTS AND RELATED DATA......................................................................................................37
GENERAL NOTE ON ISOTECH METAL FREEZE POINT CELLS..............................................................................38
PRECAUTIONS TO PREVENT DEVITRIFICATION OF QUARTZ ENVELOPES.......................................................39
METAL CLAD CELLS................................................................................................................................................39
GENERAL COMMENT .................................................................................................................................................40
ADDITIONAL SERVICES AND INFORMATION ..........................................................................................................41
ISOTECH I-CAL EASY .................................................................................................................................................42
PROGRAM EDITOR .................................................................................................................................................42
REVIEW.....................................................................................................................................................................43

Page 4 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
EMC INFORMATION
This product meets the requirements of the European Directive on Electromagnetic Compatibility (EMC)
89/336/EEC as amended by EC Directive 92/31/EEC and the European Low Voltage Directive 73/25/EEC,
amended by 93/68/EEC. To ensure emission compliance please ensure that any serial communications
connecting leads are fully screened.
The product meets the susceptibility requirements of EN 50082-1, criterion B.
Symbol Identification
Publication
Description
ISO3864
Caution (refer to manual)
IEC 417
Caution, Hot Surface
ELECTRICAL SAFETY
This equipment must be correctly earthed.
This equipment is a Class 1 Appliance. A protective earth is used to ensure the conductive parts cannot
become live in the event of a failure of the insulation.
The protective conductor of the flexible mains cable which is coloured green/yellow MUST be connected to
a suitable earth.
The Blue conductor should be connected to Neutral and the Brown conductor to Live (Line).
Warning: Internal mains voltage hazard. Do not remove the panels.
There are no user serviceable parts inside. Contact your nearest Isotech agent for repair.
Voltage transients on the supply must not exceed 2.5kV.
Conductive pollution, e.g. Carbon dust, must be excluded from the apparatus. EN61010 pollution degree 2.

Page 5 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
HEALTH AND SAFETY INSTRUCTIONS
1. Read all of this entire manual before use.
2. Wear appropriate protective clothing.
3. Operators of this equipment should be adequately trained in the handling of hot and cold items and
liquids.
4. Do not use the apparatus for jobs other than those for which it was designed, i.e. the calibration of
thermometers.
5. Do not handle the apparatus when it is hot (or cold), unless wearing the appropriate protective
clothing and having the necessary training.
6. Do not drill, modify or otherwise change the shape of the apparatus.
7. Do not dismantle the apparatus.
8. Do not use the apparatus outside its recommended temperature range.
9. If cased, do not return the apparatus to its carrying case until the unit has cooled.
10. There are no user serviceable parts inside. Contact your nearest Isotech agent for repair.
11. Ensure materials, especially flammable materials are kept away from hot parts of the apparatus, to
prevent fire risk.
12. Ensure adequate ventilation when using oils at high temperatures.

Page 6 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
UNPACKING
SECTIONAL VIEW OF TRANSPORT CLAMP
A NUT
B CHANNEL
C TUBE
D STUD
E WASHERS
F RUBBER EXPANDING BLOCK
G NUTS
EVERY EFFORT HAS BEEN MADE TO PACKAGE THIS UNIT FOR TRANSPORT AND TO ENSURE ITS
GOOD CONDITION ON ARRIVAL AT ITS DESTINATION.
BEFORE COMMISSIONING IT IS NECESSARY TO REMOVE THE FURNACE CORE TRANSIT CLAMP.
TO AVOID DAMAGE PLEASE FOLLOW INSTRUCTIONS:
1. Slacken the central nut using the required tube spanner; the insertion of a screwdriver through the
tube spanner will prevent the central stud turning.
2. Remove the 3 screws securing the transit clamp to the top of the unit. Slacken each screw equally
by degrees and then completely remove the screws.
3. Gently lift the transit clamp vertically; a central tube which has secured the furnace core will then
slide out. The 3 screws should then be replaced in the top of the unit
4. Normal commissioning procedure may now be followed.
5. Keep the transit clamp and use it if the furnace is ever transported.

Page 7 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
INSTALLATION OF THE THERMOMETER SUPPORT (REMOVED FOR
TRANSIT)
This furnace is supplied with the thermometer support for the safe storage of up to four thermometers, but
removed for transit purposes. Please see the below image for a guide to the installation of the support to
the furnace.
1. Thermometer support
2. Screw locations
Please screw the thermometer support to the furnace in the way shown above using the screws supplied.
Tighten sufficiently.
Please take care when inserting or removing thermometers from the pocket below the support.

Page 8 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
SAFETY
CAUTIONARY NOTE
PRODUCTS OF ISOTHERMAL TECHNOLOGY LTD ARE INTENDED FOR TECHNICALLY TRAINED
AND COMPETENT PERSONNEL FAMILIAR WITH GOOD LABORATORY PRACTICE. IT IS EXPECTED
THAT PERSONNEL USING THIS EQUIPMENT WILL BE KNOWLEDGEABLE AND SKILFUL IN THE
MANAGEMENT OF APPARATUS WHICH MAY BE UNDER POWER OR UNDER EXTREMES OF
TEMPERATURE (MOLTEN METALS, CRYOGENIC LIQUIDS, ETC.) AND WILL APPRECIATE THE
HAZARDS WHICH MAY BE ASSOCIATED WITH, AND THE PRECAUTIONS TO BE TAKEN WITH,
SUCH EQUIPMENT.
ELECTRICAL INSTALLATION
THE FURNACES HAVE BEEN DESIGNED FOR CONVENIENT USE AND MAY BE PLUGGED TO A
STANDARD THREE-PIN 13-AMPERE SOCKET. THEY ARE SUPPLIED SUITABLE FOR THE UK MAINS
WHICH HAS LIVE, NEUTRAL AND EARTH LINES.
THIS EQUIPMENT MUST BE EARTHED
THE FURNACE IS SUPPLIED WITH A FUSE CARRIER FITTED WITH A NEUTRAL LINK. THIS IS
CLEARLY LABELLED AND IS FOR USE WITH A MAINS SYSTEM WITH A NEUTRAL LINE, SUCH AS
THE UK SUPPLY. IF THE FURNACE IS TO BE USED ON A SYSTEM WHERE BOTH SUPPLY LINES
ARE LIVE WITH RESPECT TO EARTH THEN THE NEUTRAL FUSE LINK SHOULD BE REPLACED
WITH A FUSE. A SPARE FUSE IS SUPPLIED WITH THE FURNACE.

Page 9 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
THE LOW-TEMPERATURE FURNACE
The low-temperature furnace for realisation of metal freezing points is based on the design of Chattle (p.65,
"Supplementary Information for the International Temperature Scale of 1990," B.I.P.M., 1990). It is
furnished with two independent control systems, one for temperature control using a PRT and the other for
over-temperature protection using a type N Thermocouple.
INTRODUCTION
The Isotech Low Temperature Fixed Point Furnace is designed specifically to realize and maintain the
freeze plateaux of Isotech Indium, Tin and Zinc Fixed Point Cells, for calibration of thermometers on the
International Temperature Scale of 1990.
The Low Temperature Furnace is a single-zone furnace. The recommended procedure for establishing a
freeze plateau requires operator attention until the plateau is realized. Following that, the Model 17701
Furnace will maintain the plateau, essentially automatically, for a period of 10 to 12 hours.
The furnace core, into which the freeze-point cell is inserted, is of Aluminium alloy, which provides a very
low thermal gradient along the core length. The main furnace heater is of the parallel-tube design as used
at NIST. A pre-warming tube is provided.
Two entirely independent over-temperature safety devices are included. A dedicated (on-off) over
temperature control circuit provides active safety. A fusible link in the main power circuit provides passive
safety.
The Low Temperature Furnace is completely self-contained, castor mounted and requires no external
supplies (except power).
NEW FEATURES
The furnace has been upgraded to benefit from the latest technology. Fitted with a crystal clear colour
display the furnace is now fully programmable. Programs can be created for the furnace to switch between
set temperatures, for example to bring the furnace to the melt or freeze temperature at a desired time, or to
lower the furnace temperature after a predetermined time.
The PID control parameters are now dynamically optimised at different temperatures optimizing furnace
stability. An Ethernet interface allows the furnace temperature to be monitored across a network whilst a
USB Interface allows programs to be copied or for the furnace heat up and cool down history to be
exported.

Page 10 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
GENERAL LAYOUT
Figure 1: Front View
1. USB Socket
2. Ethernet socket
3. Main Controller
4. Overtemperature controller
5. Main power switch
Figure 2: Rear View
1. Mains power cable

Page 11 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
Figure 3: Top View
1. Gantry support
2. Pre warming pocket
3. Furnace core

Page 12 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
QUICK START
Locate the furnace in a suitable, level location. Leave a minimum of 150mm of space around and 500mm
above the furnace for air circulation. Ensure there is a suitable power supply nearby.
Assemble the furnace as in figure 18, connect the furnace to the electrical supply and power it up.
The Overtemperature controller will power up and display the current temperature of the furnace.
To power up the furnace you will need to enable the main controller. To do this, press the SCROLL button
on the Overtemperature controller until Hi Alarm is displayed, using the up/down buttons enter a new
temperature for the overtemperature protection.
Initially this can be quite a low value, say 200°C, for test purposes. Now press the SCROLL and PAGE
buttons together, once to enter the new value and a second time to reset the controller. On the second
press the furnace will make a noise as the main control circuit powers up.
The furnace is now active and ready for use. On the main controller, press the SCROLL button to highlight
the Setpoint box. Press again to adjust the value and select a suitable value, a value 20°C below the
overtemperature is suitable, using the up/down buttons. Enter the value by pressing the Scroll button. The
furnace will now rise in temperature to the selected value.
If the furnace has been in transit or not been used for several days then there may be an ingress of
moisture into the insulation and other ceramics, the furnace may need to be “dried out” by running at a low
value such as 100°C for a period of several hours.

Page 13 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
USING THE OVERTEMPERATURE CONTROLLER
Figure 4
The furnace uses an alarm value on the controller to disable the heaters if the furnace goes into the alarm
condition. If the furnace goes into the alarm condition, it will power down the Main controller and circuitry.
Adjusting the Overtemperature value on the controller:
1. Press the Scroll button to display A1 HI
2. Use the up/down buttons to scroll to the desired alarm setting. This would normally be 10-20°C
above the target temperature
3. To enter the value, you will need to press the PAGE and SCROLL buttons simultaneously
4. To re-set the controller from an alarm condition you will need to press the buttons again
simultaneously
5. If the controller is in the alarm condition and the complete furnace is powered down, the controller
will “remember” the condition and will still need to be manually reset when powered up again
The controller installed on this equipment uses an advanced three loop controller with a multi-channel
sensor input.
Other features of the controller are:
•Built in data logging
•Ethernet connection
•USB host for controller updates and data export
•Bright colour display
•Dynamic optimisation of the control PID parameters
•Eight point zone linearization for Main and Annealing furnace
•Built in Programmer, supports 100 programs, each of 25 segments
Before using the controller, please read this manual thoroughly to get the best performance from the
equipment.

Page 14 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
Certain features used in this controller require different levels of access. The Operator access requires no
passcode to use. These functions include:
•Changing the setpoint
•Changing any values using the USER ACCESS PAGE
Other features will require the user to log in as “Supervisor” to carry out these functions. These include:
•Adjusting the PID settings
•Using the Programmer function
•Changing the linearity settings
•Extracting data from the recorder function
Configuration changes to the controller require you log in as “Engineer” to perform these functions. These
include:
•Change language selection
•Change °C to °F or K
•Change equipment clock and time zone

Page 15 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
How to log in as the SUPERVISOR:
Figure 5
1. Press the Page button to display the Home menu
2. Scroll to LOG IN
3. Press the SCROLL button
4. Press up to scroll to SUPERVISOR in dialogue box
5. Press the SCROLL button to prompt for a passcode
6. Select code 15 from the soft keyboard
7. Press PAGE button to prompt to accept the changes
8. Select Yes and enter with SCROLL button to display the SUPERVISOR screen (Figure 5)
9. When logged in as the SUPERVISOR the equipment will control in the normal way
How to log in as the Engineer:
1. Press the Page button to display the Home menu
2. Scroll to LOG IN
3. Press the SCROLL button
4. Press up to scroll to ENGINEER in dialogue box
5. Press the SCROLL button to prompt for a passcode
6. Select code 17 from the soft keyboard
7. Press PAGE button to prompt to accept the changes
8. Select Yes and enter with SCROLL button to display the ENGINEER screen
9. When logged in as the ENGINEER, the equipment will not control the temperature of the heat source

Page 16 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
USING THE CONTROLLER
The Isotech splash screen and controls:
Figure 6: The USER INTERFACE start up screen and controls
1. ISOTECH splash screen
2. PAGE button
3. SCROLL button
4. DOWN button
5. UP button
Figure 7: The HOME page
1. Furnace temperature
2. Furnace setpoint
3. Furnace setpoint box
4. Data record symbol
5. PAGE button
6. SCROLL button
7. Down button
8. Up button

Page 17 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
Figure 8: The USER ACCESS page
1. Proportional band
2. Integral time
3. Derivative time
4. Autotune enable
5. Display units
6. Fixed offset
7. Network IP type
8. Setpoint Ramp Rate °C/min
Changing the Set Point
The main controller will control temperature of the furnace. The setpoint is accessible from the Home page
of the controller. The controller is only active when enabled by the overtemperature controller.
To compensate for any errors in the linearity of the display temperature, the user can adjust the linearity
using the 8 point adjustment curve for each furnace. See section below for details on how to do this.
To change the Setpoint of the equipment:
1. From the ISOTECH homepage, press the SCROLL button once, this will highlight the SETPOINT
ADJUST box.
2. Press the SCROLL button once more and this will allow adjustment of the setpoint via the UP/DOWN
buttons.
3. Scroll to the desired set point as described above.
4. When the temperature is set, press the SCROLL button again to enter and save the setting.
5. The equipment will now raise or lower the furnace temperature as required.
How to globally change from °C to °F or Kelvin:
1. Log in as the Engineer
2. Scroll to INSTRUMENT
3. Scroll to DISPLAY
4. Scroll to UNITS
5. Select by pressing the Scroll button
6. Use up/down to select from °C, °F or Kelvin
7. Press the Page button to exit and save the selection
Process to apply a User linearization to the furnace
From time to time the control sensors inside the furnace will need to be adjusted as the sensor drifts with
time and use at high temperature. The controller has the capability to compensate for these errors using an
eight point correction curve. This will need to be regularly checked for errors and can easily be corrected
within the controller using the following procedure.

Page 18 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
The image below illustrates a simplified graphical view of the process.
Figure 9
Isotech standard offset values are set at the following temperatures:
This is listed as Channel 1 on the controller
1. 156°C
2. 232°C
3. 420°C
4. 500°C
Points 5, 6, 7 and 8 are unused as standard.
Please follow the procedure below to linearise the controller display value:
1. Set the furnace up as it will be used (Figure 18)
2. Place a reference thermometer inside the cell or equalizing block
3. Set the furnace to the lowest useable temperature (recommendation would be to use the temperatures
listed above)
4. Allow the system the thermally stabilise
5. Press the PAGE button to enter the SUPERVISOR menu
6. Scroll to the CHANNELS tab and enter with the SCROLL button
7. Scroll to the ISOTECH tab and enter with the SCROLL button
8. Scroll to CAL STATUS and enter with the SCROLL button
9. Scroll to POINT 1 and enter the value from the reference thermometer
The controller is now ready to accept a value. Ensure the equipment is thermally stable, you will
now need to use the temperature value displayed by the reference thermometer.
10. Record the value on the reference thermometer and scroll to DISPLAY VALUE tab and press enter
11. This will bring up a soft keyboard, use this keyboard to enter the exact temperature displayed by the
calibrated reference standard
12. Press the PAGE button to enter the value, the controller will ask you to confirm the settings. Select
YES and enter the value
13. The controller will now accept the value and move to POINT 2 on the display
14. Exit back to the homepage and check the value on the relevant display window
15. When confirmed, move to the next temperature and repeat the process for point 2 and so on
Important Note: Ensure that Point 1 is always used as the lowest temperature and offsets are entered in
ascending order. If the values are place out of order then the controller will disregard them.

Page 19 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
Enabling the AUTOTUNE feature:
The equipment has the ability to AUTOTUNE the control parameters to hone the temperature stability at a
specific temperature. When enabled it will allow the controller to cycle the temperature and calculate the
best values for this temperature. After two cycles it will install the calculated values and use these for the
control loop.
You are not required to log in to access this feature.
To enable the AUTOTUNE feature:
1. Scroll to the USER ACCESS page
2. Press the Scroll button and then select the AUTOTUNE feature using the down button
3. Press the Scroll button again to highlight the feature
4. Use the up/down button to select ON
5. Press the Scroll button again to enter the value.
6. The controller will now begin the tuning process
During the tuning process, AT can now be seen to the left of the clock on the ISOTECH homepage.
To disable the tuning feature during a tune, repeat the process above and select OFF. This will now
disable the tune and install the previous values.
How to change the Date and Time or the Language of the equipment:
The Date and time of the equipment can be changed to suit local time. This can also incorporate the
daylight-saving time in the time zone of your country or region. The display language of some of the
display screens can also be change to suit the local language.
The options for this are:
•English
•French
•German
•Italian
•Spanish
Note: Only the Supervisor and Engineer menus will read in the alternative language. The Isotech Home
screen will still read in English when this feature is used.
To change the DATE and TIME or LANGUAGE:
•To access these features, you will need to log in as the Engineer.
•When logged in, scroll to the INSTRUMENT tab on the Engineer homepage
•Press the SCROLL button to enter
•Scroll to CLOCK and enter by pressing SCROLL button
•Alternatively scroll to LOCALE and enter by pressing SCROLL button
•Adjust as necessary and exit engineer mode

Page 20 of 43
Low Temp Furnace Model ITL-M-17701 13-07/20
The NETWORK INTERFACE:
Access to the NETWORK interface is available when logged in as the ENGINEER. This will allow
adjustment to various network parameters, should they need to be adjusted.
This menu allows writeable access to:
•IP type (FIXED or DYMAMIC)
•IP address
•Subnet Mask
•Gateway
and Read only access to:
•MAC address
•Client identifier
To access the NETWORK INTERFACE:
1. Log in as the ENGINEER
2. From the ENGINEER page scroll to NETWORK tab and enter with the SCROLL button
3. Scroll to INTERFACE and enter with the scroll button
4. Scroll to and adjust desired parameter using the pop out soft keyboard
DATA LOGGING:
The equipment will always record data for all four channels UNLESS the equipment is in ENGINEERING
mode. This is indicated by the green Rin the bottom left had side of the ISOTECH homepage (Figure 7)
The data can either be extracted via the USB socket on the front panel or to a PC by means of the FTP
protocol (Remote Archiving) using REVIEW software, see page 42 for details.
To back up the data via USB stick on the control panel use the following procedure:
1. Log in as the SUPERVISOR
2. Plug a suitable USB memory stick to the socket on the control panel (Figure 1)
3. Ensure the controller has accepted the memory stick by the icon in the lower left of the ISOTECH
homepage
4. Press the page button to scroll to the SUPERVISOR menu
5. Scroll to DEMAND ARCHIVING
6. Scroll to ARCHIVE TO and enter, select USB from the options and enter
7. Scroll to ARCHIVE and select from:
a) Bring to date
b) All
c) Last month
d) Last week
e) Last day
f) Last hour
g) None
8. When the selection is entered by pressing the SCROLL button, the transfer will begin (this may take
several minutes depending on the selection made)
9. When the transfer is complete, remove the USB stick and exit SUPERVISOR mode
The data will be stored in a folder called HISTORY.
