Congratulations on your purchase of the Itronix Duo-Touch Tablet PC!
Your new Duo-Touch features the most innovative advances in portable
computing technology. It combines state-of-the-art ergonomics, patented
RF technology, and a rugged, durable architecture to provide you with a
Tablet PC that is compact, powerful, and easy to use virtually anywhere.
Designed for a wide range of business productivity applications, the Duo-
Touch is an ideal choice for mobile workers who are on the go throughout
the day. It offers flexibility, durability and dependability along with
ruggedness and portability to make it quick and easy to transport to any
work location, indoors, outdoors, or in your vehicle.
This online document, Duo-Touch Help, contains all the information you
need to set up and use your new Tablet PC. For information on printing,
searching, navigating or using Duo-Touch Help, see How to Use This Help
System. To optimize readability, we recommend you view this document
in landscape orientation. If you have suggestions for how we may improve
this document, please e-mail [e-mail].

Unpacking Your System
After opening the package, carefully inspect the contents. Contact your dealer if any items are missing
or appear damaged. The shipping carton should contain a Duo-Touch Tablet PC with the following
features and parts:
Standard Parts
Duo-Touch Tablet PC
AC Adapter and Power Cord
(1) Digitizer Pen with Tether
(5) Pen replacement tips and (1) removal tool
Cleaning cloth
Duo-Touch Quick Start Guide
Standard Features
8.4”TFT SVGA Active Matrix Color Display
Display with two touch functions, an active digitizer touch panel and a passive touch screen
Seven (7) Hot keys
Internal 56K V.92 Fax/Modem
RF ON/OFF button
Internal Gigabyte Ethernet LAN
Li-Ion Battery
Two (2) USB 2.0 Ports
One Type II PC Card Slot
One Type II CompactFlash Slot
Audio Jacks for external speakers and microphone
Internal Speaker and Microphone
Multi-I/O Expansion Connector
Second Battery Connector (to attach the optional second battery)
Microsoft Windows XP Tablet PC Edition 2005
3-year limited warranty
Optional Features
802.11 b/g WLAN radio
Bluetooth Class II radio
GPS radio
Wireless WAN radios and antennas (CDMA and GPRS )
DDR Memory
Hard Driver Heater

Optional Accessories
The following items are normally optional, but some vendors may include them in the standard
package. Some items may not be available in some countries, or some vendors may choose not to
carry all the items. A complete list of Itronix optional peripherals and accessories is listed on the
Itronix website.
Carry Case
Desk Mount
Second Battery
External USB Floppy Disk Drive
External USB DVD/CD-RW Drive
RJ-11 Cable
Shoulder Strap
Tip and Ring Cable
Vehicle Dock
USB 2.0 Port Replicator
USB to Serial Cable
CAUTION When purchasing any of the accessories listed above, purchase only those accessories
that are approved for use with your computer. The above accessories are proprietary items. Your
system vendor can obtain these approved accessories. If you use items that are not approved for use
with this computer, you may cause your computer to malfunction, or to emit or receive
electromagnetic radiation in excess of local regulations. For non-proprietary accessories such as PC
Cards or printers, ensure that the accessory functions properly in your computer before making the
purchase. Your system vendor may be able to recommend reliable brands and models.
Where to Look For Information
About Your Duo-Touch Tablet PC
This Help System describes the key elements and functions of your computer. Be sure to read it
thoroughly before you begin using your Duo-Touch and refer to it whenever needed. It includes a
table of contents, search function, index and glossary to make finding the information you need quick
and easy. See How to Use this Help System for information about navigating, printing or otherwise
using this document.
Please refer to the Service and Support section if you have questions not answered in this document.
About Windows
For more extensive information and help about Windows, go to the following from the Start Menu:
Help and Support. View extensive Tablet PC Help. From here you can also view several
Tablet PC Tutorials.
Tour Windows XP. View an online orientation of Windows XP.
Get Going with Tablet PC. Learn the basic information about using your Tablet PC.

Precautions
You can use your computer under a wide range of environmental conditions. However, to ensure long
use and continued high performance, consider the following factors when setting up your computer:
Follow all warnings and instructions noted in this documentation, including the notification
section
Follow all warnings and instructions noted in Windows Help and Support, found on the Start
Menu
The first time you use your computer, we recommend that you carefully read the section on
Power Management to familiarize yourself with basic battery information and ensure optimum
performance
WARNING! There is danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instructions
CAUTION Internal components of the Duo-Touch will be damaged if exposed to contaminants.
When dust covers, the PC card door, or the bottom access panel are open on the computer,
shield the unit from all contaminants such as liquids, rain, snow, and dust.
Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do
not use aerosols, solvents, or strong detergents
Slots and openings in the computer case are for ventilation purposes. Do not block or cover these
openings or the system could overheat
There is a label on the bottom of the Duo-Touch containing information on the power
requirements of this system. These requirements must be followed. If you are unsure of your
local power supply, consult your dealer or local power company
Do not step on or place anything on the power cord
If you use the computer with an extension cord, ensure that the total ampere ratings of all the
devices sharing the extension do not exceed the rating of the extension cord or the rating of the
wall outlet
Unless instructed, never push foreign objects into the computer through any of the slots or
openings. Dangerous voltages are present, which could cause electric shock, fire, or damage
sensitive components
For best results, use a power strip with a built-in surge protector. Do not use inferior extension
cords as this may result in damage to your computer
Do not operate the Duo-Touch at temperatures above 140°F (60°C) or below -4°F (-20C)
Do not store the Duo-Touch at temperatures above 167°F (75°C) or below -67°F (-55°C)

The First Time...
Using your computer for the first time involves:
Connecting the AC Adapter
Turning the Duo-Touch ON/OFF
Calibrating the Display
More Basics
The next section, Getting Familiar with Your Computer, contains basic information you need to
efficiently use your Duo-Touch.

Startup Problems
If your computer does not start properly, try these solutions:
Connect the AC adapter to charge the battery if it is not charged.
NOTE The Power Status LED should be solid blue and the Power LED on the AC adapter
should be lit if the AC adapter is connected and functioning properly. Additionally, one of the
power icons should appear in the task tray.
If the AC adapter is connected, make sure the electrical outlet you are using works.
Check to make sure the battery is installed and charging properly.
If the battery does not begin charging, remove the battery, connect the AC adapter, and turn on the
computer by pressing the power button; then reinstall the battery. The Battery Status LED is
orange while the battery is charging.
The Troubleshooting section lists additional solutions you can try.

Tips for New Owner
Read the Troubleshooting section for common questions and answers about the Duo-Touch
Take the Windows tutorials
Select "Get Going with Tablet PC" from the Start Menu.
Take responsibility for backup
Back up files often. Users who need to manage large amounts of data may wish to use backup
devices such as a ZIP drive.
Don't leave passwords anywhere on your notebook or carrying case
Be careful when placing your notebook on an airport security conveyor belt
In most airports, security conveyor belts are safe for computers. If you are not sure, ask the
security staff. You should keep a close eye on your computer.
Tape your business card to the notebook and accessories
In the workplace, notebooks and accessories may often look exactly alike, leading to equipment
mix-ups. Prevent such mix-ups by placing your name on your equipment.
Use a lock
For added security, consider purchasing a Kensington lock to put into the security slot on the
left side of your computer. Use the Kensington lock to secure the computer to a desk or table.
Develop ergonomic work habits
The science of ergonomics studies the relationship between health and a suitable work
environment. For more information on ergonomics, contact your nearest computer bookstore, or
local library. The Internet also has information on this and other related subjects.
NOTE Using a computer for extended periods of time with a poor workstation setup or
incorrect work habits can cause health problems.

Getting Familiar with Your Tablet PC
Getting Familiar with your Tablet
PC
The Itronix Duo-Touch is a rugged, weather-sealed Tablet PC system built
for the demanding environment of the mobile worker. This computer is a
superior work tool for collecting, managing, and communicating
information in the field.
This section describes the external and internal features of your Duo-
Touch Tablet PC. This document uses the landscape view as the default
orientation.

Front View
# Feature Description
1 Microphone Use the sealed, integrated microphone for audio input
2 LED Status Indicators The LEDs light up when a particular function of the computer is active
3 Power Button Press this button to turn the unit on or off or to hibernate
4 Display 8.4" TFT SVGA Outdoor Transmissive Display with Digitizer Control
Panel and Touch Screen
5 Hot Keys Speeds common functions such as changing the display orientation
6 Ambient Light Sensor When enabled, the Ambient Light Sensor adjusts the display backlight in
response to ambient light conditions. It is disabled by default. See Display
and Pen Basics for more information.
7 Speaker Use the integrated speaker for audio output

Right Side View
# Feature Description
1 Fax/modem RJ-11
Jack The fax/modem can transmit data using the 56 Kbps V.90 or V.92 protocol, and send and receive faxes at 14.4 Kbps.
2 2 USB 2.0 ports The Universal Serial Bus (USB ) enables you to attach keyboards, mice,
scanners, printers and other USB devices. USB devices can be chained
together on a single cable.
3 CompactFlash Slot CompactFlash card support.
4 Audio-Out Jack Connect external speakers or a stereo headset to this jack to listen to
multimedia (mono only).
5 Audio-In Jack Connect a microphone to this jack to record audio.

Left Side View
# Feature Description
1 Security Slot Your computer has a Security Slot that can be used with a standard laptop
locking device, such as a Kensington Lock.

Top Edge View
# Feature Description
1 Pen Storage Slot Store the pen / stylus here when not using it.
2 LAN RJ-45 Jack With an Ethernet LAN (Local Area Network) you can make LAN
connections without installing PC Cards. Connection speed is
10/100/1000 Mbps.
3 Type II PC Card Slot The PC Card Slot supports 32 bit Card Bus 2.1 interface as well as Zoom
Video when in landscape orientation. You can use this slot with PC Card
Radios.
4 Pen Tether Slot Thread your pen tether through this slot.

Bottom Edge View
# Feature Description
1 Multi-IO Extension
Slot Use this Multi-IO extension slot with the Desk Mount or the Vehicle Dock.
2 DC-in Jack Power the Tablet PC by connecting the AC adapter or vehicle adapter.

Back View
# Feature Description
1 Pen / Stylus Slot Use the pen provided with your Tablet PC to navigate and input on the
touch panel display. Store it in the slot when not using it.
2 Second Battery
Connector Attach a second, external battery to this connector to extend battery life.
3 Pen Tether Attach a pen tether to the tether slot to keep the pen with the Tablet PC.
4 Thermal Grate Covers the fan. Do not cover this grate while using the Duo-Touch.
5 Master Reset Key Use the stylus tip in this hole to perform a hard reset of your Duo-Touch.
You will then need to press the power button to restart the computer.
CAUTION Any unsaved files or data will be lost during a hard reset.
6 RF ON/OFF Button This button turns off Bluetooth and disables WLAN , WWAN, and GPS
radios.

Buttons and Hot Keys
The Duo-Touch has seven Hot Keys to speed common functions. Additionally, it has a Power Button, an RF On/Off
Button, and a Master Reset Key.
Hover the mouse over each number on the picture to see a description
# Icon Hot Key Description
1
Rotate Key Use this key to switch between portrait and landscape
orientation on the display. It rotates the screen in 90°
increments. You can also program it to execute a specific
function.
NOTES You will need to calibrate the display for each
orientation and choose a primary orientation.
Some applications may not display as well in portrait
orientation. For example, you may need to scroll right to
view all the contents on the page.
2
Security Key Press this key like you would press Ctrl+Alt+Del on a
desktop computer.
3
Escape Key Press this key to go back or escape to the previous context
or window. You can also program it to execute a specific
function.
4
Enter Key Press this key just like you would press Enter on a
desktop computer. For example, implement an action,
navigate deeper or move forward through content.
Duo-Touch™ Help
Pa
g
e 1 of 3Buttons and Hot Ke
y
s
5/5/2005mk:
@
MSITStore:C:\Documents%20and%20Settin
g
s\barvill
j
.ITRXNT1\M
y
%20Documents...

FN + Hot Key Combinations
Programming Hot Keys
5
Line Up Key Press this key to move the cursor up one line. You can
also program it to execute a specific function.
6
Line Down
Key
Press this key to move the cursor down one line. You can
also program it to execute a specific function.
7
Function Key
(Fn)
Press this key in combination with another key to perform
more functions. See the standard key combinations listed
below.
Fn + Hot Key
Combinations
Icons Description
Fn + Line Up
Page up
Fn + Line Down
Page down
Fn + Enter
Speaker volume down
Fn + Escape
Speaker volume up
Fn + Security
Display brightness down
Fn + Rotate
Display brightness up
Line Down + Line Up
Switch display between digitizer and touch screen option
(if equipped) while in Windows
You can program the Escape, Rotate, Line Up and Line Down hot keys to perform specific functions. To program one
of these hot keys, do the following:
1. Select the Buttons / Device / Brightness Properties icon in the taskbar .
2. Then, select the Tablet Button tab. This allows you to associate any of the above listed buttons with any .exe
or .com in the system.
Pa
g
e 2 of 3Buttons and Hot Ke
y
s
5/5/2005mk:
@
MSITStore:C:\Documents%20and%20Settin
g
s\barvill
j
.ITRXNT1\M
y
%20Documents...

Power Button
RF ON/OFF Button
Master Reset Key
The power button is located at the top left corner above the display when the unit is in landscape orientation. Press this
b
utton to turn the unit on or off or hibernate.
This button is located on the back of the Tablet PC. It turns off Bluetooth and disables WLAN , WWAN, and GPS
radios.
NOTE The Bluetooth radio is enabled whenever the unit is turned on, even if the RF ON/OFF button had been used to
turn it off.
The master reset key is located in a recessed hole on the back of the Tablet PC. To perform a hard reset, insert the end
of a paper clip into this hole. You will then need to press the power button to restart the computer.
CAUTION Any unsaved files or data will be lost during a hard reset.
72_0127_001
05 May 2005
© 2005 Itronix Corporation. All rights reserved.
Pa
g
e 3 of 3Buttons and Hot Ke
y
s
5/5/2005mk:
@
MSITStore:C:\Documents%20and%20Settin
g
s\barvill
j
.ITRXNT1\M
y
%20Documents...

LED Status Indicators
The Duo-Touch has four LED status indicators located left of the display when the unit is in landscape orientation. The
LEDs light up when a particular function of the computer is active. LED numbers are from top to bottom when the
Tablet PC is in landscape orientation.
NOTE LEDs can be disabled by using the Setup Utility to activate Stealth Mode.
# Icon LED Light Description
1
Wireless Radio Status LED
Solid Blue Integrated radio(s) are connected
Blinking Blue Integrated radio is active
2
HDD Status LED
Green Accessing the Hard Disk Drive
3
Battery Status LED
Green Fully Charged
Orange Charging
Blinking Red Battery capacity is less than 10%
4
Power Status LED
Solid Blue Unit is turned on
Blinking Blue Suspend to RAM
Duo-Touch™ Help
72_0127_001
05 May 2005
© 2005 Itronix Corporation. All rights reserved.
Pa
g
e 1 of 1LED Status Indicators
5/5/2005mk:
@
MSITStore:C:\Documents%20and%20Settin
g
s\barvill
j
.ITRXNT1\M
y
%20Documents...

Display and Pen Basics
Your Duo-Touch has an 8.4" TFT SVGA outdoor transmissive display with digitizer control panel and
touch screen. It is an active matrix color display with integrated graphics capabilities that provides
excellent readability both indoors and outdoors.
Changing the Display Orientation
You can change between landscape and portrait orientation by pressing the rotate hot key. Each time
you press the key, the screen rotates 90°counter-clockwise. You can also change the orientation via
the input panel by tapping CTRL+ALT and then selecting one of the arrow keys.
NOTE Some applications may not display properly in portrait orientation.
Ambient Light Sensor
Your Tablet PC display has an ambient light-sensor near the display. It automatically dims the display
backlight in low light conditions. When enabled, this feature conserves battery power.
To enable or disable the ambient light sensor, perform the following:
1.Select the Buttons / Device / Brightness Properties icon in the taskbar.
2.Select the Auto adjust LCD brightness tab.
3.From the auto adjust LCD brightness tab you can activate or deactivate the auto brightness adjust.
You can also choose the backlight brightness level for four different categories of ambient light
level: dark, indoor, outside, and blaze.
