iTrybrand Technology VT03C User manual

GPS Portable Tracker
User Guide
(Version V1.1)

At a Glance
1
1.1 Overview
1.2 Accessories
1pc Lanyard
1pc USB cable
1pc User manual
1pc 3M tape
Getting Started
2
2.1 Installing the Micro SIM card
Important: 1 A Micro SIM card is required in order to use cellular services when connecting to GSM networks.
2 Keep the SIM card GPRS availability
3 Note down the SIM card phone numbers which is device contacting numbers.
Open the side plug, install the SIM card in the right direction, turn on the device.
(Note: Device must be powered off before installing SIM card)
2.2 Installing the device
2.2.1 Power on the device.

2.2.2 Install the device in following three suggested place:
Important: 1. Keep away from high power electrical devices, such as reversing radar, anti-theft device or other vehicle
communication equipment which may affect the device signal.
2. Keep the device front face up & No metallic cases above the device which may affect signal as well. Such
as the windshield which is pasted with metal thermal-protective coats or heating coating.
2.3 Setting up and activating the device
To set up and activating the device, you should send SMS to device numbers by mobile phone.
Setting server
SMS: SERVER,2,vt.protrack365.com,8842# （The default setting）
Checking location 3
3.1 Via SMS
URL#
3.2 Via tracking platform
www.protrack365.com
Ask your distributor for log-in account and password.
Basic 4
4.1 LED indication
4.1.1 Red LED
Solid bright
Charging
4.1.2 Green LED
Solid bright
Fully charged
4.1.3 Blue LED
Slow flashing
Searching GSM network
Quick flashing
Connected with server
Solid bright
Connected with server and GPS get located

Voice monitor 5
5.1 To set SOS number
To preset SOS number for voice monitor and receiving different alarm message.
SOS,A,phone number1,phone number2,phone number3#
5.2 To activate voice monitor
Use the preset SOS phone number to call the device’s SIM card number, once it is connected, it will
enter voice monitor status.
Note: The SIM card should be activated with call service.
Alarm management 6
*When any kinds of alarms happened, device will send alarm to SOS numbers.
6.1 SOS alarm
Long press the SOS number for 3 seconds, it will activate the SOS alarm.
6.2 Geo-fence alarm
After setting geo-fence range, if the device comes in & out the range, it will alarm.
6.3 Low-power alarm
When external power is cut, device will keep working with its backup battery and when its battery is too low, it will
alarm.
6.4 Over-speed alarm
When the car is over-speed , it will alarm.
6.5 Remove alarm
If the device is working in Mode 2. The light sensor will be activated. Once it is removed from the
attachment, it will send alarm.
Working Mode 7
7.1 MODE,1,T1,T2,T3,D#
D：1-30 day
GPS data will be only upload at certain time with the setting interval.
Eg. MODE,1,0900,2230,2# means the device will upload data on 9:00 and 22:30 every 2 days.

7.2 MODE,2,N#
N：10-999 second
GPS data will be uploaded on at a setting time interval，once it detects vibration. If the device does not vibrate，it will
enter sleep mode.
Eg. MODE,2,10# means every 10s, the device will upload one GPS data.
7.3 MODE,3,M#
M: 5-1140 minutes
GPS data will be only uploaded on at a setting time interval.
Eg. MODE,3,60M# means every 60m, the device will upload one GPS data.
NOTE：You can press the button to control the GPS in each working mode.
Eg.
Quick press for twice to activate the GPS to send data.
Quick press for three times to disable the GPS to send data.
