BIO100
Installer manual

UM_3201027_BIO100_EN_Rev00 2/20
Table of contents
1. DESCRIPTION........................................................................................................ 3
2. SPECIFICATIONS ..................................................................................................4
3. MOUNTING.............................................................................................................5
4. WIRING................................................................................................................... 5
5. CONNECTING TO C2P CONTROLLER ................................................................ 6
6. ENROLLMENT ....................................................................................................... 7
7. CONFIGURATING IN CONTROL SOFTWARE .................................................... 8
7.1 ADDING BIOMETRIC READER ..................................................................... 8
7.2 ENROLLING FINGERPRINTS FROM A READER .................................... 10
7.3 ENROLLING FINGERPRINTS FROM DESKTOP READERS ..................... 12
7.4 DELETING FINGERPRINTS ........................................................................ 14
7.5 UPLODING THE FINGERPRINTS TO THE BIOMETRIC READERS .......... 15
7.6 FIRMWARE UPDATE ................................................................................... 16
7.7 SEND CONFIGURATION TO A RECEIVER ................................................ 17
7.8 ADVANCED SETTINGS ............................................................................. 17
8. WIEGAND PROTOCOL DESCRIPTION ............................................................ 18
9. SAFETY INSTRUCTIONS .................................................................................... 19
10. REGULATORY DATA ........................................................................................ 19
11. UE DECLARATION OF CONFORMITY ............................................................. 19

UM_3201027_BIO100_EN_Rev00 3/20
1 Description
BIO100 is a Wiegand biometric reader for access control applications. It offers
storage up to 100 fingerprints and programable Wiegand Output (8 to 128 bits).
Configuration of the readers and fingerprint enrollment is done through CONTROL
PC Software.
Connection between the biometric readers is RS485 and it is used for fingerprint
transfer and configuration.
The tamper switch output can trigger the alarm system, if an attempt is made to open
or remove the unit from the wall.
The sensor incorporates dedicated sensing hardware to facilitate the detection of
“spoofing” attacks based on fake fingers. This data is embedded into the image data
stream, and is processed on the processor. The system is capable of detecting and
defeating well-known fake finger mechanisms, such as molded “gummy” fingers.
The coating on the surface of the TouchChip sensor provides protection from
scratching and abrasion due to normal contact with fingertips and any incidental
contact with fingernails.

UM_3201027_BIO100_EN_Rev00 4/20
2 Specifications
Fingerprint capacity
up to 100 fingerprints
Technology
Biometry (capacitive sliding sensor)
Use
internal
Authentication
Finger
Interface
Wiegand de 8 a 128 bits (26 bits por defecto)
Protocol programming
By CONTROL software
Max. wires length
50m
1:1000 identification time
970 msec, including feature extraction time
Fingerprint enrolment
On the reader or from the USB desktop reader
Panel connection
Wires, 1m
Green and Red LED
Externally Controlled
Orange LED
Idle mode
Buzzer ON/OFF
Yes
Backlight ON/OFF
Yes
Manual control
Yes
Consumption
100mA
IP Rating
IP65
Power supply
9-14VDC
Operating Temperature
-20°C to +50°C
Dimensions (mm)
80 x 80 x 9
Storage/Operating Humidity
5% to 93% RH without condensation

UM_3201027_BIO100_EN_Rev00 5/20
12V DC
9-14V DC
GND
ground
A
RS485 A
B
RS485 B
LR-
Red LED -
LG-
Green LED -
D1
Data 1
D0
Data 0
Tamper
Tamper Switch(NO)
Tamper
Tamper Switch(NO)
3 Mounting
If the biometric reader is installed and used outdoor, the reader MUST be fitted with
the MC-MINI metal cover available in our accessories in order to protect the sensor
from direct rainfall. The operating temperature of the product is between -20ºC - +
50ºC.
If the reader is installed in an environment where the temperature can drop below
-10ºC or/and if the sensor could only be exposed to direct sunlight, it is strongly
recommended to install the reader inside a third party sealed wall mount box (fitted
with additional heater if very low temperature) to keep a constant sensor level
performance.
JCM cannot guarantee the functionality of the product if measures and advice before
are not followed.
It is also strongly recommended to use double technology biometric readers when use
outdoor to offer first higher security but also the possibility to use different readers
depending on users.
4 Wiring
Red
Black
Pink
Purple
Blue
Gray
Green
Orange
Yellow
White

UM_3201027_BIO100_EN_Rev00 6/20
5 Connecting to C2P controller
The Biometric readers can’t work independently. They must be connected to virtually
a C2P controller by the Wiegand inputs (standard 26bit or self-defined).
The lines D0 and D1 are the Wiegand lines and the Wiegand Number is sent
through them.
The RS485 line (A, B) is used for fingerprint transfer and reader settings.
The Biometric readers must be powered from the controller.
If you use different power supply for the biometric reader, connect the GND from
the both devices to ensure correct transfer of the wiegand signal.
When you have connected the reader and powered on, the LED should flash in
orange light + 2 beeps. This lets you know it's on and ready for use.
Fingerprint enrollment is done from the PC Software. Connection between the
Biometric readers and the PC must be established.
If the distance Reader-Controller is high (50meters) and if the communication
with the reader can not be established, then terminate the RS485 network by
closing the jumper in the C2P Controller or as described in chapter 4.
pink
violet
green
orange
black
red
white
yellow

UM_3201027_BIO100_EN_Rev00 7/20
6 Enrollment
Follow the below instructions for correct finger swiping.
Starting from the first finger joint, place the selected finger on the swipe sensor and
move it evenly towards oneself in one steady movement.
Result:
For a valid swipe: Tricolour Status LED turns green + OK Beep(short + long
beep)
For an invalid or misread swipe: Tricolour Status LED turns red + Error Beep
( 3 short beeps)

UM_3201027_BIO100_EN_Rev00 8/20
7 Configurating in Control software
7.1 Adding biometric reader
1. Expand the Door item to view the readers
2. Right click on the reader and select properties
3. In the Basic tab, for “Type” of the Reader select “BIO100”.
4. After selecting the type, a third tab will appear “Biometric”. Go to that tab and put
the serial number of the Biometric Reader.

UM_3201027_BIO100_EN_Rev00 9/20
Important Note: The serial number of the reader can be found on a sticker inside the
reader, on the packaging box and it can be search from the software (right click on the
portal/search devices/readers).
To check if the reader is On Line, right click on the reader and select “Check version”.
In the Event Window a message should appear “Device ON Line, Type: BIO100”

UM_3201027_BIO100_EN_Rev00 10/20
7.2 Enrolling fingerprints from a reader
1. Open the Users Window and create a new user. Click on “New User”, put a
name and ID(card number).
2. Go to the “Biometric” Tab. Select the reader (with left click)
from which the enrollment will be done.
3. Right click on the fingertip and select enroll.
4. In the next 25 seconds, physically swipe the finger on the
selected reader minimum 5 times and the finger tip will
turn red; the fingertip in the screen will become red,
indicating the register percentage, while the reader will
blink in orange.
x5
5. Repeat points 3 & 4 for each finger that should be enrolled.
6. Click on “Save New” and the fingerprint will be sent automatically to all
Biometric Readers where that user has access, i.e. to all the readers according
to the Access Level assign to that user.

UM_3201027_BIO100_EN_Rev00 11/20
Example:
If the user has “Unlimited” Access level then the fingerprints will be sent to all readers,
if the user has Access level only for Reader1 and Reader 3 then the fingerprints will
be sent only to those two readers.
Note: To check if all the fingerprints are sent to the reader, right click on the reader
and select “Memory Status”.
In the event window a line will appear indicating the number of fingerprints stored in
the reader.
Note: If more fingerprints are added for one user, all fingerprints will send the same
Wiegand Code to the controller, the one written in the field User ID(card Number).
BIO100

UM_3201027_BIO100_EN_Rev00 12/20
7.3 Enrolling fingerprints from desktop readers
Plug the Swipe Desktop Reader in the PC. If the device is not installed automatically
use the drivers located on the CD provided with the Biometric reader. It is installed in
the same way as a USB Device. When the desktop reader has been installed it will
automatically appear in the Software.
1. Open the Users Window and create a new user. Click on “New User”, put a
name and ID (card number).
2. Go to the “Biometric” Tab and select the USB Swipe
desktop Reader (with left click).
3. Right click on the fingertip and select Enroll.
4. In the next 25 seconds, physically swipe the finger on the
selected reader minimum 5 times and the finger tip will turn
red; the fingertip in the screen will become red, indicating
the register percentage, while the reader will blink in
orange.
x5
5. Repeat points 3 & 4 for each finger that should be enrolled.
6. Click on “Save New” and the fingerprint will be sent automatically to all
Biometric Readers where that user has access, i.e. to all the readers according
to the Access Level assign to that user.

UM_3201027_BIO100_EN_Rev00 13/20
If the reader is offline, fingers will be sent when the connection between CONTROL
server and the readers is established. No further registration or action is required.
Fingerprints will be sent as soon as the communication is established.
Example:
If the user has “Unlimited” Access level then the fingerprints will be sent to all readers,
if the user has Access level only for Reader1 and Reader 3 then the fingerprints will
be sent only to those two readers.
Note: To check if all the fingerprints are sent to the reader, right click on the reader
and select “Memory Status”.
In the event window a line will appear indicating the number of fingerprints stored in
the reader.
Note: If more fingerprints are added for one user, all fingerprints will send the same
Wiegand Code to the controller, the one written in the field User ID (card Number).
BIO100

UM_3201027_BIO100_EN_Rev00 14/20
7.4 Deleting fingerprints
In general, the fingerprints are stored in the Biometric reader and in the Software.
Deleting can be done only in the readers or from both places.
Deleting one user from the biometric reader
Select the User and click on “Delete User”. The User together with its fingerprints will
be deleted from both the software and the fingerprint readers.
Deleting all users from the biometric reader
Right click on the reader and select “Delete all users from reader”.
Deleting one or more fingerprints
Select the User and open the “Biometric” tab. Go to the fingertip that needs to be
deleted, right click and select ”Delete” for one finger or “Delete All” for all fingers of the
User. Click “Save Changes”.

UM_3201027_BIO100_EN_Rev00 15/20
7.5 Uploading the fingerprints to the biometric readers
Right click on the biometric reader and select “Upload all users to reader”.
While receiving the fingerprints the reader will blink in orange.
Nota: Use this feature when you change or add a reader, if pending tasks are
deleted in the software or if there are doubts that fingerprints in the reader
memory are not synchronized with the software database.
In normal usage, the fingerprints are sent automatically and this feature is not
used.

UM_3201027_BIO100_EN_Rev00 16/20
7.6 Firmware update
Right-click on the reader and select Firmware update menu.
On the Firmware update window, click on the Browse button.
The default location of the firmware files installed with CONTROL is in the folder
"Firmware". Select the firmware file with a "xhc" extension. Click on the Upload button.
Important: Wait for the update end message. Do not turn off the reader, the
software or any communication device in between during the entire process.

UM_3201027_BIO100_EN_Rev00 17/20
7.7 Send configuration to a receiver
Right-click on the reader and select the Send configuration menu.
See the events panel to check the configuration flow.
Note: The biometric reader gets its settings automatically. This function is used if
the reader was off line while making the changes.
7.8 Advanced settings
Send ID for Unknown Finger: sends the desired ID when an unknown finger is
applied.
Backlight: ON or OFF
Buzzer: ON or OFF
Finger Acceptance Flexibility: Accepted tolerance. The recommended value is
“Automatic Secure”.

UM_3201027_BIO100_EN_Rev00 18/20
8 Wiegand protocol description
The data is sent over the lines DATA 0 for the logic “0” and DATA 1 for the logic “1”.
Both lines use inverted logic, meaning that a pulse low on DATA 0 indicates a “0”
and a pulse low on DATA 1 indicates a “1”.When the lines are high, no data is being
sent. Only 1 of the 2 lines ( DATA 0 / DATA 1 ) can pulse at the same time.
Example: data 0010...
Data bit 0 = approximately 100 us (microseconds)
Data bit 1 = approximately 100 us (microseconds)
Time between two data bits: approximately 1 ms (millisecond). Both data lines (D0
and D1) are high.
Description for the 26 bits Wiegand format
Each data block consists of a first parity bit P1, a fixed 8 bits header, 16 bits of user
code and a 2nd parity bit P2. Such a data block is shown bellow:
Note: Parity bits are calculated as follows:
P1 = even parity calculated over the bits 2 to 13
P2 = odd parity calculated over the bits 14 to 25
Ejemplo: 170 31527
PP Site code User code PI
1 1 0 1 0 1 0 1 0 0 1 1 1 1 0 1 1 0 0 1 0 0 1 11 0
Even
Parity
Bit
Odd
Parity
Bit
Site Code
User Code

UM_3201027_BIO100_EN_Rev00 19/20
9 Safety instructions
Do not install the device in a place subject to direct sun light without protective
cover.
Do not install the device and cabling closeto a source of
strongelectro-magnetic fieldslike radio-transmitting antenna. Do
not placethe device near or above heating equipments.
lf cleaning,do not spray or splash water or other cleaning liquids but wipe it out
with smooth cloth or towel.
Do not let children touch the device without supervision.
Note that if the sensor is cleaned by detergent,benzene or thinner,the
surface will be da maged and the fingerprint can't be entered.
10 Regulatory data
Use of the system
This equipment is designed for applications with automated garage door. It is not
guaranteed for the direct activation of devices other than those specified.
The manufacturer reserves the right to change the equipment specifications without
prior notice.
11 UE Declaration of conformity
JCM Technologies S.A., hereby declares that the product BIO100 complies with the
relevant fundamental requirements of the Directives 2014/30/EU on electromagnetic
compatibility and with the 2011/65/EU RoHS Directive, as long as its use is foreseen.
See web page www.jcm-tech.com/es/declaraciones
JCM TECHNOLOGIES, SA
BISBE MORGADES, 46 BAIXOS
08500 VIC (BARCELONA)
ESPAÑA

UM_3201027_BIO100_EN_Rev00 20/20
