2017 RENEGADE QUICK REFERENCE GUIDE

Electric Park Brake (EPB)
Your vehicle is equipped with a new Electric
Park Brake System (EPB) that offers greater
convenience. The EPB switch is located in the
center console.
To apply the park brake manually, pull up on the
switch momentarily. The BRAKE warning lamp
in the instrument cluster and an indicator on
the switch will illuminate.
To release the park brake manually, the ignition
switch must be in RUN. Then put your foot on
the brake pedal and push the park brake switch
down momentarily. Once the park brake is fully
disengaged, the BRAKE warning lamp and the
switch indicator will extinguish.
The park brake can also be automatically re-
leased. With the engine running and the trans-
mission in gear, release the brake pedal and
depress the throttle pedal. For safety reasons,
your seat belt must also be fastened.
NOTE:
• You may hear a slight whirring sound from
the back of the vehicle while the parking
brake engages or disengages.
• If your foot is on the brake pedal while you
are engaging or disengaging the parking
brake, you may notice a small amount of
brake pedal movement.
• The new Auto Park Brake feature can be
used to apply the park brake automatically
every time you park the vehicle. Auto Park
Brake can be enabled and disabled in the
Settings menu in Uconnect.
• The parking brake can be engaged even
when the ignition is OFF, however, it can only
be disengaged when the ignition is in the
RUN mode.
• Safehold is a new feature that will automati-
cally apply the park brake under certain
conditions. The EPB monitors the status of
the driver’s seat belt, driver’s door and pedal
positions to determine if the driver may have
exited while the vehicle is still capable of
moving and will then automatically apply the
park brake to prevent the vehicle from roll-
ing.
• The EPB fault lamp will illuminate if the
EPB switch is held for longer than 20 sec-
onds in either the released or applied posi-
tion. The light will extinguish upon releasing
the switch.
Park Brake Switch
STARTING AND OPERATING

Auto Park Brake
The EPB can be programmed to be applied
automatically whenever the vehicle speed is
below 1.9 mph (3 km/h) and the automatic
transmission is placed in PARK, or with a
manual transmission, whenever the ignition is
in the OFF mode. Auto Park Brake is enabled
and disabled by customer selection through the
Customer Programmable Features section of
the Uconnect Settings.
Any single Auto Park Brake application can be
bypassed by pushing the EPB switch to the
release position while the transmission is
placed in PARK (automatic transmission) and
the ignition is in the RUN mode. In some cases,
like Automatic or Dual clutch transmission,
when the ignition is in the OFF mode EPB can
automatically apply even if it has been previ-
ously disabled
For further information and applicable warnings
and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals.
Selec-Terrain
Selec-Terrain combines the capabilities of the
vehicle control systems, along with driver input,
to provide the best performance for all terrains.
Mode Selection Guide
Rotate the Selec-Terrain knob to select the
desired mode.
•AUTO: This four-wheel drive operation is a
continuous operation, is fully automatic and
can be used on and off road. This mode
balances traction to ensure maneuverability
and acceleration improvement compared to
a vehicle with two wheel drive. This mode
also reduces fuel consumption, since it al-
lows the disconnect of the drive shaft where
conditions permit.
Selec-Terrain Switch
Selec-Terrain Switch (Trailhawk)

•SNOW: This mode allows you to have greater
stability under conditions of bad weather.
It's used on and off road and on surfaces
with poor traction, such as roads covered
with snow. When in SNOW mode (depending
on certain operating conditions), the trans-
mission will use second gear (rather than
first gear) during launches, to minimize
wheel slippage, except for in 4–Low (Trail-
hawk models only).
•SAND: For off-road driving or use on surfaces
with poor traction, such as sandy bottoms.
The transmission is set to provide maximum
traction. This mode allows more wheel spin
and higher shift points to help motor through
loose areas.
•MUD: For off-road driving or use on surfaces
with poor traction, such as roads covered by
mud or wet grass.
•ROCK (Trailhawk only): This mode is only
available in 4WD LOW range. The device
sets the vehicle to maximize traction and
allow the highest steering capacity for off-
road surfaces. This mode gives you the maxi-
mum performance off-road. Use for low
speed obstacles such as large rocks, deep
ruts, etc.
NOTE:
• Rock mode is only available on the vehicles
equipped with the Trailhawk package.
• Activate the Hill Descent Control or Selec
Speed Control for steep downhill control.
For further information and applicable warnings
and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals.
Keyless Enter-N-Go —
If Equipped
The Passive Entry system is an enhancement to
the vehicle’s Remote Keyless Entry system and
a feature of Keyless Enter-N-Go. This feature
allows you to lock and unlock the vehicle’s
door(s) without having to push the key fob lock
or unlock buttons.
NOTE:
• Passive Entry can be enabled or disabled.
• If wearing gloves on your hands, or if it has
been raining/snowing on the Passive Entry
door handle, the unlock sensitivity can be
affected, resulting in a slower response time.
• If the vehicle is unlocked by the Passive
Entry Door Handle, and no door is opened
within 60 seconds, the vehicle will re-lock
and if equipped, the security alarm will arm.
PASSIVE ENTRY

• The key fob may not be able to be detected
by the vehicle keyless-go system if it is
located next to a mobile phone, laptop or
other electronic device; these devices may
block the key fob’s wireless signal and pre-
vent the keyless-go system from starting the
vehicle.
•
For further information and applicable warn-
ings and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals .
To Unlock From The Driver's Or
Passenger’s Side Doors
With a valid Passive Entry key fob within 5 ft
(1.5 m) of the driver's door handle, grab the
front driver door handle to unlock the driver's
door automatically.
NOTE:
If “Unlock All Doors 1st Press” is programmed,
all doors will unlock when you grab hold of the
front driver’s door handle.”
To Unlock From The Passenger Side
With a valid Passive Entry key fob within 5 ft
(1.5 m) of the passenger door handle, grab the
front passenger door handle to unlock all four
doors and the liftgate automatically.
NOTE:
All doors will unlock when the front passenger
door handle is grabbed regardless of the driver’s
door unlock preference setting (“Unlock Driver
Door 1st Press” or “Unlock All Doors 1st Press”).
To Lock The Vehicle’s Doors And Liftgate
With one of the vehicle’s Passive Entry key fobs
within 5 ft (1.5 m) of the driver or passenger
front door handles, push the door handle lock
button to lock all four doors.
Grab The Door Handle To Unlock

Do NOT grab the door handle when pushing the
door handle lock button. This could unlock the
door(s).
NOTE:
The Passive Entry system will not operate if the
key fob battery is dead.
The vehicle doors can also be locked by using
the lock button located on the vehicle’s interior
door panel.
For further information and applicable warnings
and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals.
Push The Door Handle Button To Lock
DO NOT Grab The Door Handle When Locking

Opening
To unlock the liftgate, use the key fob or acti-
vate the power door lock switches located on
the driver door handle.
To open the liftgate, squeeze the electronic
liftgate release and pull the liftgate open with
one fluid motion.
The Liftgate Passive Entry unlock feature is
built into the Electronic Liftgate release. With a
valid Passive Entry key fob within 5 ft (1.5 m) of
the Liftgate, push the Electronic Liftgate re-
lease to open with one fluid motion.
Closing
Grasp the liftgate closing handle and initiate
lowering the liftgate. Release the handle when
the liftgate takes over the closing effort.
NOTE:
Before closing the liftgate, make sure to be in
possession of the key because the liftgate may
be locked.
To Lock The Liftgate
With a valid Passive Entry key fob within 5 ft
(1.5 m) of the liftgate, pushing the Keyless
Enter-N-Go — Passive Entry lock button lo-
cated to the right of the outside handle release
will lock the vehicle.
NOTE:
The liftgate unlock feature is built into the
electronic liftgate release.
For further information and applicable warnings
and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals.
Passive Entry Liftgate Handle Location
LIFTGATE

My Sky Retractable Roof —
If Equipped
The roof consists of front and rear panels that
can be removed independently. On some ve-
hicles the front panel can be power operated.
To Open/Close The Front Panel
The power My Sky switches are located on the
overhead console. The switches are used to
open and close the front panel.
Venting The Front Panel
To vent the front panel push and release the
vent switch. During the vent operation, any
push on the open/close switch will stop the
closing of the panel.
Removing Panels
• Remove the panels only when the vehicle is
stationary.
• The rear panel can only be removed when the
front panel is completely closed or removed.
NOTE:
Only remove the panels with your My Sky Key,
located inside the panel storage bag in the
cargo area.
My Sky Key Location
MY SKY SUN ROOF

For more information on your My Sky Panel
Removal/Installation, refer to your My Sky Tips
Card located in your vehicle.
For further information and applicable warnings
and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals.
Front Wiper Operation
The windshield wiper/washer controls are lo-
cated on the lever on the right side of the
steering column.
My Sky Latch Assembly
1 — Panel Handle Open Position
2 — Panel Latch
3 — Front Alignment Tab
4 — Keyhole Windshield Wiper Stalk
1 — Rear Wiper Operation
2 — Front Wiper Operation
WINDSHIELD WIPER/WASHER
FEATURES

Front Wiper Operation
The front wipers are operated by rotating a
switch, located on the end of the lever.
Rear Wiper Operation
The rear wiper/washer is operated by rotating a
switch, located at the middle of the lever.
NOTE:
When the front wipers are activated and reverse
gear is engaged, the rear wiper will activate to
clear the rear window.
Rain Sensing Wipers — If Equipped
This feature senses moisture on the windshield
and automatically activates the wipers for the
driver. The feature is especially useful for road
splash or overspray from the windshield wash-
ers of the vehicle ahead. Rotate the end of the
multifunction lever to one of two settings to
activate this feature. Rain Sensing Wipers are
activated through the Uconnect Settings.
For further information and applicable warnings
and cautions, please refer to your Owner’s
Manual at
www.jeep.com/en/owners/manuals
Parkview Rear Back-Up Camera
— If Equipped
You can see an on-screen image of the rear of
your vehicle whenever the transmission is
shifted into REVERSE. The ParkView Rear
Back-Up Camera image will be displayed on the
Uconnect Display, located on the center stack
of the instrument panel.
For further information and applicable warn-
ings and cautions, please refer to your Owner’s
Manual at www.jeep.com/en/owners/manuals.
Front Fog Lights — If Equipped
The front fog light switch is built into the
headlight switch.
To activate the front fog lights, turn on the
parking lights or the low beam headlights and
push the fog light button on the headlight
switch. To turn off the front fog lights, push the
fog light button on the headlight switch a sec-
ond time or turn off the headlight switch.
An indicator light in the instrument cluster
illuminates when the fog lights are turned on.
NOTE:
The fog lights will operate with the low beam
headlights or parking lights on. Selecting the
high beam headlights will turn off the fog
lights.
PARKVIEW LIGHTS
