Jefferson Professional Tools & Equipment JEFTRCH27-GY User manual

USER MANUAL v.1.1
JEFTRCH27-GY, JEFTRCH27-GN, JEFTRCH27-OR
10W COB LED Rechargebale Inspection Lamp
www.jeffersontools.com 1
INTRODUCTION
• High quality 10W (800Lumens) COB LED inspection lamp with 3W LED directional torch
• USB rechargeable li-ion battery
• Strong magnetic plates on the rear of the housing and base allow for exible positioning in your
workspace for easy hands-free operation
• Swivel and tilt functionality allows the lamp to be rotated 360° and lilted through 90° allowing you
adjust the angle of illumination as required
• Heavy-duty, ergonomic housing with IK10 impact rating and IP65 ingress protection
• Powerful, reliable & durable 10W COB LED provides up to 800L luminosity with superior quality,
efciency and light density compared with other standard LED technologies
SPECIFICATIONS
Model Number: JEFTRCH27-GY, JEFTRCH27-GN, JEFTRCH27-OR
Luminosity: 10W COB LED Lamp 3W LED Torch
800 Lumens (High)
400 Lumens (Low)
160 Lumens
Operating Time: 2 Hours (High)
4 Hours (Low)
7 Hours
Charging Time: 4 Hours
Impact Rating: IK10
Ingress Protection: IP65
Battery: Li-ion 18650 3.7V 4000mAh
Weight: 488g
Dimensions: 51 x 49 x 241mm
SAFETY
• Warning: Bright light DO NOT shine directy into the eyes.
• The lamp must only be used on at, stable surfaces which are clean and free from dust, debris or grease.
• This equipment should never be immersed in water or other liquids.
• Do not operate with wet or greasy hands.
• Do not cover the lamp during operation.
• Must never be operated with an open housing, missing or damaged wiring, compartment, or missing or damaged lens.
• Must never be sprayed or cleaned using a steam pressure cleaner since this can damage the insulation and seals.
• Must never be repaired by the user, repairs must only be carried out by the manufacturer or an authorized service representative.
OPERATION
The inspection lamp has four switching settings: Press once on the ON/OFF switch at the rear of the housing to go to the next setting. The following
settings are available: 1. COB Half power (400 Lumens) 2. COB Full power (800 Lumens) 3. 3W Torch ON 4. 3W Torch OFF.
To position the lamp using swivel and tilt:
1. Grip the lamp housing and base simultaneously, then rotate magnetic base through 360°.
2. Grip the lamp housing and base simultaneously, then pull upward to allow pivoting 90° horizontally on the pivoting base.
Charging:
The lamp should be partially charged when rst unpacked. Charge the product fully before operation using the USB charge cable supplied.
Do not use the lamp when charging. Do not use a modied or damaged charger. Do not leave the lamp charging over the charging time.
Cleaning:
Allow the light to cool down sufciently. Clean with a dry or slightly moist, clean, lint-free cloth and a mild detergent if required.
Do not use cleaners that contain abrasives or solvents.

USER MANUAL v.1.1
JEFTRCH27-GY, JEFTRCH27-GN, JEFTRCH27-OR
10W COB LED Rechargebale Inspection Lamp
www.jeffersontools.com
2
ENVIRONMENTAL PROTECTION
Recycle any packaging and unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes
completely unserviceable, reaches the end of its working life and requires disposal, drain off any uids (if applicable) into approved
containers and dispose of the product and the uids according to local regulations.
WEEE Waste Electrical and Electronic Equipment Statement
Information on Disposal for Users of Waste Electrical & Electronic Equipment:
This symbol on the product(s) and / or accompanying documents means that used electrical and electronic products should not be
mixed with general household waste. For proper treatment, recovery and recycling, please take this product(s) to designated collection
points where it will be accepted free of charge.
For private households:
Dispose of this product at the end of its working life and in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). Contact your local solid waste authority for recycling information for this equipment. Disposing of this product correctly will help
save valuable resources and prevent any potential negative effects on human health and the environment, which could otherwise arise from
inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point. Penalties may be applicable for incorrect disposal
of this waste, in accordance with you national legislation.
For business users in the European Union:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union:
This symbol is only valid in the European Union. If you wish to discard this product please contact your local authorities or dealer and ask for the
correct method of disposal.
RoHS (2014/35/EU - Restriction of Hazardous Substances)
Based on randomly-sampled examination of the evaluated product, the results of Lead, Cadmium, Hexavalent chromium,
Polybrominated biphenyls (PBB), Polybrominated diphenyl ethers (PBDE) in tested samples comply with the limits as set by RoHS
Directive 2011/65/EU ANNEX II; recasting 2002/95/EC.
WARRANTY
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will be free of defects in workmanship or
material. Jefferson shall, upon suitable notication, correct any defects, by repair or replacement, of any parts or components of this product that are
determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage, alteration, abnormal operations, improper care, service or repair.
Unless otherwise stated, the guarantee is 12 months from purchase date, proof of which is required for any claim. Full details of how you can register and
activate your warranty as well as instructions on how to make a warranty claim are available on our website: [e-mail].
For any further information relating to Jefferson warranty cover please call [phone] (UK) or [phone] (ROI).
RoHS

USER MANUAL v.1.1
JEFTRCH27-GY, JEFTRCH27-GN, JEFTRCH27-OR
10W COB LED Rechargebale Inspection Lamp
www.jeffersontools.com 3
EU DECLARATION OF CONFORMITY
We, Jefferson Professional Tools & Equipment, as the authorised UK representative of the manufacturer, declare that this equipment conforms
to the requirements of the following:
2014/30/EU - EMC (Electro Magnetic Compatibility) Directive
Standards:
EN IEC 55015:2019+A11:2020
EN 61547:2009
2011/65/EU - RoHS Directive
Notified Testing Body: Bureau Veritas - Consumer Products Services Division (Shanghai)
Equipment Category: Inspection Lamp (LED)
Description: 10W COB LED Rechargebale Inspection Lamp:
JEFTRCH27-GY, JEFTRCH27-GN, JEFTRCH27-OR
Signed By:
Date: 20.01.2022
Name and address of manufacturer or
authorised representative:
Jefferson Professional Tools & Equipment
24 Lisgorgan Lane, Upperlands, BT46 5TE,
Tel: [phone] (UK)
[phone] (ROI)
Email: [email protected]
UKCA DECLARATION OF CONFORMITY
We, Jefferson Professional Tools & Equipment, as the authorised UK representative of the manufacturer, declare that this equipment conforms
to the requirements of the following:
BS EN IEC 55015:2019+A11:2020
Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment (British Standard)
BS EN 61547:2009
Equipment for general lighting purposes. EMC immunity requirements
Notified Testing Body: Laboratoire Central des Industries Electriques (LCIE) Shanghai
Equipment Category: Inspection Lamp (LED)
Description: 10W COB LED Rechargebale Inspection Lamp:
JEFTRCH27-GY, JEFTRCH27-GN, JEFTRCH27-OR
Signed By:
Date:
20.01.2022
Name and address of manufacturer or
authorised representative:
Jefferson Professional Tools & Equipment
24 Lisgorgan Lane, Upperlands, BT46 5TE,
Tel: [phone] (UK)
[phone] (ROI)
Email: [email protected]

Jefferson Professional Tools & Equipment
24 Lisgorgan Lane,
Upperlands,
BT46 5TE
Tel: [phone] (UK) / [phone] (ROI)
Email: [email protected]
