Jeep 2018 WRANGLER User manual

2018 JEEP
®WRANGLER QUICK REFERENCE GUIDE
ALL NEW

Vehicle User Guide
Access your Owner’s Information – right
through your Uconnect 4C or 4C NAV touch-
screen radio — If Equipped.
To access the Vehicle User Guide on your
Uconnect Touchscreen: Push the Uconnect
Apps button, then push the Vehicle User Guide
icon on your touchscreen. No Uconnect regis-
tration is required.
NOTE:
Vehicle User Guide features are not available
while the vehicle is moving. If you try to access
while the vehicle is in motion, the system
displays: Feature not available while the vehicle
is in motion.
Pre-Installed Features
• Your User Guide
— Updated in
real-time
• Available when
and where you
need it
• Touchscreen
convenience
• Customizable
interface
• Maintenance
schedules and
information
• Multilingual
• Comprehensive
icon & symbol
glossary
NOTE:
Uconnect screen images are for illustration
purposes only and may not reflect exact soft-
ware for your vehicle.
Introduction To Keyless
Enter-N-Go
The Keyless Enter-N-Go — Passive Entry sys-
tem is an enhancement to the vehicle’s key fob.
This feature allows you to lock and unlock the
vehicle’s door(s) without having to push the key
fob lock or unlock buttons as well as starting
and stopping the vehicle with the push of a
button.
Vehicle User Guide Touchscreen Icon
VEHICLE USER GUIDE — IF
EQUIPPED
KEYLESS ENTER-N-GO —
PASSIVE ENTRY

To Lock The Vehicle’s Doors
With a valid Keyless Enter-N-Go key fob within
5 ft (1.5 m) of the driver or passenger front door
handles, push door handle lock button to lock
all doors.
Do NOT grab the door handle, when pushing
the door handle lock button. This could unlock
the door(s).
NOTE:
• After pushing the door handle lock button,
you must wait two seconds before you can
lock or unlock the doors, using either Passive
Entry door handle. This is done to allow you
to check if the vehicle is locked by pulling
the door handle without the vehicle reacting
and unlocking.
• The Passive Entry system will not operate if
the key fob battery is dead.
The vehicle doors can also be locked by using
the key fob lock button or the lock button
located on the vehicles interior door panel.
Push The Button To Lock
Do NOT Grab The Handle When Locking

To Unlock From The Driver Or
Passenger Side
With a valid Keyless Enter-N-Go key fob located
outside the vehicle and within 5 ft (1.5 m) of
the driver or passenger side door handle, grab
either front door handle to unlock the door
automatically.
For further information, and applicable warn-
ings and cautions, please refer to the Owner’s
Manual at www.mopar.com/en-us/care/
owners-manual.html (U.S. Residents) or
www.owners.mopar.ca (Canadian Residents).
To Unlock/Lock The Swing Gate
To Unlock/Enter The Swing Gate
The Swing Gate passive entry unlock feature is
built into handle of the Swing Gate. With a valid
Passive Entry key fob within 5 ft (1.5 m) of the
Swing Gate, pull the Swing Gate handle to open
with one fluid motion.
Grab The Door Handle To Unlock
Swing Gate Passive Entry Location

To Lock The Swing Gate
With a valid Passive Entry key fob within 5 ft
(1.5 m) of the Swing Gate, push the passive
entry lock button located on the outside Swing
Gate door handle.
NOTE:
The Swing Gate passive entry lock button will
lock all doors and the Swing Gate. The Swing
Gate unlock feature is built into the Swing Gate
handle.
Front Door Removal
NOTE:
•Doors are heavy; use caution when removing
them.
•Hinge pin can break if overtightened during
door reinstall (Max Torque: 7.5 ft· lb / 10 N·m).
1. Roll down the glass window to prevent any
damage.
2. Remove the hinge pin screws from the upper
and lower outside hinges (using a #T50 Torx
head driver).
NOTE:
The hinge pin screws and nuts can be stowed
in the rear cargo tray located under the rear
loadfloor.
Door Removal Warning Label
Hinge Pin Screw
DOORS

3. Remove the plastic wiring access door under
the instrument panel by sliding the plastic
panel along the door frame toward the seats
until the tabs are detached.
NOTE:
Do not pry back to open, as this will break the
plastic cover.
4. Pull up on the red locking tab to unlock the
wiring harness.
5. Push and hold down the black security tab
under the wiring harness, and lift the har-
ness into the open position.
6. With the wiring harness open, pull down-
ward on the wiring connector to unplug.
Store wiring connector in the lower door
basket.
7. Remove the check screw from the center
door check (using a #T40 Torx head driver).
Wiring Access Door
Closed Wiring Harness
1 – Locking Tab
2 – Wiring Harness
Door Check

8. With the door open, lift the door with the
help of another person, to clear the hinge
pins from their hinges and remove the door.
To reinstall the door(s), perform the previous
steps in the opposite order.
NOTE:
The upper hinge has a longer pin, which can be
used to assist in guiding the door into place
when reinstalling.
Rear Door Removal (Four-Door
Models)
NOTE:
•Doors are heavy; use caution when removing
them.
•Hinge pin can break if overtightened during
door reinstall (Max Torque: 7.5 ft· lb / 10 N·m).
1. Roll down the glass window to prevent any
damage.
2. Remove the hinge pin screws from the upper
and lower outside hinges (using a #T50 Torx
head driver).
NOTE:
The hinge pin screws and nuts can be stowed in
the rear cargo tray located under the rear load
floor.
3. Slide the front seat(s) fully forward.
4. Pry open and remove the plastic wiring ac-
cess door from the bottom of the B-pillar.
5. Unplug the wiring connector.
Door Removal Warning Label

NOTE:
Squeeze the tab on the base of the wiring
harness. This will unlock the connector tab,
allowing the wiring connector to be unplugged.
6. Remove the check screw from the center
door check (using a #T40 Torx head driver).
7. With the door open, lift the door with the
help of another person, to clear the hinge
pins from their hinges and remove the door.
To reinstall the door(s), perform the previous
steps in the reverse order.
NOTE:
The upper hinge has a longer pin, which can be
used to assist in guiding the door into place
when reinstalling.
For further information, and applicable warn-
ings and cautions, please refer to the Owner’s
Manual at www.mopar.com/en-us/care/
owners-manual.html (U.S. Residents) or
www.owners.mopar.ca (Canadian Residents).
Easy Entry Seat — Two Door
Models
Pull upward on the easy entry lever located on
the outboard side of the seat back, and slide the
entire seat forward.
To return the seat to a sitting position, fold the
seatback upright until it locks and push the
seat rearward until the track locks.
Wiring Connector
Easy Entry Lever
SEATS

Fold And Tumble Rear Seat —
Two Door Models
Folding The Rear Seat
1. Lift the seatback release lever, located on
the seatback between the head restraints,
and fold the seatback forward.
2. Slowly flip the entire seat forward.
3. Use the two retention straps located on the
back of the rear seat and two corresponding
wire loops located on the back of each
b-pillar, and thread the hook-and-loop fas-
teners on the straps through the loops to
secure the seat in the folded position.
For further information, and applicable warn-
ings and cautions, please refer to the Owner’s
Manual at www.mopar.com/en-us/care/
owners-manual.html (U.S. Residents) or
www.owners.mopar.ca (Canadian Residents).
Folding Rear Seat — Four Door
Models
To fold the seat, lift upward on the seatback
release lever, located on the outboard sides of
the rear seat, and slowly fold down the seat-
back. The head restraint will fold automatically
with the seat when this lever is pulled.
Rear Seat Tumble Position Retention Strap
Seatback Release Lever
1 — Seatback Release Lever
2 — Head Restraint Release Lever

Four–Wheel Drive Operation
Four And Five Position Transfer Case
The transfer case provides the following mode
positions:
2H
Rear Wheel Drive High Range — This range is
for normal street and highway driving on dry,
hard surfaced roads.
4H AUTO — If Equipped
Four-Wheel Drive Auto High Range — This
range sends power to the front wheels. The
four-wheel drive system will be automatically
engaged when the vehicle senses a loss of
traction. Additional traction for varying road
conditions.
4H / 4H PART TIME (P-T)
Four-Wheel Drive High Range — This range
maximizes torque to the front driveshaft, forc-
ing the front and rear wheels to rotate at the
same speed. This range provides additional
traction for loose, slippery road surfaces only.
NEUTRAL (N)
Neutral — This range disengages both the front
and rear driveshafts from the powertrain. To be
used for flat towing behind another vehicle.
Refer to “Recreational Towing” in “Starting
And Operating” in your Owner’s Manual at
www.mopar.com/en-us/care/owners-manual.html
(U.S. Residents) or www.owners.mopar.ca (Ca-
nadian Residents) for further information.
4L
Four-Wheel Drive Low Range — This range
provides low speed four-wheel drive. It maxi-
mizes torque to the front driveshaft, forcing the
front and rear wheels to rotate at the same
Four Position Four-Wheel Drive Gear Selector
Five Position Four-Wheel Drive Gear Selector
STARTING AND OPERATING
