Technical Manual
HTI8 Home Theater Series
JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797
Rev 2 2/06
00526
9
12
11
13
10
L1
0.6mH
L3
0.6mH
C2
20uF
100V
R1
7.5 ohms
5 watts
C1
16uF
100V
INPUTS
+
-
L2
0.5mH
C3
3uF
250V
C4
3uF
250V
R2
1.2 ohms
5 watts
.250 +
.205 -
GREEN
BLACK
BLACK .110
+
YEL .110
-
00525
LOW-
FREQUENCY
TRANSDUCER
330-0137
HIGH-
FREQUENCY
TRANSDUCER
300-0078
GREEN +
BLACK -
BLACK +
YELLOW -
L.F.
H.F.
NETWORK
340-0227
HTi8 SCHEMATIC
340-0227
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance 8 ohms
• Max Amp Power 120 watts*
• Frequency Response 30Hz – 20kHz (–10dB)
• Sensitivity 90dB (2.83V @ 1 meter)
• Crossover Frequency 2.5kHz
SYSTEM COMPONENTS:
• Grille 590-0104
• Low-Frequency Transducer 8" (200mm) polymer-coated
aluminum cone w/rubber
surround
(330-0137)
DC Resistance 5.2 ohms ±10%
• High-Frequency Transducer 1" (25mm) pure-titanium
dome, w/swivel mount
(300-0078)
DC Resistance 6.1 ohms ±10%
• Crossover Network 340-0227
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test 6.0V input 30Hz – 20kHz
• L.F. Aural Sweep Test 5.0V input 30Hz – 3kHz
• H.F. Aural Sweep Test 2.83V input 2kHz – 20kHz
PHYSICAL SPECIFICATIONS:
• Plate Size (W x H) 10-1/8" x 13-1/8" (257mm x 333mm)
• Mounting Cutout
Size (W x H) 8-7/8" x 11-13/16" (225mm x 300mm)
• Mounting Depth 4" (100mm)
• Weight 12 lbs/5.4kg sold in pairs
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
PACKING WIRING DIAGRAM
HTI8 Home Theater Series
LEGEND ON PAGE 2
JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797
Rev 2 2/06
EXPLODED VIEW
1
BAFFLE
7
DOG (4)
3
WOOFER
4
NETWORK
5
TWEETER
6
CLOTH
2
GRILLE
8
LOGO
00527
HTI8 Home Theater Series
1 020-0095 BAFFLE HTI8/SP8
2 590-0104 GRILLE HTI8/SP8
3 330-0137 WOOFER HTI8
4 340-0227 NETWORK HTI8
5 300-0078 TWEETER HTI8
6 GRILLE CLOTH not sold alone – see 590-0104
7 210-0205 DOG, SOUNDPOINT®
8 180-0008 JBL LOGO
9 220-0411 BEAUTY CARTON HTI8
10 220-0438 CARTON TEMPLATE HTI8/SP8
11 170-0033 JBL OWNER’S MANUAL HTI8
12 170-0022 JBL WARRANTY CARD
13 170-0023 JBL CUSTOMER SURVEY CARD
Ref No. Part No. Description
HTI8 ROUGH-IN FRAME part # RIF8
Technical Manual
HTI8 Home Theater Series
