Compass
Jeep is a registered trademark of Chrysler Group LLC.

Ready, willing, and all-weather capable.
2.4L DOHC 16V Dual VVT Engine • Freedom Drive I 4WD System • Uconnect™ Phone
with Voice Command • Hill Start Assist • Flip-Down Liftgate Speakers • Power Heated
Manual-Folding Exterior Mirrors • Fully Independent Touring-Tuned Suspension •
Premium Leather-Trimmed Seats • Fog Lamps Brake Assist • Illuminated Cup Holders
• Tire Pressure Monitoring Display • Antilock Brake System (ABS) • Roof-Rack Side
Rails • Advanced Multistage Driver and Front-Passenger Air Bags(1) • Electronic
Stability Control (ESC)(2) • Power Sunroof • Outside Temperature Gauge • Leather-
Wrapped Steering Wheel with Audio and Speed Controls • Continuously Variable
Automatic Transmission with AutoStick • All-Speed Traction Control • Electronic Roll
Mitigation (ERM) • Side-Curtain Air Bags(1) • Sentry Key® Antitheft Engine Immobilizer •
60/40 Flat-Folding Reclining Rear Seats •
Standard and available equipment shown. A note about this brochure: All disclaimers and disclosures can be found on inside back cover.

MUD HAPPENS. So does snow,
rain, and ice. Compass takes on
all challenges like a true Jeep®
4WD champion, earning capability
kudos for helping you arrive in style
and on time.
On-road style meets proven off-road capability. Compass moves you up and over to authentic Jeep®
brand freedom with Freedom Drive I Off-Road Group. It helps you confidently rule the road, rocks, mud,
and almost every other driving condition in-between. This active full-time 4WD system with LOCK Mode
works to get you through severe conditions like deeper snow and sand.
CVT2. CVT2 with AutoStick
uses a 30 mm high-strength
multilayer steel drive belt and two
active V-pulleys to vary vehicle
speed. The result: a smooth, quiet
ride that’s very economical too.
SOLID CONTACT. Four-wheel inde-
pendent touring-tuned suspension
helps to improve on-road handling
and cornering and helps to provide
a smooth ride.
MEET THE OPTIMIZER. The available
AutoStick shifter puts optimal vehicle
performance under your control.

AIR OF CONFIDENCE. The standard air bag(1) system includes supplemental side-curtain air
bags (1) for outboard occupants plus advanced multistage driver and front-passenger air bags(1).
Front seat active head restraints(3) move forward and upward in the event of a rear-end collision
to decrease the space between the head restraint and occupant’s head, thereby helping to
reduce the chance of injury.
Compass has your back, your sides, and your front end.
Head out with confidence, knowing a robust set of safety and security systems are in place to give
you peace of mind, on the road and on the trail. You’re protected by a safety cage structure that
contains a front crumple zone, specifically designed to absorb energy during a frontal impact. The
standard Electronic Stability Control (ESC)(2) integrates a four-wheel Antilock Brake System
(ABS), all-speed traction control, and a Brake Assist system that automatically helps provide
braking to appropriate wheels and reduces engine power when the system detects overly sharp
steering and/or impending wheel lift.

TIRE PRESSURE MONITORING SYSTEMS. Embedded sensors continuously
monitor the pressure in the tires and will immediately notify the driver when levels
drop below the minimum acceptable level.
FREEDOM DRIVE I 4WD. Rain and sand dunes are no match for Freedom Drive I
on Compass. It automatically provides optimal traction to all wheels, adjusting
torque on demand while boosting fuel economy.
HILL START ASSIST (HSA). HSA helps stop that annoying roll-back when you
tackle uphill climbs.
SENTRY KEY ®. A unique embedded key code matched only to your vehicle
helps keep your Compass safely where it belongs.
HEATED POWER EXTERIOR MIRRORS. Melt ice off your sideview mirrors as
you warm up your interior. Helps keep your mirrors icicle-free as you drive, as
well.
Safety and Security Features

Stay connected to the people, music, and devices that matter most. Uconnect™ is an
intuitive hub for all your media — mobile phone, radio, navigation system, MP3 player,
and smartphone. The sole purpose of these user-friendly systems is to make your life easier,
wherever you may roam.
PHONE. Talking on thephone
while driving has never been
easier – or more responsible.
Uconnect
™ Phone is the in-vehicle voice-
activated communication system that
allows you to talk on your Bluetooth®-
compatible phone virtually hands-free.
This clever system is also smart enough
to synchronize with your Bluetooth®-
compatible phone’s address book(4) – up
to 1,000 entries – every time you get into
your vehicle.
VOICE COMMAND.
It simplifies driving by
letting you keep your eyes
on the road and your hands on the
wheel. Vocally select radio stations
and record memos. This smart
system technology can also be
trained to better recognize your voice
and can understand commands in
Dutch, English, French, Italian, and
Spanish.
ENTERTAINMENT.
Manage all of your media.
Access your audio
via CDs, DVDs, MP3s, iPod®-
compatible USB port, 30GB
hard drive, Voice Command,
or Bluetooth®-streaming audio.
Rear Seat Video, an authentic
Jeep® accessory from Mopar, can
be accessed three ways: DVDs,
compatible multimedia devices,
and gaming consoles.
NAVIGATION. Provides
turn-by-turn guidance
by voice command
and/or visual display. It can also
locate neazhrby restaurants,
shopping, hospitals, or points of
local interest, and update traffic,
road closure, traffic flow, and
accident information, allowing you
to take the road less traveled.

ALL-WEATHER HERO. The standard rack-and-pinion power steering and independent front and rear suspension
on Compass create a first-class all-weather ride and handling experience. And with a collection of more than 30
standard safety features, the value is clear.
Jeep® Compass Limited. A new profile gives Compass a refreshingly updated look. Its reborn
front and rear fascias with chrome insert project strength. Its bright glint of chrome on the
grille insert and rear bright exhaust tip speaks of Limited’s refinement. An optional power sunroof
opens up your world to the sky above, bringing fresh air and warmth along for the ride.
Opt for Freedom Drive I 4WD, an active full-time system, and you’ll enjoy world-class capability
wherever you may roam.

COMPASS LIMITED. Go forth and conquer with upscale style and all-weather capability. STANDARD:
2.4L (CVT) 16V dual VVT engine, with Hill Start Assist (HSA), fog lamps, heated exterior power mirrors,
heated front bucket seats, leather-wrapped steering wheel with speed and audio controls, power six-way
adjustable driver’s seat, Media Center 235 radio, automatic temperature control, Freedom Drive I, 18-inch
cast aluminum wheels. AVAILABLE: CVT2 transaxle with AutoStick, and nine-speaker Boston Acoustics®
sound system, STD two flip-down liftgate speakers and subwoofer.

COMFORTABLY SOUND ALL AROUND. Compass Limited sends your music in the right direction with
its available premium sound system. It sends out 368 watts of power via nine Boston Acoustics®
speakers, including a subwoofer and two flip-down liftgate speakers.

LEATHER SAYS IT ALL. Limited’s premium interior is comfortably inviting with
standard premium leather-tr imme d heated fro nt seats, and a leather-wrapped
steering wheel with audio and speed controls.
Jeep® Compass Limited. Reach out to Limited’s new soft-to-the-touch interior, softly
padded where you’ll appreciate it most: the center console armrest, upper front console,
and door trim. Chrome accents add a decidedly upscale sparkle to the instrument panel,
center stack, and air vents. Limited’s cabin gives luxury a new name, with standard
features like automatic temperature control, heated front bucket seats, and an optional Media
Center 735N navigation radio.
WIDE OPEN RECEIVER. With the steering wheel
audio controls and available Media Center 431 radio with
30GB hard drive, your hands stay on the wheel while
you browse through the radio’s 6,700-song capacity.
A standard auxiliary input jack keeps you conveniently
connected.

Jeep
® Compass Sport. Outfitted with room to move efficiently in comfort,
capability, and style. Compass Sport stands ready to roam with a standard
170 hp, 2.4L (CVT) 16V dual VVT engine. With standard features like fog
lamps, speed-sensitive power locks, and remote keyless entry, Sport adds value
with its cache of ready-to-go features.
CONFIDENT FREEDOM. Freedom Drive I Off-
Road Group for authentic Jeep® brand capability.
Whether you’re combating inclement weather in the
city or navigating the far reaches of nature’s bounty,
you’ll benefit from an active full-time four-wheel-
drive system with LOCK Mode. It can send equal
and maximum amounts of torque to the rear axle
for improved low-speed traction.

COMPASS SPORT. Where city cruising and country driving meet comfortable capability.
STANDARD: 2.4L (CVT) 16V dual V V T engine with Hill Start Assist (HSA), Antilock Brake System
(ABS), Electronic Stability Control (ESC),
(2) Brake Assist, all-speed traction control, Electronic Roll
Mitigation (ERM), dual front and supplemental side-curtain air bags,
(1) Freedom Drive I, fully
independent touring-tuned suspension, Sentry Key® antitheft engine immobilizer, deluxe
cloth-trimmed seats, Media Center 135 CD/MP3 radio, roof side rails, Electronic Vehicle
Information Center (EVIC) with outside temperature gauge. AVAILABLE: Media Center 235 with
MW/FM/CD/DVD radio and auxiliary input jack.

Jeep
® Compass Sport. Inside the cabin, Sport plays very nice, with an
updated interior that focuses on the details. The new and standard leather-
wrapped steering wheel with audio controls helps drivers keep their eyes
ahead while keeping passengers musically entertained. Vents, knobs, and
fittings have been upgraded and updated. The standard 60/40 split-folding
rear seats can be arranged to carry a configurable cache of people and
cargo.
ILLUMINATING DETAILS. The standard illuminated
cup holders add a unique and functional ambiance to the
interior. These are the details that give Compass a
personality that is sure to impress.
OPEN TO ADJUSTMENTS. A configurable interior
offers roomy seating for up to four passengers.
The front-passenger seat folds flat to act as a
secure landing spot for laptops and small electric
household items.
* And for the comfort of your
backseat passengers, the rear seats have a recline
feature of up to 12 degrees for added relaxation.
*Properly secure all cargo.

Make every journey an adventure. Known around the world for its supreme
durability and capability, Jeep® vehicles are designed to take you up, over, and
through the world’s most severe environments. With style and confidence. With pride
and sophistication. This is where dreams come true, where life becomes more than
a daily commute. Welcome to the Jeep® life.

This brochure is a publication of Chrysler Group LLC. All product illustrations and specifications
are based upon current information at the time of publication approval. Chrysler Group LLC
reserves the right to make changes from time to time, without notice or obligation, in prices,
specifications, colors, materials and to change or discontinue models, which are considered
necessary to the purpose of product improvement or for reasons of design and/or marketing.
Jeep, the Jeep grille, Compass, Sentry Key and Uconnect are registered trademarks of Chrysler
Group LLC. Bluetooth is a registered trademark of Bluetooth SIG. Boston Acoustics is a
registered trademark of Boston Acoustics, Inc.
(1)The advanced front air bags in this vehicle are certified to the new U.S. federal regulations for
advanced air bags. Children 12 years old and younger should always ride buckled up in a rear
seat. Infants in rear-facing child restraints should never ride in the front seat of a vehicle with a
passenger front air bag. All occupants should always wear their lap and shoulder belts properly.
(2)No system, no matter how sophisticated, can repeal the laws of physics or overcome careless
driving actions. Performance is limited by available traction, which snow, ice and other conditions
can affect. When the ESC warning lamp flashes, the driver needs to use less throttle and adapt
speed and driving behavior to prevailing road conditions. Always drive carefully, consistent with
conditions. Always wear your seat belt. (3)Always sit properly with head restraint properly adjusted.
Never place anything in front of the head restraint. (4)Phone must support Bluetooth® Phone Book
Access Profile (PBAP).
