J.Burrows MATRIX JBLECTURN User manual

JBLECTURN
JBLECTOA
MATRIX GAS LIFT LECTERN
ASSEMBLY INSTRUCTIONS
1/8
This design and instruction booklet is subject to copyright. 1 Carton
www.officeworks.com.au
For spare parts or hardware call 1300 OFFICE

2/8
Customer Service Contact Details
Spare Parts & Hardware
1300 OFFICE
People Required
General Advice
Officeworks Ltd. | 236-262 East Boundary Road | Bentleigh East VIC 3165 | AUSTRALIA

3/8
Tools Required
CAUTION: Do not use tools other than those required, as this
can damage your new item.
NOTE
•Please check you have all hardware before assembling.
•If you are missing any hardware, please contact the store of purchase.
•Please ensure you have the name of the item, required hardware part and quantity.
•Please retain your receipt as proof of purchase to validate your warranty.
CAUTION
•Do not tighten screws before all screws are in the right place.
•Do not use this product unless all bolts, screws and knobs are firmly secured.
•Check that all bolts, screws and knobs are securely tightened at least every 4 months.
WARNING
•If parts are missing, broken, damaged or worn stop using the product until all repairs
are made using manufacturer authorised parts.
•Failure to follow these warnings could result in serious injury.
DANGER
•CHILDREN MUST BE SUPERVISED.

1234
567
X1 X1 X1
X1 X2 X2
8
X1
A B C D
X4M6X20 X1M10 X1Ø10 Ø10 X1
F G
X1 X1M10 4mm
X1
E
X3M5X16
4/8
Parts List
Included Hardware

5/8
7
6
6
5
2
1
A
E
E
E
7
A
A
A
G
Assembly
Step 1
Step 2
A 4x E 3x

6/8
4
3
Step 3
Step 4
Ensure the joint is
assembled correctly.

7/8
B
C
D
B 1x C x 1 D 1x
8
F
Step 5
Step 6
Ensure the nut is tightened.

8/8
Please unscrew this screw
before using.
Step 7
Troubleshooting
Problem Solution
The desk is very
wrobbly.
Ensure the joint in step 4 is assembled correctly.
Ensure the nut in step 5 is tightened.
CAUTION
The product is intended to hold the maximum weight indicated.
Exceeding the maximum weight will resule in instability and may cause injury.
Thank you for your purchase. Please retain your receipt to validate warranty.
If you would like to know more about our furniture products, please visit www.officeworks.com.au
Gently pull the handle to lift
the desk top.
Gently pull the handle and press
on the centre of the desk top
to push the lectern down.
The handle does not move Check if the screw in step 7 is taken off.
Maximum movement loading capacity: 5kgs
Maximum static loading capacity: 40kgs
